E-BIKE
USER'S MANUAL
Caution read the manual before using your equipment
IMPORTANT SAFETY INSTRUCTION ....
GENERAL INFORMATION ...............
BIKE USAGE ............................
INSTALLATION AND ADJUSTMENT ......
METER OPERATION .....................
BATTERY AND CHARGING ...............
MAINTENANCE ..........................
WARRANTY .............................
ATTACHMENT ...........................
WARNING ...............................
CONT ENTS
01
03
07
08
11
17
21
22
23
25
01
WHEN USING THIS PRODUCT BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED,
INCLUDING THE FOLLOWING:
Read all the instructions before using the product.
To reduce the risk of injury, close supervision is necessary when the product is
used near children.
Do not use this product if the exible power cord or output cable is frayed, has
broken insulation, or any other signs of damage.
Do not put your ngers, hands or feet into the rotating wheel.
Don't lend this product to people who can't operate it, so as not to cause harm; if
you lend the bike, please let the user follow instructions, it could help to decrease
the risk of accident.
The E-bike cannot be used as o-road vehicles or used for extreme bicycle sports;
when riding the bicycle, please wear a safety helmet and protective gear. It is
forbidden to ride with one hand.
Please abide by the trac rules and prohibit riding on motorized lanes and roads
with multiple pedestrians.
Carry people or objects in accordance with the requirements of laws and
regulations, and do not park in the building's lobby, evacuation stairs, walkways,
and safe entrances and exits.
It is recommended to charge and park in an outdoor dedicated parking hall, while
avoiding rain; when charging, keep away from combustibles, and the charging
time should not be too long.
For safety reasons, please do not change the default speed setting of the electric
bicycle and do not exceed speed limit in accordance with the trac rule. Riding
on non-motorized lanes, downhills and paved roads not exceeding 15km/h.
IMPORTANT SAFETY INSTRUCTION
●
●
●
●
●
●
●
●
●
●
THINGS TO KNOW BEFORE USE
02
IMPORTANT SAFETY INSTRUCTION
When adjusting the handlebar or saddle, please be careful not to exceed the
safety line markings on the handlebar and saddle.
When using the motor, please be careful not to hit vigorously and keep the
rotating shaft lubricated.
Try to avoid riding in severe weather such as heavy rain and snow.
It is not allowed to exceed the maximum load of the vehicle body when riding (the
maximum load is 120KG).
It is suitable for people of 16+ years old and physically t adults, and it is strictly
forbidden to drive electric bicycles on the road by people under 16 years old.
Slow down when riding in rain or snow since the braking distance will be increased
in such slippery conditions.
●
●
●
●
●
●
03
GENERAL INFORMATION
1. ABOUT ANCHEER ELECTRIC BIKE
ANCHEER electric bike is a leading icon of e-bikes. For years, ANCHEER has been not
only dedicating to innovation, cutting-edge technology and premium materials, but
also providing cost eective e-bikes, to satisfy riders' various needs of transportation
and even desire of exploring sports & outdoors life. Just ride freely with ANCHEER !
