USER GUIDE
4.5 Cu. Ft. Compact
Refrigerator
NS-CF43TMSS6/NS-CF43TMSS6-C
www.insigniaproducts.com
2
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Main components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setting up your refrigerator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Before using your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Finding a suitable location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Providing proper ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Leveling your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Providing a proper power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting the thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Reversing the doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Before you begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Removing the doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Reinstalling the doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Maintaining your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Cleaning your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Defrosting your refrigerator and freezer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Changing the interior light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Shutting down your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Moving your refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Tips on saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
ONE-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Introduction
Congratulations on your purchase of a high-quality Insignia product. Your
NS-CF43TMSS6 or NS-CF43TMSS6-C represents the state of the art in compact
refrigerator design and is designed for reliable and trouble-free performance.
3
4.5 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
Important Safety Instructions
Read all instructions before use.
Keep these instructions.
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards.Obey all safety messages that follow this
symbol to avoid possible injury or death.
This symbol indicates: Flammables/Pyrophoric/Self-Heating/
Emits Flammable Gas/Self-Reactives.
DANGER: Risk of fire or explosion
• Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
• To be repaired only by trained service personnel. Use only
manufacturer-authorized service parts. Do not puncture refrigerant tubing.
• Do not store or use gasoline or any flammable liquids inside or in the vicinity
of this refrigerator.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent, or a similarly qualified person in
order to avoid a hazard.
WARNING: Risk of fire/flammable materials
• Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
• Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
• Dispose of the refrigerator according to local regulators because it uses
flammable blowing gas and refrigerant.
• When positioning the appliance, ensure the supply cord is not trapped or
damaged.
• Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
• Do not use extension cords or ungrounded (two prong) adapters.
4
NS-CF43TMSS6/NS-CF43TMSS6-C
www.insigniaproducts.com
WARNING: Risk of child entrapment
Before you throw away your old refrigerator or freezer:
• Take off the doors
• Leave the shelves in place so that children may not easily climb inside.
WARNING
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance. Cleaning and
maintenance should not be performed by children without supervision.
WARNING
This appliance is intended to be used in household and similar applications such
as:
• staff kitchen areas in shops, offices and other working environments.
• farm houses and by clients in hotels, motels and other residential type
environments
• bed and breakfast type environments
• catering and similar non-retail applications
WARNING
• Turn off the appliance before unplugging it.
• Unplug your refrigerator before carrying out user maintenance on it.
• If a component part is damaged, we recommend it be replaced by the
manufacturer, its service agent, or similar qualified persons in order to avoid a
hazard.
WARNING: Grounding requirement
• This appliance must be grounded. This appliance is equipped with a cord
having a grounding wire with a grounding plug. The plug must be inserted
into an outlet that is properly installed and grounded.
• Improper use of the grounding plug can result in a risk of electric shock.
Consult a qualified electrician or service person if the grounding instructions
are not completely understood, or if doubt exists as to whether the appliance
is properly grounded.
5
4.5 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
Features
• 3.3 cu. ft. (.09 cu. m) refrigerator size holds your meals, drinks and more
• 1.18 cu. ft. (.03 cu. m) top freezer with shelf and door rack houses your frozen meals
and leftovers
• Three tempered glass refrigerator shelves (two adjustable) safely hold your foods
• Six refrigerator door racks hold additional items such as soda cans and a 2-liter bottle
(bottom rack only)
• Bottom drawer keeps vegetables or other foods separate and organized
• Reversible door hinge adjusts to fit your space
• Recessed handle takes up no additional space
• Mechanical dial makes it easy to adjust to your chosen temperature
Package contents
• 4.5 cu. ft. compact refrigerator
• User Guide
Main components
Glass shelves
Crisper
Leveling foot
Freezer door rack
Refrigerator door
Freezer shelf
Thermostat/controls
Bottle rack
Can racks
Door racks
6
NS-CF43TMSS6/NS-CF43TMSS6-C
www.insigniaproducts.com
Dimensions
Setting up your refrigerator
Before using your refrigerator
• Remove the exterior and interior packing.
• Let your refrigerator stand upright for approximately four hours before connecting
it to power. This reduces the possibility of a malfunction in the cooling system from
improper handling during transportation.
• Clean the interior surface with lukewarm water using a soft cloth.
Finding a suitable location
• This refrigerator is designed to be free standing only, and should not be recessed or
built-in.
