INSTRUCTION MANUAL
TOASTER OVEN
TL-MC40EZF(GR)
BEFORE OPERATING THIS PRODUCT,
READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLIST FOR FUTURE REFERENCE
NOTE
PRODUCT SAFETY
IMPORTANT SAFEGUARDS ............................................................................................................................................EN-3
INSTRUCTION FOR USE
BEFORE FIRST USE ...........................................................................................................................................................EN-5
NAME OF PARTS ................................................................................................................................................................EN-6
CONTROL PANEL ................................................................................................................................................................EN-7
HOW TO USE .....................................................................................................................................................................EN-8
OPERATION ..........................................................................................................................................................................EN-9
CARE AND CLEANING ......................................................................................................................................................EN-12
SPECIFICATION ................................................................................................................................................................EN-12
CONTENTS
EN-3
IMPORTANT SAFEGUARDS
SAFETY WARNING
1. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
2. Children should be supervised to ensure that they do
not play with the appliance.
3. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
4. WARNING: Ensure that the appliance is switched o
before replacing the lamp to avoid the possibility of
electric shock.
5. The appliances are not intended to be operated by means
of an external timer or separate remote-control system.
6. The temperature of accessible surfaces may be high when
the appliance is operating.
7. Accessible parts may become hot during use.
Young children should be kept away.
8. The appliance is intended to be used freestanding.
When using electrical appliances, basic safety precautions
should always be followed including the following:
PRODUCT SAFETY
EN-4
SAFETY WARNING
IMPORTANT SAFEGUARDS
9. Remove plug from outlet when the appliance is not in use,
before putting on or taking o parts, and before cleaning.
Allow to cool before handing.
10. Ectreme caution should be exercised when using containers
constructed of other metal or glass.
11. Do not store any materials, other than manufacturers
recommended accessories in this oven when not in use.
12. Do not place any of the following materials in the oven:
paper, carboard, plastic, and the like.
13. Avoid contacting moving parts.
14. This appliance is intended to be used in household
and similar applications such as:
-sta kitchen areas in shops, oces and other working
environments;
-by clients in hotels, motels and other residential type
environments;
-farm houses;
-bed and breakfast type environments.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
The surfaces are liable
to get hot during use.
EN-5
The oven may smoke during this process. This is normal for a new
Oven andwill not last more than 10-15 minutes.
NOTE
BEFORE FIRST USE
1. Remove all accessories and shipping materials packed inside the oven.
2. Wash the rack and grill tray in warm soapy water. Wipe the inside of the oven
with a damp cloth or sponge. Blot dry with paper towels to be sure the unit is
dry before using.
3. Place oven on a at counter or other stable surface. DO NOT OPERATE ON THE
SAME CIRCUIT WITH ANOTHER APPLIANCE.
4. Make sure the crumb tray is properly installed before using.
5. Before working, place the crumb tray under the bottom heating pipes.
For the rst time only, set the Temperature Knob to MAX, the function setting on
toast and the timer to 15 minutes. This will burn o any oils still on the oven.
INSTRUCTION FOR USE
EN-6
NAME OF PARTS
Crumb Tray Grill Tray Rack Remover Holder
Heat-protecting glass
Door handles
Rotisserie Fork Rotisserie Kit
CONTROL PANEL
EN-7
Temperature
knob of upper
heating pipes
Function knob
Temperature
knob of lower
heating pipes
Time knob
Light
TIME SETTING
0-120 MINUTES: The timer can be set up to
120 minutes. The oven will not turn on
without the timer being set. When the
Time knob is in the "OFF" position, the oven
will not operate. To set the time, turn the
knob clockwise to the desired time.
Indicator Light is lit only when time has
been set. When the Timer has reached the
"OFF" position, a bell sound will be heard.
Power supply will be cut o automatically.
ADJUSTING TIME
Timer can be change during cooking cycle.
Just turn the timer knob to the desired time
and continue cooking.
NOTE: To select the cooking time, rst
rotate the timer knob more than 90
degrees, and then turn the switch back to
the time you require.
TEMPERATURE SETTING
Turn the temperature knob clockwise to the
desired temperature setting. The
temperature can be set from 70℃ to 230℃ .
STAY ON
For use the toaster without time control,
turn the timer knob to position" Stay on".
In this case, the toaster will work until the
timer knob is set to " OFF " position.
Note: the food may catch re if the cooking
time is setting too long. Close supervision is
necessary during cooking and the timer do
not being set too long.
℃温度/上
F功能
℃温度/下
时间
持续工作
温馨提示
若定时小于10分钟，旋至超过10分钟后，
再回旋到所需时间
INSTRUCTION FOR USE
HOW TO USE
CAUTION: THE OVEN SURFACES ARE HOT DURING AND AFTER USE GENERAL
INSTRUCTIONS
1. Place the rack in position that will accommodate the height of the food to be
cooked.
