CORDLESS HEDGE TRIMMER
HY20CHT
INSTRUCTION MANUAL
WARNING: READ THE INSTRUCTIONS CAREFULLY BEFORE USE. ISS: NOV/24
www.hyundaipowerproducts.co.uk
2
Introduction.......................................................................................................................3
Safety Information............................................................................................................4
Unboxing.........................................................................................................................15
In The Box.........................................................................................................................16
Features...........................................................................................................................17
Assembly..........................................................................................................................18
Operation........................................................................................................................22
Maintenance & Care....................................................................................................25
Technical Data...............................................................................................................27
Recycling & Disposal......................................................................................................28
EU Declaration Of Conformity.......................................................................................30
Notes................................................................................................................................31
Useful Information...........................................................................................................32
Product Record............................................................................................................33
Contact Us......................................................................................................................34
Contents
3
www.hyundaipowerproducts.co.uk
Introduction
Thank You For Purchasing Your HYUNDAI Product
Important!
We work very hard to give all of our customers the best possible service.
If you have any problems, before leaving negative feedback, please
contact us to give us a chance to resolve the issue. We would be
delighted if you left us positive feedback! Thank you for purchasing this
product.
WARNING: READ THE INSTRUCTION BOOKLET THOROUGHLY BEFORE
USING THE MACHINE. Keep for future reference and pass it on if
the machine is loaned or sold to another user.
This manual has been produced by Hyundai Power Products and should
be kept with the product. Please read and understand these instructions
before you use your product. Failure to do this may result in personal
injury or damage to the product.
The safety precautions and warnings are to ensure your safety and
protect you from harm or damage to the product.
The information contained in this manual was accurate at the time of
production, however HYUNDAI Power Products may make modications
to the product without notication.
www.hyundaipowerproducts.co.uk
4
Safety Information
General Power Tool Safety Warnings
WARNING: Read all safety warnings, instructions, illustrations and
specifications provided with this power tool. Failure to follow all
instructions listed below may result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
Work Area Safety
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of ammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical Safety (When Using the Charger)
a) Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
5
www.hyundaipowerproducts.co.uk
Safety Information
Personal Safety
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal
injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your nger on the switch or
energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool may
result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair
and clothing away from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action
can cause severe injury within a fraction of a second.
Power Tool Use and Care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.
c) Disconnect the plug from the power source and/or remove the battery
pack, if detachable, from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety
www.hyundaipowerproducts.co.uk
6
measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or
binding of moving parts, breakage of parts and any other condition that
may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe
handling and control of the tool in unexpected situations.
Battery Tool Use and Care
a) Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
re when used with another battery pack.
b) Use power tools only with specically designated battery packs. Use
of any other battery packs may create a risk of injury and re.
c) When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small metal
objects, that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or a re.
d) Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable behaviour
resulting in re, explosion or risk of injury.
f) Do not expose a battery pack or tool to re or excessive temperature.
Exposure to re or temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or
Safety Information
7
www.hyundaipowerproducts.co.uk
Safety Information
tool outside the temperature range specied in the instructions. Charging
improperly or at temperatures outside the specied range may damage
the battery and increase the risk of re.
Service
a) Have your power tool serviced by a qualied repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
b) Never service damaged battery packs. Service of battery packs
should only be performed by the manufacturer or authorised service
providers.
Hedge Trimmer Safety Warnings (With Charger)
a) Do not use the hedge trimmer in bad weather conditions, especially
when there is a risk of lightning. This decreases the risk of being struck by
lightning.
b) Keep all power cords and cables away from cutting area. Power cords
or cables may be hidden in hedges or bushes and can be accidentally
cut by the blade.
c) Wear ear protection. Adequate protective equipment will reduce the
risk of hearing loss.
d) Hold the hedge trimmer by insulated gripping surfaces only, because
the blade may contact hidden wiring. Blades contacting a "live" wire
may make exposed metal parts of the hedge trimmer "live" and could
give the operator an electric shock.
e) Keep all parts of the body away from the blade. Do not remove cut
material or hold material to be cut when blades are moving. Blades
continue to move after the switch is turned off. A moment of inattention
while operating the hedge trimmer may result in serious personal injury.