• Place your refrigerator on a floor that is strong enough to support your refrigerator
when it is fully loaded.
• Allow 2 in. (5 cm) of space between the top, back, and sides of your refrigerator and
any surrounding walls. This allows the proper air ventilation. Adjust the feet to keep
your refrigerator level.
18 3/4 in. (47.4 cm)
36 in. (91.4 cm)
44 7/16 in. (112.7 cm)
19 1/8 in. (48.6 cm)
7
4.5 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
• Locate your refrigerator away from direct sunlight and sources of heat (stove,
heater, radiator, and so on). Direct sunlight may affect the acrylic coating and heat
sources may increase electrical consumption. Ambient temperature below
50° F (10° C) or above 110° F (43.3° C) will hinder the performance of this
refrigerator. This refrigerator can be placed in a temperature controlled garage, as
long as the ambient temperature in the garage is not below 50° F (10° C) or above
110° F (43.3° C) .
• Avoid locating your refrigerator in moist areas.
• This refrigerator can be placed on carpet, but care should be taken not to damage
the carpet when moving your refrigerator.
Providing proper ventilation
Place your refrigerator at least 2 in. (5 cm) from top, back, and side walls to ensure proper
airflow to the compressor. Do not place your refrigerator near any heat sources, such as a
heater or stove, as this may put a strain on the compressor.
2 in. (5 cm)
2 in. (5 cm)
2 in. (5 cm)
2 in. (5 cm)
8
NS-CF43TMSS6/NS-CF43TMSS6-C
www.insigniaproducts.com
Leveling your refrigerator
• It is very important for your refrigerator to be level in order to function properly. If
your refrigerator is not leveled during installation, the doors may not close or seal
properly, causing cooling, frost, or moisture problems.
• To level your refrigerator, you may either turn the leveling foot clockwise to raise
that side of your refrigerator or turn it counter-clockwise to lower that side.
Providing a proper power supply
Check your local power source. This refrigerator requires a 110V-120V, 60Hz power
supply.
Use a receptacle that accepts the grounding prong. The power cord is equipped with a
3-prong (grounding) plug which goes into a standard 3-prong (grounding) wall outlet to
minimize the possibility of electric shock.
Setting the thermostat
Note: Having someone push against the top of your refrigerator helps to take some
weight off the leveling foot, making it easier to adjust.
Notes:
• Your refrigerator should always be plugged into its own individual electrical outlet
which has a voltage rating that matches the rating plate.
• Never unplug your refrigerator by pulling on the power cord. Always grip the plug
firmly and pull straight out from the outlet.
3-prong receptacle
Receptacle box cover
3-prong plug
Grounding lead
Grounding adapter Receptacle box cover
Screw
Receptacle
Using a 3-prong plug and outlet Using a grounding adapter
9
4.5 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
1 The first time you turn your refrigerator on, adjust the thermostat to Max and run for
at least two hours before putting food in.
2 After it is fully cooled, the Med setting should be appropriate for home or office
refrigerator use.
Reversing the doors
Your refrigerator is built with reversible doors. Based on the location where you plan to
use your compact refrigerator, you may find it more convenient to reverse the position of
the doors, to have them open from right to left instead of left to right.
Before you begin
• Make sure that your refrigerator is unplugged and empty.
• Have someone available to assist you in the process.
• Keep all of the parts you remove to reuse them later.
• Removing the door requires that your refrigerator be tilted backwards. Rest your
refrigerator on something solid, such as a chair, just below the top panel.
• Do not lay your refrigerator completely flat so that you do not damage the coolant
system.
Notes:
• Turning the thermostat to the OFF position stops the cooling cycle but does not
shut off the power to your refrigerator.
• If your refrigerator is unplugged or loses power, you must wait three to five minutes
before restarting it. If you attempt to restart before this time delay, your refrigerator
will not start.
• Large amounts of food will lower the cooling efficiency of your refrigerator.
• If you choose to change the thermostat setting, adjust it by one increment at a time.
Allow several hours for the temperature to stabilize between adjustments.
CAUTION
To avoid injury to yourself or your property, we recommend that someone assist
you during the door reversal process.
