MANUALPWX-3200s
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have questions or need assistance, please call customer service at
+1 (689) 888-7131 or service email: [email protected]
1
TABLE OF CONTENTS
Introduction..........................................................................................................................................2-3
Safety.....................................................................................................................................................4-7
Electrical....................................................................................................................................................8
Components.............................................................................................................................................9
Assembly............................................................................................................................................10-12
Operation...........................................................................................................................................13-15
Care and maintenance....................................................................................................................16-17
Troubleshooting.....................................................................................................................................18
Warranty..................................................................................................................................................19
INTRODUCTION
2
WARNING
This product and other substances that may become
airborne from its use contain chemicals, including
lead, known to the State of California to cause
cancer, birth defects, or other reproductive harm.
Wash hands after handling. For more information go
to www.P65warnings.ca.gov.
DISCLAIMERS
ALL RIGHTS RESERVED
UPDATES
PRODUCT REGISTRATION
For Your Records
Date of Purchase:
Model Number:
Serial Number:
Amazon Order Number:
For trouble-free warranty coverage, it is important
to register your AIVOLT product.
You can register by:
• Registering your product on-line
at
aivolt group.com/pages/warranty-registration.
• Scanning the above QR code with your smart-
phone camera to be directed to the mobile regis-
tration link.
All information, illustrations, and specifications in
this manual were in effect at the time of publishing.
The illustrations used in this manual are intended as
representative reference views only. We reserve the
right to make any specification or design change
without notice.
The latest User Manual for your AIVOLT products
can be found under our support tab, https://www.ai-
voltgroup.com/manuals. Or scan the following QR
code with your smartphone camera to be directed to
the link.
All rights reserved. No reproduction allowed in any
form without written permission from AivoltGroup
Limited Company.
DANGER
!
Read this manual before using or
performing maintenance on this product.
Failure to follow the instructions and
safety precautions in this manual can
result in serious injury or death.
IMPORTANT: Keep your purchase receipt for
trouble-free warranty coverage.
!
INTRODUCTION
HAVE QUESTIONS?
Email us at [email protected]
or call +1 (689) 888-7131
3
NOTICE
WARNING
!
NEVER spray directly at a person, animal, electrical
device, or the unit itself. Failure to heed this warning
could result in serious injury, electric shock, or
death.
NEVER allow the pressure washer pump to run for
more than one minute after you have turned off the
water supply. This can cause the motor and pump to
overheat and fail. ALWAYS unwind the garden hose
completely and remove any objects that may be
restricting or preventing the flow of water to the
machine.
NOTICE
SPECIFICATIONS
Water Temperature
Peak Pressure
Rated Pressure
Maximum Water Flow Rate
Rated Water Flow Rate
Phase
Input
PWX-3200s
Cold Water Only
2400 PSI
1800 PSI
1.76 US GPM (5.3 LPM)
1.24 US GPM (4.7 LPM)
Single
120V AC, 60Hz, 13A
Thank you for choosing AIVOLT! PLEASE READ
BEFORE RETURNING THIS PRODUCT FOR ANY
REASON.
If you have a question or experience a problem with
your AIVOLT purchase, call us at +1 (689) 888-7131
or contact us customer service email:
[email protected] to speak with an agent.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
SAFETY SYMBOLS
Symbol
Description
Safety Alert Symbol
Risk of Injection.
Do Not Operate in Wet
Conditions
Electric Shock
Read Manufacturer's
Instructions
Kickback
Double-insulated construction
Wear Eye and Hearing Protection
SAFETY
4
SAFETY DEFINITIONS
WARNING
!
CAUTION
!
DANGER
!
The words DANGER, WARNING, CAUTION, and
NOTICE are used throughout this manual to
highlight important information. Make sure that the
meaning of this safety information is known to
everyone operate, perform maintenance on, or are
near the pressure washer.
Indicates a hazardous situation which, if not avoid-
ed, will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a situation which can cause damage to the
pressure washer, personal property, and/or the envi-
ronment, or cause the equipment to operate improp-
erly.
Follow all safety information contained in this user's
manual as well as the information on the product
labeling.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE
NOTE: Indicates a procedure, practice or condition
that should be followed for the pressure washer to
function in the manner intended.
