TABLE OF CONTENTS
INTRODUCTION AND SAFETY 2
COMMISSIONING 4
OPERATION 6
MAINTENANCE 8
FAULT AND REMEDIAL MEASURES 9
TECHNICAL DATA 11
PARTS LIST 12
Thank you for purchasing this product.
This tool is an electric pump. It is used for pumping water and
other similar water applications.
After opening the package, please ensure that the products are
complete.
If the products are damaged or there is something missing,
please do not use it and bring it back to your dealer.
If you give this tool to another person, please give him this
instruction manual.
1.In order to operate the equipment safely, the users shall care-
fully read and understand the instructions before the first applica-
tion.
2.The users shall obey all safety instructions. Otherwise, you and
others may suffer from injury.
3.You shall preserve all application and safety instructions for the
further reference.
The equipment shall be used when it has normal functions.
4.Please use the equipment according to the safety and techni
cal
requirements as specified in the instructions.
5.The semi-stationary and static form of the equipment is
designed to be transferred to the house and garden: Spray water
and make watering.
6.The equipment shall be used within its performance range.
Please don't use the equipment which has abnormal switch.
7.The equipment is prohibited to be used for providing water or
conveying food.
8.Please don't use the equipment in the room which contains the
inflammable and combustible liquid or gas.
Danger!
Danger type and source:
The personal injury or death is likely to be caused in
case of refusing to obey this danger notice.
2
INTRODUCTION AND SAFETY
9.When the components which fail to be tested and recognized
by manufacturers are improperly used, the equipment is likely to
suffer from the unforeseen damage.
10.Any application which deviates from the intended purpose as
specified in the instructions will be considered as the unautho-
rized application, as a result, the generated problems are inde-
pendent of the manufacturers.
11.Please ensure that the closed equipment will not be started
again by mistake.
12.The equipment shall be connected to the socket which has
correct installation and grounding.
13.The fuse wire shall serve as the current circuit breaker when
the residual current exceeds 30mA.
14.Please ensure that the power supply can satisfy the connec-
tion regulations before the equipment connection.
15.Please don't bend, extrude, pull or drive the power wire to
avoid the related dangers caused
by line breakage.
16.Please check the plug and power cable before application.
When the power cable has been damaged, please disconnect the
plug immediately. Please don't use the equipment which has
damaged power line.
17.When the equipment is idle, please ensure that the plug has
been pulled out. Meanwhile, the equipment has been closed,
then, unplug the power supply.
3
INTRODUCTION AND SAFETY
As for the fixed application, please apply four screws to tighten
the equipment on the foundation support firmly.
When the equipment is used for the pound and swimming pool
in the garden, the equipment shall be subject to the special
setup to avoid the overflow and falling.
The equipment shall be installed in the well-ventilated places to
avoid the weather effect. In case of indoor operation, please
ensure that the floor is equipped with drainage ditch or leak-
age-proof mechanism.
Please check the suction hose and guarantee its airtightness
before startup. When the air foam is absorbed in the hose, the
equipment is likely to be out of order because the leakage
exists possibly.
Danger!
Danger type and source!
In order to avoid any mechanical force or
tension, the suction pipeline shall be installed.
When the transmission pipeline is polluted,
please apply filter to make cleaning and
protection.
Attention:
We advise to install one check value to avoid
the equipment shutdown which is caused by
water loss absence during the pump.
4
COMMISSIONING
All interfaces which are connected to the suction pipeline shall
be sealed by hemp and thick slurry or sealing tape. The leak-
age will reduce the air exhaust.
The interface of metal pipe thread shall be sealed by sealing
tape.
All components of suction pipeline shall be installed by profes-
sionals.
The inner diameter of suction pipe shall be 25mm at least; The
suction pipe shall be kinking resistant and suitable for the
vacuum environment.
Considering that the increasing pipe length will reduce the
transmission capacity, the suction pipeline shall be as short as
possible.
The suction pipeline shall uplift the pump steadily to avoid any
bubble.
Please ensure that the suction pipeline has enough water
supply; The terminal of suction hose shall be submerged in
water all the time.
All components of pressure pipeline shall be compressive.
All components of pressure pipeline shall be
installed by profes-
sionals.
5
COMMISSIONING
Danger!
Danger!
The equipment can be firmly connected to the pipeline system
(such as, internal water supply in families). In such case, the
equipment shall apply the highly flexible hose to connect to the
pipeline system to avoid the vibration.
The equipment shall be operated only in the following conditions:
1.The equipment is only connected to the socket which has
protective contacts, moreover, which shall be installed, grounded
and checked by professional electricians.
2.The power voltage and fuse protection shall satisfy the
technical data.
3.The equipment shall be equipped with the protective device
for less than 30mA residual current when the equipment is oper-
ated in the swimming pool, garden and similar places.
4.In case of outdoor operation, the electrical connection shall
be splash-proof; The equipment shall not be operated in water.
5.The extension wire shall have enough c
onductor cross
section; The cable drum shall be unfolded completely.
