H6Pro-LS3 Thermo-Hygrometer Sensor Kit
User Manual
Introduction What's in the Box
Setup Button
Status Indicator Light
Sensing Part (built-in)
Product Label
LS3 ID (same as SN)
Built-in AAA battery
1
7
8
2
9
10
11 12 13
3 4 5 6
v1.0
Introduction What's in the Box Product Parameter
Mounting
LS3
LoRa
Up to 2000 ft (Line-of-Sight)
4.17 × 2.22 × 0.83 in
3.4 oz
3 × AAA Batteries (Replaceable)
32°F to 140°F (0°C to 60°C)
±0.54°F (±0.3°C)
0 - 80% (Non-condensing)
Specifications
Model
Wireless Connection
Communication Range
Dimensions
Weight
Battery
Operating Temperature Range
Temperature Accuracy
Operating Humidity Range
±3%RH (Typ.)Humidity Accuracy
How the System Works
How the System Works
Note: Pressing "Restore to Factory Settings and Restart" will
reset the sensor to its factory defaults. You’ll need to add the
sensor again using the app. Only perform this action if neces-
sary.
LS3 Sensor Button Functions
Function
Enter Setup
Restore Factory Settings
and Restart
Report Data Now
Button Operation
Press and hold for 3s, then release
Press and hold for more than
15s, then release
Press the button once
Indicator Light Behavior
The blue light is flashing
The red LED stays on when pressed
for 10s, and turns off at 15s
The blue light flashes once
H6Pro-LS3 Kit — Your Smart Temperature & Humidity Monitoring
System
Track environmental changes in real-time and receive instant alerts
wherever you are.
Includes:
LS3 Sensor — A high-precision LoRa sensor that monitors both tempera-
ture and humidity with long-range wireless stability.
H6Pro Hub — A versatile gateway that supports Bluetooth LE and LoRa
sensors, connecting them to the MOCREO app while providing a soft night
light.
76.9
76.9
49.3% 49.3%
76.9
49.3%
1.The LS3 Sensor sends real-time temperature and humidity
data to the H6Pro Hub via LoRa protocol (Long range, up to
2000 ft Line-of-Sight).
2.The H6Pro Hub uploads the data to MOCREO Cloud via
2.4GHz Wi-Fi.
Users can access the monitoring data anytime through the
MOCREO Smart App.
SpecificationsH6Pro Hub
Night Light
Status Light
Plug
Setup Button
LoRa Hub
Model:H6Pro
FCCID:2BFZL-H5LT
SN:MCXXXXXXXXXXXX
Power:110-240V50/60Hz
LED Behavior
Breathing Purple
Breathing Red
Breathing Blue
Off
Status
Normal Operation
Hub Offline
Wi-Fi Setup Mode
No Power / Power Issue
H6Pro Hub LED Status Indicator
LS3 Sensor
SetupSetup
Setup
❶Download MOCREO Smart App
Setup
❸Open the app to add the H6Pro Hub first, then
add the LS3 Sensor
❷Power up your H6Pro Hub
Plug in your H6Pro Hub. The light turns on.
Scan and
Download
Google Play App Store
MOCREO
Smart App
MOCREO Smart
or
Welcome to MOCREO smart
My Home >
All
H6Pro Hub × 1
User Manual
LS3 Sensor × 3
H6Pro-LS3 Temperature Sensor Kit
User Manual
Velcro × 3
H6Pro
Wi-Fi 2.4GHz, LoRa, BLE
3.5 × 2.0 × 1.8 in
2.47 oz (70 g)
Max 1W
110V - 240V AC
32°F to 104°F (0°C to 40°C)
1
90dB@1ft (0.3m)
Model
Wireless Protocols
Dimensions
Weight
Night Light
Operating Voltage
Operating Temperature
Physical Button
Buzzer
Customer Service
Search [ MOCREO ] on YouTube to watch the setup video tutorials.
User Guide Manual
+1 (530) 988-8608
https://doc.mocreo.com/
FCC ID (LS3 Sensor): 2BFZL-LS1 (Shared certification)
FCC ID (H6Pro Hub): 2BFZL-H5LT (Shared certification)
MOCREO