This safety alert symbol appears with
most safety statements. It means atten-
tion, become alert, your safety is
involved! Please read and abide by the
message that follows the safety alerts
symbol.
Risk of Explosion. Never spray flam-
mable liquids. Flammable liquids and
their vapors can be explosive.
SAFETY
IMPORTANT SAFETY
INSTRUCTIONS
KEEP THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
5
WARNING
!
To reduce the risk of injury, the user must read and
understand the instructions before using this
product.
WARNING
!
Risk of liquid injection. Never spray humans or
animals, as injury could result. Engage trigger lock
when the pressure washer is not in use.
WARNING
!
When using this product, basic precautions should
always be followed, including the following:
• ALWAYS take time to read all the instructions
before using the product.
• It is recommended to carefully read and under-
stand all operating aspects of the pressure
washer outlined in this manual to avoid personal
injury and/or damage to property and to maxi-
mize your pressure washing experience.
• Understand and know how to safely stop the
product and bleed pressures quickly. Be fully
familiar with all controls.
• Follow the maintenance instructions as speci-
fied in the manual.
• DO NOT use your pressure washer when you
are under the influence of alcohol or drugs. Use
this power tool carefully and only when you are
alert.
• Keep operating area clear of all people, animals,
and hazardous objects.
• DO NOT overreach or stand on unstable
support. Keep good footing and balance at all
times.
• The pressure washer is equipped with a Ground
Fault Circuit Interrupter (GFCI) which greatly
reduces the chance of electric shock while the
unit is in use. If replacement of the plug or cord
is needed, use only identical replacement parts.
GROUND FAULT CIRCUIT INTERRUPTER
PROTECTION
This pressure washer has a ground-fault circuit-in-
terrupter (GFCI) built into the plug of the power-sup-
ply cord. A GFCI provides additional protection from
the risk of electric shock. If replacement of the plug
or cord is necessary, use identical replacement parts
that include GFCI protection.
SERVICING OF A DOUBLE-INSULATED
APPLIANCE
In a double-insulated product, two systems of insu-
lation are provided instead of grounding. Grounding
means are not provided for a double-insulated prod-
uct, nor should grounding means be added to the
product.
A double-insulated product is marked with the
words 'DOUBLE INSULATION' or 'DOUBLE INSULAT-
ED'. This symbol may also be marked on the product.
• Failure to read and follow the instructions in the
user manual(s) could result in death, bodily
injury, and/or property damage.
• When using the pressure washer near children,
make sure they are closely supervised by an
adult to avoid injury. NEVER let a child use the
pressure washer.
• This pressure washer conforms to CSA and other
safety and consumer standards. DO NOT modify
or rebuild any part of your pressure washer.
• Watch your balance and footing while using your
pressure washer. Surfaces become slippery
when wet and are extra slippery when using a
detergent or cleaner.
• NEVER operate the pressure washer in bare
feet, sandals, or open-toed shoes.
• DO NOT touch the high-pressure spray with
your fingers, hands, feet, and be careful to avoid
any contact with your eyes as the powerful
spray can cause blindness or blast holes in the
skin.
• ALWAYS wear eye protection to prevent injury
to eyes when operating the pressure washer.
SAFETY
6
• To avoid accidents causing injury,ALWAYS use
the trigger safety lock when the pressure washer
is not in use even if the spraying stops for a
moment.
• Point the spray gun in a safe direction when
beginning to use your pressure washer.
• NEVER spray directly at a person, animal,
electrical device, or the unit itself. The pressure
washer can break glass if hit with direct contact.
• Hold the spray gun and lance with both hands
(one hand to pull the trigger and the other to
stabilize the gun) until you get used to the
'recoil'.
• When you stop the pressure washer, water
pressure may remain in the system. To release
the pressure, point the spray gun in a safe direc-
tion and pull the trigger.
• NEVER spray flammable liquids.
• NEVER use the pressure washer in areas that
contain combustible dust, liquids, or vapors.
• Examine the hose regularly. Replace it if
damaged. Due to the high pressure involved, it
cannot be repaired if cut or damaged.