f) When clearing jammed material or servicing the hedge trimmer,
make sure all power switches are off and the battery pack is removed
or disconnected. Unexpected actuation of the hedge trimmer while
clearing jammed material or servicing may result in serious personal injury.
g) Carry the hedge trimmer by the handle with the blade stopped and
taking care not to operate any power switch. Proper carrying of the
hedge trimmer will decrease the risk of inadvertent starting and resultant
personal injury from the blades.
h) When transporting or storing the hedge trimmer, always use the blade
www.hyundaipowerproducts.co.uk
8
cover. Proper handling of the hedge trimmer will decrease the risk of
personal injury from the blades.
i) Check the hedges and bushes for foreign objects, e.g. wire fences and
hidden wiring.
j) Hold the hedge trimmer properly, e.g. with both hands if two handles
are provided.
k) The hedge trimmer is intended to be used by the operator at ground
level and not on ladders or any other unstable support.
l) Before operating the hedge trimmer, the user should make sure the
locking device(s) of any moving elements (e.g. the extended shaft and
pivoting element), if any, are in the locked position.
Safety Warnings for Lithium Battery Pack
WARNING: DO NOT use these batteries if they become damaged, swollen
or hot during charging or use.
WARNING: DO NOT charge these batteries overnight when unattended.
a) Do not dismantle, open or shred cells or battery pack.
b) Do not short-circuit a battery pack. Do not store battery packs
haphazardly in a box or drawer where they may short-circuit each other
or be short-circuited by conductive materials. When battery pack is not
in use, keep it away from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals together
may cause burns or a re.
c) Do not expose battery pack to heat or fire. Avoid storage in direct
sunlight.
d) Do not subject battery pack to mechanical shock.
e) In the event of battery leaking, do not allow the liquid to come into
contact with the skin or eyes. If contact has been made, wash the
affected area with copious amounts of water and seek medical advice.
f) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a clean dry cloth if they become
dirty.
g) Battery pack needs to be charged before use. Always refer to this
instruction and use the correct charging procedure.
h) Do not maintain battery pack on charge when not in use.
i) After extended periods of storage, it may be necessary to charge
and discharge the battery pack several times to obtain maximum
Safety Information
9
www.hyundaipowerproducts.co.uk
performance.
j) Recharge only with the charger specied by Hyundai. Do not use any
charger other than that specically provided for use with the equipment.
k) Do not use any battery pack which is not designed for use with the
equipment.
l) Keep battery pack out of the reach of children.
m) Retain the original product literature for future reference.
n) Remove the battery from the equipment when not in use.
o) Dispose of properly.
p) Do not mix cells of different manufacturer, capacity, size or type within
a device.
q) Keep the battery away from microwaves and high pressure.
r) Warning! Do not use non-rechargeable batteries.
SAFETY WARNINGS FOR CHARGER
WARNING! Read all safety warnings and all instructions. Failure to
follow all instructions listed below may result in electric shock, re and/or
serious injury.
Save all warnings and instructions for future reference.
WARNING! Never allow children or people unfamiliar with these
instructions to use the product. Local regulations can restrict the minimum
age of the operator.
Keep children, pets, and other people not using the unit a sensible
distance away from the work area. Be alert and shut off the unit if
anyone enters work area. Keep children under the watchful care of a
responsible adult.
If the supply cord is damaged, It must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
a
)
Before charging, read the instructions.
b
)
Do not charge a leaking battery.
c
)
Do not use chargers for works other than those for which they are
designed.
d
)
Before charging, ensure your charger is matching the local AC supply.
e
)
For indoor use, or do not expose to rain.
f
)
The charging device must be protected from moisture.
g
)
Do not use the charging device outdoors.
h
)
Do not short out the contacts of battery or charger.
i
)
Respect the polarity “+/-“ when charging.
j
)
Do not open the unit and keep it out of the reach of children.
