Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-800-887-6326
Monday – Friday 9:00 a.m. – 5:00 p.m. CST
SKU Number: 352-5976
2-Light Indoor Flush Mount
Model Number: CC5976NB
PACKAGE CONTENTS
HH
II
B
A
221102
HARDWARE CONTENTS Note: Hardware not shown actual size.
AA
CC
BB
Mounting Strap
X1
Long Screw
X2
Mounting Screw
X2
EE
Threaded Pipe
X1
Wire Connector
X3
DD
Hex Nut
X1
FF
GG
HH
II
Metal Pad
X1
Decorative Cap
X1
Finial
X1
Please read and understand this entire manual before attempting to assemble, operate or install the product.
WARNING
● Turn off electricity at main fuse box (or circuit breaker box) before beginning installation by removing fuse (or
switching off circuit breaker).
● Be careful not to damage or cut the wire insulation (covering) during fixture installation. Do not permit wires to contact
any surface having a sharp edge. To do so may damage or cut the wire insulation, which could cause serious injury
or death from electric shock.
CAUTION
● All electrical connections must be in agreement with local codes, ordinances or the national electric code (NEC).
Contact your municipal building department to learn about your local codes, permits and/or inspections.
● Risk of fire – most dwellings built before 1985 have supply wire rated for 140°F/60ºC. Consult a qualified electrician
before installation.
● Do not connect this fixture to an electrical system that does not provide a means for equipment grounding. Never use
a fixture in a two-wire system that is not grounded. If you are not sure your lighting system has a grounding means,
do not attempt to install this fixture. Contact a qualified, licensed electrician for information with regards to proper
grounding methods as required by the local electrical code in your area.
PREPARATION
Before beginning assembly, installation or operation of product, make sure all parts are present. Compare parts with
package contents list and diagram on previous page. If any part is missing or damaged, do not attempt to assemble,
install or operate the product. Contact customer service for replacement parts.
Tools Required for Assembly (not included): Slotted Screwdriver, Phillips Screwdriver, Pliers, Electrical Tape, Wire
Cutters, Safety Glasses, Ladder, Wire Stripper.
Page 2 of 3
SAFETY INFORMATION
221102
ASSEMBLY INSTRUCTIONS
Turn off the power at fuse or circuit box.
AA
CC
1
1. Attach two long screws(CC) to the
holes on the mounting strap(AA).
Thread them in part way: 2 to 3
turns only.
2. Attach the mounting strap (AA) to
the outlet box using two mounting
screws (BB).
AA
BB
2
3. Connect fixture black wires to house
black wire and fixture white wires to
house white wire using wire
connectors (DD) provided.
Connect the copper wire or green
/ yellow wire from the light fixture to
the mounting strap (AA) by
securing it with the preinstalled green ground screw,
then connect it to the house ground wire with wire
connector (DD).
Tuck all the wires into outlet box.
DD
AA
3
A
4
CC
Keyhole
4. Attach the ceiling pan (A) to the
mounting strap (AA) by inserting
two long screws (CC) heads into
the keyholes, rotate the ceiling
pan (A) until it is locked in place,
then secure the long screws (CC)
tightly.
A
5
EE
5. Attach the threaded pipe (EE) into
the coupling of the ceiling (A) and
secure the preinstalled washer and
hex nut.
NOTE: Depth of threaded pipe
may need to be adjusted to
properly fit glass shade,
decorative cap and finial.
● To clean, turn off and wipe with a damp, non-abrasive cloth.
1) The light does not work:
a) Make sure the wall switch and circuit breaker are on.
b) Make sure the wiring is correct.
2) Fuse blows or circuit trips when light is turned on.
Check for crossed wires, ensure wiring is correct.
If unable to fix any of the above issues, please consult a certified electrician.
Questions, problems, missing parts?
Before returning to your retailer, call our customer service at 1-800-887-6326
Monday – Friday 9:00 a.m. – 5:00 p.m. CST
CARE AND MAINTENANCE
TROUBLESHOOTING
FIVE-YEAR LIMITED WARRANTY: If, during normal use, this PATRIOT LIGHTING lighting fixture breaks or fails
due to a defect in material workmanship within five (5) years from the date of original purchase, simply bring this
lighting fixture with the original sales receipt back to your nearest MENARDS retail store. At its discretion, PATRIOT
LIGHTING agrees to have the product or any defective part(s) repaired or replaced with the same or similar PATRIOT
LIGHTING product or part free of charge, within the stated warranty period, when returned by the original purchaser
with original sales receipt. This warranty; (1) excludes expendable parts including but not limited to light bulbs; (2) does
not cover damage that has resulted from abuse or misuse; and (3) does not cover any losses, labor, injuries to
persons/property or costs. This warranty does give you specific legal rights and you may have other rights, which vary
from state to state.
R
R
R
R
Spare Parts List:
Assembly Kit
4704MM (1 SET)
Glass Shade
9424FC
B
Page 3 of 3
221102
The following parts are available for reorder if damaged or missing. Call our toll-free at 1-800-887-6326.
A
B
EE
EE
GG
FF
II
HH
6
6. Install 2 X 60W Max. medium
base bulbs (Type A , not included).
See relamping label at socket
area or packaging for maximum
wattage allowed.
Attach the glass shade (B) to the
ceiling pan (A) by inserting the
threaded pipe (EE) through the
hole of the glass shade, and then
secure it with a metal pad (GG) and
a hex nut (FF).
ASSEMBLY INSTRUCTIONS (continued)
7
7. Attach the decorative cap (HH) to
the end of threaded pipe(EE), then
secure it with the finial(II).
Turn on the power at fuse or circuit
box.
AA
CC
BB
Mounting Strap
X1
Long Screw
X2
Mounting Screw
X2
EE
Threaded Pipe
X1
Wire Connector
X3
DD
Hex Nut
X1
FF
GG
HH
II
Metal Pad
X1
Decorative Cap
X1
Finial
X1
Bulb Type A Max.60W
(not included)
