Product Instructions
Product No. 2000361
SMALL SPOT
CLEANER
2 3
Need further help?
suppor[email protected]
See our full range at
www.vonhaus.com
Let’s get started!
Visit our product hub for
useful tips and tricks on
getting the most out of
your new product.
SCAN ME
Product Overview
A. Clean Water Tank
B. Main Frame
C. Hook For Brush
D. Brush
E. Water-Spray Button
F. Handle
G. Dirty Water Tank
H. Hose
I. On/Off Switch
A
B
C
D
E
F
G
H
Brush Big Brush Self-Cleaning
Hose Nozzle
Hook for Brush Screw
I
4 5
Assembly
• Remove all accessories from the clean and
dirty water tanks
• Insert the hook for the brush on to the back
of the product. Secure in place with the
screw provided.
Assembly
• Ensure the hose is securely attached to the
main unit.
• Insert your desired brush head into the end
of the hose. It will click in to place once it
has been secured in place.
• Wrap the hose around the bottom of the
unit and secure in place with the hook for
the brush.
1. Remove the clean water tank from the unit
and remove the lid.
2. Fill the tank up with warm water but do not
exceed the maximum fill line.
3. For stubborn stains, you can mix water
with spot cleaning detergent directly in the
water tank. Follow the detergent guidelines
and ensure the maximum fill line is not
exceeded.
4. Do not use carpet shampoo as this foams
and it not suitable for this type of product.
5. Secure the lid back in to place and insert
the clean water tank back in to the unit .
Plug the power cord in to the mains and press
the On/Off switch to turn on.
1
2
3
4
6 7
Operation Operation
Add spot cleaning detergent on to
the spillage and let it sit, following
the detergent guidelines.
Press the water release button, on
the hose, to spray water on to the
surface.
Move the brush head backwards and
forwards to help to remove the stain
from the surface.
Stop pressing the water release button and tilt
the brush head forward so the brushes aren’t
in contact with the surface.
Pull the brush head backwards towards
yourself and ensure the suction inlet is
collecting the dirty water.
Once you have finished
cleaning, turn the product off
using the On/Off switch and
unplug the power cord.
Over or under tilting
the brush tool may
result in poor water
suction
2
1
4
3
Suction
Inlet
8 9
Cleaning & Maintenance
To clean the brush head, remove it from the hose and rinse with warm soapy water. The
transparent cover on the brush head can be removed for deeper cleaning.
To clean the hose, remove the brush head and affix the self-cleaning hose nozzle to the
end of the hose.
Press the water release button and this will help to clean the hose.
1
2
Cleaning & Maintenance
Remove the clean water tank from the unit and empty the water. Ensure the water tank
is clean and dry before placing back in to the unit.
Remove the dirty water tank from the unit and empty the water after every use, or when
the water reaches the maximum fill line.
Rinse with warm soapy water and ensure the water tank is dry before placing back in
to the unit.
4
3
10 11
Remove the small foam filter which is located underneath the dirty water tank.
Rinse with warm water and ensure it is fully dry before replacing it back in to the unit.
Ensure all parts are cleaned and dry after every use
Wipe down the main unit with a damp cloth before storing away
6
5
Cleaning & Maintenance
Why won’t my machine start?
Possible reasons:
• The plug may not be properly connected.
• The power cord may be damaged.
What to do:
• Switch off the machine and check the plug
is secure.
• If the power cord is damaged contact
the customer services team on support@
vonhaus.com
Why is there no water after
pressing the water-spray
button?
Possible reasons:
• The spray nozzle may be blocked.
• The handle or pump may be damaged.
What to do:
• Remove the brush and clean the spray
nozzle.
• if the problem persists, contact support@
vonhaus.com
Why is there no suction?
Possible reasons:
• The dirty water tank may be full
• The hose might not be properly connected
• The suction inlet on the brush head is
blocked
• The foam filter is blocked
What to do:
• Empty and clean the dirty water tank
• Check the hose is properly connected and
use the self-clean nozzle to check for any
blockages
• Clean the brush head in warm water and
gently scrub to ensure the suction inlet isn’t
blocked
• Clean or replace the foam filter located
under the dirty water tank
Troubleshooting
12 13
Safety Information
Important Safety Notice
This product is not suitable for use by children
or by individuals with physical, sensory, or
mental impairments that may limit their ability
to operate the equipment safely, unless they
have been given supervision or instruction
concerning the safe use of the product by a
person responsible for their safety.
