Sod Cup Installation Guide

This is the main product document for model SODCUPXL. Additionally, the document applies to other Rain Bird models: B11000

The file format is pdf, 1 pages, you can download this manual here .

background
1. REMOVE THE RUBBER COVER
2. REMOVE THE SCREWS
1
2
Rain Bird 11000 Series Rotor - Sod Cup Installation
3. PLACE THE INNER CUP ON THE
NOZZLE HOUSING.
4. REINSTALL THE SCREWS
5. PLACE THE OUTER RING AROUND
THE ROTOR CASE TOP.
55
3
4
Rain Bird 11000 Series Rotor - Sod Cup Installation
Remove the rubber covers.
Remove the screws.
Place the inner cup on the
nozzle housing.
Reinstall the screws.
Place the outer ring around
the rotor case top.
11000 SERIES ROTORS
Sod Cup Installation Guide

Specifications
