At a Glance
1. Power
2. Bluetooth
3. Spatial Sound
4. BassUp
5. Volume Down
6. Play / Pause
7. Volume Up
8. USB-C Charging Input
9. AUX IN
Charging
Use a certified USB-C cable and charger to prevent any damage.
Fully charge this speaker before the first use to prolong the lifespan of the
built-in battery.
Flashing red Low battery
Steady red Charging
Steady white Fully charged
Powering On / O
Press once
Power on
Steady white
Press and hold for at least 2 seconds
Power o
Light o
This speaker will power o automatically aer 20 minutes if no device is
connected.
Using Your Speaker
Bluetooth Mode
With this speaker, you can enjoy music through your Bluetooth-enabled
devices.
Press once Enter Bluetooth pairing mode
Flashing blue Bluetooth pairing
Steady blue Bluetooth connected
• To re-enter Bluetooth pairing mode, press the Bluetooth button once.
• This speaker can only play music on one mobile device at a time. To
play from another connected device, pause the device that's currently
active first.
• Each time you power on your speaker, it will automatically connect to
your last connected device if available within the Bluetooth range. If
not, press the Bluetooth button to enter Bluetooth pairing mode.
TWS (True Wireless Stereo) Mode
Two identical Motion X600 speakers can pair with each other for stereo
sound. Both speakers can play the same audio (one as the le channel
and the other as the right channel).
1. Connect either speaker with your Bluetooth device.
2. On both speakers, press and hold the Bluetooth button for at least 2
seconds to enter TWS pairing mode.
Press and hold for at least 2
seconds
Enter TWS pairing mode
Flashing white TWS pairing
Steady blue (Speaker 1)
TWS connected
Steady white (Speaker 2)
To exit TWS mode, press and hold the Bluetooth button for at least 2
seconds.
Spatial Sound
Spatial sound places sound all around you to create an immersive
listening experience.
x1
OFF
ON
Press once Turn spatial sound on / o
Steady white Spatial sound on
Light o Spatial sound o
LDAC
Use devices powered by Android 8.0 or later to experience LDAC quality
sound.
1. Open the soundcore app.
2. Go to the Settings icon on the home page.
3. Click on "Sound Mode."
4. Select "Preferred audio quality" to switch to LDAC codec.
1
2
3
4
• It takes about 10 seconds to switch audio codecs. You may be
requested to update the speaker's firmware if available.
• LDAC provides higher quality sound, increases power consumption,
and reduces playtime.
• Enable LDAC in a low-inteerence environment to ensure a stable
Bluetooth connection.
AUX Mode
Insert a 3.5mm AUX cable (not included) to play audio on an external
device.
When using AUX mode, control audio playback via the connected device.
Button Controls
Press once Power on
Press and hold for at least 2
seconds
Power o
Press once Enter Bluetooth pairing mode
Press and hold for at least 2
seconds
Enter / exit TWS pairing mode
Press once Turn spatial sound on / o
Press once Turn BassUp on / o
Press Volume up / down
Press once Play / pause
Press twice Next track
Press three times Previous track
Press once Answer / end a call
Press and hold for at least 2
seconds
Reject a call
Press and hold for at least 2
seconds
Activate voice assistant
soware
Reset
Press and hold the Bluetooth button and volume up button simultaneously
for at least 4 seconds to reset the speaker.
4
App
Download the soundcore app to enhance your experience.
Product information: Check the product name and soware version, or
read the user manual.
Firmware update: You will be informed once a new version of firmware is
detected when you connect the speaker with the app.
Battery status: Indicates the remaining battery level of your speaker.
Volume control: Adjust the volume level via the app without pressing the
buttons on the speaker.
EQ settings: There are 6 EQ settings you can choose from in the app to
optimize your experience while enjoying dierent music genres.
• soundcore Signature: Standard EQ mode optimized for well-balanced
sound.
• Voice: Voices stand out more clearly from other ambient sounds.
• Treble Boost: High frequencies are enhanced.
• Balance: No enhancement for high-frequency and low-frequency
sounds.
• Custom: Customize the EQ setting to suit you in the app.
• BassUp: Turn on BassUp to enhance the low-frequency sound.
Set auto-power o time: Set an auto-power o time (5 / 10 / 20 / 60
minutes, 20 minutes by default). The speaker will automatically power o
when the time is up.
Voice prompt: Mute or restore the voice prompt while powering on / o.
soundcore
$SSOHDQGWKH$SSOHORJRDUHWUDGHPDUNVRI
Apple Inc.
*RRJOH3OD\DQGWKH*RRJOH3OD\
ORJRDUH
WUDGHPDUNVRI*RRJOH,QF
Specifications
Specifications are subject to change without notice.
DC power input 5V 3A
Battery capacity 6400mAh / 7.2V
Audio output power 50W
Charging time 6 hours
Playtime (varies by volume level
and music content)
12 hours
Waterproof level IPX7
Bluetooth version 5.3
Bluetooth range 100m / 328
Note: The 'x' of SN Code: xxxxxxxxxxxxxxxx is a variable, see below table.
Variable 'x' Range of variable Content
Seventh 0-9 or A-F
Denotes the hardware version which is not
eected on the safety compliance.
Eighth 8,9,A,B,C...
Denotes the year, 8 means 2018, 9 means 2019, A
means 2020, B means 2021, C means 2022, and
so on.
Ninth and tenth 01,02,03...
Denotes weeks, 01 means the first week in this
year, 02 means the secondary week in this
year, and so on.
Eleventh 1-7
Denotes date, 1 means Monday, 2 means
Tuesday..., 7 means Sunday and so on.
The last five 00001-99999 Denotes serial No.
Hereby, Anker Innovations Limited declares that this device is in compliance
with The Product Security and Telecommunications Infrastructure (Security
Requirements for Relevant Connectable Products) Regulations 2023. For the
Statement of Compliance, visit the website:
https://uk.soundcore.com/pages/psti-related.
1. Power consumption in standby mode: ≤0.5W
2. Power management: ≤ 20min
3. Information of applicable adapter:
Brand: ANKER
Manufacturer: Anker Innovations Limited
Model: A2337
Input: 100-240V~ 1.0A, 50-60Hz
Output: 5.0V
⎓
3.0A 15.0W / 9.0V
⎓
3.0A 27.0W / 12.0V
⎓
2.5A 30.0W / 15.0V
⎓
2.0A
30.0W / 20.0V
⎓
1.5A 30.0W (30.0W Max)
Default Open Port: Classic Bluetooth + BLE (Bluetooth Low Energy)
Port Description: After the device is powered on, both Classic Bluetooth
visibility (or pairing mode) and BLE broadcasting are automatically
enabled, providing Bluetooth pairing (or control) services. The Bluetooth
service is disabled when the device is powered o.
