sync
TM
+
Bluetooth Sensor
SP-MSB-DCE-06-AUX-L7
Non-UV Resistant White Finish
3.5mm PIN BLUETOOTH SENSOR & CONTROLLER
Description:
Our low-voltage Bluetooth wireless PIR/Daylight sensor with an integrated
3.5mm jack is designed for simple plug-in installation. This sensor provides
360° coverage at heights of 40Ft with an IP65 rating, 52’ radius detection
range from 40Ft height. Download our SLG Sync plus app on
IOS/android for easy commissioning, convient controls, and a total lighting
network experience.
Features:
• Network LLLC (LLLC) enabled with wireless bluetooth technology.
• Easy to install in the eld with pre-installed 3.5 mm PIN receptacle
for SLG Lighting controls ready xtures or with an SLG Lighting PIN adapter.
• User friendly commissioning with SLG Sync+ App (Available in IOS and Android).
• Local Bluetooth Network - no gateway needed.
• Occupancy and Daylight Harvesting.
• Multi-level dimming: Manual ON/OFF Automatic ON/OFF, and Automatic
Partial ON/OFF control capability with the SLG Sync App.
• Create scenes for more customized dimming scenarios via SLG Sync App.
• Time clock scheduling for individual lights, groups, or scenes via SLG Sync App.
• High & Low-Trim/Tuning sets the maximum light level based on customer
requirements in each space.
• 5 Year Warranty.
Ordering Information:
Sensor/Controller
Product Number Description
SP-MSB-DCE-06-AUX-L7
Commissioning:
SLG Sync mobile App is the easiest way to pair
devices, create groups, set scenes, set schedules,
dimming, color tuning, and adjust high trim based
on needs.
Visit www.slgus.com/slgsync for How-to-Videos and
a comprehensive commissioning guide.
App Download:
• Check www.slgus.com/slg-sync for SLG Ligting xture compatibility.
SPMSBDCE06AUXL7.26.01
Last Updated: January 30, 2026 18:00 PM
2
11325 Cash Road, Suite #100, Houston, Texas 77477
713-389-5680 | [email protected] | www.slgus.com
©2026 SLG Lighting, Inc. All Rights Reserved.
sync
TM
+
Wiring
Dimensions
Coverage
Bluetooth Transmit
200 ft. Max
Radio Frequency
2.4 GHz +- 75 MHz
Mounting Height
40 ft. Max
0-10V Signal Output
20mA
Detection Range
52 ft Max
Detection Angle
360°
Operating Temperature
-25°C to 55°C (-13°F to 131°F)
Warranty
5 Year warranty
Input Voltage
12-24VDC
IP Rating
IP65
Unit: in
The detection area for movement can be roughly divided into two parts:
2.30
1.70
M20
1.45
1.16
0.56
0.30
1.87
0.14
0
0m
4m2m2m4m8m
4m
8m
12m
8m
SPMSBDCE06AUXL7.26.01
Last Updated: January 30, 2026 18:00 PM
3
11325 Cash Road, Suite #100, Houston, Texas 77477
713-389-5680 | [email protected] | www.slgus.com
©2026 SLG Lighting, Inc. All Rights Reserved.
sync
TM
+
Dimmer
Luminaries
Wall Switch
SLG Sync+® App
Application
Sensor
Installation Precautions
Avoid areas with frequent temperature changes: Keep away from air conditioners, fans, refrigerators, ovens, and other objects that cause rapid
temperature changes. The detection effectiveness of PIR motion sensors is closelyrelated to temperature uctuations, and vents or heat
sources can lead to false alarms.
Avoid areas with signicant air ow.
Avoid installing opposite large, constantly moving objects: Large objects with signicant motion can cause suddenchanges in airow within the
detection area, leading to false alarms. Outdoor PIR motion sensors should not beinstalled opposite large trees or tall bushes.
Avoid areas with screens, furniture, large potted plants, or other obstacles within the detection range.
Avoid areas exposed to direct sunlight.
Avoid facing glass doors and windows directly:
1 ) Do not face glass doors and windows directly to avoid interferencefrom strong light.
2) Avoid complex environments outside doors and windows, such as direct sunlight, crowds, and moving vehicles.
Federal Communications Commission (FCC) Statement.This device complies with part 15 of the FCC Rules. Operation is subject to the
following twoconditions:
(1)This device may not cause harmful interference, and
(2)this device must acceptany interference received,
including interference that may cause undesired operation.Note: This equipment has beentested and found to comply with the limits for a
Class B digitaldevice, pursuant to part 15 of the FCC Rules. These limits are designed to provide Reasonableprotection against harmful
interference in a residential installation. This equipment generates,uses and can radiate radio frequency energy and, if not installed and
used in accordance with theinstructions, may cause harmful interference to radio communications. However, there is noguarantee that
interference will not occur in a particular installation. If this equipment doescause harmful interference to radio or television reception,
which can be determined by turningthe equipment off and on, the
user is encouraged to try to correct the interference by one ormore of·1the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly approved by
may void the FCC authorization to operate this device.Note: The manufacturer is not responsible for any radio or TV interference caused
byunauthorized modifications to this equipment. Such modifications could void the user’s authorityto operate the equipment.
RFexposurestatement:
This device complies with FCC RF radiation exposure limits set forth for anuncontrolled environment.The device is installed and operated
without restriction.
