Model : AX160
160PSI
Air Compressor
Thank you for choosing ASPERX Air Compressor. To ensure a good user experience, personal
safety, and property security, please read all of the instructions carefully before using this
product, please keep this manual for reference.
Charge It First !
While reading through the manual, you can start to charge your AX160 with the wall charger.
WELCOME
1
2
PRODUCT OVERVIEW & PACKAGE
USB C 9V 2A
Input Port
Aerated
LCD Display
LED Flash Light
Light switch
Setting button
5V/2A Output Port
Power switch
Pressure increase
Pressure decrease
Operation Instructions
Battery Power:
1 Bar 2 Bars 3 Bars 4 Bars
0 Bar
ry Icon
Press the power button to check the battery power:
The battery icon will blink one by one during the period of charging. Different bars of battery
icon show different battery power, the battery icon becomes 4 bars when the charging
process was finished.
This unit can be charged with the type-c cable and wall charger(wall charger Not Included).
How to Charge the AX160
3
BATTERY LEVEL INDICATOR & CHARGING
4
KEY POINTS
160PSI Superfast Cordless air Inflator: The AX160 portable air compressor provides max pressure of
160 PSI and airflow of 35L/Min. When fully charged, 29PSI tires can be inflated to 36PSI in 1 minutes
(Testing data based on a flat standard tire 205/55/R14).Cordless lightweight design and comfortable
grip make it easy to carry.
7500mAh Ultra-big Battery Capacity: The AX160 electric tire pump built-in 7500mAh rechargeable
battery. It does not require an extra power supply while inflating and can provide a cordless continuous
inflation up to 45 mins. It can be also used as a power bank for your phone or other digital devices.
Ultra-large LED Screen: The AX160 Digital tire pump for car tires has a large LED digital display screen
with 3 pressure measurement units- PSI, KPA, BAR. Super bright LED with 2 lighting modes (lighting
and strobe) makes your car air pump suitable for roadside emergency and night time use.
4+N Smart Modes: 4 types of preset inflation modes (bicycle, motorcycle, car, and ball) are consider-
ate for beginners to choose. The manual mode allows you to set the pressure value (3-160psi) accord-
ing to the inflation object, easy to operate and meet your various inflation needs.
Auto Shut Off: The AX160 Electric air pump built-in pressure gauge and pressure preset function, this
air compressor will pump accurate amount of air and automatically stop inflating when the tire
pressure reaches to the preset value, offering you a safe, quick and reliable using experience.
3
5
4
2
1
45PSI
2.4BAR8PSI
2.5BAR
1. Long press the "power" button for 2 seconds so that the air inflator displays information on the
electrical configuration(1), preset tire pressure value (2), BAR, PSI & KPA (3), static air pressure
value(4), or icons of cars, SUVs, basketballs, bicycles or other inflatable items (5), The electric quantity
will be displayed on the bar (see the illustration above), and the charger will enter the to-be-inflated
mode.
2. Short press the lighting button to turn on the LED light, and the white light will remain on. Press the
switch button again, and the LED will enter the white flashing mode. Press again to turn off the light.
3. After the load is removed, the product automatically enters the dormant mode 30 seconds later.
4. When the product is in the standby mode or working normally, press the "Set" key to enter the
5
BUTTONS AND DISPLAY SCREEN
BUTTONS AND DISPLAY SCREEN
inflating pump editing mode, after which the SUV icon will display; at the same time, preset the tire
pressure value (unit: BAR), where you can short press the "+" "-" key to adjust the pressure value, or
long press the "Set" key to alter the unit (KPA, BAR or PSI); short press the "Set" key to switch the
item to be inflated until the car icon displays, and preset the pressure value (unit: BAR), before short
pressing the "+" "-" key to adjust the pressure value or long pressing the "Set" key to switch the unit
(KPA, BAR or PSI). Then short press the "Set" button until the bicycle icon and the preset air pressure
value (unit: PSI) are displayed; press the "Set" button again to adjust the air pressure value, and long
press the "Set" button to switch the unit (KPA, BAR or PSI). Press the "Set" button again to display
the basketball icon and the preset air pressure value (unit: PSI); short press the "+" and "-" button
again to adjust the air pressure value. Long press the "Set" key to switch units between KPA, BAR
and PSI under the free mode.