• Only use detergent specifically formulated for
pressure washers and follow the instructions
on the detergent’s label.
• Detergent can be harmful to your skin, eyes,
and lungs. Please be cautious when handling
any chemicals. Dish and laundry soap are too
thick and will clog the nozzle of your detergent
bottle.
• NOTE: Store the pressure washer indoors in a
heated environment to prevent the water in the
unit from freezing and expanding.
• When the water freezes and expands, the
high-pressure pump will crack and render the
pressure washer inoperable. It is recommended
you use pump saver (not included) to protect
pumps from freezing and cracking.
• NEVER use hot water with your pressure
washer. It will overheat and damage the seals
and components in the high-pressure pump
that cannot be repaired.
SAFETY LABELS AND DECALS
SAFETY
7
The following information is on your pressure washer’s
labels and decals.
Risk of Electrocution
• Inspect cord before using. Do not use if the cord
is damaged.
• Keep all connections dry and off the ground.
• Do not touch the plug with wet hands.
• Double Insulated - when servicing use only iden-
tical replacement parts.
• This product is provided with a ground fault
circuit interrupter built into the power cord plug.
If replacement of the plug or cord is needed, use
only identical replacement parts.
• Read instruction manual before using.
Refer to the 'EZ Start Instructions' label and the
instructions in the Operations section when starting
and stopping the pressure washer.
• Use only pressure washer detergents.
• Inlet water - Cold Tap Water.
(See Page 4)
2
4
5
6
7
Cancer and reproductive harm -
www.P65Warnings.ca.gov/product
(See Page 7)
• Failure to read and follow the instructions in the
user manual(s) could result in death, bodily
injury, and/or property damage.
• ALWAYS point the gun in a safe direction and
squeeze spray gun trigger to release pressure
and avoid kickback each time.
• The spray gun kicks back- Hold firmly with two
hands.
• Risk of liquid injection. Never spray humans or
animals, as injury could result. Engage trigger
lock when the pressure washer is not in use.
• Risk of eye injury. Always use caution. Wear
safety googles with side shields.
• Risk of electrocution. Never spray water on any
electric power sources.
• Do not store the machine or accessories in a
place where the temperature could drop below
40°F (4.5°C).
3
AVERTISSEMENT:
RISQUE D'ÉLECTROCUTION
1. VÉRIFIEZ LE CORDON AVANT UTILISA
TION, N’UTILISEZ PAS SI LE CORDON EST
ENDOMMAGÉ.
2. MAINTENEZ TOUTES LES CONNEXIONS
SÈCHES ET HORS DU SOL.
3. NE TOUCHEZ PAS LA PRISE AVEC LES
MAINS MOUILLÉES.
4. DOUBLE ISOLATION - LORS DE L’ENTRE
TIEN, UTILISEZ UNIQUEMENT DES PIÈCES
DE RECHANGE IDENTIQUES.
5. CE PRODUIT EST ÉQUIPÉ D’UN
DISJONCTEUR DIFFÉRENTIEL (GFCI)
INTÉGRÉ DANS LA PRISE DU CORDON
D’ALIMENTATION. SI UN REMPLACEMENT
DE LA PRISE OU DU CORDON EST
NÉCESSAIRE, UTILISEZ UNIQUEMENT
DES PIÈCES DE RECHANGE IDENTIQUES.
6. LISEZ LE MANUEL D’INSTRUCTIONS
AVANT UTILISATION.
5. ESTE PRODUCTO ESTÁ EQUIPADO CON
UN INTERRUPTOR DE CIRCUITO POR
FALLA A TIERRA (GFCI) INCORPORADO
EN EL ENCHUFE DEL CABLE DE
ALIMENTACIÓN. SI ES NECESARIO
REEMPLAZAR EL ENCHUFE O EL CABLE,
USE ÚNICAMENTE PIEZAS DE REPUESTO
IDÉNTICAS.
6. LEA EL MANUAL DE INSTRUCCIONES
ANTES DE USARLO.
