LS2 Temperature Sensors Kit
H5Pro-LS2D
2
.............................................................................................................................
What’s in the Box
3
.................................................................................................................
Product Parameter
4
...............................................................................................................
Setup
11
...........................................................................................................................................
Mounting
5
..................................................................................................................................
12
......................................................................................................
Introduction
How the System Works
......................................................................................................
..................................................................................................................
Customer Service 23
Precautions and Disclaimer 17
.............................................................................................
FCC Statement 19
........................................................................................................................
Warranty 22
....................................................................................................................................
Content
Introduction What's in the Box
Button Functionality
1
8
9
2
Setup
10
11
12 13 14 15
3 4 5 6 7
❶Download MOCREO Smart App
17 18 19 20 21 22 23
v1.1
16
-
-
The H5Pro-LS2D Kit is a long-range, reliable solution for remote
temperature monitoring, featuring the H5Pro LoRa Hub and LS2
LoRa Temperature Sensor.
LS2 Sensor: Equipped with a high-precision, professional-grade
ensor, the LS2 Sensor ensures accurate temperature readings.
Its waterproof probe and low power consumption make it
perfect for continuous use in challenging environ-ments, such
as refrigerator and freezers.
H5Pro Hub: The H5Pro Hub leverages LoRa technology to
communicate with multiple sensors across expansive areas. Its
2-inch display provides real-time monitoring at a glance,
making it the dashboard for managing sensors, checking
historical data, alerts, etc.
Customer Service
Search [ MOCREO ] on YouTube to watch the setup video tutorials.
User Guide Manual
+1 (530) 988-8608
https://doc.mocreo.com/
MOCREO Sensor
Introduction What's in the Box Product Parameter
Mounting Setup
Google Play App Store MOCREO
Smart App
MOCREO Smart
Scan and Download
(1) Add H5Pro Hub
❷Add Device
Power the H5Pro Hub, check if your phone's Bluetooth is on,
and ensure the MOCREO Smart app has Bluetooth permissions.
Position the device as high as possible, avoiding obstacles and sources of signal
interference.
Open the MOCREO Smart App, follow the instructions
provided by the app, and complete the Add H5Pro Hub
addition process.
Return to the MOCREO Smart App and complete the LS2
Sensor addition process.
Insert the external probe, pull out the battery insulating tab.
Welcome to MOCREO smart
No device found.Click the top right corner to add.
My Home > My Home >
All
Add Devices
Hub
All
Note：If connected via Ethernet,
the device online icon is
IoT Hub Pro
IoT Hub Pro
°F
°F
H5Pro
(2) Add LS2 Sensor
Add Devices
Hub
Sensor
°F
IoT Hub Pro
Temperature
Sensor
LS2
H5Pro
My Home >
All
All
IoT Hub Pro LS2 Sensor
My Home >
All
IoT Hub Pro
°F °F
Precautions and Disclaimer
Precautions for Use
To ensure the normal use of the product, please pay attention
to the following situations:
• Do not expose the Device to high temperatures, humidity, or
dusty environments.
• Do not place the Device near flammable materials.
• Do not put heavy objects on the Device or use it as a support.
• Children should not use the Device without adult supervision.
Disclaimer
The contents about how to use the product and the App
guidance are only for reference; please refer to the actual
situation for specific applications. If there is something different
from the instructions during using the product, please contact
MOCREO Support for updates.
This product is for detecting and monitoring only. MOCREO is
not responsible for any property damage or other consequenc-
es of the use of this product.
FCC Statement
FCC ID (LS2 Sensor): 2BFZL-LS2
FCC ID (H5Pro Hub): 2BFZL-H5LR
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, according to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communi-
cations.
However, there is no guarantee that interference will not occur
in a particular installation. lf this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
• Increase the separation between the equipment and the
receiver.
• Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Warranty
MOCREO products enjoy a 12-month limited warranty (starting
from the date when the customer receives the product), which
applies only to hardware components of the device that are not
subject to accident, misuse, neglect, fire, or other external
causes, alterations, or repair.
LS2
LoRa
1640 ft / 500 m (No obstacles)
4.20 x 2.22 x 0.79 in
3.7 oz
4.9 ft (1.5 m)
0.16 x 0.05 in
AAA battery x 3 (Replaceable)
-40°~ 221°F(-40°~ 105°C)
±0.9°F (±0.5°C)
Specifications
Model
Wireless Connection
Communication Range
Dimensions
Weight (Including probe)
Cable Length
Cable Cross Section
Battery
Probe Measuring Range
Temperature Accuracy
Specifications
H5Pro
Rotary Encoder ×1, Side Button ×1
2-inch, 320 × 240 IPS display, non touch
7-segment 4-digit clock display
2.4GHz
915MHz
10Mbps/100Mbps
BLE 5.0
5.04 × 3.08 × 3.77 in (Include antenna)
4.1 oz
DC 5V/1A
Model
Button
Dimensions (L x W x H)
Weight
Power
Display
Network
Physical Button ×2
LCD Display (W × H)
LED Dot Matrix
Wi-Fi
LoRa
Ethernet
BLE
How the System Works
1. The LS2 Sensor sends temperature data to the H5Pro Hub via
LoRa protocol (Long range, 1640ft, no obstacle).
2. The H5Pro Hub uploads the data to MOCREO Cloud via Wi-Fi
or Ethernet.
Users can access the monitoring data anytime through the
MOCREO Smart App.
°F
How the System Works
76.9 76.9
76.9
Rotary Encoder: The rotary button allows moving the selection
box up and down the screen, and pressing the button confirms
the selection.
Side Button: Return to the previous interface.
Button Functionality
Side Button
Rotary Encoder
USB Type-C
Power Port
LED Dot Matrix LCD Screen
LAN Port LoRa
Antenna
Setup Button
Status Indicator Light
USB Type-C
Connector
Product Label
LS2 SN
Built-in AAA battery
Inductive
Probe
Note: "Restore default settings and restart" will reset the
Sensor to factory settings. You will need to re-add the Sensor
through the App. This action is generally not recommended
unless necessary.
LS2 Sensor Button Functions
Function
Enter Setup mode
Restore default settings
and restart
LS2 Sensor reports data
(Battery level, signal strength,
monitoring data)
Button Operation
Press and hold for 3s, then release
Press and hold for more than
15s, then release
Press the button once
Indicator Light Behavior
The blue light is flashing
The red light briefly illuminates
and then extinguishes
The blue light flashes once
LS2 Temperature Sensors Kit
H5Pro-LS2D
4.9ft Probe Cable x2
Velcro x2
H5Pro Hub x1
User Manual x1
LS2 Sensor x2
Power Adapter x1
USB Type A
-Type C x1
LoRa Antenna
×1
Probe/Cable Clip x4
or
