HOUSEHOLD USE ONLY
Read this manual thoroughly before using and save it for future reference
Espresso Coffee Maker
Model: 201
INSTRUCTION MANUAL
Applicable Scenarios: Home, Office, Outdoor, Party, Leisure
support@xixubx.com
CONTENTS
IMPORTANT SAFEGUARDS ................................................ 1-2
SAVE THESE INSTRAUCTION ................................................ 2
SPECIFICATIONS ................................................................. 3
KNOW YOUR COFFEE MAKER .............................................. 4
THE FIRST USE .................................................................... 5
PRE-HEAT THE BREWING SYSTEM ........................................ 6
USER TIPS .......................................................................... 7
MAKING ESPRESSO ......................................................... 8-9
NO WATER COMING OUT ................................................... 10
FROTHING MILK ........................................................... 11-12
PRE-SOAKING FUNCTION ................................................... 13
VISIBLE TEMPERATURE GAUGE ............................................ 14
CLEANING AND MAINTENANCE ........................................... 15
CLEANING THE COFFEE MAKER ..................................................... 15
CLEANING THE FILTER BASKETS AND THE PORTAFILTER .................. 15
CLEANING THE STEAM WAND ...................................................... 16
CLEANING THE GROUP HEAD ........................................................ 17
DESCALING THE APPLIANCE ............................................... 18
TROUBLESHOOTING ..................................................... 19-20
INDICATOR LIGHTS GUIDE ................................................... 21
WARRANTY INFORMATION ................................................ 22
IMPORTANT SAFEGUARDS
Read all instructions and keep them for future reference.
Before using the appliance, check that the voltage of the wall outlet corresponds
to the voltage marked on the rating plate.
To protect against fire, electric shock, and injury, do not immerse the power cord
or plug in water or other liquids.
Remove the plug from the wall outlet before cleaning and when not in use. Allow
the appliance to cool down completely before removing or attaching components,
or before cleaning.
operate any appliance with a damaged power cord or plug, after the
appliance has malfunctioned, or is dropped or damaged in any way. Take the appli-
ance to the nearest authorized service facility for examination, repairs or adjust-
ments, or contact the dealer.
The use of accessory attachments not recommended by the appliance manufactur-
er may result in fire, electric shock and injury.
Place the appliance on a flat surface or table.
hang the power cord over
the edge of the table or counter.
Ensure the power cord does not touch the hot surface of the appliance.
place the coffee maker on a hot surface or next to an open flame.
To disconnect the appliance, turn it off, then remove the plug from the wall outlet.
When removing the plug from the outlet, hold by the plug, never pull on the cord.
use the appliance other than for the intended use.
Always supervise closely when the appliance is used by or near children.
Be careful when using the appliance, as steam may escape and pose a risk of get-
ting scalded.
touch any hot surface of the appliance(including the steam wand and the
filter). Only use the handle or knobs.
operate the coffee maker without water.
5020218
Removing the water tank during the brewing cycle poses a risk of getting scalded.
remove the portafilter when in use or when steam or hot water escape
from the filter holder.
Release pressure through the steam wand before removing the water tank or por-
tafilter.
This appliance is not intended for use by children or any individuals with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given adequate instruction concerning the use of the appli-
ance and/or are under supervision by a responsible adult.
Cleaning and user maintenance shall not be made by children without supervision.
This appliance is intended to be used in household and similar applications such
as: staff kitchen areas in shops, offices and other working environments; farm
houses; bed and breakfast type environments.
place on or near a hot gas or electric burner, or in a heated oven.
place on or near a hot gas or electric burner, or in a heated oven.
SAVE THESE INSTRUCTIONS
Plug Note:
This appliance utilizes a polarized plug (one blade wider than the other). To minimize
the risk of electric shock, the plug is designed to fit into a polarized outlet in one
direction only. If the plug does not fit fully, try reversing it. If it still doesn't fit, con-
tact a qualified electrician. Do not attempt to modify the plug in any way.