Safety Information
www.hyundaipowerproducts.co.uk
10
k
)
Do not charge the batteries of other manufactures or ill-suited models .
l
)
Ensure that the connection between the battery charger and battery is
correctly positioned and is not obstructed by foreign bodies.
m
)
Keep battery charger’s slots free of foreign objects and protect
against dirt and humidity. Store in a dry and frost-free place.
n
)
When charging batteries, ensure that the battery charger is in a well-
ventilated area and away from inflammable materials. Batteries can
get hot during charging. Do not overcharge any batteries. Ensure that
batteries and chargers are not left unsupervised during charging.
o
)
Do not recharge non-rechargeable batteries, as they can overheat
and break.
p
)
Longer life and better performance can be obtained if the battery
pack is charged when the air temperature is between 18
o
C and 24
o
C.
Do not charge the battery pack in air temperatures below 0
o
C, or above
40
o
C. This is important as it can prevent serious damage to the battery
pack.
q
)
Charge only battery pack of the same model provided by
manufacturer and of models recommended by manufacturer.
Noise & Vibrations (Where Applicable)
The declared vibration total value and the declared noise emission value
have been measured in accordance with a standard test method and
may be used for comparing one tool with another.
The declared vibration total value and the declared noise emission value
may also be used in a preliminary assessment of exposure.
WARNING: The vibration and noise emissions during actual use of the
power tool can differ from the declared value depending on the ways
in which the tool is used especially. Please consider the following the
factors:
• How the tool is used and the materials being cut.
• The tool being in good condition and well maintained.
• The use of the correct accessory for the tool and ensuring it is sharp
and in good condition.
• The tightness of the grip on the handles and if any anti vibration and
noise accessories are used.
• The tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not
adequately managed.
Safety Information
11
www.hyundaipowerproducts.co.uk
WARNING: For an accurate estimation of exposure level during normal
working conditions, please consider all parts of the operating cycle such
when the tool is switched off or running idle. This may signicantly reduce
the exposure level over the total working period.
Best practices to minimise your exposure:
• Always use sharp chisels, drills and blades (where applicable).
• Maintain this tool in accordance with these instructions and keep well
lubricated (where applicable).
• If the tool is to be used regularly then invest in anti vibration and noise
accessories.
• Plan your work schedule to spread any high vibration tool use across
a number of days.
Residual Risks
Even when tool is used as prescribed it is not possible to eliminate all
residual risk factors. The following hazards may arise in connection with
the tool’s construction and design:
1. Damage to lungs if an effective dust mask is not worn.
2. Damage to hearing if effective hearing protection is not worn.
Health defects resulting from vibration emission if the power tool is being
used over longer period of time or not adequately managed and
properly maintained.
WARNING: This machine produces an electromagnetic field during
operation. This eld may under some circumstances interfere with active
or passive medical implants. To reduce the risk of serious or fatal injury,
we recommend persons with medical implants to consult their physician
and the medical implant manufacturer before operating this machine.
Safety Information
www.hyundaipowerproducts.co.uk
12
Safety Information
Intended Use
The HY20CHT is an battery powered hedge trimmer from HYUNDAI.
This machine is a garden tool. The machine is manufactured according
to the latest safety requirements. Every precaution is only effective when
it is followed exactly.
Intended Use
The machine is intended for cutting and trimming hedges and bushes in
domestic use.
User Types
This product is for personal domestic DIY use only.
It is not suitable for commercial, industrial, or trade use.
13
www.hyundaipowerproducts.co.uk
Symbol
Read the operating instructions and store them in a safe
place.
Warning
Wear eye protection
Wear ear protection
Wear dust mask
Keep hands away from blade
Do not expose to rain
Do not burn
Batteries may enter water cycle if disposed improperly,
which can be hazardous for ecosystem. Do not dispose of
waste batteries as unsorted municipal waste.
Safety Information
Appropriate Personal Protective Equipment (PPE), MUST be worn at all
times when operating or repairing the machine. No protective equipment
can ensure 100% protection.
When selecting PPE, make sure it’s CE marked and it suits the user in
terms of size, fit, etc. If more than one item of PPE is worn at the same
time, make sure they can be used together, e.g. wearing safety glasses
may disturb the seal of a respirator, causing air leaks.
www.hyundaipowerproducts.co.uk
14
Safety Information
Li-I on
Li-Ion battery This product has been marked with a symbol
relating to ‘separate collection’ for all battery packs and
battery pack. It will then be recycled or dismantled in
order to reduce the impact on the environment. Battery
packs can be hazardous for the environment and for
human health since they contain hazardous substances.