5. While choosing the mode for the inflating pump for SUVs, cars, bicycles or basketballs, icon 4 will
display the preset tire pressure value. Note that the preset value serves as reference only, and
please adjust in accordance with the actual situation.
The preset values for different inflatable items are(see the illustration above):
SUVs: 2.5 BAR=36 PSI=248 KPA
Cars: 2.4 BAR=35 PSI=241 KPA
Bicycles: 3 BAR=45 PSI=310 KPA
Basketballs: 0.5 BAR=8 PSI=55 KPA
6
Long press the light switch button to turn on the LED light, the white light will stay on after
pressing the switch button again, the LED will enter the white light flashing, and then press to
turn off the light.
BUTTONS AND DISPLAY SCREEN
Please switch the unit accordingly on the left. Only one unit can be displayed for each item.
6. While charging, the bars at the battery icon will flash in accordance with the actual level of
remaining battery life.
7. When a product’s remaining battery life falls below 10%, the corresponding indicator will flash.
7
8
BUTTONS AND DISPLAY SCREEN
9
TECHNICAL SPECIFICATION
Model
Battery Capacity
Dimensions
Inflation Pressure Range
Length of air hose
Working Noise
lnput
Operating Temperature
Output
Input Port
Output Port
Charging Time
Sensor Accuracy
AX160
27.75Wh
187mm*70mm*70mm
4-160psi
500mm
Lower than 80dB within 1 meter
5V 2A, 9V 2A Max 18W
-20-60 ºC/ -4-140ºF
5V 2A Max 10W)
USB Type-C
USB-A
about 2h
±2psi
---
---
---
Q1: What is the operating temperature of this unit and how to store it?
A: This unit is lithium polymer battery, operating temp is -20-60 ºC/ -4-140ºF. If the ambient
temperature is higher than 60ºC/140ºF, the internal construction of the battery cells may be
damaged, it may swell and become unsafe. So don’t store the device in vehicle which parked
in hot weather for long periods of time.
Q2: What should I do if this unit can’t charge up?
A: Charge it with a usb-c cable and wall charger for a full overnight period. If it still does
not work, contact us at: [email protected] ( Attach your order ID).
Q3: What should I do if this unit can’t charge other devices?
A: Try to charge the device with another charging cable, If it works, which means the charging
cable we provided is defective, we will provide you a new one; If it still does not work, please
email us at: [email protected] ( Attach your order ID).
10
FAQ
Q4: Can this unit charge other devices while it is being charged?
A: Yes.
Q5: How often does this unit need to be recharged?
A: It would be best to recharge it every 3 months.
Q6: Why it shuts off in 30s when charging other devices?
A
This unit may shut off automatically when charging for the devices that need light
charging current, such as headphone, smart watch,etc since there is minimum load current
limitation (200mA) on this unit, it will be automatically off after 30s if the load current is less
than 200mA.
11
FAQ
1. Please read this user manual carefully before using this machine.
2. Please be careful when using this machine. If you do not follow the instructions, you may
injure yourself or damage the equipment or vehicle battery.
3. Do Not allow people who do not have proper knowledge or ability to operate the device
without supervision.
4. Do Not use this unit as a toy. Keep it away from children to avoid accident.
5. Do Not use this unit when any cable, clamp, or cord was damaged or when this unit was.
6. Don't over-discharge the unit (don't let the battery run out), charge it regularly, it would
be best to recharge it every 3 months.
7. Do not operate this product in an explosive environment, such as a place where flammable
liquid, gas or dust exists.
8. Do Not let the product be immersed in water.
To protect the motor, when the temperature of the electric core is higher than 55 ° C, it
will stop working, and when the temperature drops to 45 ° C, it will restart working.
The Air Inflator's air hose may get very hot after inflating. To prevent injuries, exercise
caution when disconnecting it from a valve.
