Sencor SWM 2000 Bluetooth Car FM Transmitter User Manual

SWM2000

EN User Manual MP3/BT FM MODULATOR

SWM 2000

Uživatelská příručka MP3/BT FM MODULÁTOR

SWM2000

Používateľská príručka MP3/BT FM MODULÁTOR

SWM2000

Felhasználói kézikönyv MP3/BT FM TRANSZMITTER

SWM2000

Podręcznik użytkownika TRANSMITER MP3/BT FM

SWM2000

EN - 1

DESCRIPTION OF EQUIPMENT

1 – previous track (short press)

– reduce volume (long press)

2 USB port for playback

3 Display

4 Microphone

5 USB charging port

6 – next track (short press)

– increase volume (long press)

MP3/BT FM MODULATOR SWM 2000

EN - 2

7 Multifunction button

– change frequency (long press)

– play/pause (short press when track is playing)

– incoming calls control (short press to answer/hang

up incoming call, long press to reject incoming call,

press 2x to dial last dialed number)

8 TF memory card slot

9 Connector for car outlet 12 – 24 V

SETTING UP AND PAIRING WITH FM RADIO

Before rst use, be sure to read the safety instructions con-

tained in this user's manual carefully. Connect the modulator

to the car socket power supply (12 – 24 V). The rst value dis-

played on the display panel indicates the voltage of the vehi-

cle's onboard electrical system, for example 12 V. Tune your

car radio to any unoccupied FM frequency, and set the same

FM frequency on the modulator by pressing and holding the

Multifunction button (No. 7 in the diagram). When this button

is pressed, the frequency number on the modulator display will

start ashing, the press the arrow buttons (No. 1 and 6 in the

diagram) to set the desired frequency matching the one of your

FM car stereo.

PAIRING VIA BLUETOOTH

Find the Bluetooth modulator name “SWM 2000” on your Blue-

tooth portable device to be paired (such as a mobile phone) and

start the pairing process. If you are requested to enter a pairing

code while your device and the modulator are being paired, use

the following code: "0000".

EN - 3

Note: To ensure a stable Bluetooth connection, make sure that

the distance between the modulator and your connected device

is kept within 5m.

USB CHARGING INPUT

This input (No. 5 in the “Device description” diagram) is de-

signed for connecting and charging portable devices.

Note: Power supply cables of lower quality may cause playback

interference when connected.

USB INPUT FOR PORTABLE DEVICES AND

PLAYBACK OF TF MEMORY CARDS

Once the USB ash drive is connected to the USB playback

input (No. 2 in the diagram) or the memory card is connect-

ed to the relevant slot (No. 8 in the diagram), the modulator

will recognise the connected device and search it for playable

tracks. To select from the tracks being played“ press the “Previ-

ous track" or “Next track” button “(No. 1 and 6 in the diagram).

A short press of the Multifunction button (No. 7 in the diagram)

pauses/resumes playback.

Caution: With respect to the variety of devices on the market,

the compatibility and playability of all media is not guaranteed.

Memory devices that you wish to connect should be tested in

advance or formatted to the FAT32 le format. It may not be

possible to playback protected media, les or content contained

on them. Playback tested and unprotected media and content.

Note: Media with a power consumption greater than ash

memory should only be connected only if they have a separate

power supply. If the USB ash drive is bigger than 32 GB (e.g.

64 GB), format it to FAT32 and verify its compatibility and rec-

EN - 4

ognition by this device before use. If the device does not read

the memory even though it should contain playable content, use

a di󰀨erent card or memory/media type.

INSERTING THE TF MEMORY CARD

Insert the TF memory card in the relevant slot (No. 8 in the

diagram) so that the contacts face the control buttons and the

modulator display. Carefully push the TF memory card with your

nail or a at tool until it clicks gently in place. To remove the TF

memory card, press it gently into the modulator body with your

ngernail or a at tool. The card will release. While removing

the TF memory card, hold it gently so that you can catch it after

it is released.

CALLING

If your mobile phone is paired with the modulator via Bluetooth,

an incoming call will interrupt the played track. A short press of

the Multifunction button (No. 7 in the diagram) answers/ends

a call. To reject an incoming call, long-press the Multifunction

button. To start dialling the last call number, briey press the Mul-

tifunction button twice.

VOLUME CONTROL

To change the volume, use the Volume buttons (No. 1 – de-

crease the volume and No. 6 – increase the volume, as shown

in the diagram).

Note: The resulting playback volume is inuenced by the cur-

rent volume setting on the modulator, car stereo and your porta-

ble device. To set optimal volume, it may be necessary to adjust

the volume level on each of these devices.