Risk for injury!
When the components are unable to withstand
the compression or the installation is incorrect,
the pressure pipeline is likely to burst during the
operation.
Risk for liquid ejection!
Attention:
The equipment is only used for industrial water
supply, such as,toilet and washing machine shall
not be used for the drinking water supply.
Electric shock risk！
Please don't operate the equipment in the humid
environment.
6
OPERATION
Attention！
Filling and suction
1.Unscrew the pump cover.
2.The pump shall be filled with water completely.
3.Install the filter again and screw the pump cover and sealing
elements.
4.When it is necessary to shorten the suction time, please fill in
the suction hose.
5.Open the pressure pipeline (faucet or nozzle) to make the air
escape during the intake process.
6.Switch on the equipment.
7.Switch off the equipment when water is exhausted evenly.
Risk for equipment damage!
The pump shall be filled with water when the new
equipment is connected. It is unnecessary to make
up additional water during the extension operation.
The dry running of equipment is likely to damage
the equipment during the unmanned supervision.
7
OPERATION
1.Please disconnect the power supply before any operation of
maintenance.
2.The equipment will only fulfill the maintenance and trouble
removal tasks as specified in the instructions. Other faults shall
be removed by experts.
3.Please apply the original components. Only these replaceable
components are specifically designed and produced for the
equipment. When other components are replaced, the warranty
will be invalid and you and your environment are likely to be
endangered.
Danger!
Risk for electric shock!
Please disconnect the power supply before any
operation of equipment.
Attention:
Danger type and source!
All gaskets shall be renewed when components
are dismantled.
8
MAINTENANCE
Error shooting Reasons Response measures
In most cases, you will be able to troubleshoot problems easily by
yourself. Before you contact us, please refer to the following table
for technical support. This will help you save a lot of work and
possible expenses.
If you are unable to remove the faults, please contact with the
local suppliers directly. Please remember that the repairing of
laypeople will invalidate your warranty and claims for compensa-
tion and give rise to the extra costs.
The pump
fails to make
operation.
The water
pump fails to
draw water
regardless of
its operation.
1.Whether the power
voltage is absent?
2.The overheating
motor is mainly
caused by: Exces-
sively high liquid
temperature .
3.Whether it is
caused by foreign
body obstruction?
4.Whether the residu-
al current circuit can
start up the breaker?
5.Motor fault?
1.Whether it is
caused by the suction
inlet obstruction?
2.Whether the pump
has inhaled air?
3.Whether the pump
is blocked by foreign
body?
1.Please check the
power cable, plug,sock-
et and fuse.
2.Find out the specific
reasons and solve it.
3.Clean filter.
4.Activation RCCB
,When RCCB is started
again, please contact
with the qualified electri-
cian.
5.Contact with the
service partners.
1.Remove blockage.
2.Check the joint
airtight
ness.
3.Clean filter.
9
FAULT AND REMEDIAL MEASURES
Error shooting Reasons Response measures
Excessively
low hydraulic
head .
The pump
has extremely
loud enough
voice during
operation?
1.Whether the
hydraulic head has
excessively large
height?
2.Whether the pres-
sure pipeline has
excessively small
diameter?
3.Whether the pres-
sure pipeline is
blocked?
4.Whether it is
caused by the suction
inlet obstruction?
5.Whether the pres-
sure pipeline is
kinked?
6.Whether the pres-
sure pipeline is
untight?
Pump inhaled air.
1.Satisfy the maximum
hydraulic head height.
2.Please apply the
pressure pipe which
has large diameter.
3.Remove blockage.
4.Clean up the suction
inlet.
5.Straighten the pres-
sure line.
6.Seal the pressure
pipeline and screw
the threaded connec-
tion.
Please ensure that
there are enough
liquid. Check the joint
airtightness.
10
FAULT AND REMEDIAL MEASURES
Technical data
Model
Nominal voltage
Horsepower
Protection type
Max. Flow Rate
Max. Head
Max. Lift
76091
115 V / 60 Hz
1HP
IPX4
26FT
930GPH
145FT
This Pump Has Been Evaluated for Use With Water
Only
WARNING -“Risk of electric shock - This pump is
supplied with a grounding conductor and grounding
type attachment plug. To reduce the risk of electric
shock, be certain that it is connected only to proper-
ly grounded, grounding-type receptacle”.
CAUTION !
11
TECHNICAL DATA
PARTS LIST
12
PARTS LIST
PARTS LIST
13
PARTS LIST
PARTS#
NO.