Caution
Only use the machine for its intended cleaning
purpose.
This appliance is for household use only.
Keep away from open flames and heat
sources.
Stop using the machine if the spray nozzle or
suction hole becomes blocked, or if foreign
objects are sucked in.
Always empty and clean the tanks and remove
blockages before reusing.
Do not tilt, ride, or place excessive weight on
the machine.
Keep out of reach of children; do not use where
children can touch the unit.
Not for outdoor use.
Discontinue use if the machine makes unusual
noises or emits an unusual smell.
Power Cord and Plug Safety
Clean the plug regularly.
Ensure the plug is firmly connected when in
use.
Unplug the appliance when not in use for
prolonged periods, before maintenance,
checking, or moving.
Never plug in or unplug the machine with wet
hands.
Keep the plug away from children.
Do not damage the power cord or remove the
plug forcefully.
Do not use if the power cord or plug is
damaged.
Avoid using overloaded sockets.
If the appliance malfunctions, switch it off and
unplug it immediately.
Don’t Use the Machine For:
• Dry dust
• Large amounts of powder, sand, stones, or
rubbish
• Metal objects such as needles and pins
• Large plastic bags or stockings
• Items likely to clog the machine
Additional Precautions
This is a wet-use machine; do not use it for
large amounts of dry dust.
In extremely cold conditions, dry the clean
water tank, dirty water tank, and hose after
each use to prevent freezing.
Remove foreign objects from the hose before
reusing if blocked.
Use only water below 40°C.
Do not use the machine on items or surfaces
unsuitable for wet cleaning (e.g., delicate
crafts, certain fibres, sensitive surfaces).
Do not tilt the appliance if the tank contains
water to prevent spills.
Stop and empty the dirty water tank when it
reaches the full line.
Use only recommended detergents and check
they are suitable for your items.
Do not use foam detergents.
Do not use with flammable liquids, hot air, oils,
or combustible materials.
Do not use if the hose is damaged or excessively
bent.
Do not block the air outlet.
Never attempt to disassemble or repair the
Safety Information
appliance yourself.
This product can be used to clean cars or
other domestic vehicles. Use only during
dry weather. Do not allow the product to be
exposed to rain, snow or high winds.
Never immerse the appliance in water or other
liquids.
Do not use to pick up hazardous or infectious
materials.
The dirty water tank must be in place for
operation.
If the supply cord is damaged, it must be
replaced by the manufacturer, their service
agent, or a qualified person.
Important
• Avoid allowing children/ animals in
proximity during use
• Check that any cleaning chemicals used
in combination with the product is suitable
for your home; check if pet friendly/ for
allergens and is suitable to use with the
machine
Note:
This appliance is not a toy and should not be
used by children. Individuals with reduced
physical, sensory or mental abilities should use
it only with support and supervision.
The unit is suitable for use on 50Hz or 60Hz
mains frequency; no adjustment is required.
Disposal Information
This symbol indicates that this product should not
be disposed of with regular household waste.
To help protect the environment and human
health from uncontrolled waste disposal,
please recycle this product responsibly.
14 15
Customer Service
If you are having difficulty using this product
and require support, please contact
suppor[email protected]
Warranty
To register your product and find out if you
qualify for a free extended warranty please
go to www.vonhaus.com/warranty
Please retain a proof of purchase receipt or
statement as proof of the purchase date.
The warranty only applies if the product is used
solely in the manner indicated in the warnings
page of this manual, and all other instructions
have been followed accurately.
Any abuse of the product or the manner in
which it is used will invalidate the warranty.
Returns
Returned goods will not be accepted unless
re-packaged in its original packaging and
accompanied by a relevant and completed
returns form. This does not affect your statutory
rights.
No rights are given under this warranty to a
person acquiring the appliance second-hand
or for commercial or communal use.
