PowerPipe
Install Guide
for 650PTM, 800PTM, 1000PT/M,
1200PT-1/M, 1200PT-2/M & 1500PTM
4
Construction
Dry Wall
Vertical Stud
Adaptor
Flang Adaptor
Fexible Tuned Port
Low Frequency Device
Input Terminal
Pedestal
Ground/Floor
1:
2:
3:
4:
5:
6:
7:
8:
9:
Material Specs
Die-Cast or T6 Aluminum
High Impact Polystyrene
Composite Polyurethane/Vinyl
Medium Density Fiber
Dry Wall
ceiling Joists
Trim Ring/Grille
Flang Adaptor
Fexible Tuned Port
Low Frequency Device
Input Ter
minal
Mounting Straps
Mounting Hardware
1:
2:
3:
4:
5:
6:
7:
8:
9:
Material Specs
High Impact Polystyrene
High Impact Polystyrene
Composite Polyurethane/Vinyl
Medium Density Fiber
Make sure clamps are tight and there are no
air leaks at the tube ends
Avoid severe bends in the tube as this will
increase port noise.
Each powerpipe model has an optimized
length for proper tuning. Minor adjustments
(+/- 6 inches) can be tolerated. Larger changes
will adversely aect performance.
Flexible Port Shipped: 650PT = 4” x 48”;
800PT = 4” x 36”; 1000PT = 4” x 28”;
1200PT = 4” x 28” (48” for dual-port);
1500PT = 8” x 36”
IMPORTANT:
1:
2:
3:
1
2
5 6
7
8
9
3
4
90
o
9
8
7
56
2
1
3
4
1
3
2
5
9
6
7
8
v3/13
535 Airpark Road, Napa, CA 94558 • Ph: 707.265.6343 • www.JamesLoudspeaker.com
C
E
ILI
N
G
MOU
N
T
WITH STRAPS
20180312
In-ceiling Construction
(Recommended Strap Installation Location)
LOOKING UP AT CEILING