ITEM QTY UNIT
P76091-0010 0010 FAN COVER 1 PCS
P76091-0011 0011 SCREW COMPONENT 4 PCS
P76091-0020 0020 SHAFT RETAINING RING 1 PCS
P76091-0030 0030 FAN 1 PCS
P76091-0040 0040 REAR COVER 1 PCS
P76091-0050 0050 CORRUGATED GASKET 1 PCS
P76091-0060 0060 HEX BOLT 4 PCS
P76091-0070 0070 ALUMINUM HOUSING 1 PCS
P76091-0071 0071 SCREW COMPONENT 1 PCS
P76091-0072 0072 EXTERNA
L SE
RRATED LOCK WASHER 1 PCS
P76091-0074 0074 AMPHENOL CONNECTOR 1 PCS
P76091-0075 0075 CONDUCTING WIRE 0.25
METER
P76091-0080 0080 STA
TOR 1 PCS
P76091-0090 0090 BEARING 1 PCS
P76091-0100 0100 ROTOR 1 PC
S
P76091-0110 0110 BEARING 1 PCS
P76091-0120 0120 WIRE BUSHING 1 PCS
P76091-0130 0130 CAPACITOR 1 PC
S
P76091-0140 0140 CUSTOMIZATION TAPPING SCREW 2 PCS
P76091-0150 0150 CABLE BRIQUETTING 1 PCS
P76091-0160 0160 CABLE SHEATH 1 PCS
P76091-0170 0170 POWER CORD 1 PCS
P76091-0180 0180 JUNCTION BOX BODY 1 PCS
P76091-0190 0190 CROSS HEAD TAPPING SCREW 4 PCS
P76091-0191 0191 CUSTOM TAPPING SCREWS 2 PCS
P76091-0192 0192 CABLE
BRIQUETTING 1 PCS
P76091-0193 0193 ROCKER SWITCHES 1 PCS
P76091-020
0 0200 JUNCTION BOX COVER 1 PCS
P76091-0210
0210
CUSTOMIZATION TAPPING SCREW
2 PCS
PARTS#
NO.
ITEM
QTY
UNIT
P76091-0220 0220 HANDLE COMPONENT (0220+0230) 1 PCS
P76091-0230 0230 HANDLE COMPONENT (0220+0230) 1 PCS
P76091-0240 0240 NUT 2 PCS
P76091-0250 0250 CABLE SLEEVE 2 PCS
P76091-0260 0260 NUT 4 PCS
P76091-0270 0270 FRONT COVER 1 PCS
P76091-0280 0280 WATER PROOF RING 1 PCS
P76091-0290 0290 O-RING 1 PCS
P76091-0300 0300 DIFFUSER PLATE 1 PCS
P76091-0310 0310 MECHANICAL SEAL 1 PCS
P76091-0320 0320 IMPELLER 1 PCS
P76091-0330 0330 DIFFUSER PLATE ASSEMBLY 1 PCS
P76091-0340 0340 O-RING 1 PCS
P76091-0350 0350 DIFFUSER PLATE 1 PCS
P76091-0360 0360 O-RING 1 PCS
P76091-0370 037
0 PUMP HEAD 1 PCS
P76091-0380 0380 DRAIN PLUG 1 PCS
P76091-0381 0381 O-RING 1 PCS
P76091-0390 0390 DUST COVER 2 PCS
P76091-0400 0400 HEXAGON SOCKET CAP SCREWS 4 PCS
P76091-0410 0410 VALVE COVER 1 PCS
P76091-0411 0411 O-RING 1 PCS
P76091-0430 0430 NYLON SECURE LINE PRESSING CAP 3 PCS
P76091-0440 0440 NYLON SECURE LINE PRESSING CAP 1 PCS
P76091-0450 0450 TIE 1 PCS
P76091-0460 0460 DOUBLE-SIDED FILM 0.06 METER
P76091-0470 0470 CONNEC
TOR PIN 4 PCS
P76091-0480 0480 CONDUCTING WIRE 0.2 METER
P76091-0490
0490
SHRINKABLE TUBE
0.15
METER
CUSTOMER SERVICE
If you have any questions about ordering our outdoor furnitures and replacement parts or other furniture
products, please feel free to contact us using the following contact information:
Customer Service and Technical Support
Phone: (909) 628-0880
Email: [email protected]
Hours of Operation: Monday – Friday, 9AM – 4PM (CST)
DISCLAIMER
PLEASE READ THE FOLLOWING CAREFULLY
The manufacturer and/or distributor have provided the parts list and assembly diagram in this manual for
reference purposes only. They do not make any representation or warranty to the buyer that they are qualified
to make repairs to the product or replace any parts of the product. In fact, the manufacturer and/or distributor
expressly state that all repairs and parts replacements should be undertaken by certified and licensed
technicians, and not by the buyer.
The buyer assumes all risk and liability arising from their repairs to the original product or replacement parts
or arising from their installation of replacement parts. It is strongly advised that qualified professionals handle
any repairs or replacements to ensure safety and proper functioning of the product. Improper installation and
operation may result in injury, property damage, or voiding of warranty. The manufacturer and/or distributor
shall not be held responsible for any accidents, damages, or malfunctions resulting from the buyer's
installation and operation of the product. It is essential to follow all safety guidelines and recommendations
provided in this manual and to seek professional assistance if unsure about the installation or operation
procedures.