Adjustable wrench
Flathead screwdriver
Phillips screwdriver
You will need:
8mm socket wrench
or
10
NS-CF43TMSS6/NS-CF43TMSS6-C
www.insigniaproducts.com
Removing the doors
1 Using a flathead screwdriver, remove the top hinge cover and set it aside.
2 Using a Phillips screwdriver, remove the screws holding the top hinge to your
refrigerator, then remove the hinge and set it aside.
3 Using a flathead screwdriver, remove the hole cover from the top left side of your
refrigerator.
11
4.5 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
4 Move the core cover from the top left side of the freezer door to the top right side of
the freezer door.
5 Lift the freezer door from the cabinet and set it on a padded surface to prevent
scratches.
6 Using a Phillips screwdriver, remove the screws holding the middle hinge on your
refrigerator, then remove the hinge.
7 Lift the refrigerator door from your refrigerator and set it on a padded surface to
prevent scratches.
8 Move the hinge hole covers from the left side of your refrigerator to the right side.
9 Lay your refrigerator down on a soft pad (to prevent scratching).
12
NS-CF43TMSS6/NS-CF43TMSS6-C
www.insigniaproducts.com
10 Using a Phillips screwdriver, remove the screws holding the bottom hinge on the
bottom right side of your refrigerator, unscrew both adjustable feet, then remove
adjustable feet and the hinge.
11 Using an adjustable wrench, unscrew the hinge pin from the hinge, turn the hinge
over and replace the hinge pin on the other side.
You may need extra leverage to remove the hinge pin. We advise holding the wrench
with two hands, bracing the hinge on the floor, then turning it clockwise with the
wrench.
12 The hinge pin may be difficult to remove, as it may move with the wrench while you
are trying to unscrew the retaining nut. If this is the case, you can use the wrench to
immobilize the nut, holding the wrench and hinge together in the left hand, then use
a flathead screwdriver in the right hand to unscrew the pin.
13
4.5 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
Reinstalling the doors
1 Using a Phillips screwdriver, mount the hinge on the bottom left side of your
refrigerator, then replace the adjustable feet.
2 Stand your refrigerator up, then align the hole in the bottom left of the refrigerator
door with the bottom hinge pin and install the door on the hinge pin.
3 Move the hinge hole cover from the top left side of the refrigerator door to the top
right side.
4 Install the middle hinge on the left side of your refrigerator with the screws you
previously removed. Do not fully tighten the screws.
5 Check the fit and alignment of the door and make sure that it opens and closes freely,
then tighten the screws holding the middle hinge.
Note: Make sure that
you use the correct
screw.
Middle hinge
Note: Make sure that
you use the correct
screw.
14
NS-CF43TMSS6/NS-CF43TMSS6-C
www.insigniaproducts.com
6 Align the hole in the bottom-left of the freezer door with the top pin in the middle
hinge, then install the freezer door on the hinge pin.
7 Place the top hinge pin into the top of the freezer door, then install the top hinge on
the top left side of your refrigerator with the screws you previously removed.
8 Check the fit and alignment (vertical and horizontal) of the door and make sure that it
moves freely open and closed, then tighten the screws holding the top hinge.
9 Replace the hinge cover and hole cover on the top of your refrigerator.
10 Adjust the leveling feet to level your refrigerator.
Maintaining your refrigerator
Your refrigerator is designed for year-round use with only minimal cleaning and
maintenance.
Cleaning your refrigerator
When you first receive it, wipe the case with a mild detergent and warm water, then wipe
dry with a dry cloth. Do this periodically to keep your refrigerator looking new.
CAUTION
To prevent damage to the finish, do not use:
• Gasoline, benzine, thinner, or other similar solvents.
• Abrasive cleaners.
Note: Make sure that
you use the correct
screw.
15
4.5 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
1 Turn off your refrigerator and unplug it from the wall outlet.
2 Remove all food.
3 Wash the inside with a damp warm cloth soaked in a solution of one quart of
lukewarm water to two tablespoons of baking soda solution.
4 Be sure to keep the door gasket (seal) clean to keep your refrigerator running
efficiently.
5 Dry the interior and exterior with a soft cloth.
Defrosting your refrigerator and freezer
This refrigerator is not designed to defrost automatically. In order to prevent damage to
the interior liner of your refrigerator from excessive frost build-up, defrost your
refrigerator every three months or when ice or frost is approximately 1/4 in. (0.6 cm) thick
inside the freezer compartment.