Read operator's manual
For indoor use only
Positive terminal
Negative terminal
Double insulation
Fuse
Waste electrical products must not be disposed of with
household waste. Please recycle where facilities exist.
Check with your local authorities or retailer for recycling
advice.
15
www.hyundaipowerproducts.co.uk
Unboxing
WARNING: Unboxing and assembling the machine should be done on
a at, surface with enough room. Disposal of the packaging should be
done in accordance with the local regulations in force.
WARNING: Some of the packaging material may be harmful to
children. Keep out of reach of children.
1. Carefully remove the product from the packaging and examine it for
any sign of damage caused during shipping.
2. Lay the contents out and check them. If any part is damaged or
missing, you must not use the machine. Contact HYUNDAI POWER
PRODUCTS immediately.
3. You must keep the packaging material in case the machine needs to
be returned or repaired.
4. Ensure that you have all the accessories and tools you need for
assembly and operation including the suitable personal protective
equipment.
www.hyundaipowerproducts.co.uk
16
*Not To Scale
In The Box
A
Hedge trimmer assembly
B
Blade sheath
C
Battery pack
D
Charger
A
B
C
D
17
www.hyundaipowerproducts.co.uk
Features
A
Blade
B
Safety guard
C
Front handle with safety switch
D
On/off switch
E
Rear handle
F
Battery pack release button
G
Battery pack
H
Blade sheath
A
B
G
F
H
C D E
www.hyundaipowerproducts.co.uk
18
Assembly
Assembly Overview
There are 3 steps to the assembly:
STEP 1. Battery Charging
STEP 2. Removing/Installing the Battery Pack
STEP 3. Removing the Blade Sheath
STEP 1 : Battery Charging
1. Charge the battery pack
Use only the charger specically provided for use with this equipment.
If the battery pack becomes very hot you must remove your battery
pack from the charger and allow time for the battery to cool down
before recharging.
Fully charge the battery before storing it. For prolonged storage,
recharge the battery every three months to maintain its performance
2. To remove or install the battery pack
1. To remove the battery pack, firmly press the release button (F) and
then slide the battery pack (G) out from your tool.
2. After recharging, slide the battery pack back into tool’s battery port. A
simple push with light pressure will be sufcient to secure it into place.
1
2
F
F
G
G
3. Charging procedure
1) Plug the charger into the correct power supply. The green light will
illuminate.
2) Slide the battery pack into the charger, ensuring it is securely
positioned in the correct charging orientation. The green light will turn off,
and the red light will illuminate to indicate that charging has begun.
19
www.hyundaipowerproducts.co.uk
Assembly
3) Once charging is complete, the red light will turn off, and the green
light will illuminate.
4) After the battery is fully charged, unplug the charger and remove the
battery pack.
NOTE:NOTE: If the battery pack is locked in the charger, press the battery pack
release button to release and remove it.
WARNING: If the battery charge is depleted after continuous use or
exposure to direct sunlight or heat, allow the tool to cool down before
recharging to ensure a full charge is achieved.
Red light
Green light
Charger
2
M
N
1
4. Charging indicator
This charger is equipped to detect potential issues with battery packs.
Indicator lights signal any problems (refer to the table below). If a
problem arises, insert a new battery pack to verify if the charger is
functioning properly.
• If the new battery charges correctly, the original battery pack is
defective and should be returned to a service centre or recycling
facility.
• If the new battery pack exhibits the same issue as the original, have the
charger inspected and tested at an authorised service centre.
Light
ON/OFF ash Status
Red on
Charging
Red ash
- - - - - Defective battery
Green on
Fully charged
Green ash
- - - - - Battery too hot/cold
www.hyundaipowerproducts.co.uk
20
Assembly
5. Checking the power condition of battery pack
The battery level can be known from the battery indicator light by
pressing the button (a) beside the lights.
a
100%
0%
STEP 2 : Removing/Installing the Battery Pack
1.Press the battery pack release button (F) and slide the battery pack (G)
out from your tool.