ADVERTENCIA:
AIVOLT
DO NOT REMOVE THIS TAG
NO RETIRE ESTA ETIQUETA
NE RETIREZ PAS CETTE ÉTIQUETTE
1
DOUBLE INSULATION
ELECTRICAL
8
NOTICE
Double insulation eliminates the need for a
three-wire grounded power cord. Double insulated
products do not need to be grounded because
exposed metal parts are covered in protective insu-
lation that isolates them from internal metal motor
components.
A double-insulated system is designed to protect
against shock caused by a break in the product's
internal insulation. To avoid electric shock, follow all
ordinary safety procedures.
NOTE: Double-insulated products should only be
serviced by qualified service technicians. For more
information, please contact us customer service
email [email protected]
WARNING
!
AC MOTOR
GROUND FAULT CIRCUIT
INTERRUPTER PROTECTION
To test the GFCI:
The electric motor in this product was designed to
work with a nominal 120V/60Hz AC power supply
(average U.S. household circuit). It is not intended to
operate on direct current (DC). A significant voltage
drop will result in a loss of power and could damage
the motor.
See Figure 1
This pressure washer has a ground-fault circuit
interrupter (GFCI) built into the plug of the
power-supply cord. A GFCI protects against ground
fault currents such as a current that would flow
through a person standing on a wet surface while
holding a product with faulty insulation. GFCI plugs
do not protect against shocks, short circuits, and
overloads. If replacement of the plug or cord is
necessary, use identical replacement parts that
include GFCI protection.
• Plug the power supply cord into a receptacle.
• Press the TEST button and listen for a 'click'
indicating that the connection to the power
supply was broken.
• Press the RESET button to restore power to the
device. The LED light will turn on when power is
restored. Test the GFCI monthly to ensure
proper operation.
FIG. 1
A - RESET Button
B - TEST Button
A
B
or call +1 (689) 888-7131
COMPONENTS
9
FIG. 2
UNDERSTANDING YOUR
PRESSURE WASHER
See Figure 2
To reduce the risk of injury and product failure, read
and understand the information in this user’s manual
as well as the information on the product labeling.
CORD RETAINER
When not in use, wrap the power cord and hang it on
the side of the pressure washer.
HANDLE
Use the handle when transporting the unit.
HIGH PRESSURE HOSE
The high-pressure hose included with this unit is
lightweight, flexible, and durable. When not in use,
the hose can be stored on the hose retainer.
NOZZLES
Nozzles of varying sizes are included with this unit
and can be used for different cleaning applications.
Foam Cannon
Use the foam cannon to add detergent.
SPRAY GUN
Use the spray gun and lance to control and direct the
stream of water.
START/STOP BUTTON
Push once to start the pressure washer. Push again
to stop the pressure washer.
A
B
C
D
E
- Lance
- Spray Gun
- Nozzle Kit
- Water Outlet
- Wheel
F
G
H
I
J
- Start/Stop Switch
- Handle
- High-Pressure Hose
- Power Cord Hook
- Power Cord
K
L
M
- Water Inlet
- Foam Cannon
- Accessory Hook
A
B
C
E
M
L
K
G
H
I
J
F
D
ASSEMBLY
10
REMOVING CARTON CONTENTS
Do not connect the pressure washer to a power
supply until it is fully assembled. To avoid accidental
starting and possible serious injury, only connect a
power supply when the pressure washer is ready for
use.
WARNING
!
WARNING
!
This product requires assembly. Do not attempt to
operate this product if any items in the INCLUDED
LIST are already assembled when you remove the
carton contents. These items are not assembled by
the manufacturer and should require customer
assembly. Using an improperly assembled product
can be hazardous and could result in serious
personal injury.
• Carefully cut down the sides of the packaging
and remove the carton contents.
• Inspect the carton contents. verify that all the
items in the INCLUDED LIST are present and
undamaged.
• Recycle or dispose of the packaging materials
properly.
ASSEMBLING THE PRESSURE
WASHER
See Figures 4-8.
• Hold the pressure washer unit at a slight angle.
• Push the casters into the slots at the base of the
pressure washer until they snap into place.
• Make sure the casters are secure, then return
the unit to a fully upright position.
• Align the tabs on the upper- and lower-gun
holsters with the slots on the side and bottom of
the pressure washer. Slide the holsters into
place.
• Attach the hook to the back mounting holes and
tighten the screws securely.
