User Manual
E-Waste Management
For E-Waste & ROHS compliance
refer to www.portronics.com/ewaste
www.portronics.com
For Support
Visit : www.portronics.com
Email : [email protected]
Contact No. : +91 9555245245
(Working Hrs. : Monday - Saturday 10:00am - 6:00pm)
ð Portable Wireless Speaker 1 N
ð Charging Cable 1 N
User Manual 1 Nð
Package Contains
Product Details
Bluetooth Mode
1. Power Button
Long-press for Power On/Off.•
Activate Bluetooth of mobile phone and pair with the speaker.
2. Mode Button
Short-press to switch playing modes, Long-press to pair or•
disconnect TWS.
Technical Data
V5.3
ð
Bluetooth Version
2.75 inch*1
ð
Speaker Size
27mm*1
ð
Tweeter Size
14W
ð
Peak power output
3.7V, 2000mAh
ðð
Battery Capacity
80HZ-16KHZ
ð
Frequency Response
179*(L)*141(H)*77.5(W)mm
ð
Size
Resonate
14W Wireless
Bluetooth Speaker
1. Type-C Charging Jack
2. USB Port
3. Backward/Volume Down
4. Forward/Volume Up
5. Play/Pause
6. Mode Button (turn among Bluetooth, USB disk )
7. Power On/Off
3. Play/Pause
Short-press to play or pause, Long-press to disconnect and •
reconnect the Bluetooth connection with the mobile device fast
double-press to activate voice assistant function.
4. Backward/Volume Down
Short-press for volume down, Long-press for last song.•
5. Forward/Volume Up
Short-press for volume up, Long-press for next song.•
Note:
If your smartphone is disconnected from speaker due to shutdown
or switching mode, the speaker will automatically reconnect your
smartphone when it is turned on again or switched back to
Bluetooth mode.
TWS Mode
Turn on 2 identical speakers, both under BT mode.
Select one speaker and Long-press Mode button (for 2 seconds)
to start TWS function , the speaker will make a tone to start to pair,
and there will be a prompt tone again after paired successfully.
Connect the paired speaker with your phone via Bluetooth and
play wirelessly.
Long-press Mode button (for 2 seconds) again to disconnect
TWS.
1. Mode Button
Long-press to pair or disconnect TWS, Short-press to•
switch playing modes.
2. Play/Pause
Short-press to play or pause, Long-press to disconnect and •
reconnect the Bluetooth connection with the mobile device.
3. Backward/Volume Down
Short-press for volume down, Long-press for last song.•
4. Forward/Volume Up
Short-press for volume up, Long-press for next song.•
Note:
If TWS is disconnected from speaker due to shutdown or
switching mode, they will automatically reconnect when they
are turned on again or switched back to Bluetooth mode.
Sunset Lamp
You can switch below different modes of LED illumination
( include Off ) by Short-Press button
Mode 1: Sunset light on constantly
Mode 2: Green light on constantly
Mode 3: Purple light on constantly
Mode 4: Sunset light flash Breathing
Mode 5: RGB lights rhythm flash and follow the beat of playing
music.
The device will automatically enter mode 1 when powered on.
Hands-free call
1. Under Bluetooth connection status, if there is an incoming call,
user can short-press Play/Pause button to accept the
call or long-press Play/Pause button to reject the call.
2. During the call, user can long-press Play/Pause button
to switch to talking on the phone.
2. Short-press Play/Pause button to end the call.
Reset Functionality
1. Long-press button Volume Down for more than 5 seconds ,
device will power off. Meanwhile it will clear all Bluetooth & TWS
connection memory, and restore factory setting.
How to charge
1. The charger is not included in the package, please charge this
speaker via a rated 5V/2A charger.
2. Charge time should be around 3 hours.
3.To protect the battery, please do not use the speaker while it is
charging.
Warning
1. Please store and use this product in an environment of normal
temperature.
2. Please do not expose this product to rain or moisture environment.
3. Please do not disassemble, repair or modify this product by
yourself without authorization.
4. When cleaning this product, please use a soft cloth or with little
water if needed, please do not use chemicals for cleaning.
5. In order to have an extended product life and protect your hearing,
please avoid listening to songs on maximum volume for long time.
6. The product is with built-in lithium battery, to avoid dangers,
please do not discard or put it in the fire.
Specifications:
Features:
1. Bluetooth 5.3 for more stable , faster and stronger compatibility on
connection
2. Texture Portable Speaker with Sunset Lamp
3. Emitting Endless Comfort and Coziness
4. Multiple Sunset Lamp Modes
5. Leather handle for easy carrying
6. TWS function, achieve true wireless playing with double enhanced
stereo sound
7. With A2DP Bluetooth, wireless stream music from any Bluetooth-
enabled device
8. Hands-free Mic for easy picking up the call
9. Optimized voice assistant control
10. USB support
11. Built-in lithium rechargeable battery 2000mAh
USB Mode
1. Power Button
Long-press for Power On/Off•
2. Mode Button
Short-press to switch the playing modes•
3. Play/Pause
Short-press to play or pause•
4. Backward/Volume Down
Short-press for volume down, Long-press for last song•
5. Forward/Volume Up
Short-press for volume up, Long-press for next song•
Note:
Under any playing mode, when you insert a USB disk to the
speaker, it will switch to play the USB disk.