2. WHAT’S IN THE BOX (PARTS LIST)
Description Quantity
ANCHEER Electric Bike
Pedal
Bell
2
1
User Manual
Saddle 1
1
Charging Adapter
Kickstand
1
1
2Reector
Tools Kit
1
1
04
3. BIKE COMPONENTS
01
02
03
04
05
06
07 08 09 10 11 12
13
14
15
16
17
18192021222324252627
NO. NO. NO.PART PART PART
Wheel Rim Seat Tube Rear Disc Brake
Tyre Saddle Tyre
Front Fork Tail Light Chain
Front Light Rear Suspension Chain Wheel
Vertical Folding Clasp Chain Cover Crank
Stem Rear Fender Frame
Controller Rear Disc Brake Caliper Front Fender
Battery Box Motor Front Disc Brake Caliper
Battery Kickstand Front Disc Brake
01 10 19
02 11 20
03 12 21
04 13 22
05 14 23
06 15 24
07 16 25
08 17 26
09 18 27
GENERAL INFORMATION
05
3. BIKE COMPONENTS
GENERAL INFORMATION
28 33
31
30
29
32
34
35
36
NO. NO. NO.PART PART PART
Left Brake Lever Bell Left Brake Lever
Left Handlebar Pedal Throttle
Power Switch Front Reector LED meter
28 31 34
29 32 35
30 33 36
06
GENERAL INFORMATION
4. TOOL LIST
5. STANDOVER HEIGHT
0.20inch(5mm)
Allen Key
0.24inch(6mm)
Allen Key
Slotted-Phillips
Head Screwdrive
13-15mm Open
End Wrench
3-8 cm
1-3 in
52 cm
22.37 in
For the sake of safety and comfortable riding, when the rider stands on the ground
there should be clearance of 59cm/23in from ground to the crotch of the rider. Also, at
least 3-8cm/1-3in between the crotch and the top tube of the bike.
Note:
Standover height does not apply to bicycles with step-through frames. Instead, the
limiting dimension is determined by saddle height range. You should adjust your
saddle position without exceeding the limit line on the saddle tube.
07
After Riding
During Riding
BIKE USAGE
Before Riding
Before riding the bike on the open road, try all the settings on the electric bike, and
get used to various results in a safe and controllable environment.
Please check the power circuit, lighting circuit, and test the brake system before
cycling.
Always check the tire pressure before starting to ride, and make sure that the tire is
inated to a pressure within the specied range.
In order to ensure the safety of riding, please check regularly for loose parts or
screws. The places that need to be checked include but not limited to the seat tube,
wheels, handlebars and pedals.
If necessary, please conrm whether the battery capacity can meet you riding demand.
2
1
If the pressure is too low, the wheel may be damaged, or the inner tube may be
squeezed, causing the tire to leak air.
If the pressure exceeds the recommended maximum value, the tire may blow
out of the rim, which may damage the bicycle and cause injury to the cyclist and
nearby people.
Please wear helmets and riding gear that meet the requirements in accordance with
regulations.
Avoid traveling in severe weather such as heavy rain and snow,etc.
Carry people or objects in accordance with the requirements of laws and regulations,
and the load of the entire bike should not exceed 120kg.
Obey the trac rules.
●
●
●
●
●
●
●
●
●
After heavy use, do not touch the hot surface, such as the disc brake rotor or the side
edge of the brake rim.
When folding the kickstand, always make sure that the stand is secure and the base
is rm to prevent the bicycle from falling.
If the bicycle is splashed with moisture, please wipe it dry and clean in time.
●
●
●
08
INSTALLATION AND ADJUSTMENT
1. Quick Start Unfolded Folding
Quick start unfolded folding, and adjust the handlebar angle.
1. Unfold the stem.
2. Fold the vertical folding clasp.
3. Fasten the safety buckle.
Must Be Fastened/Locked
Open the package of the bike, take out the electric bike and all the parts inside and
use the tool to cut o the packing rope. Please follow our YouTube channel- ANCHEER
SPORT, we have provided installation tutorial.
Installation Video
Note:
09
INSTALLATION AND ADJUSTMENT
2. Mount The Pedals
Ensure that the thread of each pedal is fully inserted into the crank arm. Tighten the
pedals completely with a wrench. (Counterclockwise screw the pedal marked "L" on
the left side crank. Clockwise screw the pedal marked "R" on the right side crank.)
3. Install The Seat
Install the saddle tube into post receiver. Set right its position and adjust height
to t your riding habit. (Note: please be careful not to exceed the limit line)
Tighten the fastening nut clockwise rst, and then fasten the seat tube clamp.
Adjust the seat angle to the most comfortable position.
3.1
3.2
Don't
exceed the
safety line.