FIG. 4
A - Slot
B - Caster
C - Screw
A - Upper Gun Holster
B - Lower Gun Holster
FIG. 5
FIG. 3
A
FIG. 6
A - Hose Retainer
- Spray Gun
- Foam Cannon
- Lance
- Nozzle Kit
- Gun Holster
- Gun Rack Storage
- Accessory Hook
- High-Pressure Hose
- Power Cord Hook
- Wheel
- Screwdriver
- Screw*6
- Pressure Washer
A
B
C
D
E
F
G
H
I
J
K
L
M
A
B
C E M
LK
G
H
I
J
F
D
A
C
B
A
B
ASSEMBLY
CONNECTING THE LANCE TO THE
SPRAY GUN
CONNECTING THE LANCE TO THE
SPRAY GUN
CONNECTING THE HIGH-PRESSURE
HOSE TO THE PRESSURE WASHER
See Figure 10
• Install the wire clip following the direction of
the slot.
• Repeat these steps to install the hose retainer
on the back of the unit and the cord retainer on
the side opposite the holsters.
• If desired, place the nozzles, spray gun, lance,
and power cord in their storage areas.
• Push the lance into the spray gun and turn
clockwise to tighten. Do not overtighten.
• Gently pull on the lance to be certain it is
secured.
See Figure 8
• Pull the collar on the high-pressure hose back
and push the hose fitting firmly into the spray
gun.
• Screw the collar onto the spray gun and tighten
securely.
A - Threaded Outlet
B - High Pressure Hose
FIG. 10
NOTE: Be careful not to damage the threads on the
spray gun doing so could cause the gun to leak during
use.
• Gently pull on the hose to be certain it is secured.
11
FIG. 7
A - Nozzles
B - Gun Holster
C - Spray Gun
FIG. 8
A - Spray Gun
B - High Pressure Hose
C - Collar
FIG. 9
See Figure 9
B
B
A
B
C
A
B
C
B
A
• Straighten and untangle the high-pressure hose
to remove any kinks or twists.
• Take the quick-connect end of the hose and
align it with the outlet on the machine.
• Firmly push the connector into the machine’s
outlet until it clicks into place.
Note: After connection, gently pull on the hose to
make sure it is securely attached.
ASSEMBLY
NOTICE
CONNECTING A GARDEN HOSE TO
THE PRESSURE WASHER
See Figure 11
A - Water Inlet
B - Garden Hose
FIG. 11
Follow local regulations and ordinances when
connecting your pressure washer to a water supply.
Some jurisdictions may prohibit you from connecting
directly to public drinking water in order to prevent
the possibility of chemicals feeding back into the
system. Connections made through a backflow
preventer or receiver tank are generally permitted.
NOTICE
The water used in this device must come from a
water main. DO NOT use this device with water from
a lake, pool, pond, etc. NEVER use hot water with
this product.
• Turn the water faucet completely off.
• Uncoil and straighten the garden hose to remove
any bends or kinks.
• Flush water through the hose for several
seconds to remove debris and then turn the
faucet off again.
• Inspect the screen inside the water inlet for
damage or clogs. Clean or replace as needed.
NEVER connect a garden hose without the
screen in place.
• Insert the garden hose into the water inlet.
• Thread the collar on the inlet onto the garden
hose. Tighten securely.
NOTICE
ALWAYS turn the water supply “ON ” before turning
the pressure washer power to “ON”. Running the
pump dry of water will cause damage to the internal
components and render the pressure washer inop-
erable.
OVERVIEW
This pressure washer can produce very high levels of
water pressure and can be used for a variety clean-
ing applications such as cleaning decks and walk-
ways, washing vehicles and equipement; and remov-
ing dirt from home exteriors and fences.
12
B
A
OPERATION
STARTING AND STOPPING THE
PRESSURE WASHER
See Figure 12
FIG. 12
A - Start/Stop Switch
• Connect a garden hose as described previously
and turn the water on.
NOTICE: ALWAYS turn the water supply “ON” before
turning the pressure washer power to “ON”. Running
the pump dry of water will cause damage to the
internal components and render the pressure
washer inoperable.
• Connect a garden hose and turn the water on.