Cord Note:
1. A short power supply cord (or detachable cord) is provided to reduce the risk of entang-
lement or tripping over a longer cord.
2. Longer detachable power supply cords or extension cords are available and can be
used with caution.
3. If using a longer detachable cord or extension cord, please note:
a. The cord's electrical rating should be at least as high as the appliance's.
b. Arrange the cord to avoid draping over countertops or tables where children
might pull on it or people could trip over it.
SPECIFICATIONS
Intertek
5012504
-3-
-4-
Rinse and get your coffee maker ready to operate.
1. Remove the silico-
ne plug from
bottom of
water tank.
2. Fill the water tank,
but not above the
max line.
3. Plug in the wall
outlet.
4. Press the “ ”
→ Power and Br-
ew blink (prehe-
ating starts).
5. Blinking stops
→ preheating
done.
6. Place a cup under
the steam wand.
7. Rotate the steam
knob to “ ”
position.
8. Press the “ ”
button.
NOTE: There will be a loud noise and some shakes when the coffee maker runs for
the first time, this is normal. The noise will decrease with further uses.
-5-
9. Wait until water/
steam runs 5 sec.
10. Press “ ”
to stop.
11. Rotate the steam
knob to "OFF".
12. Now you can
brew coffee
normally.
5
Sec
-MAX-
TIP: Repeat the above steps 2-3 times for smoother coffee making.
1. Insert the empty
filter basket into
the portafilter.
2. Keep it level and
insert it from the
" " position.
3. Turn the portafil-
ter to the right.
4. The portafilter sho-
uld be in the ” ”
position.
5. Ensure the steam
knob is set to the
“OFF” position.
6. Press the “ ”
button to start
preheating.
7. Pre-heating compl-
ete. ON and BREW
buttons steady.
8. Tap “ ” for
single shot; hold
3 seconds for
double.
9. Run hot water th-
rough the machine
to preheat it.
10. The machine is
ready to brew
hot coffee.
Cold filter baskets, portafilters and cups can lower the extraction temperature, espe-
cially when the ambient temperature is low. Please preheat the coffee machine before
brewing.
-6-
Or
The flavor of espresso is influenced by the quantity and variety of coffee grounds
utilized.
Various factors contribute to the unique taste of a coffee bean, yet its taste and
aroma are primarily shaped by the roasting procedure. Beans roasted at elevated
temperatures for an extended period exhibit a darker hue and yield richer flavors
compared to lightly roasted ones.
Espresso machines necessitate a finely pulverized coffee grounds. We suggest
opting for a conical burr grinder instead of a blade mill for optimal results.
Choose fresh, high-quality coffee beans to achieve the best flavor extraction.
Store your coffee beans/grounds in an airtight container in a cool, dry place,
away from direct heat sources.
Serve espresso immediately after preparation for optimal taste.
Fine Medium Coarse
French Press
Our Espresso Coffee Machine
Grind
Setting
Best for
-7-
1. Press the “ ”
button to turn on
the machine.
2. Blinking stops
→ ready to
brew.
3. Insert the filter
basket into the
portafilter along
the groove.
5. Fill the filter bask-
et with ground
coffee.
6. Tamp the ground
coffee evenly and
firmly.
8. Do not fill ground
coffee beyond
the MAX line.
4. Turn it left or rig-
ht until it snaps
into place.
9. Keep it level and
insert it from the
" " position.
10. Turn the portafi-
lter to the right.
11. The portafilter
should be in the
” ” position.
12. Ensure the steam
knob is set to the
"OFF" position.
-8-
MAX
7. Wipe filter basket
edges to remove
residue.
Pour Over / Drip
11. Ensure the “ Ste-
am Knob” is set
to the “ ”
position.
-9-
13. Tap once “ ”
for single shot,
hold for 3 seco-
nds to brew
double.