10
INSTALLATION AND ADJUSTMENT
If the brake is not sensitive, loosen
the anchor bolt of the brake cable
to shorten the brake distance of the
brake cable and then tighten the bolt.
Or, lengthen the distance of the brake
cable when the brake is too sensitive.
Ensure that the brake cables are properly inserted into the brake levers before aligning
a mechanical disc brake. If the disc rotor is bent or damaged, replace the rotor rst.
If the rotor always rubs against the
brake pad or the gap is too large,
loose the two centering adjustment
screws, but do not remove them.
Slowly rotate the wheel and check
the space between the rotor and
the brake pad; adjust the position
of the brake pad and the rotor.
Centering the rotor and the pads to
avoid friction. After the adjustment is
complete, tighten the screws.
Leave the same clearance
on both sides of the disc
rotor
Brake pad
Disc rotor
Adjust caliper to
center the rotor
Centering
adjustment screws
4. Brake Adjustment
11
Fig. 2-1 Picture of Display
Fig. 2-2 Top View of Display
Dimensions
Fig. 2-3 Side View of Display Dimensions
58 mm
15 mm
17 mm
20 mm
35 mm
METER OPERATION
Activate The Battery
1. Product Name
2. Appearance And Dimensions
Before turning on the meter and using the lights, please turn on the switch button
on the left handlebar to activate the battery. "ON" means open, and "OFF" means
shut down.
Intelligent LCD display for e-bike.
Intelligent LCD display for e-bike.
12
METER OPERATION
3. Meter Function
Button Denitions
Function Overview
Functional Area Layout
3.1
3.2
3.3
There are three buttons on the operating unit of display, the light button , plus
button and minus button .
Speed unit -- Metric system: km, km/h; lmperial system: mile, mph
Speed Indicator — Speed unit Metric system: km/h; Imperial system: MPH
ODO/Trip distance indicator
Riding mode — Including eco speed, med speed and High speed (Pure Electric)
Battery level indicator
Display provides a variety of functions to meet the riding needs of users, including:
Battery level indicator
Headlight indicator
Speed indicator (including eco speed, med speed and High speed (Pure Electric))
Mileage indicator (including total mileage(ODO) and trip distance (Trip))
Parameter setting function
●
●
●
●
●
1
2
1
2
3
4
5
3
4
5
13
METER OPERATION
4. General Operation
Power On/O
Display Interface
Assist Level Selection
Cruise mode:
Eco Speed Middle Speed High Speed
4.1
4.2
4.3
By switching the button "ON", the display will start to work and the working power
supply of the controller will be turned on; switching it to "OFF", your e-bike will be
powered o.
After the display is turned on, the display will show the real-time speed (mph) and the
mileage (mile) by default.
By pressing the button , the e-bike assist level will be switched to change the
motor output power. There are 3 assist levels(pure electric mode (throttle mode)) --
ECO, MID, HIGH.
When twisting and holding the throttle for 8 seconds, the "ECO/MID/HIGH" indicator
ashes and it will enter the cruise state, then release the speed accelerator at this
time, the electric bicycle will keep the current speed and continue to drive. After
braking or twisting the throttle again, you can cancel the cruise state. Please pay
attention to the road conditions and use cruiser mode carefully.
14
METER OPERATION
Battery level indicator
Error code indicator
4.4
4.5
The battery level indicator consists of four segments. When the battery is fully charged,
the four segments will be all on. In case of undervoltage, the last segment of the battery
indicator light will ash, which means the battery has to be charged immediately.