1 Set the thermostat to OFF, then remove all contents from the freezer compartment.
2 Leave the freezer door open to allow accumulated ice and frost to melt. Remove large
pieces of ice as needed.
3 After defrosting, remove accumulated ice and water, then wipe the freezer
compartment dry with a soft cloth.
4 Even though ice is not visibly present in the freezer compartment, allow the
evaporator, located behind the freezer wall, to completely defrost for approximately
two hours (total) before restarting your refrigerator.
5 Restart following the instructions in Setting the thermostat
on page 8.
Changing the interior light
1 Hold the lamp cover and push toward the inside of the cabinet to remove it from the
refrigerator compartment.
2 Unscrew the old bulb, then install the new bulb (10W/12E).
3 Re-install the lamp cover.
Shutting down your refrigerator
1 Turn off your refrigerator and unplug it from the wall outlet.
2 Remove all food.
3 Clean your refrigerator.
CAUTION
• Do not use hot water or electric heating devices to melt the accumulated ice.
• Your refrigerator door must remain closed while defrosting the freezer.
• Do not use any sharp instruments because they are likely to scratch the
surface.
CAUTION
• All parts removed must be saved to reinstall the light bulb.
• Before removing the light bulb, unplug your refrigerator from the power
supply. Failure to do so could result in electrical shock or personal injury.
16
NS-CF43TMSS6/NS-CF43TMSS6-C
www.insigniaproducts.com
4 Leave the door open slightly to avoid possible formation of condensation, mold, or
odor.
Moving your refrigerator
1 Turn off your refrigerator and unplug it from the wall outlet.
2 Remove all food.
3 Securely tape down all loose items inside your refrigerator.
4 Tape the doors shut.
Tips on saving energy
• Locate your refrigerator in the coolest area of the room, away from heat producing
appliances or heating ducts and out of direct sunlight.
• Let hot foods cool before placing them in your refrigerator. Overloading your
refrigerator forces the compressor to run longer. Foods that freeze too slowly may
lose quality or spoil.
• Wrap foods properly and wipe containers dry before placing them in your
refrigerator. This cuts down on frost build-up inside your refrigerator.
• Organize and label food to reduce door openings and extended searches.
Troubleshooting
CAUTION
Use extreme caution with children. Your refrigerator should not be accessible to
child's play.
WARNING
Be sure your refrigerator stays in the upright position during transportation.
PROBLEM SOLUTION
My refrigerator does not work. • Make sure that your refrigerator is securely plugged
into a working outlet.
• Make sure that your power source has the correct
voltage. Your refrigerator’s voltage rating is on a label
on the back of your refrigerator.
• Check the house fuse or circuit breaker box and
replace the fuse or reset the circuit breaker.
The refrigerator compartment
has a bad odor.
• Make sure that all food with a strong odor (like
onions) is wrapped or stored in airtight packaging.
• Certain containers and wrapping materials (such as
paper, foil, or plastic) can cause odors. If you think this
might be the case, try using different containers or a
different brand of wrapping material.
• Check for spoiled food and remove it.
• Clean the inside of your refrigerator. See Maintaining
your refrigerator on page 14.
17
4.5 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
My refrigerator doors do not
close completely.
• Make sure that no food packages are in the way.
• Make sure that the door gaskets (seals) are clean. See
Maintaining your refrigerator on page 14.
• If the door gasket does not seal, try heating then
cooling the seal. You can use an electric hair dryer to
heat the seal.
• Make sure that your refrigerator is level. See Leveling
your refrigerator on page 8.
• Make sure that the top of your refrigerator is tilted
backward about .4 in. (10 mm) to .6 in. (15 mm). See
Leveling your refrigerator on page 8.
The temperature is too hot. • You may have left the doors open too long or opened
them too frequently.
• Make sure that no obstacle is keeping the doors from
closing correctly.
• Adjust the refrigerator or freezer compartment
temperature. See Setting the thermostat
on page 8.
• Your refrigerator may not have enough clearance
from walls or the ceiling. See Providing proper
ventilation on page 7.
The temperature is too cold. • Adjust the refrigerator or freezer compartment
temperature. See Setting the thermostat
on page 8.
A layer of frost occurs in one of
the compartments.
• A layer of frost may occur on the compartment’s
interior walls if the freezer is opened frequently or
kept open too long.
• Make sure that the air outlets are not blocked by food.
• Make sure that the doors are fully closed.