2. The food must be put into the grill tray to avoid the re danger that caused
by the accumulation of food chipping on the heating pipes.
3. Make sure that you always use an ovenproof container in the oven, never use
plastic or cardboard containers in the oven.
4. Clean the heating pipe periodically.
5. Never use glass or ceramic pans or lids.
6. DO NOT let juice run to the bottom of the oven. Use the crumb tray when
cooking.
7. Set the temperature as suggested by the recipe or as desired.
8. Securely shut the door and set the cooking time to begin operating the oven.
EN-8
FUNCTION SETTING
This oven oers six dierent functions for versatile cooking all in one appliance.
Bake: The lower heating elements are working during this function.
Broil: The upper heating elements are working during this cycle.
Toast: The upper and lower heating elements are working during this function.
Rotisserie: The upper straight electric heating elements, along with the Rotisserie
Motor is working. Follow Rotisserie instruction for proper use.
Fermentation: It is suitable for fermented yogurt and so on.
Convection: The upper and lower heating elements, along with the motor fan are
working.
OPERATION
BAKE
EN-9
1. Set the function knob to " ".
2. Rotate the lower tube temperature knob to set the lower temperature.
3. Rotate the time knob to set cooking time.
4. Continuing baking for desired length of time.
5. Check food temperatures before moving to ensure that proper internal
temperatures have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
BROIL
1. Set the function knob to " ".
2. Rotate the upper tube temperature knob to set the upper temperature.
3. Rotate the time knob to set cooking time.
4. Continuing broiling for desired length of time.
5. Check food temperatures before moving to ensure that proper internal
temperatures have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
TOAST
1. Set the function knob to " ".
2. Rotate the lower tube temperature knob to set the lower temperature.
3. Rotate the upper tube temperature knob to set the upper temperature.
4. Rotate the time knob to set cooking time.
5. Continuing toasting for desired length of time.
6. Check food temperatures before moving to ensure that proper internal
temperatures have been reached.
7. Always remove food with oven mitts. The food and oven are very hot.
INSTRUCTION FOR USE
EN-10
OPERATION
1. Set the function knob to " ".
2. Rotate the upper tube temperature knob to set the upper temperature.
3. Rotate the time knob to set cooking time.
4. Continuing cooking for desired length of time.
5. Check food temperatures before moving to ensure that proper internal
temperatures have been reached.
6. Always remove food with oven mitts. The food and oven are very hot.
1. Set the function knob to " ".
2. Rotate the lower tube temperature knob to set the lower temperature.
3. Rotate the upper tube temperature knob to set the upper temperature.
4. Rotate the time knob to set cooking time.
5. Continuing cooking for desired length of time.
6. Check food temperatures before moving to ensure that proper internal
temperatures have been reached.
7. Always remove food with oven mitts. The food and oven are very hot.
CONVECTION FUNCTION:
ROTISSERIE FUNCTION:
1. Set the function knob to " ".
2. Rotate the time knob to set cooking time.
3. Continuing fermenting for desired length of time.
4. Check food temperatures before moving to ensure that proper internal
temperatures have been reached.
FERMENTATION FUNCTION:
EN-11
ROTISSERIE FUNCTION USING THE ROTISSERIE FORK:
1. Insert a fork into the rotisserie pole.
2. Tighten the screw to x the fork in an appropriate place.
3. Put the food into the rotisserie pole and then use the fork to x a side of the food.
4. Insert the other fork into the rotisserie pole to x the other side of the food.
5. Tighten the screw to x the fork in an appropriate place.
6. Use the rotisserie kit to put the food with rotisserie fork in the oven.
7. Insert the pointed end of the rotisserie fork into the hole of the right side of the oven.
Then put the other side of the rotisserie fork on the notch of the left side of the oven.
INSTRUCTION FOR USE
EN-12
SPECIFICATION
Warning: Hot Surface!
Advertencia: ¡Supercie Caliente!
Avertissement: Surface Chaude!
CAUTION : HOT
SURFACE
CARE AND CLEANING
1. Before cleaning unplug the oven and allow it to cool completely.
2. Wash all the attachments with mild, soaped water including the rack and the
grill tray.
3. Do not use abrasive cleansers, scrubbing brushes and chemical cleaner as this
will cause damage to the non-stick coating of grill tray.
4. Using a wet cloth to wipe the inner of the oven.
5. To clean the door by using a wet cloth saturated with detergent or soap.
6. Never immerse the unit in water or other liquid.
7. Any other servicing should be performed by an authorized service representative.
MODEL
VOLTAGE
AC FREQUENCY
POWER
230-240V~
50/60Hz
1650-1800W
TL-MC40EZF(GR)
PN:16171000A12871
