SMR 109
EN User Manual Walkie-Talkie
CZ Uživatelská příručka Vysílačka
SK Používateľská príručka Vysielačka
HU Felhasználói kézikönyv Adó-vevő
PL Podręcznik użytkownika Krótkofalówka
EN – 2
1. INSTRUCTION FOR USE
This set includes 2 walkie-talkie units: there are communication devices
which operate on 446.00625MHZ, range up to 500 meters in open area.
Notes:
• Please read the user manual carefully before using the equipment
and retain for future consultation!
2. SPECIFIC RECOMMENDATIONS
• If you carry any kind of personal medical device, Please consult
a doctor before use.
• To avoid the risk of burns, do not use the device if The aerial is
damage in any way.
• Don not use the device in a potentially explosive setting (e.g.
Around pumps, on the lower deck of a boat or around a fuel-storage
installation.
• Switch off the device if on an airplane or in a hospital.
• Never use the device in close proximity to a radio that avoid to
interference.
• Never mix used and new batteries.
• Position the transmitter and antenna ≥ 5cm from your face. Direct
the antenna upwards and speak normally.
• Clean the device with a damp cloth. Don’t use agents And solvent
for cleaning.
• Do not modify the device in any way. In the event of damage
occurring, ensure that the device us checked
• by a qualified professional.
• The device cannot be used to contact the emergency services.
• This device is not a toy.
EN – 3
3. BEFORE USE THE DEVICE
3.1 Removing the belt clip
Before insert batteries into the device, first remove the belt clip latch
away from the device. Pull up the clip and push out it.
3.2 Installing the Batteries
1. Open the screw by the screw diver at the bottom.
2. Open the battery compartment at the bottom of battery compartment
cover.
3. Insert 3* AAA Alkaline batteries (not included) into each unit.
4. Position the batteries according to the polarity making on the battery
compartment.
5. After placing batteries into correct positions, replace the battery
cover.
4. USING THE DEVICE
4.1 Turning the device on/off
• Switch on the device: Move the right switch upwards until the LED
light to green.
• Switch off the device: Move the right switch downwards, until the
LED light turn off.
4.2 Sending a call tone
• Press CALL button quickly, the call tone will be transmitted.
4.3 Receiving/transmitting communications
• The devices are in “Reception” mode when it is turned on and no
transmitting. When a signal is received, the device will in reception.
The LED light is green in standby and reception mode.
• When you press the PTT (push to talk) button, the devices switches
to “Transmission” mode. The LED light is red in transmission mode.
EN – 4
• Hold the device in a vertical position with the Mic (microphone)
3-5cm away from your mouth. While holding the PTT button, speak
into the microphone in a normal tone of voice.
• Release the PTT button when you have finished transmitting.
Notes:
1. The talking range will depend on your surroundings and
environment. It will be affected by obstructions such as walls and
buildings.
2. Don’t try to use two devices which are less than 1.5m (5 feets)
apart. Otherwise, you may experience noise.
5. TECHNICAL SPECIFICATIONS
Frequency......................................................................446.00625 MHZ
Channel number ......................................................................1 channel
Transmission Power ...................................................................<10mW
Range .....................................................Up to 500 meters in open area
Battery type ........................................ Require 3*AAA alkaline batteries
each walkie talkie (Not included)
EN – 5
INSTRUCTIONS AND INFORMATION ON THE
DISPOSAL OF DISCARDED PACKAGING MATERIALS
Take the packaging material to a collection centre for recycling.
DISPOSAL OF DISCARDED ELECTRICAL AND
ELECTRONIC EQUIPMENT
This symbol on the product, accessory or packaging
indicates that the product must not be treated as ordinary
household waste. Please dispose of this product in
a collection centre designated for the recycling of electrical
and electronic equipment. In some EU states or other
European countries, you can return your old product to
the retailer when purchasing an equivalent new product.
Proper disposal of this product helps to conserve valuable
natural resources and prevent potential negative impacts
on the environment and human health that could result
from improper disposal. Further details can be obtained
from local authorities or the nearest collection centre.
Failure to dispose of this type of waste properly may result
in legal penalties.
For Companies in European Union Countries
If you want to dispose of electrical or electronic
equipment, request necessary information from your
retailer or supplier.
Disposal in Countries Outside the European Union
Request information regarding the proper disposal of this
product from local authorities or your retailer.
This product meets the EU requirements.
EN – 6
FAST ČR, a. s. hereby declares that the radio device type SMR 109
complies with Directive 2014/53/EU.
For the full version of the EU
Declaration of Conformity, please visit: www.sencor.com
Text, design and technical specifications are subject to change without
notice; we reserve the right to make such changes.
The original version is in Czech.
Manufacturer: FAST ČR, a. s., U Sanitasu 1621, Říčany 251 01,
Czech Republic, info@sencor.cz
Authorised service centres: For detailed information on authorised
service centres, please visit www.sencor.com.
EN – 7
EN
Warranty conditions
Warranty card is not apart of the device packaging.
This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty
is limited to the following conditions. Warranty is referred only to the customer goods using for common
domestic use. The claim for service can be applied either at dealer’sshop where the product was bought, or
at below mentioned authorized service shops. The end-user is obligated to set up aclaim immediately when
the defects appeared but only till the end of warranty period. The end user is obligated to cooperate to certify
the claiming defects. Only completed and clean (according to hygienic standards) product will be accepted.
In case of eligible warranty claim the warranty period will be prolonged by the period from the date of claim
application till the date of taking over the product by end-user, or the date the end-user is obligated to take it
over. To obtain the service under this warranty, end-user is obligated to certify his claim with duly completed
following documents: receipt, certificate of warranty, certificate of installation.
This warranty is void especially if apply as follows:
Defects which were put on sale.
Wear-out or damage caused by common use.
The product was damaged by unprofessional or wrong installation, used in contrary to the applicable
instruction manual, used in contrary to legal enactment and common process of use or used for another
purpose which has been designed for.
The product was damaged by uncared-for or insufficient maintenance.
The product was damaged by dirt, accident of force majeure (natural disaster, fire, and flood).
Defects on functionality caused by low duality of signal, electromagnetic field interference etc.
The product was mechanically damaged (e.g. broken button, fall).
Damage caused by use of unsuitable media, fillings, expendable supplies (batteries) or by unsuitable
working conditions (e.g. high temperatures, high humidity, quakes).
Repair, modification or other failure action to the product by unauthorized person.
End-user did not prove enough his right to claim (time and place of purchase).
Data on presented documents differs from data on products.
Cases when the claiming product cannot be indentified according to the presented documents (e.g. the
serial number or the warranty seal has been damaged).
Manufacturer:
FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic
info@sencor.com
Authorized service centers:
Visit www.sencor.com for detailed information about authorized service centers.
The original version of the instructions is in the Czech language, other language versions are made by the
appropriate translation.