• To remove the frost, see Defrosting your refrigerator
and freezer on page 15.
My refrigerator door is hard to
open.
• When you open your refrigerator door, warm air
rushes inside. When you close the door, the warm air
rushes to the condenser which causes a vacuum. This
causes the door to be hard to open for about 10 to 15
seconds after closing.
• If the door is hard to open at other times, try rubbing
paraffin wax or petroleum jelly along the edges of the
entire gasket. Paraffin wax is used for canning and is
safe for use around food.
The compressor runs for a long
time or turns on and off
frequently.
The compressor runs longer if:
• The room temperature is high.
• You just added a large amount of food. Wait for the
food to freeze, then check again.
• You open and close the door frequently.
• The door gasket is dirty. Clean the gasket. See
Maintaining your refrigerator
on page 14.
• Your refrigerator has been disconnected for a period
of time. Wait for your refrigerator to cool (about four
hours) before adding food.
• You have the temperature set too low.
PROBLEM SOLUTION
18
NS-CF43TMSS6/NS-CF43TMSS6-C
www.insigniaproducts.com
Specifications
The light inside my refrigerator
does not turn on.
• Make sure that your refrigerator is plugged into a
working outlet.
• If a door stays open too long, your refrigerator
automatically turns off the light.
• Close then open the door again.
• Check to see if the light is damaged. If the light is
damaged, have it replaced by a qualified service
technician. See Changing the interior light
on
page 15.
My refrigerator makes unusual
noises or vibrations.
The following sounds are normal:
• Compressor running noises.
• Air movement noise from the small fan motor in the
freezer compartment or other compartments.
• Gurgling sound similar to water boiling.
• Clicking noise before the compressor starts.
Other unusual noises or vibrations may occur:
• If you have items on the top of your refrigerator.
Remove the items.
• If your refrigerator is not level. See Leveling your
refrigerator on page 8.
• If your refrigerator is touching walls. Move it away
from the walls.
• If the shelves or drawers are installed incorrectly.
The outside of my refrigerator is
hot.
Heat dissipation from the condenser may make the
outside feel hot. This is normal and happens if:
• The room temperature is high.
• You have too much food in your refrigerator.
• You open and close the doors excessively.
Water condenses on the outside
of my refrigerator.
• Condensation on the exterior surface and door seal is
normal when the room humidity is high.
• When you open the door, warm, moist outside air
meets the cold dry air inside your refrigerator. This is
normal.
Dimensions (HxWxD) 44 7/16 x 18 3/4 x 19 1/8 in. (112.7 x 47.4 x 48.6 x cm)
Weight 61.7 lbs. (28 kg)
Total capacity 4.5 cu. ft. (.127 cu. m)
Refrigerator capacity 3.3 cu. ft. (.09 cu. m)
Freezer capacity 1.2 cu. ft. (.03 cu. m)
Power requirements 115 V~60 Hz
Current 1.4 A
Power consumption (annual) 327 kWh
Power cord length 5.1 ft. (155 cm)
PROBLEM SOLUTION
19
4.5 Cu. Ft. Compact Refrigerator
www.insigniaproducts.com
ONE-YEAR LIMITED WARRANTY
Best Buy, or its Authorized Partner of Insignia branded products, warrants to you, the original
purchaser of this new Insignia branded product (“Product”), that the Product shall be free of defects
in the original manufacture of the material or workmanship for a period of one (1) year from the date
of your purchase of the Product or the date of delivery (if later than the date of purchase) (“Warranty
Period”).
For this warranty to apply, your Product must be (i) purchased in the United States or Canada from a
Best Buy branded retail store, online at www.bestbuy.com or www.bestbuy.ca, or from Best Buy’s
Authorized Partner, and (ii) packaged or sold with this warranty statement.
The term “Best Buy”, as used in this warranty, refers to Best Buy branded retail stores,
www.bestbuy.com
, www.bestbuy.ca, and Best Buy’s Authorized Partner.
Because Insignia cannot control the quality of products sold by unauthorized sellers, this warranty
applies only to Products that were purchased from Best Buy or an Insignia Authorized Partner, unless
otherwise prohibited by law. Insignia reserves the right to reject warranty claims for Products
purchased from unauthorized sellers, including unauthorized websites.