2. Slide the fully charged battery pack (G) onto the tool with sufficient
force until it clicks into position.
2
G
F
1
G
F
21
www.hyundaipowerproducts.co.uk
Assembly
STEP 3 : Removing the Blade Sheath
Remove blade sheath (H) as shown below.
H
www.hyundaipowerproducts.co.uk
22
Operation
Switching On and Off
1. To switch the tool on, with one hand, press the safety switch (C) on the
front handle. Simultaneously, press the on/off switch (D) with the other
hand to turn on the hedge trimmer.
The trimmer will remain operational as long as both switches are pressed.
2. To switch off, move the hedge trimmer away from the cutting area be-
fore stopping.
Release either the safety switch (C) or the on/off switch (D). The trimmer
will stop almost immediately.
WARNING: If any parts are missing, damaged or broken, do not
operate your hedge trimmer until all damaged parts have been replaced
or repaired. Failure to do so could result in serious personal injury. DO
NOT USE WITHOUT HANDLE AND GUARD.
2
1
C
D
How to Use Your Hedge Trimmer
Inspect the area to be cut before each use, remove objects which can
be thrown or become entangled in the cutting blades.
Always hold the Hedge trimmer with both hands and with the blade
away from you before turning it on. When trimming new growth, use a
wide sweeping action so that the stems are fed directly into the blade.
Allow the cutting blades to reach full speed before entering the material
to be cut.
Always work in the direction going away from people and solid objects
such as walls, large stones, trees, vehicles etc.
If the blade stalls, immediately stop the Hedge trimmer. Remove the
battery pack and clear the jammed debris from the cutting blade.
23
www.hyundaipowerproducts.co.uk
Operation
Wear gloves when trimming thorny or prickly growth.
Move the Hedge trimmer to feed the branches directly into the blade
cutting edges.
Do not try to cut stems that are too large to feed into the cutting blade.
1. Top cutting
Use a wide sweeping motion. A slight downward tilt of the cutting blades
(A) in the direction of motion gives the best cutting results.
A
2. Side cutting
When trimming the sides of the hedge, begin at the bottom and cut
upwards, tapering the hedge inward at the top. This shape will expose
more of the hedge, resulting in a more uniformed growth.
A
www.hyundaipowerproducts.co.uk
24
Lubricating the Cutting Blade
For optimum performance and longer life, lubricate the cutting blades
(A) before and after each use. Before lubricating, make sure the battery
pack is removed from your hedge trimmer. Apply the oil so that it runs
between the two blades (A). Common light duty/machine oil can be
used.
Your trimmer should be stopped, disconnected and oiled occasionally
during use.
A
Operation
25
www.hyundaipowerproducts.co.uk
Cleaning
Do not use cleaning agents, solvents or water to clean the blade rail.
These may cause severe damage to the tool. The blade rail should be
cleaned and treated with ne oil after each use. Brush the blade using
a stiff nylon brush to remove any debris. Keep clean the ventilation slots,
motor housing and handles of the device.
Maintenance
Regular maintenance of your equipment extends the lifespan of the
equipment. You will also achieve optimum cutting performances and
avoid accidents. Inspect the hedge trimmer before each use. Have the
unit professionally repaired if any damage occurs.
For Battery Tools
The ambient temperature range for tool and battery use and storage is
32
o
F - 113
o
F (0
o
C-45
o
C).
The recommended ambient temperature range for the charging system
during charging is 32
o
F - 104
o
F (0
o
C-40
o
C).
Storage & Transport
• Clean the equipment before putting it away.
• Store the device in a dry, frost-free, and dust-protected place, and out
of reach of children.
• Do not place other objects on top of the machine.
• Use the blade sheath for transportation and storage.
• Store the battery only in a partially charged state. The state of charge
should be 40 – 60 % over a longer storage period. (Two LED lights of the
state of charge display light up green).
• During longer storage periods, check the state of charge of the
battery and recharge if necessary (every 2 to 3 months).
• In order to keep the battery well charged, avoid exposing the device
to extreme heat or cold in storage.
• Store the equipment between 50°F (10°C) and 77°F (25°C). During
storage, avoid extreme cold or heat so the battery does not lose
power.
