Data Sheet SAMSUNG PROPRIETARY
Revision 2.2
1
fㅋ
Revision 2.0
2024 Data Sheet
Samsung microSD UHS-I Card
: PRO Plus Lineup
Data Sheet SAMSUNG PROPRIETARY
Revision 2.2
2
DISCLAIMER
SAMSUNG ELECTRONICS RESERVES THE RIGHT TO CHANGE PRODUCTS, INFORMATION AND SPECIFICATIONS
WITHOUT NOTICE.
Products and specifications discussed herein are for reference purposes only. All information discussed herein
may change without notice and is provided on an “AS IS” basis without warranties of any kind. This document
and all information discussed herein remain the sole and exclusive property of Samsung Electronics. No license
of any patent, copyright, mask work, trademark or any other intellectual property rights is granted by one party
to the other party under this document by implication, estoppels or otherwise. Samsung products are not
intended for use in life support, critical care, medical, safety equipment, or similar applications where product
failure could result in loss of life or personal or physical harm, or any military or defense application, or any
governmental procurement to which special terms or provisions may apply. For updates or additional
information about Samsung products, contact your nearest Samsung Electronics’ authorized representative.
COPYRIGHT © 2024
This material is copyrighted by Samsung Electronics. Any unauthorized reproductions, use or disclosure of this
material or any part thereof, is strictly prohibited and is a violation under copyright law. The microSD, microSDHC
and microSDXC mark and logo are trademarks of SD-3C LLC. All other marks are property of their respective
owners.
TRADEMARKS & SERVICE MARKS
The Samsung Logo is the trademark of Samsung Electronics. Adobe is a trademark and Adobe Acrobat is a
registered trademark of Adobe Systems Incorporated. All other company and product names may be trademarks
of the respective companies with which they are associated.
Data Sheet SAMSUNG PROPRIETARY
Revision 2.2
3
1. TECHNICAL SPECIFICATIONS
Samsung microSD Ca r d PRO Plus
Hardware
Information
Form Factor microSDXC
TM
User Capacity
128GB 256GB 512GB 1TB
128,144,375,808
Bytes
1)
256,288,751,616
Bytes
1)
512,644,612,096
Bytes
1)
1,025,356,333,056
Bytes
1)
Bus Speed
Mode
UHS-I SDR104
2)
/
UHS-I DDR200
3)
with Samsung microSD Reader
Dimensions 15 x 11 x 1 (mm) (L x W x H)
Weights Approx. 0.25g (Card only)
Performance
Speed Class Class 10, V30
4)
App Perf.
Class
A2
5)
Speed Grade Grade 3 (U3)
Sequential
Read Speed
6)
Up to 180MB/s
Sequential
Write Speed
6)
Up to 130MB/s
Reliability Temperature
Operating : -25°C to 85°C
Non-Operating : -40°C to 85°C
EMC Certifications FCC (IC), CE (UKCA), VCCI, RCM
Warranty 10 year limited
7)
1) 1GB=1,000,000,000 bytes. Actual usable storage capacity may vary. User capacity measured with SD Formatter 3.1 tool with FAT
file system.
2) SDR104: 1.8V Signaling, Frequency up to 208 MHz, up to 104MB/sec, Max. Current Consumption 800mA (varies by test conditions)
3) DDR200 : 1.8V Signaling, Frequency up to 208 MHz, up to 200MB/sec, Max. Current Consumption 800mA (varies by test
conditions)
4) V30 : Video Speed Class means sustained video capture rates of 30MB/s(V30) which enable to support real-time video recording
to UHS Bus interface products. Transfer speeds may vary by host device.
5) A2 : Application Performance Class means Min. Random Read 4000 IOPS(A2), Random Write 2000 IOPS(A2), and Sustained Seq.
Write 10MB/s(A1, A2), which makes app performance faster. Performances may vary by host device.
6) Performance results are based on internal testing conditions. Stated performance was achieved by using PRO Plus SD card with
Samsung SD Card reader (ver2.0) in a controlled environment. Actual read/write speeds may vary depending on user environment.
For more information, please see "4. Card Reader Compatibility."
7) Warranties provided herein do not extend to any use of the product for or with continuous recording instruments or any other
write-intensive devices, including without limitation security cameras, surveillance systems, dashboard cameras, blackbox
cameras, internet protocol/network cameras, continuous recording set top box devices and continuous data logging devices like
servers, dedicated devices for benchmarking test, the primary drive for certain devices and any other excessive uses.
Data Sheet SAMSUNG PROPRIETARY
Revision 2.2
4
2. PRODUCT LINEUP
Form Factor Lineup Capacity Model Name
microSD PRO Plus
128GB
MB-MD128S
256GB MB-MD256S
512GB
MB-MD512S,
MB-MY512K
1TB MB-MD1T0S
3. Regulatory Compliance
4. Card Reader Compatibility
Maximum read/write speeds are possible only when PRO Plus SD card is used with specific Samsung SD Card
reader (ver2.0 and ver3.0). Actual speeds may vary depending on user environment including host device and
use conditions.
PRO Plus Reader (ver 1.0) PRO Plus Reader (ver 2.0 and 3.0)
Up to 160MB/s Up to 180MB/s
Data Sheet SAMSUNG PROPRIETARY
Revision 2.2
5
5. 6-Proof Features
Items
Conditions
Water-proof
1M depth, salt water (3% NaCl), 72hrs
(*1TB : 1M depth, salt water (3% NaCl), 24hrs)
Temperature-proof
Operating temperatures of -25℃ to 85℃ (-13°F to 185°F)
Non-operating temperatures of -40℃ to 85℃ (-40°F to 185°F).
X-Ray-proof Withstands standard airport x-ray machines (Up to 100mGy, 210sec)
Magnetic-proof Magnetic field equivalent of a high-field MRI scanner (Up to 15,000 gauss, 30secs)
Drop-proof
Withstand drops up to 5 meters (16.4 feet), 10 cycles
*1TB : 1.5 meters (4.9 feet), 10 cycles
Wearout-proof Up to 10,000 swipes
The multi-proof testing results reported herein were obtained under strictly controlled lab environment, as more fully described in the
respective footnote for each test. Any attempt to replicate such results are not covered under Samsung’s warranty program and Samsung
disclaims any and all liability with respect to damages resulting from such attempts, including without limitation, damage to product,
loss of property, or loss of data. For more information on Samsung’s warranty policy, please visit: www.samsung.com/support.
6. REVISION HISTORY
Revision
Number
Description Revision Date
1.0 Initial Release February 2023
1.1 Changes in Reader March 2023
1.2
Adding Model Code
May 2023
2.0 Adding 1TB model February 2024
2.1 Modifying Multi-Proof conditions August 2024
2.2 Modifying Drop-Proof conditions August 2024