14. The temperature
needle is now
in the “ESPRESSO
RANGE”.
15. The machine star-
ts dispensing
coffee.
16. Wait until all the
coffee has come
out before
removing.
18. Knock out the es-
presso puck.
17. Turn the portafilter to the left to unlock and remove it.
19. Wash all parts
with water. Do
not wash in a
dishwasher.
-10-
If the coffee machine is operating normally but not brewing coffee, it is likely due
to air entering the water pump, causing an airlock (a blockage resulting from
trapped air).
This may occur in the following situations:
1.New machines: During transportation, the water pump may dry out, leading to air
ingress during initial use.
2.After prolonged inactivity: When the machine is unused for an extended period
and then restarted.
3.Water tank depletion: If the water tank is completely emptied and refilled before
reuse.
4.Accidental air intake: If the machine inadvertently draws in air during operation.
Please refer to the “THE FIRST USE” procedure to solve this problem.
-MAX-
21. Purge out any
residual milk.
23. Wipe the “Ste-
am Wand” wit-
h a damp cloth.
Pour Over / Drip
16. Remove the espr-
esso puck from
the “Filter Holder”.
17. Wash all parts
with warm water.
Do not use a dis-
hwasher.
-11-
1. Fill the water tank,
but not above the
MAX line.
4. Press the “ ”
button for preh-
eating.
5. Steam ready when
blinking stops.
6. Fill a pitcher with
cold whole milk
to no more than
half its capacity.
7. Place the end of
the steam wand
just under the
milk's top layer.
2. Ensure the steam
knob is set to
the “OFF”
position.
3. Press the “ ”
button to turn
on the machine.
8. Insert the nozzle
about 0.4 inches
into the milk.
9. Rotate the steam
knob to“ ”
position
slawly.
10. Frother makes a
soft hissing
sound.
11. As milk level rises,
lowver the pitcher
to keep it worki-
ng well.
12. Milk is ready wh-
en the pitcher is
too hot to touch.
140-149°F
-MAX-
Cleaning the “Steam Wand”
13. Rotate the steam
knob to "OFf"
position,
14. Your microfoam
is ready.
15. Rotate the steam
knob to “ ”
position.
16. Purge out any
residual milk.
17. Rotate the steam
knob to “OFF”
position.
-12-
17. Wipe the steam
wand” with a
damp cloth.
WARM TIP:
1.When pressing the steam button for preheating, condensation may occur and
brief dripping from the brew head is normal.
2.When switching to the brew button immediately after using the steam function,
overheating protection will be triggered, and you need to wait for the tempera-
ture to cool down to the “ESPRESSO” temperature zone before brewing. If you
want to cool down quickly, press the brew button directly to release the hot
water without placing the portafilter to the brewing head.
The Pre-Soaking function in a coffee machine is an extraction optimization tech-
nique designed to enhance the flavor and ensure even extraction of coffee. The
main principle is to first use lower water pressure to gently pre-wet the coffee
grounds before applying the full high pressure for extraction. This allows the coffee
puck to expand and absorb water evenly before the main brewing phase begins.
17. Milk is ready wh-
en the Pitcher is
too hot to touch.
18. Rotate the “Stea-
m Knob” clockwi-
se to “ ”
position.
-13-
1. More Even Extraction
Pre-infusion helps the ground coffee fully absorb
water and expand, reducing the risk of “channeling,”
where water flows unevenly through the coffee puck.
2. Enhanced Flavor
It allows for better release of aromatic compounds,
resulting in a richer and more balanced taste.
3. Reduced Bitterness
By preventing high-pressure water from immediately
hitting dry ground coffee, pre-infusion minimizes the
chances of over-extraction, which can lead to
excessive bitterness or astringency.
4. Improved Crema in Espresso
A more even extraction contributes to a finer, more
stable crema, enhancing the smoothness and texture
of the espresso.
Benefits
-14-
Low Temperature
Effects
Under-extraction, Sour Taste, Weak Body.