When a fault occurs in the electronic control system of your e-bike, the display will
automatically indicate the error code: E001; then press the button to display the
corresponding error code in the mileage area in the format of E0*
Full battery level
indication
Fig.4-2 Battery level Switching Interface
Undervoltage
ashing
Error codes
Error codes Error codes
Communication Reception Abnormality
Denition Denition
Meter Communication Transmission
Abnormality
Throttle Abnormality
Controller Abnormality
Brake Abnormality
Motor Hall Eect Sensor Abnormality
Motor Phase Loss
Assist Sensor Abnormality
Battery Undervoltage
E001 E006
E002 E007
E003
E004
E005
E008
E009
15
Metric/imperial system setting5.1
All parameters can only be set when your e-bike stops. The steps for custom setting
are as follows:
Keep in the power-on state, and the display indicates the speed of 0.
1. Press and hold the buttons and at the same time for more than 3
seconds to enter the selection interface of custom setting options. The display will
indicate the code “P02”.
2. P02 refers to the metric/imperial system setting option. Press the button /
* to select the metric/imperial, then press the button and at the
same time for more than 3 secands to set and return to the general interface.
METER OPERATION
5. Custom Setting
Metric system indicator interface
Fig. 5-1 Metric/imperial System Setting Interface
Imperial system indicator interface
16
METER OPERATION
Odometer reset5.2
6. CAUTIONS
Please use safely, and do not plug or unplug the display when it is powered on.
Please avoid bumping as far as possible.
Please do not alter the background parameter settings of the display at will,
otherwise normal riding cannot be guaranteed.
If the display fails to work normally, it should be repaired as soon as possible.
Due to product upgrades of the company, part of the displayed contents or
functions of the product you bought may be different from the manual, depending
on the actual model.
●
●
●
●
1. Press and hold the buttons and at the same time for more than 3
seconds to enter the selection interface of custom setting options, then press
for one time. The display will indicate the code "P26".
2. P26 refers to the odometer reset. Press / for more than 3 seconds to
empty the mileage. Then press the button and at the same time for
more than 3 secands to return to the general interface.
17
BATTERY AND CHARGING
Charging: Safe Operation Guide
When Charging The Battery
Safty Information
Please follow the instructions for use, otherwise the consequences are at his own
risk. Please use the original special charger. It is strictly prohibited to use other
chargers.
Pay attention to the battery type and applicable voltage that the charger can
charge, and it is strictly forbidden to mix them. The charging current shall not
exceed 5A.
Insert the charger probe into the charger
port on the e-bike battery. As shown in the
figure.
Insert the pronged end of the battery cord
into the battery charger.
Insert the AC plug into an AC outlet.
The red indicator light turns on and will
remain red until it is fully charged. The
indicator light turns green once the battery
is fully charged.
●
●
●
●
●
●
Keep the battery dry, do not put the battery in acidic, alkaline liquid or
combustibles, keep away from rain, fire and high temperature environment.
It is strictly forbidden to connect the positive and negative poles of the battery
reversely, and it is strictly forbidden to damage,disassemble or short-circuit
the battery. Contact between the battery contacts and metal objects such
as paper clips, coins, keys, nails, screws or other metal items could result in
shorting out the battery and cause electrical fires, explosion, or severe burns.
Failure to observe the following warnings could result in electrical res, explosion,
severe burns or electrocution.
●
●
18
BATTERY AND CHARGING
Used batteries are hazardous chemicals, and the used batteries should not be
disassembled without authorization, and recycled by relevant professional
departments.
It is forbidden to modify the battery, electronic control system and the frame
structure of the bike, etc. Otherwise, it may cause safety hazards and void the
warranty service. If you continue to do so, all will be at your own peril.
Use the original battery.
Do not replace it with other brand's or product's battery.
The battery and battery charger contain hazardous materials. Always keep the
battery and battery charger away from children, animals, or persons incapable
of understanding the potential hazards.
A damaged battery or battery charger (e.g. cable, plug or housing) may result
in leakage of hazardous materials or be a potential source of sparking and fire.
Always examine the battery and battery charger before each use. Never charge
a damaged battery or use a damaged battery charger.
