REVISED BULLETIN
SERVICE PARTS LIST
BULLETIN NO.
STARTING
SERIAL NO.
WIRING INSTRUCTION
DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CATALOG NO.
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg.1
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 42-70-2116 Light Band Clip Kit (Set of 2) (1)
2 42-70-2117 Hard Hat Clips (Set of 2) (1)
3 44-52-0015 Pad (1)
4 31-15-2116 Rubber USB-C Cover (1)
5 42-44-1210 Wall Plug and USB-C Cable (Optional) (1)
6 48-11-2131 REDLITHIUM
®
USB Battery (Optional) (1)
7 12-20-2116 Service Nameplate (Not Shown) (1)
54-06-2316
USB RECHARGEABLE BEACON™ HARD HAT LIGHT
2116-21
H90B
July 2023
0
00
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
4
2
1
3
5
6
4
FIG. NOTES
7 A clean, dry surface is essential for proper
performance for any adhesive system. The area
intended for application of any adhesive label or
nameplate must be prepared by cleaning with
isopropyl alcohol. The solvent is to be applied with a
clean, lint free applicator and the surface allowed to
dry before applying the label or nameplate.
= Part number change from
previous service parts list.
