English GEEVON Thermometer
with Weather Station
Item No. 86278
User Manual
Thank you for purchasing 86278 thermometer with
weather station.Please take a moment to read this
guide and store it for future reference
Controls and Displays:
1.Weather Forecast
2.Outdoor Temperature
3.Indoor Temperature
4.Time Display
5.Alarm
6.RF signal
7.Channel 1/2/3
8.Low battery indicator for sensor
9.Outdoor Humidity
10.Low battery indicator for main display
11.Indoor Humidity
12.Magnetic Sheet (total 2 sheets)
13.Stand Bracket
14.USB port
15.DC port
16.Wall mount hole
17.Battery Compartment (3 x AAA Batteries, not Included)
18.Wireless RF Signal Indicator (Flashes when data is being
sent to the display unit)
19.Integrated Hang Hole
20.Sensor Compartment (2 x AAA Batteries Not Included)
21.Channel Selector of Sensor (Maximum 3 Channels
Available)
22.USB Line
A. button
B. button
C. button
D. button
Package Content:
1.Display unit
2.1 x outdoor sensor
3.Instructions Manual
4.USB Line
Main Features:
1.4 function buttons: [ ] [ ] [ ] [ ];
2. Temperature units: °F/°C switchable
3. 433MHz ASK RF Signal Reception
4. Support up to 3 outdoor sensors(Package comes with 1
sensor only)Max/min indoor and outdoor temperature and
humidity memory (can be cleared manually)
5.weather forecast: sunny, cloudy, overcast, rainy, snowy
6.Main unit：3×1.5V AAA
7.DC 5.0V 1A input
8. Outdoor sensor: 2 x 1.5V AAA
Getting Started
1. Insert 2 x AAA batteries into the remote sensor after
selecting the channel.
2. Insert 3 x AAA batteries and plug in the usb cable to power
on the thermometer.
3. Place or hang the main unit indoors and the remote sensor
indoors or outdoors (AVOID DIRECT SUNLIGHT AND RAIN)
Function of Buttons:
1. button
a.Single press to light up the backlight for 10 seconds.
b.Press and hold more than 2 seconds to set the temperature
unit (°C/°F).
2. button
a.Single press to set the alarm
b.Press and hold more than 2 seconds to set the time and the
date.
3. button
a.Single press to view the max/min temperature and humidity
memory.
b.Press and hold more than 2 seconds to clear the max/min
temperature and
humidity memory.
4. button
a.Single press to select channel 1/2/3.
b.Press and hold more than 2 seconds to enter RF long
receiving mode.
RF Receiving Function
• After power on, the host will automatically enter the 3-minute
RF receiving mode to receive the RF signal transmitted by the
outdoor sensor, and then the received OUTDOOR
temperature and humidity values are displayed on the screen.
During the RF long receiving mode, the RF signal “ ”
displays and flashes. When the signal is received successfully,
it will automatically turn off the RF receiving, and the RF signal
“ ” fully displays but not flash.
• When no signal is received, press and hold the [ ]
button to clear the outdoor temperature and humidity value,
and reinstall the battery to the transmitter. When the red
indicator light on the transmitter flashes, it indicates that the
host and the transmitter are matched, and then check whether
the temperature and humidity value is displayed on the
screen. If there is temperature and humidity appeared on the
screen, it indicates that the host and the transmitter matches
successfully, otherwise it fails to receive the signal, and then
repeat the receiving operation to receive again;
• In standard mode, press the [ ] button to select the
OUTDOOR RF channel1/2/3. Open the battery cover of the
transmitter to adjust the temperature and humidity channels on
the transmitter.
Note: The temperature and humidity channel on the
transmitter needs to be the same as the channel selected by
the host.
If the host selects channel 1, then the transmitter should also
be dialed to channel 1.
Temperature and Humidity
1.Indoor temperature range: 14.18°F ~ +122°F(-9.9°C ~
+50°C). When the indoor temperature is lower than + 14.18
°F(-9.9 °C), display as LL. L °C & °F, higher than+122°F (50
°C), display as HH. H °C & °F;
2.Outdoor temperature range: -40°F ~ +140°F(-40°C ~ 60°C).
When the outdoor temperature is lower than -40°F(-40°C),
display as LL. L °C & °F, higher than+140°F (60 °C), display as
HH. H °C & °F;
3.Indoor/outdoor humidity range: 20%RH ~ 95%RH. When the
indoor/outdoor humidity is lower than 20%, display 20%;
higher than 95%, display 95%;
4.Temperature resolution: 0.1°C & 0.1°F
5.Humidity resolution: 1%RH
Note: During the 3-minute RF long reception process,
temperature and humidity detection is not performed, and
INDOOR temperature and humidity values are not updated.
Accuracy:
1. Temperature accuracy:
-40°F ~ -4°F: ± 7.2°F
-4°F ~ 32°F: ± 3.6°F
32°F ~ 122°F: ±1.8°F
Note: when the temperature in 122°F ~ 158°F range, the
temperature is only for reference.
2. Humidity accuracy: +/- 5 % RH (35%RH to 70%RH);
+/- 10 % RH (20%RH to 36%RH, 71%RH to 95%RH)
Max/Min Temperature & Humidity Memory
1.In standard mode, press the [ ]button to view the
max/min temperature and humidity records, the sequence is:
MAX value→MIN value → current value;
2.When viewing the max/min temperature and humidity value,
D
A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
18
19
20
21
22
17
15
B
C
NO
Outdoor
Signal
Reception
/ Outdoor
Reading
Always
Flashes or
Shows
"--"
it will automatically return to the current temperature and
humidity if there is no key operation for 5 seconds;
3.In max/min display, press and hold the [ ]button for
more than 2 seconds to clear the max/min temperature and
humidity memory, at the same time the max/min temperature
and humidity display as “- -”.