Maintenance & Care
www.hyundaipowerproducts.co.uk
26
Troubleshooting
NOTE:
All corrective actions should be carried out by suitably
qualied person/s.
Problem Possible cause Fault correction
Hedge trimmer
will not operate.
Battery discharged. Recharge battery. Refer to
“Battery charging”.
Battery too hot/cold. Allow to cool/warm.
Motor is broken. Contact Customer Service.
Internal wiring of machine
damaged.
Contact Customer Service.
Hedge
trimmer runs
intermittently.
Motor is broken. Contact Customer Service.
Battery not fully charged. Recharge battery.
On/off switch defective. Contact Customer Service.
Excessive
vibrations/noise.
Machine defective. Contact Customer Service.
Hedge trimmer
is not cutting
properly.
Blade is blunt or damaged. Contact Customer Service.
Continuous
lighting of the
battery charge
indicator/
battery not
charging.
Battery not (properly)
inserted.
Properly insert battery into
battery charger.
Battery contacts
contaminated.
Clean the battery contacts
or replace the battery.
Battery defective. Replace the battery.
Battery charge
indicator does
not light up.
Plug of battery charger not
plugged in (properly).
Insert mains plug (fully) into
the socket outlet.
Outlet or mains cable
defective.
Check the mains voltage.
Battery charger defective. Replace the battery
charger.
Maintenance & Care
27
www.hyundaipowerproducts.co.uk
Specication
Rated voltage:
20 V
Max.
No load speed: 2400/min
Max cutting diameter:
20mm
(0.8 in.)
Cutting length: 51cm (20 in.)
Blade length: 55cm (22 in.)
Battery capacity (BI20-2): 2.0 Ah
Charger input (C20-2): 100-240V~50/60Hz, 55W
Charger output (C20-2):
20V
2.0A
Charging time: 1 Hour
Charger protection class:
/II
Machine weight (with battery): 2.36 kg
A weighted sound pressure L
pA
:
(K
pA
= 3 dB(A))
77,02 dB(A)
A weighted sound pressure L
wA
:
(K
wA
= 0,96 dB(A))
85,02 dB(A)
Typical weighted vibration a
h
:
(uncertainty K= 1,5 m/s
2
)
2,92 m/s
2
Technical Data
www.hyundaipowerproducts.co.uk
28
Recycling & Disposal
Recycling & Disposal
We do not offer a takeback scheme for the recovery of Waste Electrical
Electronic Equipment (WEEE) & Batteries. Instead the responsibility to
dispose of WEEE and/or Batteries is passed onto you by us.
So when it becomes necessary to dispose of your machine you must take
it to your local Civic Amenity Site. For further information please contact
your local Authority for disposal advice.
You MUST make sure that all unused oil and fuel is disposed of correctly
either beforehand or at your local Civic Amenity Site.
• Under NO circumstances must any fuel or oil be put down any drains.
• Certain products contain WEEE waste which should not be disposed of
in your domestic waste.
• You MUST recycle WEEE in accordance with your local authority or
recycling centre.
• Certain products contain batteries which should not be disposed of in
your domestic waste.
• You MUST recycle batteries in accordance with your local authority or
recycling centre.
• Unwanted packaging and materials should be stored and taken
to a recycling centre so it can be disposed of in a manner which is
compatible with the environment.
We are a Member of the VALPAK National Compliance Scheme and our
registration number is RM08660. For further information about disposal
please contact your Local Authority.
You can also get more advice and guidance about recycling at the
following website http://www.recycle-more.co.uk
Should you pass this product on to another user either sold or loaned,
you MUST pass on this user manual. This will make sure that all other users
can use and maintain this machine safely.
29
www.hyundaipowerproducts.co.uk
Environmental Protection
1. Environmental protection should be a priority of considerable
importance when using the machine, for the benefit of both social
coexistence and the environment in which we live. Try not to cause any
disturbance to the surrounding area.
2. You must comply with local regulations and provisions for the disposal
of packaging, oils, fuel, filters, damaged parts or any elements which
have a strong impact on the environment. This waste must not be
disposed of as normal waste. It needs to be separated and taken to
specied waste disposal centres where the material will be recycled.
