Eco Glow Bolt
Rechargeable Magnetic LED Torch
User Manual
Product Overview
Portronics Eco Glow Bolt is a compact yet
powerful rechargeable LED torch designed for
everyday use, emergencies, and travel. Crafted
from premium aluminium alloy with a smooth
oxidized matte finish, it combines durability with a
sleek, modern look. The LED light delivers up to 650
lumens of brightness across three adjustable
modes — Low, Medium, and High — making it
suitable for home repairs, outdoor activities, and
vehicle maintenance. Its magnetic base and
back enable hands-free illumination on any
metal surface, while the side clip adds portability
for on-the-go convenience. Powered by a 400
mAh rechargeable battery with Type-C fast
charging, the Eco Glow Bolt ensures reliable,
efficient lighting whenever you need it.
Specifications
1. Lumens :
Low : 190 LM
Medium : 370 LM
High : 650 LM
2. Battery Capacity :
400 mAh Lithium-Polymer
3. Runtime :
Low : 4.5 hrs
Medium : 2 hrs
High : 1 hr
4. Charging Time : 1–2 hours
Material : Aluminium Alloy (Matte Finish)
Charging Port : Type-C
Package Contents
1 × Eco Glow Bolt Torch
1 × USB-C Charging Cable
1 × User Manual
Operating Instructions
2. To Power ON : Press the power button once.
3. To Change Modes : Each short press cycles
through the modes in sequence.
4. To Turn OFF:
Option 1: Long-press the button.
Option 2 (Quick-Off Function) : After 8 seconds of
lighting in any mode, press once to switch OFF
directly — no need to cycle through all modes.
Charging the Torch
• Pull open the rubber cover on the side to
expose the Type-C port.
• Plug the included USB-C cable into the torch
and connect the other end to a wall adapter.
• Indicator Light:
1. Red Light : Charging
2. Green Light : Fully Charged
• Charging Time: Approx. 1–2 hours.
Magnetic Mount
Built-in dual magnets — one at the base and one
at the back — allow easy hands-free attachment
to any metal surface (car hood, fridge,
workstation, etc.).
Clip Function
The side clip lets you easily attach the torch to a
pocket, belt, or bag strap for quick access on the
go.
Safety & Maintenance
• Charge only using 5V 1A adaptor.
• Do not disassemble or modify the product.
• Wipe the torch with a soft, dry cloth; avoid
chemical cleaners.
• Recharge at least once every 3 months when
not in use.
1. Light Modes :
The Eco Glow Bolt has 3 brightness levels:
a) Low (b) Medium (c) High
• Do not submerge in water or expose to rain for
long durations.
• Avoid looking directly into the light.
• Keep away from high heat or open flames.