• Completely unwind the power cord and connect
it to a grounded 120-volt outlet.
WARNING
!
Do not alter or modify this product unless instructed
to do so in this manual or by the manufacturer. Do
not use attachments or accessories that are not
recommended for use with this product. Making
unauthorized modifications and using incompatible
accessories can damage the unit and may void your
warranty.
WARNING
!
WARNING
!
NEVER spray directly at a person, animal, electrical
device, or the unit itself. Failure to heed this warning
could
WARNING
!
Keep all connections dry and off ground. Do not
touch the plug with wet hands.
ALWAYS wear eye protection to prevent injury to
eyes when operating the pressure washer.
13
USING THE SPRAY GUN
See Figure 13
WARNING
!
Hold the spray gun and lance with two hands (one
hand to pull the trigger and the other to stabilize the
gun) until you get used to the 'recoil'. Do not lose
control of the spray gun doing so could result in
injury to yourself and others.
• Start the pressure washer.
• Release the safety lock by pushing it down into
the slot in the trigger.
• Squeeze and hold the trigger to start the flow of
water.
• Release the trigger to stop the flow of water.
• Lock the trigger by pushing it up to its original
position.
NOTE: Squeeze the trigger to make sure it’s locked
and will not move. ALWAYS keep the spray gun
locked when it’s not in use.
• Hold the spray gun with both hands and point
the lance in a safe direction.
• Turn the switch clockwise/counterclockwise
once to start/stop the pressure washer. The unit
will run for several seconds and shut off. This is
a normal function of the auto-start feature.
NOTE: The unit could be pressurized even if you
don’t hear the motor and pump running. Always be
cautious when you are around a pressure washer.
• Turn the switch clockwise/counterclockwise
again to stop/start the pressure washer.
• When you stop the pressure washer, water pres-
sure may remain in the system. Point the spray
gun in a safe direction and pull the trigger to
release the water pressure.
FIG. 13
A
OPERATION
NOZZLE GENERAL USE
See Figure 15
FIG. 15
INSTALLING NOZZLES
See Figure 14
A - Nozzle
B - Lance
C - Quick-Connect Lance Coupler
D - Install Nozzle Vertically
E AND F - Pull Back the Quick-Connect Lance Coupler to
Remove the Nozzle
WARNING
!
ALWAYS turn off the pressure washer, release the
pressure in the spray gun, and lock the trigger
before removing or installing a nozzle. NEVER point
the lance at your face. Failure to heed this warning
could result in serious injury.
• Stop the pressure washer and turn the water
faucet completely off.
• Point the spray gun in a safe direction and pull
the trigger to release the water pressure.
• Lock the trigger.
• Push the nozzle into the lance until it clicks into
place and is secure.To remove the nozzle, pull
the collar back and move the nozzle away from
the lance.
FIG. 14
D
E
F
C
B
A
• Turn to open the top of the soap bottle nozzle,
slowly pour in the detergent, and then tighten it
securely.
• Attach the soap bottle nozzle to the spray gun.
• Turn the water on and start the pressure
washer.
• Squeeze the trigger and wait several seconds
for detergent to appear in the water stream.
• Start cleaning at the bottom of the surface and
work your way up in a side-to-side motion. Do
not allow soap to dry on the surface being
cleaned.
14
NOZZLE GENERAL USE
0°（Red）
15 °（Yellow）
25°（Green）
40°（Gray）
High Pressure. Use to clean
concrete, remove tough
stains,and strip paint. Use
with caution.
Moderate pressure. Safe to
use on brick and paved
patios.
Low Pressure. Safe for cars,
windows and decks.
OPERATION TIP
FIG. 16
• Fill the soap bottle with a properly formulated
detergent-to-water ratio, following the deter-
gent manufacturer’s instructions.
NOTE: Use detergents designed for pressure
washers. The detergent should be the consistency
of water. DO NOT use thick, gel-like detergents, as
they will clog the pressure washer and may cause
damage.
See Figure 16
FIG. 17
See Figure 17
OPERATION
OPERATING TIPS
• Stop the pressure washer and turn the water
faucet completely off.
• Point the spray gun in a safe direction and pull
the trigger to release the water pressure.