Warm Tips
• It's the coffee maker preheating zone.
• Not recommended for brewing espresso.
Normal Temperature
Effects
Optimal Extraction, Rich Crema,
Full-bodied Taste.
Ideal Conditions
• Proper grind size.
• Even tamping of ground coffee.
High Temperature
Effects
Over-extraction, Bitter and Harsh Taste,
Inconsistent Extraction.
Warm Tips
• Designed for steam functions.
• Avoid brewing espresso here.
• Brewing in the espresso temperature zone.
Cleaning the coffee maker
Cleaning the filter baskets and the portafilter
1. Turn the steam knob to "OFF" position and allow the coffee maker to cool
down completely before cleaning.
The filter baskets should be kept clean to guarantee perfect results.
1. Remove the filter basket from the portafilter and wash them with warm water.
2. If you notice a malfunction when brewing coffee, immerse the filter basket in
boiling water for 10 minutes and then rinse with running water.
2. Regularly clean the casing of the coffee maker with a damp sponge, to clean
the water tank, drip tray and dry them.
3. Clean all the attachments and dry them thoroughly.
NOTE: Do not clean the drip tray until the coffee machine completes pressure
release and it cools down fully.
To avoid burns, the filter basket must only be removed when the portafil-
ter has cooled down completely.
-16-
Cleaning the steam wand
1. After frothing milk, keep the steam function on
for 2–3 seconds to purge any remaining milk
from the nozzle and prevent clogging. Then
wrap the steam wand with a damp cloth and
wipe off any milk residue to avoid buildup.
2. If the steam wand becomes clogged with milk
residue, wait for it to cool down. Then use the
cleaning needle to unclog it, and run the
“Steam” function to flush it clean.
3. If the steam wand is still blocked, wait for it to cool down completely. Unscrew
the nozzle and place it in a cup of warm water with one espresso machine
cleaning tablet. Soak for a few minutes, then use the cleaning needle again
to unclog it. Finally, run the “Steam” function to flush thoroughly.
NOTE: Do not clean any of the parts in the dishwasher.
Cleaning the group head
Regularly remove any residual coffee grounds from the group head with
a brush, and wash with hot water following the steps below.
1. Do not insert the portafilter.
2. Place an empty cup under the group head.
3.Press either the “ ” button to start brewing.
4.The appliance will stop automatically once the brewing process is finished.
Do not try to disassemble the group head. It will damage the group head
and lead the leakage.
To make sure your coffee maker operates efficiently, to clean the internal pipes,
and to preserve the flavor of your coffee, the coffee machine needs to be des-
caled, cleaned and maintained periodically. It is recommended to clean the ma-
chine every 2-3 months.
1. Fill the water tank with water and a descaling agent (4 parts water to 1 par
descaling agent) to the “Max” level.
Please also refer to the instructions on the descaling agent. Please use a house-
hold descaling agent, or you can use citric acid instead of a commercial descaling
agent(in this case use 100 parts of water to 3 parts of citric acid).
2. Place a cup or other container on the drip tray and start the brewing process,
when the water is ready to drip out of the brewing head, stop the brewing
process and leave the descaling solution in the water tank for 5 minutes.
After that, start the brewing process again and drip a half water into the
cup to clean the brewing pipes. Then, start the steam process and let all the
water come out of the steam wand to clean the steam pipes.
3. Turn on the appliance again and repeat the previous steps 3 more times.
4. Next, repeat the process 2 more times using only DRINKING WATER without
any descaling agent.
TROUBLESHOOTING
Coffee is ground too finely.
Ground coffee is tamped
too strongly.
Tamp ground coffee less
strongly.
Coffee is ground too coarsely.
Too little coffee in the filter
basket.
Ground coffee is not tamped
strong enough.
The temperature is too low
and the machine and coffee
cup are not preheated.
The water tank is empty.
The nozzle is clogged.