Please use the original special charger. It is strictly prohibited to use other
chargers. Charging the battery with an incompatible battery charger may result
in electrical fires, explosion, severe burns or electrocution. Ensure the battery
charger and the A/C outlet are the same voltage before charging the battery.
Never use the battery charger to charge any other batteries.
Pay attention to the battery type and applicable voltage that the charger can
charge, and it is strictly forbidden to mix them.
The charging time shall not exceed 12 hours, and the charging current shall not
exceed 1.5A.
Charging at 0
°
°
C/-4
°
F~113
F. Please do not store the battery in temperatures above 35
°
C~40° C/ 32
°
F~104
°
F, and discharging at -20
°
°
C
C
~
/
4
9
5
5
°
F or below
-5
°
C/ 23
°
F.
disassemble, or modify the battery or charger.
Improper handling of the battery and battery charger may result in electrical
fires, explosion, severe burns or electrocution.
Do not move the battery or battery charger during charging.
Do not hold the battery charger during a thunder or lighting storm.
Do not plug or unplug the battery charger with wet hands.
●
●
●
●
●
●
●
●
●
●
●
The battery and battery charger contain no serviceable parts. Do not open,
●
●
●
●
19
BATTERY AND CHARGING
Do not place any items on the battery charger.
When charging, it should be placed in a ventilated environment, and it is
strictly forbidden to charge in a confined space, residential building or in a hot
environment.
The charger should not be carried with the ebike as much as possible. If it is
really necessary to carry it, it should be placed in the toolbox after the shock
absorption treatment is done. It is not allowed to disassemble or replace the
components in the charger by yourself.
It is recommended to charge the battery in the fireproof battery charging
cover when charging. And the battery should be stored in the fireproof battery
charging cover when not in use.
When not in use for a long time, keep the battery in a cool and dry place, and
charge the battery for two hours a month.
●
●
●
●
●
Charge a new battery 4 hours before you use it in your product for the first time.
If the battery is dropped or damaged due to a bicycle accident, there may be a
danger of electrolyte leakage. Please stop using it immediately.
It is better not to wait until the power is completely exhausted before charging,
which can more effectively extend the battery life. Besides, Overheating or
undercharging the battery may shorten battery life.
How far can a fully charged battery go?
It depends on the load weight, road conditions and battery capacity. But under
the same conditions, the average speed can last longer riding distances. Using
pedal assist mode allows you to go further.
Reminder
It is recommended to charge the battery in the fireproof battery charging
cover when charging. And the battery should be stored in the fireproof
battery charging cover when not in use.
20
Battery Disposal
BATTERY AND CHARGING
Battery must be recycled or disposed of in an environmentally sound manner.
Do not dispose of the battery in a fire. The battery may explode or leak.
Do not dispose of a battery in your regular household trash.
●
●
●
21
MAINTENANCE
The front and rear wheels of the vehicle should be located in the center of the front
fork or frame.
After riding, please store the bike in a place without sunlight and rain.
Water showering is forbidden, and the surface of the car body can be wiped with a
semi-dry cloth.
Do not touch the charging hole on the bicycle, or touch it with metal, otherwise, it
may cause an accident due to an instantaneous short circuit of the current.
Check all cables and cable housings for fraying, breaks, rust, or corrosion and
replace if necessary.
Check the motor and brake frequently, and do not ll the brake area with oil.
Additionally, check the brake pads for any damage as they will be worn over time
and eventually need replacement.
Regularly check the various screws of the car and the places that need to be
fastened, and regularly reinforce to prevent injury and unnecessary wear and tear
on your e-bike.
Recommended torque (unit: kgf.cm): the horizontal screw 60-80, the stem screw
175- 200, the seat cushion screw 175-250, the wheel screw 320-450.
Regularly check the tension of the chain, which can be adjusted by the chain
regulator.
Always check the tire for scratches, cracks, or excessive wear. The inner tube and
the valve should be perpendicular to the wheel hub and not crooked. Accidentally
punctured, damaged or excessively worn inner and outer tires need to be replaced
immediately, please seek professional technicians to repair or replace your tires.