EN - 5

TECHNICAL SPECIFICATIONS

Charging:

2x USB-A (5 V / 2.4 A)

Inputs:

Bluetooth V5.3

Micro SD card (up to 32 GB)

USB port for music playback and charging

Telephoning:

Wireless hands-free support

Built-in microphone for calls

Supports call answering through car stereo

Commands – Answer / Decline / Hang up / Callback

Other:

Volume Control

Pause, previous/next functions

Memory for last frequency, track number and volume

Digital tuning and frequency display

Support: MP3, WMA, FLAC, WAV

Voltage meter in car power supply system

FM transmission frequency range: 87,5 – 108 MHz

Power supply: DC 12 / 24 V (car cigarette lighter)

Dimensions: (w × h × d) 41 x 69 x 42 mm

Weight: 30 g

EN - 6

NOTICE

• This device’s operating voltage is 12 V – 24 V. If the voltage

is too high or too low, damage or failure to the device may

occur.

• For safety reasons, always connect the USB ash drive to

the device before connecting the device to the car’s igniter

socket.

• This unit may not support all types of USB ash discs or

memory cards.

• If the device fails to read data from the USB ash drive, try

to reinsert the USB ash drive or reconnect it to the igniter

socket. If the problem persists, use other USB ash drive.

• The car FM tuner frequency should be the same as the

unit’s frequency.

• Do not pull out or insert the USB ash drive while the device

is powered from the igniter. If you want to do so, rst discon-

nect the unit from the socket and insert or remove the drive/

card before reconnecting the unit to the power supply.

• If there are too many audio les stored on the USB ash

drive, their processing may be slow.

EN - 7

INSTRUCTIONS AND INFORMATION ON THE

DISPOSAL OF PACKAGING MATERIALS

Dispose of packaging material at a collection yard.

DISPOSAL OF DISCARDED

ELECTRICAL AND ELECTRONIC

EQUIPMENT

This symbol on the product, accessories or pack-

aging indicates that the product must not be treat-

ed as regular household waste. Please dispose

of this product in a collection centre designated

for the recycling of electrical and electronic equip-

ment. In some European Union countries or in

some European countries, you can return your

products to the local retailer when purchasing an

equivalent new product. Correct disposal of this

product helps save valuable natural resources

and prevents possible adverse impacts on the en-

vironment and human health that might be caused

by improper waste disposal. Please contact local

authorities or the nearest waste collection yard for

further details. Improper disposal of this type of

waste may result in legal penalties.

EN - 8

Warranty conditions

Warranty card is not apart of the device packaging.

This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty

is limited to the following conditions. Warranty is referred only to the customer goods using for common

domestic use. The claim for service can be applied either at dealer’sshop where the product was bought, or

at below mentioned authorized service shops. The end-user is obligated to set up aclaim immediately when

the defects appeared but only till the end of warranty period. The end user is obligated to cooperate to certify

the claiming defects. Only completed and clean (according to hygienic standards) product will be accepted.

In case of eligible warranty claim the warranty period will be prolonged by the period from the date of claim

application till the date of taking over the product by end-user, or the date the end-user is obligated to take it

over. To obtain the service under this warranty, end-user is obligated to certify his claim with duly completed

following documents: receipt, certiﬁcate of warranty, certiﬁcate of installation.

This warranty is void especially if apply as follows:

 Defects which were put on sale.

 Wear-out or damage caused by common use.

 The product was damaged by unprofessional or wrong installation, used in contrary to the applicable

instruction manual, used in contrary to legal enactment and common process of use or used for another

purpose which has been designed for.

 The product was damaged by uncared-for or insufﬁcient maintenance.

 The product was damaged by dirt, accident of force majeure (natural disaster, ﬁre, and ﬂood).

 Defects on functionality caused by low duality of signal, electromagnetic ﬁeld interference etc.

 The product was mechanically damaged (e.g. broken button, fall).

 Damage caused by use of unsuitable media, ﬁllings, expendable supplies (batteries) or by unsuitable

working conditions (e.g. high temperatures, high humidity, quakes).

 Repair, modiﬁcation or other failure action to the product by unauthorized person.

 End-user did not prove enough his right to claim (time and place of purchase).

 Data on presented documents differs from data on products.

 Cases when the claiming product cannot be indentiﬁed according to the presented documents (e.g. the

serial number or the warranty seal has been damaged).

Manufacturer:

FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic

info@sencor.com

Authorized service centers:

Visit www.sencor.com for detailed information about authorized service centers.

The original version of the instructions is in the Czech language, other language versions are made by the

appropriate translation.

For Companies in the European Union

If you need to dispose of electrical or electronic equipment, ask

your retailer or supplier for the necessary information.

Disposal in countries outside the European Union

To dispose of this product, please ask your local authorities or

dealer for the necessary information on correct disposal.

This product complies with EU requirements.

FAST ČR, a.s. hereby declares that the SWM

2000 type device conforms to the 2014/53/EU

Directive. For full version of the EU declaration

of conformity, please refer to the www.sencor.eu

website.

Changes in the text, design and technical specications may

be made without prior notice and we reserve the right to make

such changes.

The original version is in the Czech language.

Manufacturer’s address:

FAST ČR, a. s., U Sanitasu 1621, Říčany CZ-251 01

EN - 9