Weather forecast:
The device predicts weather conditions for the next 12-24
hours based on humidity and temperature detected by the
sensor, with an accuracy rate of about 40%-45%.
Placement of the Device:
1.Display unit placement:
a. Place the display unit in a dry area free of dirt and dust.
b. Display unit stands up right for tabletop/countertop or hangs
on the wall to use.
2.Outdoor sensor placement:
The remote sensor is IP44 water-resistant and designed for
general outdoor use. However, to prevent damage, place the
sensor in an area that is protected from the direct weather
elements and direct sunshine. The best location is 4 to 8 feet
above the ground with permanent shade and plenty of fresh
air to circulate around the sensor.
3.Important Placement Guidelines:
a. To ensure accurate temperature measurement, place units
out of directsunlight and away from any heat sources or vents.
b. Display unit and outdoor sensor must be within 200ft(60m)
of each other.
c. To maximize wireless range, place units away from large
metallic items, thickwalls, metal surfaces, or other objects that
may limit wireless communication.
d. To prevent wireless interference, place both units at least
3ft(1m) away from electronic devices(TV, computer,
microwave, radio, etc.
Outdoor Sensor Function:
a.Once the display unit has been set up and the channel
synchronized with the outdoor sensor, the display unit will
begin the registration process. It can take up to 3 minutes to
complete the registration, where the display unit will search for
an RF (Radio Frequency) signal from the outdoor sensor. The
outdoor sensor signal strength will show the connection
strength to the outdoor sensor. If there are no bars or if bars
are not showing at its maximum strength (4 bars) (3) try
placing the outdoor sensor or display unit elsewhere for better
connection.
b.If the RF Signal was lost and not reconnected, the outdoor
temperature and humidity level will begin to flash after 1 hour
of lost connection. If no connection was found after 2 hours
only a dotted line ‘ - - ’ will be displayed in place of the
temperature and humidity level.
c. To manually restart the RF registration, press and hold the
“ ” button for 3 seconds. The display unit will now
search for the RF signal for the next 3 minutes.
If you have any questions, please kindly contact Geevon
Customer Support through your order page.
Cautions:
Place the sensor vertically on a North-facing wall or well-shad-
ed location to avoid sunlight and rain.Direct sunlight will cause
temperatures to read high. Recommend placing the sensor 6
inches under the eaves or the deck rail is preferred. The
transmission range to the base station is 200ft/60m in open
air, not including walls or floors.
FCCID:2AM88-TX19
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received,including
interference that may cause undesired operation.
TROUBLE SHOOTING
Problem
Possible Solution
Flashing of the outdoor reading is generally an
indication of wireless interference. This
thermometer is arranged to communicate with
three external sensors.One of these comes with
the unit, the remaining two are optional.
1. Bring both of the sensor and display indoors,
side byside and remove batteries from each.
Power the thermometer as described in Getting
started.
2. Set the selector in the outdoor sensor to the
desired transmission channel (1, 2, or 3). Automatic
data will be transmitted. Always make sure the
channel chosen on the display unit matches the
channel option chosen on the outdoor sensor.
3. Relocate the main unit and/or the outdoor
sensor. The units must be within 200ft (60m) of
each other.
4. Make sure both units are placed at least 3ft (1m)
away from electronics that may interfere with the
wireless communication(such as TV,
microwave,computer, radio, etc).
5. Do not use heavy-duty or rechargeable
batteries.The outdoor sensor requires alkaline
batteries in low temperature conditions.
6. Do not mix old and new batteries.
Inaccurate
temperature/
humidity
Inaccurate
Weather
Forecast
Backlight
doesn't stay
on
"HH.H/LL."
display in
indoor and/or
outdoor
temperature
Care and
maintenance
1. Make sure both the main unit and
sensor are placed out of direct sunlight
and away from any heat sources or vents.
2. Do not tamper with the internal
components.
3. Temperature accuracy: Temperature
accuracy:
-40°F ~ -4°F: ± 7.2°F
-4°F ~ 32°F: ± 3.6°F
32°F ~ 122°F: ±1.8°F
4. Humidity accuracy: +/- 5 % RH (35%RH
to 70%RH);
+/- 10 % RH (20%RH to 36%RH, 71%RH
to 95%RH)
Weather forecast readings should be
disregarded for the next 24 hours. This will
allow sufficient time for the weather station
to collect date and therefore result in a
more accurate forecast.Common to
weather forecasting, absolute accuracy
cannot be guaranteed.
The backlight turns off after 10s to save
energy when powered by batteries. If you
want the weather station always lights on,
please plug in with USB cable.
If the temperature is higher than the
detection range, HH.H will display on
screen for indication;If lower than the
detection range, LL.L will display on
screen for indication.
1. To maximize wireless range, place units
away from large metallic items, thick walls,
metal surfaces, or other objects that may
limit wireless communication.
2. Please immediately change the
batteries if the low battery indicator is
displayed on the LCD for sensor.
3. Do not clean any part of the product
with benzene,thinner or other solvent
chemicals. When necessary, clean it with
a soft cloth.
4. Never immerse the product in water.
This will damage the product.
5. Do not subject the product to extreme
force, shock, or fluctuations in
temperature.
3 feet
(0.9m)
APART
(200 feet maximum) (60 meters)
AT
LEAST