It is forbidden to modify key structural parts such as the frame, front fork, standpipe,
and electrical function parts. If damaged, use the original parts to replace it.
Otherwise, the guarantee service will not be provided. Any loss or damage caused
by the modication shall be solely responsible.
●
●
●
●
●
●
●
●
●
●
●
22
Your electric bike includes a One Year Limited Hardware Warranty. ANCHEER provides
warranty service for the electric bikes. If there is a hardware defect and a valid claim
is received during the warranty period, we will resend new parts within the scope
permitted by law.
The Warranty covers product defects in materials and workmanship under normal
use. This Warranty is limited to original purchasers and is not assignable or
transferable.
The Warranty starts on the date of your purchase and lasts for one year (the "Warranty
Period") and the Warranty Period is not extended if the product is repaired or
replaced.
The Warranty does not cover any damage due to: improper use; failure to follow the
product instructions or to perform any preventive maintenance; unauthorized repair;
external causes such as accidents, abuse, or other actions or events beyond our
reasonable control.
We provide lifetime customer support services. For any questions about the product,
please contact customer service from where you brought the equipment. We will be
happy to answer your questions.
You can also email us your inquiries at support@iancheer.com.
Accessories Warranty Period
Service Content
Quality Problem
A year
A year
A year
A year
A year
Motor
Controller
Charger
Lithium
Battery
Accelerator
Free delivery of parts
Free delivery of parts
Free delivery of parts
Free delivery of parts
Free delivery of parts
Motor will not be able to use
Natural conditions (such as
impact force cannot be used
except damage)
Failure occurs under normal
use
Failure occurs under normal
use
Can't charge discharge
under normal use
WARRANTY
One-Year Limited Hardware Warranty
Support Services
23
ATTACHMENT
Performance index
Project
Material
Released Size
Wheel size
Package size
Color
Weight
Max load
Uphill
Working Temperature
W
aterproof
Battery
Power
Rated voltage
Charging voltage
Input voltage
B
MS
Charging time
Lights
Cruise
Brake
Parameter
Iron
1315*530*1065 mm
14 inches
1300*225*675 mm
Black/ White
22KG
264.55lbs/120kg
15 degree
-
�℉~���℉/-��℃~��℃
48V
54.6V
AC100~240V
Yes
4-5 H
Front & Rear Lights
Yes
IPＸ4
7.8Ah
500W(max)
Front & Rear Disc Brake
SIZE
PERFORMANCE
FEATURES
STANDARDS
24
ATTACHMENT
Remarks:
The amount of battery remaining, load of the bike(weight of rider and cargo), tire
pressure, road environment, chain and wheel axle lubrication, etc. will aect the
maximum speed;
Riding habits, temperature, load, tire pressure, road environment and other
factors will aect the riding range.
●
●
25
Operation General
Personal Restrictions
Only use the e-bike and the drive assist system for safe, recreational riding. Use of the
e-bike for a purpose it was not intended for is dangerous and could result in property
damage, serious injury or death. Always follow the instructions for intended use and
limitations.
Use of this e-bike by persons (including children) with reduced physical, sensory or
mental capabilities or persons lacking experience and knowledge in the use of the
e-bike could result in serious injury or death. The owner of this e-bike must ensure
this product is not used by people with the conditions described above. Always
follow the rules, regulations and laws (including age limits) related to the use of an
e-bike in its area of use.
A child may not realize or understand the e-bike has moving parts and components
(e.g. battery). Never allow children to play or come into contact with the e-bike
or its parts. Always follow all rules, regulations and laws regarding age limits and
operation in the e-bike area of use.
Riding the e-bike through water could result in loss of control and damage to the
drive assist system. Do not ride into, or attempt to ride through, water or sub-merge
any part of the e-bike.