12
WARNING
10. Do not modify or disassemble this machine. Only service technicians can repair this
equipment.
11. Do not expose the product to extreme heat or fire.
12. Do not drop or squeeze the device. If the device is hit hard or damaged in any other way,
it should be inspected by a qualified battery technician.
13. Do not store in places where the temperature may exceed 60ºC/140ºF.
14. Only charge at ambient temperature of -10~45ºC/14~113ºF.
15. Under extreme conditions, the battery may leak. If there is a liquid leak from the device,
do not handle it with bare hands. If there is skin contact, wash immediately with soap and
water. If the liquid accidentally touches the eyes, immediately rinse the eyes with water for
at least 10 minutes and seek medical help.
16. The device contains a lithium battery. At the end of the product's service life, or if the
device leaks liquid, dispose of the device according to local regulations.
13
WARNING
9. Do not operate this product in an explosive environment, such as a place where flammable
liquid, gas or dust exists.
Within 18 months, we will provide timely and effective online after- sales service after your
purchase
18 Months Online After- Sales Service
Within the first 30 days after your purchase, you can apply return for it through Amazon
when you have any product issue.
30 Days Money Back Guarantee
We will replace the defective unit due to manufacturing issues with a new one within 18
months.
30 Days to 18 Months
Your Warranty Includes
Disclaimer
A. When the product needs to be repaired or replaced, the original purchaser should show
the original receipt (order ID), and the warranty will take effect.
14
WARRANTY AND SUPPORT
B. The warranty does not cover damage or product failures caused by normal wear and tear,
physical abuse, improper installation, misuse, modification, or unauthorized third-party
repairs.
C. We are not responsible for any accidental or indirect damage caused by incorrect use or
misuse of this product.
D. All warranty claims are limited to repair or replacement of the defective product and at the
sole discretion of ASPERX.
15
WARRANTY AND SUPPORT
Do Not Place Near or Into Fire
Avoid Extreme Temperatures
Do Not Drop
Do Not Disassemble
Do Not Submerge In Water
16
ATTENTION
18 Months Limited Warranty Service
Lifetime Technical Service
Feel Free to Contact Us
For FAQ and More Information
17
CUSTOMER SERVICE
18
THANK YOU
Distributor ：
Distributor Address ：
Manufacturer ：
Shenzhen Jiahongjing Technology Co.,Ltd.
2307 Block A, Zhantao Technology Build., Crossing of Minzhi Rd and Gongye
East Rd, Xinniu Comty, Minzhi Str., Longhua Dist., Shenzhen, China.518110
Shenzhen Carku Technology Co.,Limited
Manufacturer Address ：
No.103, block A, Qixing Creative factory, GaoFeng community, Dalang street,
LongHua, Shenzhen.
After-sales service E-mail ：
Name ：
Air Compressor
Model No ：
AX160
Trademark ：
AsperX
Name ：
GSG CONSULTING GROUP LIMITED
Address ：
Unit 3 Matthew street Gorton Manchester
E-mail ：
Manufacturer Information
Product Information
UK-Representative Information
UK REP
Distributor ：
Distributor Adresse ：
Manufacturer ：
Shenzhen Jiahongjing Technology Co.,Ltd.
2307 Block A, Zhantao Technology Build., Crossing of Minzhi Rd and Gongye
East Rd, Xinniu Comty, Minzhi Str., Longhua Dist., Shenzhen, China.518110
Shenzhen Carku Technology Co.,Limited
No.103, block A, Qixing Creative factory, GaoFeng community, Dalang street,
LongHua, Shenzhen.
Manufacturer Adresse ：
After-sales service E-mail ：
Name ：
Air Compressor
Modell ：
AX160
Markenzeichen ：
AsperX
Name ：
AMZLAB GmbH
Adresse ：
Laubenhof 23, 45326 Essen，Germany
E-mail ：
LUCID-Reg.-Nr. :
DE5563631458912
Herstellerinformationen
Produktinformation
EU-Bevollmächtigter
EC REP
WEEE-Reg.-Nr. DE 84758543
Made in China