Steam function has been used
for more than 2 minutes.
You used room-temperature
skim milk.
Please use refrigerated whole
milk instead.
No steam comes out.
The container is too big, or
the shape is not fit.
Add enough water and unclog
the nozzle.
Use high and narrow pitcher.
Stop using steam function at
least 1 minute.
Remove the sleeve and unclog
the steam nozzle with the
cleaning needle.
Fill the water tank with
drinking water.
There is much water in the
drip tray.
The water tank is not i
nstalled correctly.
Remove the water tank and
correctly install it.
Please clean the drip tray.
In a low room temperature
environment, preheat the
brewing system and
coffee cup with water
in advance.
Tamp ground coffee more
strongly.
The filter is clogged up. Clean the filters hole.
Please use espresso-ground
coffee.
Use the correct amount of
coffee(Single-7g/Double-14g).
Do not use extra-fine
coffee grounds.
TROUBLESHOOTING
'
()
The machine is not turned
on or is unplugged.
The machine voltage is not
compatible.
The thermostat is damaged
or detached.
It is because there's air-block
develops in the water line.
Prolonged contact with coff-
ee residue or coffee liquid.
Use mild or neutral cleaners —
avoid harsh chemicals.
Don't wash it in dishwasher.It may be corroded by the
dishwasher.
No clean correctly after
cleaning mineral deposits.
The ground coffee is stored
in a hot, wet place for a
long time. The ground
coffee turns bad.
Contact our customer support.
Please use fresh ground coffee,
or store unused ground coffee
in a cool, dry place.
Use of corrosive cleaning
agents.
The ground coffee are not
fresh and are lightly roasted.
Too little coffee in the filter
basket.
Coffee is ground too coarsely.
Plug in and turn on the
machine.
Ensure the voltage is 120V,
60Hz (US standard).
Contact our customer service
support.
Refer to the “THE FIRST USE”
procedure to solve this problem.
Clean and dry it immediately
after use.
Use the correct amount of
coffee(Single-7g/Double-14g).
Please use espresso-ground
coffee.
Use fresh medium-dark roast
or dark roast ground coffee.
INDICATOR LIGHTS GUIDE
The power and brew buttons are flashing.
The power and brew buttons are staying on.
The power and steam buttons are flashing.
The power and steam buttons are staying on.
Power button is staying on. Brew button is
breathing.
Power button is staying on. Steam button is
breathing.
Power button is staying on. Brew button is
flashing.
After powering on, the machine preheats
for coffee brewing.
The machine has finished preheating
and is ready to brew coffee.
The steam is preheating.
The steam is ready.
Single shot or double shot brewing in
progress.
Steam is running, but there is not enough
hot water in the boiler, automatic heating
in progress.
Coffee mode, overheating triggers prote-
ction. Wait for cooldown.
NOTE: If your problem is not listed, please contact Customer Support.
WARRANTY INFORMATION
The manufacturer provides warranty in accordance with the legislation of the cus-
tomer’s own country of residence, with a minimum of 12 months, starting from the
date on which the appliance is sold to the end user.
The warranty only covers defects in material or workmanship.
The warranty will not apply in cases of:
- Normal wear and tear.
- Incorrect use, e.g. overloading of the appliance, use of non-approved accessories.
- Use of force, damage caused by external influences.
- Damage caused by non-observance of the user manual, e.g. connection to an
unsuitable mains supply or non-compliance with the installation instructions.
- Partially or completely dismantled appliances.
support@xixubx.com www.xixubx.comwww.xixubx.net
E-mail
Warranty
Website
ACTIVATE WARRANTY
Scan& Save
^ĐĂŶƚŚĞYZĐŽĚĞƌĞŐŝƐƚĞƌLJŽƵƌƉƌŽĚƵĐƚ
ĂŶĚŐĞƚĂϭϮͲŵŽŶƚŚdžƚĞŶĚĞĚtĂƌƌĂŶƚLJ