Riding with the kickstand in the down position may result in unexpected contact
with the ground or other objects causing loss of control. Always ensure the
kickstand is in the up position and securely locked in place before riding the e-bike.
Sitting on the e-bike with the kickstand down may result in the e-bike tipping over.
Never sit on the e-bike when it is only supported and stabilized by the kickstand.
The kickstand is not designed to support the weight of a person.
Overloading a rear basket could create dangerous riding conditions. Always
observe the maximum weight limit. Never overload the rear basket.
An improperly secured load on a rear rack could create dangerous riding conditions.
Always ensure the load on the rear rack is properly secured before riding.
●
●
●
●
●
●
●
●
26
Never move the shifter while pedaling backward, nor pedal backwards immediately
after having moved the shifter. This could jam the chain and cause serious damage
to the bicycle.
Like any mechanical device, a bicycle and its components are subject to wear and
stress. Dierent materials and mechanisms wear or fatigue from stress at dierent
rates and have dierent life cycles. If a component’s life cycle is exceeded, the
component can suddenly and catastrophically fail, causing serious injury or death
to the rider.
Scratches, cracks, fraying and discoloration are signs of stress caused fatigue and
indicate that a part is at the end of its useful life and needs to be replaced. Product
life is often related to the kind of riding you do and to the treatment to which you
submit the bicycle. The bicycle's warranty is not meant to suggest that the bicycle
cannot be broken or will last forever. It only means that the bicycle is covered
subject to the terms of the warranty.
Frequent inspection of your bike is important to your safety. Periodic, more detailed
inspection of your bicycle is important. How often this more detailed inspection
is needed depends upon you. You, the rider/owner, have control and knowledge
of how often you use your bike, how hard you use it and where you use it. The
materials used to make your bike determine how and how frequently to inspect.
Ignoring this WARNING can lead to frame, fork or other component failure, which
can result in serious injury or death.
●
●
●
●
●
●
Operation Details:
Correct tightening force on fasteners- nuts, bolts, screws- on your bicycle is
important. Too little force, and the fastener may not hold securely. Too much force,
and the fastener can strip threads, stretch, deform or break. Either way, incorrect
tightening force can result in component failure, which can cause you to loose
control and fall.
Loose or damaged handlebar grips or extensions can cause you to lose control and
fall. Unplugged handlebars or extensions can cut you and cause serious injury in an
otherwise minor accident.
27
●
●
●
●
●
The area in which you ride may require specific safety devices. It is your
responsibility to familiarize yourself with the laws of the area where you ride and
to comply with all applicable laws, including properly equipping yourself and your
bike as the law requires. Observe all local bicycle laws and regulations. Observe
regulations about bicycle lighting, licensing of bicycles, riding on sidewalks, laws
regulating bike path and trail use, helmet laws, child carrier laws, special bicycle
trac laws. It’s your responsibility to know and obey the laws. Failure to wear a
helmet when riding may result in serious injury or even death.
Do not remove the front or rear reectors or reector brackets from your bicycle.
They are an integral part of the bicycle’s safety system. Removing the reectors
reduces your visibility to others using the roadway.Being struck by other vehicles
may result in serious injury or death.The reector brackets may protect you from
a brake straddle cable catching on the tire in the event of brake cable failure. If a
brake straddle cable catches on the tire, it can cause the wheel to stop suddenly,
causing you to lose control and fall.
Although many catalogs, advertisements and articles about bicycling depict riders
engaged in extreme riding, this activity is extremely dangerous, increases your
risk of injury or death, and increases the severity of any injury. Remember that the
action depicted is being performed by professionals with many years of training
and experience. Know your limits and always wear a helmet and other appropriate
safety gear. Even with state- of the-art protective safety gear, you could be seriously
injured or killed when jumping, stunt riding, riding downhill at speed or in
competition.Bicycles and bicycle parts have limitations with regard to strength and
integrity, and this type of riding can exceed those limitations or dramatically reduce
the length of their safe use.
