9. / (Repeat) Button
Long press to activate or
deactivate vocal cancel
during karaoke
PORTABLE KARAOKE SPEAKER A12
USER MANUAL
Before You Begin
Specification
PLEASE READ ALL INSTRUCTIONS
CAREFULLY AND RETAIN IT FOR
FUTURE USE
Disposal And Recycling Information
This symbol (with or without a solid bar) on the device, batteries
(included), and/ or the packaging. indicates that the device and its
electrical accessories (for example, a headset, adapter or cable) and
batteries should not be disposed of as household garbage.
Warranty
Thank you for purchasing products. If any manufacturing
defect problems occur within 12 months from the date of purchase,
user can enjoy our company's warranty service.
Matters Needing Attention
1 . The warranty card and the proof of purchase should be kept by the
user properly, and it will not be replaced if lost.
2. If the product fails due to non-human factors, the user can present the
warranty card and proof of purchase to the customer service center
for free maintenance during the warranty period.
Non-warranty Situation
This warranty does not cover the following cases:
1. Out of warranty period.
2. Damage caused by use not in accordance with the instructions.
3. Damage caused by man-made causes.
4. Failure caused by unauthorized disassembly, maintenance,
or modification of the product.
5. Damage caused by force majeure factors
(such as floods, earthquakes, lightning, etc.).
7. Other failures and damages that are not caused by the
quality of the product itself.
Warranty Card
Dear user, thank you for using the product of our company.
Please read and keep properly the warranty card after purchasing
the product so that we can provide better services to you.
User Information
User's name
Phone Number
Address
Email
Product Information
Model No
Product code
Product Serial Number
Sales Information
Purchase Date
Sales Unit
Phone Number
Address
Warnings
1. Replacement of a battery with an incorrect type that
can defeat a saf
eguar
d (for example, in the case of
some lithium battery types);
2. Disposal of a battery into fire or a hot oven, or
mechanically crushing or cutting of a battery. that
can result in an explosion;
3. Leaving a battery in an extremely high temperature
surrounding environment that can result in an explosion
or the leakage of flammable liquid or gas;
4. A battery subjected to extremely low air pressure that
may result in an explosion or the leakage of flammable
liquid or gas.
Note:
Charge the speaker and microphone fully before first use.
The Speaker’s usage time depends on charge in the battery,
1.Operating mode indicator
2. Button
3. Mode(M) Button
4. LED Button
5. Button
6. Button
7. - Button
8. + Button
11. Echo +/-
12. Monitor Button
13. Headphone Monitor Jack
14. OTG (On-The-Go) Port
15. Battery Charging Indicator
16. USB-C charging jack(15W PD
fast charging supported)
17. Aux-in Jack
18. USB Port (For playback only)
19. GUITAR Jack
mode, volume level etc.
1. Power On/Off Button
2. Mic Volume +/- Button
3. M Button
-Press to toggle voice changer
Operating Pannel
• Pairing
When you turn on the device, a sound will indicated the
speaker is on. Activate the bluetooth feature on your
phone, and set the phone to search for bluetooth
device "A12’’.
• OFF/ON button
Long press POWER on/off button in the status of power off, the
product will automatically power on, and if it is not pluged into
a 3.5 audio cable, it enters Bluetooth by default. Long press the
power on/off button to power off.
•
•
•
Charging port
Connect the small end of the t ype-C charging cable (included)
to the type-C port of the speaker. Connect the larger end of the
cable to your computer's USB port or an AC adapt
or(not included).
The battery charging indicator will turn on in orange while
charging. Once fully charged, the charging indicator changes
to white.
User Manual
Play Time
Approx. 7 Hours
Appr
(based on 5V/3A 15W PD fast charging
ox. 4.5Hours
Working Distance
10m.
Charging Time
Battery Capacity
10.8V 5000 mAh
Output Power
80W
Speaker Impedance
4Ω
BT Version
5.3V
Input Voltage
5V
Playback option
Speaker Dimensions
Speaker Weight
BT, AUX-IN, USB
350x140x174mm
4.5 kgs
1 2 3 4 5 6 7 8
9 10
17
16
19
18
1
4
1
5
1312 11
1
2
3