REPAIR OR REPLACEMENT, AS PROVIDED UNDER THIS WARRANTY, IS YOUR EXCLUSIVE REMEDY FOR
BREACH OF WARRANTY. INSIGNIA SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR THE BREACH OF ANY EXPRESSED OR IMPLIED WARRANTY ON THIS PRODUCT,
INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT, LOST BUSINESS, OR
LOST PROFITS. INSIGNIA PRODUCTS MAKES NO OTHER EXPRESS WARRANTIES WITH RESPECT TO
THE PRODUCT. ALL EXPRESSED AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING BUT
NOT LIMITED TO ANY IMPLIED WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET
FORTH ABOVE AND NO WARRANTIES, WHETHER EXPRESSED OR IMPLIED, WILL APPLY AFTER THE
WARRANTY PERIOD. SOME STATES, PROVINCES, AND JURISDICTIONS DO NOT ALLOW LIMITATIONS
ON (i) HOW LONG AN IMPLIED WARRANTY LASTS, (ii) EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, or (iii) LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO
STATE OR PROVINCE TO PROVINCE.
How long does the coverage last?
The Warranty Period lasts for 1 year (365 days) from the date you purchased the Product or the date
of delivery (if later than the date of purchase). Your purchase date is printed on the receipt you
received with the Product. In the event that Authorized Partner ceases to sell the covered Insignia
branded product, this warranty shall terminate for that product and there shall be no repair or
replacement of the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or workmanship of the
Product is determined to be defective by an authorized Insignia repair center or store personnel,
Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the
Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced
under this warranty become the property of Insignia and are not returned to you. If service of
Products or parts are required after the Warranty Period expires, you must pay all labor and parts
charges. This warranty lasts as long as you own your Insignia Product during the Warranty Period.
Warranty coverage terminates if you sell or otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location or from a Best Buy online website
(www.bestbuy.com
or www.bestbuy.ca), please take your original receipt and the Product to any
Best Buy store. Make sure that you place the Product in its original packaging or packaging that
provides the same amount of protection as the original packaging. If you purchased your Product
from an Authorized Partner, call Insignia at 1-877-467-4289.
To obtain warranty service, in the United States and Canada call 1-877-467-4289. Call agents may
diagnose and correct the issue over the phone.
20
NS-CF43TMSS6/NS-CF43TMSS6-C
www.insigniaproducts.com
If you purchased the Product from an Authorized Partner other than Best Buy, please call
1-888-BESTBUY in the United States or 1-866-BESTBUY in Canada. You will be asked to provide proof
of purchase and to return your Product to Best Buy. Make sure that you put the Product in its original
packaging or packaging that provides the same amount of protection as the original packaging.
Where is the warranty valid?
This warranty is valid only in the United States and Canada to the original purchaser of the product
from an Authorized Partner, in the country where the original purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Food, beverage, and or medicine loss/spoilage.
• Damage to other products caused by a power surge or other similar issue while connected to
the Product.
• Customer instruction/education.
• Installation.
•Set up adjustments.
• Cosmetic damage.
• Damage due to weather, lightning, and other acts of God, such as power surges.
• Accidental damage.
•Misuse.
•Abuse.
•Negligence.
• Commercial purposes/use, including but not limited to use in a place of business or in
communal areas of a multiple dwelling condominium or apartment complex, or otherwise used
in a place of other than a private home.
• Modification of any part of the Product, including the antenna.
• Display panel damaged by static (non-moving) images applied for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance.
• Connection to an incorrect voltage or power supply.
• Damage due to attempted repair by any person not authorized by Insignia to service the
Product.
• Products sold “as is” or “with all faults”.
• Consumables, including but not limited to batteries (i.e. AA, AAA, C etc.).
• Products where the factory applied serial number has been altered or removed.
• Loss or Theft of this product or any part of the product.
• Display panels containing up to three (3) pixel failures (dots that are dark or incorrectly
illuminated) grouped in an area smaller than one tenth (1/10) of the display size or up to five (5)
pixel failures throughout the display. (Pixel based displays may contain a limited number of
pixels that may not function normally.).
• Failures or Damage caused by any contact including but not limited to liquids, gels or pastes.
Contact Insignia:
1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
*Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2025 Best Buy. All rights reserved.
www.insigniaproducts.com
1-877-467-4289 (U.S. and Canada)
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2025 Best Buy. All rights reserved.
V1 ENGLISH
25-0073