• If installed, remove the soap nozzle.
• Install an appropriate nozzle for the task you
are performing.
• Turn the water on and start the pressure
washer.
• Release the safety lock and begin pressure
washing by squeezing the trigger all the way
into the handle.
NOTE: Always test in a small inconspicuous area to
avoid or reduce damage.
• Start cleaning at the bottom of the surface and
work your way up in a side-to-side motion.
• It is normal to hear the motor run intermittently
when the trigger is not being squeezed. The
pump is priming itself to operate when the
trigger is squeezed again.
• To avoid damaging surfaces:
+ Always use an appropriate nozzle.
+ Reduce water pressure by adjusting the angle
of the stream or by increasing the distance
from the nozzle to the surface.
• Always spray detergent on a dry surface.Do not
pre-soak the surface. Wetting the surface first
dilutes the detergent and reduces its cleaning
ability.
• For tough stains, it may be necessary to reapply
the detergent and use a bristled brush to scrub
the stain.
15
• Release the trigger to stop the pressure washer.
• Allow the motor to come to a complete stop
before squeezing the trigger again.
NOTE: Squeezing the trigger rapidly may cause the
auto-start feature to miss an on/off cycle and may
prevent the washer from turning on. Use slow,
deliberate trigger pulls to avoid this.
• When you are finished, remove excess deter-
gent from the soap bottle and fill it with clean
water. Spray the water through the soap nozzle
to flush the system.
CARE AND MAINTENANCE
CLEANING THE PRESSURE
WASHER
CLEANING THE NOZZLES
See Figure 18
A - Nozzle Cleaning Tool
B - Turbo Nozzle
WARNING
!
WARNING
!
ALWAYS turn off the pressure washer, release the
pressure in the spray gun, and unplug the pressure
washer before performing maintenance.
Replace damaged or worn items with recommended
or equivalent replacement parts. Using an incorrect
or incompatible part might create a hazard that
could result in serious personal injury.
FIG. 18
FIG. 19
NOTICE
Check the physical condition of the product prior to
each use. Look for loose bolts, fluid leaks, and other
signs of wear. Replace all damaged items. For
replacement parts or assistance, contact our
customer service team.
To prolong the life of this product, follow the care
and maintenance instructions in this section. Con-
tact customer service before servicing any recall or
warranty parts.
• Stop the pressure washer and turn the water
faucet completely off.
• Release the pressure in the spray gun and
unplug the pressure washer.
• Remove the nozzle from the spray gun.
• Use a nozzle cleaning tool or fine needle to
clean debris from the inside of the nozzle.
• Using a garden hose, back flush water through
the nozzle.
• When the nozzle is clean, place it back on the
lance or in the nozzle storage area.
CLEANING THE WATER INLET
SCREENS
See Figure 19
Do not store or operate your pressure washer in
dirty, dusty, or corrosive environments. Do not allow
foreign materials and debris to clog the vents on the
unit.
NEVER clean the pressure washer with a garden
hose. Water can damage the pressure washer’s elec-
trical components. If the unit needs to be cleaned,
use a soft brush and damp cloth to clean the exterior
and use low-pressure air (no greater than 25 psi) to
clean the vents.
Never use gasoline as a cleaning agent.
16
The screens inside the garden hose adapter should
be cleaned periodically. Remove the screens, rinse
them with clean water, and place them back in the
inlet.
A - O Ring
B - Water Inlet Filter Screen
A
B
A
B
CARE AND MAINTENANCE
WARNING
!
Do not use attachments or accessories that are not recommended for use with this
product. Making unauthorized modifications and using incompatible accessories can damage the unit and void
your warranty.
STORAGE
NOTE: Use commercially available pump protectors to extend the life of the pump. Follow the manufacturer’s
instructions for use.
• Release the pressure in the spray gun and unplug the pressure washer. Wrap the cord around the cord
retainer.
• Remove the garden hose and store it properly. Tilt the pressure washer to allow excess water to drain
from the inlet.
• Remove all nozzles and place them in the nozzle storage area.
• Disconnect the high-pressure hose and wrap it around the hose retainer.
• Disassemble the spray gun and lance and place them in the gun holsters.
