The PCO875 oers the most convenient solution in synchronizing the power level of
more than one power supply. When you use these audio equipments together, you
need many sockets. This power sequence controller can turn ON the devices from
CH 1 to CH 8 or turn OFF from CH 8 to CH 1. It solves the problem of wrong operation
and avoid damage of devices (e.g. Power Amplier, Speakers, etc). It can protect your
equipment when voltage uctuates, swell, or spike during storms and power outages.
The audio equipments operator can turn ON/OFF all the devices simply by press
ONE power switch. Easy Operation.
How to use the sequence controller
When the sequence controller is turned ON, CH 1- CH 8 is turned ON in sequence.
Usually turn ON from low power equpiment to high power equipment. And turn OFF
from high power equipment to low power equipment. Usually, power amplier is at
the last channel or CH8. (The speakers is connected to power amplier. In order to
protect the speaker from damage, the power amplier should be turned ON at lastly,
but turned OFF at the rst.)
FRONT PANEL
1. 2 non-sequence outlet
2. LED indicators of each CH
3. Standby LED indicator
4. 5V outlet: for LED lamp
5. LCD display of Working Voltage
6. POWER ON/OFF switch
BACK PANEL
7. AC INPUT: AC90-240V 50-60HZ
8. 8 Sequence OUTLET: CH 1–CH 8
PCO875
Professional 10 Channel Power Sequencer
2000W/Outlet, 6000W/Unit Max. Power Supply Controller Sequencer
System, 30A High-Quality Relay With Voltage Display Screen
1 2 34 5 6
7
8
www.PyleUSA.com
Features:
• Professional 8-way Power Sequencer
• Eectively Reduce the Impact of Current on the Equipment
• Pure Copper Core Cable with Flame Retardant and Waterproof Skin
• 8 Channels Universal Outlets Relay Controlled
• 2 Channels Outlets Output Directly
• Power Supply Controller Sequencer System
• Audio Video (A/V) Power Conditioner
• 30A High-Quality Relay is Adopted
• With Voltage Display Screen, Display the Current-Voltage Value
• Universal Socket, Suitable for All Kinds of Plugs
• Standby LED Indicator
• POWER ON/OFF Switch
• Built-in Switching Power Supply
• Support for Multiple Connections
• For public broadcasting, mini bar, small outdoor performances, the school lecture
room, multimedia conference hall, multi-function hall, training center, villas,
hotels, Home Furnishing, etc.
What's in the Box:
• Sequence Controller Unit • Link Cable: 3.28 ft.
Technical Specs:
• Housing Materials: Metal
• Power: AC90-240V 50-60HZ
• Outlet: 8 + 2 Universal Outlets
• Link Connector: S-Video, 4-Pin
• Max. Power: 2000W/Outlet, 6000W/Unit
• AC Input: AC 90-240V 50-60HZ
• 8 Sequence Outlet: CH 1 – CH 8
• Outlet Materials: Antifoaming ABS
• Turn-ON/OFF the Outlets in Sequence: 1 second
• Outlet Relay: 30A 277VAC
• BNC Connector: 5V
• MAX Output Current: 13 Amp RMS
• Power Cable Size: 3.28' ft.
• Product Size: 18.9'' x 8.3'' x 1.9'' -inches (Standard 1U)
