H5Pro-LS3 Temperature Sensor Kit
User Manual
Introduction What's in the Box
Setup Button
Status Indicator Light
Sensing Part (built-in)
Product Label
LS3 ID (same as SN)
Built-in AAA battery
Button Functionality
1
8
9
2
Setup
10
11
12 13 14 15
3 4 5 6 7
❶Download MOCREO Smart App
17 18
v2.0
16
Customer Service
Search [ MOCREO ] on YouTube to watch the setup video tutorials.
User Guide Manual
+1 (530) 988-8608
https://doc.mocreo.com/
Introduction
Note:
For 1 sensor kit: n=1
For 2 sensor kits: n=2
For 3 sensor kits: n=3
What's in the Box Product Parameter
Mounting Setup
Scan and Download
Google Play App Store MOCREO
Smart App
MOCREO Smart
❷Power the Hub
❸Add devices via the App
Provide power to your H5Pro Hub.
Position the devices at a relatively elevated location in the current environment,
ensuring that the LS3 Sensor and H5Pro Hub antennas are oriented vertically.
°F
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communi-
cations.
However, there is no guarantee that interference will not occur
in a particular installation. lf this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
• Increase the separation between the equipment and the
receiver.
• Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
LS3
LoRa
1640ft / 500m (No obstacles)
4.17 x 2.22 x 0.83in
3.4 oz
AAA battery x 3 (Replaceable)
32° - 140°F(0° - 60°C)
±0.54°F(±0.3°C)
0 - 80% (Non-condensing)
Specifications
Model
Wireless Connection
Communication Range
Dimensions
Weight
Battery
Operating Temperature Range
Temperature Accuracy
Operating Humidity Range
±3%RH (Typ.)Humidity Accuracy
Specifications
H5Pro
Rotary Encoder ×1, Side Button ×1
2-inch, 320 × 240 IPS display, non touch
7-segment 4-digit clock display
2.4GHz（not support 5GHz Wi-Fi）
915MHz
10Mbps/100Mbps
BLE 5.0
5.04 × 3.08 × 3.77in (Include antenna)
5.04 × 2.06 × 1.86in (No antenna)
Physical Button ×2
LCD Display (W × H)
LED Dot Matrix
Wi-Fi
LoRa
Ethernet
BLE
Model
Button
Display
Network
Weight
Power
4.1 oz
DC, 5V, 1A, Type-C ×1
Dimensions (L x W x H)
How the System Works
1. The LS3 Sensor sends temperature and humidity data to the
H5Pro Hub via LoRa protocol (Long range, 1640ft, no obstacle).
2. The H5Pro Hub uploads the data to MOCREO Cloud via
Wi-Fi or Ethernet.
Users can access the monitoring data anytime through the
MOCREO Smart App.
How the System Works
76.9
49.3% 49.3%
76.9
76.9
Rotary Encoder: The rotary button allows moving the selection
box up and down the screen, and pressing the button confirms
the selection.
Side Button: Return to the previous interface.
Button Functionality
Side Button
Rotary Encoder
Velcro x n
LS3 Sensor x n
H5Pro Hub
Power
Adapter
USB Type A
-Type C
LoRa
Antenna
Note: Pressing "Restore to Factory Settings and Restart" will
reset the sensor to its factory defaults. You’ll need to add the
sensor again using the app. Only perform this action if neces-
sary.
LS3 Sensor Button Functions
Function
Enter Setup
Restore Factory Settings
and Restart
Report Data Now
Button Operation
Press and hold for 3s, then release
Press and hold for more than
15s, then release
Press the button once
Indicator Light Behavior
The blue light is flashing
The red LED stays on when pressed
for 10s, and turns off at 15s
The blue light flashes once
or
The H5Pro-LS3 Kit is a long-range, reliable solution for remote temperature
and humidity monitoring, featuring the H5Pro LoRa Hub and LS3 LoRa
Temperature Sensor.
LS3 Sensor: Designed for environmental monitoring, the LS3 Sensor
accurately detects temperature and humidity changes. Ideal for daily
management in indoor and dry environments, it is commonly used in
scenarios requiring stable climate control, such as warehouses, greenhouses,
and laboratories. With long-range communication technology, it supports
seamless large-scale deployment and real-time data synchronization,
delivering reliable support for environmentally sensitive areas.
H5Pro Hub: The H5Pro Hub leverages LoRa technology to communicate
with multiple sensors across expansive areas. Its 2-inch display provides
real-time monitoring at a glance, making it the dashboard for managing
sensors, checking historical data, alerts, etc.
Warranty
MOCREO products enjoy a 12-month limited warranty (starting
from the date when the customer receives the product), which
applies only to hardware components of the device that are not
subject to accident, misuse, neglect, fire, or other external
causes, alterations, or repair.
USB Type-C
Power Port
LED Dot Matrix LCD Screen
LAN Port LoRa
Antenna
Status Light
Precautions and Disclaimer
Precautions for Use
To ensure the normal use of the product, please pay attention
to the following situations:
• lt is recommended to install the H5Pro Hub in a high place.
• Do not expose the Sensor to High-temperature environment.
• Do not place the Device near flammable materials.
• Do not put heavy objects on the Device or use it as a support.
• Children should not use the Device without adult supervision.
Disclaimer
The contents about how to use the product and the App
guidance are only for reference; please refer to the actual
situation for specific applications. If there is something different
from the instructions during using the product, please contact
MOCREO Support for updates.
This product is for detecting and monitoring only. MOCREO is
not responsible for any property damage or other consequenc-
es of the use of this product.
FCC Statement
FCC ID (LS3 Sensor): 2BFZL-LS3
FCC ID (H5Pro Hub): 2BFZL-H5LR
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by
the party responsible for compliance could void the user's
authority to operate the equipment.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, according to part 15
of the FCC Rules.
1. Open the MOCREO Smart App
2. For new users: Register and verify your account
Existing users: Log in directly
3. Follow the in-app instructions to:
• Add and bind your H5Pro first
• Pull out the sensor battery insulating tab
• Then add and pair your Sensor
MOCREO
