INSTRUCTION MANUAL
IMPORTANT:
①Read Before Using
②After-sale Mailbox:[email protected]
Electric Ratchet Wrench
SAFETY WARNINGS
WORK AREA
ELECTRICAL SAFETY
• Keep your work area clean and well lit. Cluttered benches
and dark areas invite accidents.
•Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases, or
dust.
Power tools create sparks which may ignite the dust or fumes.
•Keep bystanders, children, and visitors away while
operatinga power tool. Distractions can cause you to lose
control.
•Don't expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
PERSONAL SAFETY
•Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use too while
tired or under the influence of drugs, alcohol, or medication.
•A moment of inattention while operating power tools may
result in serious personal injury.
•Dress properly. Do not wear loose clothing or jewelry.
Contain long hair. Keep your hair, clothing, and gloves away
from moving parts. Loose clothing, jewelry, or long hair can
be caught in moving parts.
-1-
•Avoid accidental starting. Be sure switch is off before
plugging in. C arrying tools with your finger on the switch or
plugging in tools that have the switch on invites accidents.
•Remove adjusting keys or wrenches before turning the
tool on. A wrench or a key that is left attached to a rotating
part of the tool may result in personal injury.
•Do not overreach. Keep proper footing and balance at all
times. Proper footing and balance enables better control of
the tool in unexpected situations.
•Use safety equipment. Always wear eye protection. Dust
mask, non-skid safety shoes, hard hat, or heanng protection
must be used for appropriate conditions.
TOOL USE AND CARE
•Use clamps or other practical way to secure and support
the work piece to a stable platform. Holding the work by
hand or against your body is unstable and may lead to loss of
control.
•Do not force tool. Use the correct tool for your application.
The correct tool will do the job better at the rate for which it is
designed.
•Do not use tool if switch does not turn it on or off. Any
tool that cannot be controlled with the switch is dangerous
and must be repaired.
-2-
COMPONENTS AND SPECIFICATIONS
-3-
•Store idle tools out of reach of children and other
untrained persons. Tools are dangerous in the hands of
untrained users.
•Check for misalignment or binding of moving parts,
break- age of parts, and any other condition that may
affect the tool's operation. If damaged, have the tool
serviced before using. Many accidents are caused by poorly
maintained tools.
•Use only accessories that are recommended by the
manufacturer for your model. Accessories that may be
suitable for one tool, may become hazardous when used
on another tool.
G A
A. 3/8" Square Drive
B. Battery Indicator
C. LED
D. Lock Switch
E. Paddle Switch
F. Battery
G. Forward/Reverse Toggle
C
BD
F
E
SPECIFIC INSTRUCTIONS
-4-
WARNING! Hold power tool by insulated gripping
surfaces, when performing an operation where the
fastener may contact hidden wiring. Fasteners cont-
acting a "live"wire may make exposed metal parts of
the power tool "live" and could give the operator an
electric shock.
Inserting / Removing the Battery
To insert the battery, slide the
pack into the body of the tool.
Make sure it latches securely into
place.
Model
Square Drive
Max Torque
Rated Speed/No Load Speed
Rated Battery Voltage Weight
(Bare Tool)
Weight (Tool + Battery)
RT800L
3/8lnch
40 Foot Pounds
220 RPM
12V
1.72 bs
2.12 bs
-5-
To remove the battery, push in
the release buttons and pull the
battery pack away from the tool.
Attaching and Removing Acce-
ssories These tools are intended
only for use with accessories
designed for impact tools. Other
sockets could shatter or break,
causing injury.To attach a socket
or other accessory, align the
accessory with the drive anvil and
push it firmly onto the tool. To
remove the accessory, pull the
accessory off the drive anvil.
-6-
Using the Forward/Reverse
Toggle For forward (clockwise)
rotation, Forward rotate the
forward/reverse toggle countercl-
ockwise.Check the direction of
rotation before use.
For reverse (counterclockwise)
rotation, rotate the forward/re-
verse toggle clockwise. Check the
Reverse direction of rotation
before use.
BATTERY INDICATOR
Rem aining
Capacity
Indicator Lights
≦50%
≦50%-80%
Red Light ON
Red & Yellow Lights ON
Red & Yellow & Green
Lights ON
≦80%-100%
-7-
MPORTANT SAFETY INSTRUCTIONS FOR
BATTERY CARTRIDGE
Charge Battery
Charger Indicator
Red Indicator
ON
OFF
Green Indicator
OFF
ON
Battery Pack
Charging
Charged
Status
Charging
Charged
To Charge the battery, align the battery pack with the
bay and slide the battery pack into the charger as far as
possible. The red light will come on, either flashing
(battery pack is too hot or cold) or continuous (pack is
charging). A fully discharged battery pack with an internal
temperature in the normal range will charge in 30 to 90
minutes, depending on the battery pack and charger.
•Before using battery cartridge, read all instructions and
cautionary markings on (1) battery charger, (2) battery, and
(3) product using battery.
•Do not disassemble battery cartridge.
•If operating time has become excessively shorter, stop
operating immediately. It may result in a risk of overheating,
possible burns and even an explosion.
Short
Circuited
Short
Circuited
OFF OFF
-8-
•If electrolyte gets into your eyes, rinse them out with clear
water and seek medical attention right away. It may result in
loss of your eyesight.
•Do not short the battery cartridge:
(1)Do not touch the terminals with any conductive material.
(2)Avoid storing battery cartridge in a container with other
metal objects such as nails, coins, etc.
(3) Do not expose battery cartridge to water or rain.
A battery short can cause a large current flow, overheating,
possible burns and even a breakdown.
Warranty Policy
Every Seesii product is thoroughly inspected and tested
before leaving the factory. It is warranted to be free of defects
from workmanship and materials for the period of THREE
YEAR from the date of original purchase. Should any trouble
develop during this three year period, please contact us via
[email protected]. If inspection shows the trouble is
caused by defective workmanship or material, Seesii will
repair (or at our option, replace) without charge.
This Warranty does not apply where:
•Repairs have been made or attempted by others.
•Repairs are required because of normal wear and tear.
•The tool has been abused, misused or improperly maintained.
•Alterations have been made to the tool.
Warranty Policy