Failure to confirm compatibility, properly install, operate and maintain any
component or accessory can result in serious injury or death.Exposed springs on the
saddle of any bicycle tted with a child seat can cause serious injury to the child.
Changing the components on your bike with other than genuine replacement parts
may compromise the safety of your bicycle and may void the warranty. Contact
customer service before changing the components on your bike.
If your seat post is not inserted in the seat tube, the seat post, binder or even frame
may break, which could cause you to lose control and fall.
28
●
●
●
●
●
●
●
When making saddle angle adjustments with a single bolt saddle clamp, always
check to make sure that the serrations on the mating surfaces of the clamp are not
worn. Worn serrations on the clamp can allow the saddle to move, causing you to
lose control and fall. Always tighten fasteners to the correct torque. Bolts that are
too tight can stretch and deform. Bolts that are too loose can move and fatigue.
Either mistake can lead to a sudden failure of the bolt, causing you to lose control
and fall.
An insufficiently tightened stem clamp bolt, handlebar clamp bolt or bar end
extension clamping bolt may compromise steering action, which could cause you
to lose control and fall. Place the front wheel of the bicycle between your legs and
attempt to twist the handlebar/stem assembly. If you can twist the stem in relation
to the front wheel, turn the handlebars in relation to the stem, or turn the bar end
extensions in relation to the handlebar, the bolts are insufficiently tightened.Be
aware that adding aerodynamic extensions to handlebars will change the steering
and braking response of the bicycle.
Bolt or bar end extension clamping bolt may compromise steering action, which
could cause you to lose control and fall. Place the front wheel of the bicycle between
your legs and attempt to twist the handlebar/stem assembly. If you can twist the
stem in relation to the front wheel, turn the handlebars in relation to the stem, or
turn the bar end extensions in relation to the handlebar, the bolts are insuciently
tightened.Be aware that adding aerodynamic extensions to handlebars will change
the steering and braking response of the bicycle.
WARNING! The shorter the brake lever reach, the more critical it is to have correctly
adjusted brakes, so that full braking power can be applied within available brake
lever travel. Brake lever travel insucient to apply full braking power can result in
loss of control, which may result in serious injury or death.
All quick-release levers should be inspected before every ride to be sure they are
fully closed and secure. Failure to properly close a quick-release lever can cause loss
of control of the bicycle resulting in injury or death.Make sure the wheel is properly
seated and the quick-release lever is properly closed.
Disregarding or misunderstanding of the following safety warnings, the safety
warnings in the manuals associated with the e-bike parts, and safety labels on the
e-bike could result in serious injury or death.
WARNING! The shorter the brake lever reach, the more critical it is to have correctly
adjusted brakes, so that full braking power can be applied within available brake
lever travel. Brake lever travel insucient to apply full braking power can result in
loss of control, which may result in serious injury or death.
29
●
●
All quick-release levers should be inspected before every ride to be sure they are
fully closed and secure. Failure to properly close a quick-release lever can cause loss
of control of the bicycle resulting in injury or death.Make sure the wheel is properly
seated and the quick-release lever is properly closed.
Disregarding or misunderstanding of the following safety warnings, the safety
warnings in the manuals associated with the e-bike parts, and safety labels on the
e-bike could result in serious injury or death.
Anyone assembling, using, maintaining, transporting or storing this e-bike must
read, understand, and follow these safety warnings before performing any of the
actions stated.
SAVE THESE INSTRUCTIONS.
Input: DC 48V, 1.5A
Max Speed: 20 mph (32km/h)
Power: 500W(max)
Tel: +1 626 688 9296
Monday-Friday
9:00-12:00 AM PST
14:00-18:00 PM PST
support@iancheer.com
ANCHEER Customer Service
Customer Service
Shenzhen DYU Intelligent Mobility Technology Co.,Ltd
Made in China
Model: AMA005931
E Bike
