User Manual
COOLCUBE
PORTABLE DESKTOP FAN
• Do not insert foreign objects into the fan when
using it to avoid damage to the product
• Do not use this product in a humid
environment (such as a bathroom). Contact
with water may result in Product failure or
damage.
• If the product accidentally enters water or
other liquid, immediately turn off the fan
power switch and let it Completely dry and
try again.
• Do not knock or beat this product. Repeated
strokes may cause internal damage.
• If you do not use this product for a long
time, do not store it in a place with high
temperature and high humidity.
• Do not disassemble, modify or repair this
product by yourself.
• Do not put the product into fire so as to avoid
danger of explosion.
• Do not use at temperatures above 60 degrees
Celsius.
Hands Up
Three Mode Of Speed
LED Lights
Type-C Charging Port
Charging and Operation Instructions
Charging: Use the provided cable to charge the
device under normal circumstances. Plug in the USB
cable to start charging. The first indicator light will
turn on to confirm the connection.
Operating the Fan
Press the power button once: The second indicator
light will turn on, and the fan will start at low
speed (first gear).
Press the button again: The third indicator light
will turn on, and the fan will switch to medium speed
(second gear).
Press the button once more: The fourth indicator
light will turn on, and the fan will operate at
maximum speed.
Product Parameters
Product Name : CoolCube
Product Model : POR 3051
Product Size : 200x200x66mm
Rated Voltage : 5V 1A
Rated Power : 5.5Wh
• If the product cannot be charged, replace
the charging head or charging cable and
try again.
• If the product is abnormally hot or deformed
during charging, stop immediately Charge
and contact customer center for processing.
• If liquid leakage occurs, the body inadver-
tently comes in contact with liquid.Seek
medical help. Do not continue using the
product.