3. You must comply with local regulations for the disposal of waste
materials after mowing.
4. When disposing, do not pollute the environment with the machine, but
hand it over to a disposal centre, in accordance with the local laws in
force.
Recycling & Disposal
www.hyundaipowerproducts.co.uk
30
EU Declaration Of Conformity
Importer and Authorised Representative
Genpower Ltd
Isaac Way, Pembroke Dock, SA72 4RW
Country of Origin: China
Description: 20V Hedge trimmer
SKU Code: HY20CHT
Date of Issue: 20/12/2024
Regulations and Directives of Compliance
2006/42/EC, 2014/30/EU, 2011/65/EU&(EU)2015/863, 2000/14/EC
amended by 2005/88/EC, (EU)2023/1542, 2014/35/EU
The notied body involved
2000/14/EC amended by 2005/88/EC:
- Conformity Assessment Procedure as per Annex V
- Measured Sound Power Level 85,02 dB(A)
- Declared Guaranteed Sound Power Level 87,0 dB(A)
Statement of Declaration
We the importer and authorised representative of the product described
confirm conformity within the provisions of applicable regulations and
directives listed within this document.
Standards conform to
EN 62841-1, EN 62841-4-2, EN ISO 3744, EN IEC 55014-1, EN IEC 55014-2,
EN IEC 63000, EN 60335-1, EN 60335-2-29, EN 62233, EN IEC 61000-3-2, EN
61000-3-3
Signed on Behalf of Genpower Ltd
Place of Issue: Genpower Ltd
Signatory Name: Roland Llewellin
Position: Managing Director
……………………………………
31
www.hyundaipowerproducts.co.uk
Notes
www.hyundaipowerproducts.co.uk
32
Useful Information
Check Out Our YouTube Channel
Our videos on YouTube include:
Unboxing
Assembly of your machine
How to service your machine
Products in use
‘How To’ videos
Product features
Go to YouTube and search ‘Hyundai Power Products’.
Warranty
Proof of purchase will be required before you make a warranty claim.
Full warranty terms and conditions can be found on the HYUNDAI POWER
PRODUCTS website:
www.hyundaipowerproducts.co.uk
Manual Updates
Our manuals are constantly being reviewed and updated. Should
you find an error, omission or something unclear, please contact us for
assistance. We reserve the right to make any modications without prior
notice whenever necessary.
Our latest manuals are also placed online. All our manuals can be
downloaded at: www.hyundaipowerproducts.co.uk
Returning Your Product
If you are returning your product, please contact the dealer for their
returns policy.
Leaving A Review
We work very hard to give all of our customers the best possible service.
If you have any problems, before leaving negative feedback, please
contact us to give us a chance to resolve the issue. We would be
delighted if you left us positive feedback! To leave a review, please go
to: uk.trustpilot.com/review/hyundaipowerequipment.co.uk
Ordering Spare Parts
You can nd the spare part you are looking for at power-spares.co.uk
33
www.hyundaipowerproducts.co.uk
Product Record
Information
As soon as you have purchased the machine, we recommend that
you ll out the following. If you need to contact an authorised dealer or
customer service for information on servicing, you may need to provide
the following information.
Date Of Purchase:………………………………………………………………….
..
Dealer Name:…………………………………………………………………………
Dealer Phone:…………………………………………………………………………
Model Number:………………………………………………………………………
Serial / Batch Number:………………………………………………………………
www.hyundaipowerproducts.co.uk
34
Contact Us
Need Help? Talk To Our Experts
Our friendly aftersales team will be more than happy to help you.
Phone
Call our team on 01646 687 880
Email
Online Live Chat
Go to www.hyundaipowerproducts.co.uk
Post
Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72
4RW.
Hyundai Support Website
Go to hyundaisupport.co.uk
For Inquiries, Please Contact:
GENPOWER LTD
Isaac Way, London Road,
Pembroke Dock, UK, SA72 4RW.
T: +44 (0) 1646 687 880
www.hyundaipowerproducts.co.uk
Imported / Distributed by Genpower Ltd
for the United Kingdom & Ireland
Licensed by Hyundai Corporation
Holdings, Korea