• Store the pressure washer in a dry, covered location away from extreme heat which could dry out the
pump seals and extreme cold which could cause freeze damage.
Maintenance parts can be purchased directly from the factory. A partial list of maintenance parts is below. For
a complete list of maintenance parts or for additional information email us at [email protected]
or call +1 (689) 888-7131
CARE AND MAINTENANCE
17
Inlet Filter
Foam Cannon
0° Nozzle
15° Nozzle
25° Nozzle
40° Nozzle
70009-00860-00
70010-04486-00
34036-00218-00
34036-00219-00
34036-00220-00
34036-00221-00
Unit will not turn on.
The unit is running but
there is no water flow.
Water is leaking where
the hose connects to
the spray gun.
The pressure washer
turns on for 2 seconds,
shuts off, and will not
turn back on.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTION
The auto-start feature is turning the
unit off.
Defective or missing O-ring
between the high pressure hose
and the spray gun.
POSSIBLE CAUSE: Defective spray
lance.
Improper water source.
Pressure washer is not connected
to a power source or the power
source isn’t grounded.
Clogged nozzle.
When the pressure washer is turned on,
the motor may run for 1-2 seconds to
prime the pump. Then it will automati
-
cally shut off until the spray gun trigger
is squeezed. This is normal and does
not indicate a problem.
Replace the O-ring.
Replace the lance.
lean the nozzle.
Connect the power cord to a grounded
120 Volt outlet.
Water pressure is in the hose Pull the trigger to release the water pres-
sure.
GFCI is tripped. Press the RESET button on the power
cord.
Defective motor or power cord. contact us customer service email
[email protected] or call
+1 (689) 888-7131
Connect the pressure washer to a water
main. Do not use this device with water
from a lake, pool, pond, etc.
18
AIVOLT THREE YEAR LIMITED WARRANTY
AIVOLT RESPONSIBILITY
OR AIVOLTGROUP.COM/REGISTER TO EXTEND YOUR PRODUCT
WARRANTY.
Activate your warranty in just 5 minutes to enjoy FULL PRODUCT
PROTECTION.
OWNER'S RESPONSIBILITY
PRODUCT WARRANTY APPLICATIONS AND PRODUCT WARRANTY
PERIODS
CONSUMER APPLICATION
COMMERCIAL APPLICATION
WARRANTY
AIVOLT warrants to the original purchaser that its AIVOLT line of electric pressure washers will be free from
defects in material and workmanship. Under normal use and maintenance from the date of purchase, AIVOLT
agrees to repair or replace at AIVOLT's sole discretion, any defective product free of charge at any authorized
AIVOLT Authorized Service Dealer within the below-listed applications, time periods, limitations, and exclu-
sions.
As an added bonus for qualifying purchases, complete your registration online today for an
Parts and labor will be fully covered for a period of one year from the date of purchase.
Parts only will be fully covered for a period of two years from the date of purchase.
arts and labor will be fully covered for a period of ninety days from the date of purchase.
DISCLAIMER OF IMPLIED WARRANTIES
This limited warranty is in lieu of all other expressed or implied warranties, including any warranty of FITNESS
FOR A PARTICULAR PURPOSE OR USE.
EXCLUSIONS
The following items are excluded from warranty coverage:
•Utilization of non- aivolt replacement parts except where authorized by AIVOLT in writing.
•Costs of routine/normal maintenance.
•Repairs or diagnostics performed by a non-authorized service dealer.
•Product failures due to normal wear and tear, accident, misuse, or negligence.
19
To ensure hassle-free warranty coverage, it is important that you register your AIVOLT electric pressure washer
online at www.aivoltgroup.com , contact us customer service email [email protected]
or call +1 (689) 888-7131, or by filling out and returning to AIVOLT the warranty registration card supplied with
your pressure washer.
Your receipt for purchase including date, model, and serial number must be maintained and presented to AIVOLT
customer service in order to obtain warranty service.
Please keep the manual properly for future reference or scan the QR code to
download and save the electronic manual.
http://www.aivoltgroup.com
8410 W Sandidge Rd, Olive Branch, MS 38654
32082-07971-01
+1 (689) 888-7131
