Instruction Manual
WARNING: Read the instructions carefully before use. Iss:Nov/24
20V Cordless Grass Trimmer
HY2187
www.hyundaipowerproducts.co.uk
2
Contents
Introduction……..……………………………3
Safety Information…..…………………..4-13
Understand Your Machine.…..…………...4
Personal Safety...…….……………………4-5
Inspect Your Machine…………………......5
Work Area…….……………………………....6
During Use…….………………………………7
Batteries…….…………………………………8
Charger………………………………………..8
Electricity…….………………...…………...8-9
Double Insulated Devices…......…….........9
Vibrations….…………………………..........10
Noise…….……………………………..........10
Residual Risks…………………....................10
Intended Use………………………............11
Personal Protective Equipment…...........12
Symbols On The Machine………………..13
Unboxing…………………………...............15
Features………………………….................16
Assembly……..…………………….......17-20
Attach Edging Wheel………………………….17
Trimmer Guard Installation……………………18
Front Guard and Auxiliary Handle…………..19
Insert Battery……………………………………..20
Operation……...………………………..21-25
Battery Charger Operation…………………...21
Machine Adjustment…......……………………22
Edging Wheel Use……………………………....23
Stopping and Starting……….…………………24
Tips for Use……………………..…..…………….25
Maintenance & Care……………..…26-27
General Maintenance……..…………...…26
Storage………………..……………………...26
Replacing Trimmer Line………………..27-28
Replacing Spool ………………………..29-30
Snapped Line………………………………..31
Troubleshooting……………………………..31
Technical Data…………...........................32
Recycling And Disposal..………………...33
Declaration Of Conformity…..…………..34
Useful Information…..……………………..35
Our YouTube Channel…..………………..35
Warranty…………………………………….35
Manual Updates….……………………….35
Returning Your Product….……………….35
Leaving A Review….……………………...35
Ordering Spare Parts.……………………..35
Product Record…..………………………...36
Notes……………………………………..37-38
Contact Us…..……………………………....39
www.hyundaipowerproducts.co.uk
3
Introduction
Thank You For Purchasing Your HYUNDAI Product
We work very hard to give all of our customers the best possible service. If you
have any problems, before leaving negative feedback, please contact us to give
us a chance to resolve the issue. We would be delighted if you left us positive
feedback! Thank you for purchasing this product.
Important!
This manual has been produced by Hyundai Power Products and should be kept
with the product. Please read and understand these instructions before you use
your product. Failure to do this may result in personal injury or damage to the
product.
The safety precautions and warnings are to ensure your safety and protect you
from harm or damage to the product.
The information contained in this manual was accurate at the time of production,
however HYUNDAI Power Products may make modifications to the product
without notification.
WARNING: READ THE INSTRUCTION BOOKLET THOROUGHLY BEFORE USING
THE MACHINE. Keep for future reference and pass it on if the machine is
loaned or sold to another user.
!
www.hyundaipowerproducts.co.uk
4
Safety Information
Understand Your Machine
• WARNING! You must read these instructions carefully before operating the
machine. Make sure that you are familiar with the controls and properly operate
the machine. You must learn how to stop the machine quickly. If you do not follow
the warnings and instructions, it may result in fire and/or serious injury. Make sure to
save all warnings and instructions for future reference.
• Read this manual and labels affixed to the machine to understand its limitations
and potential hazards.
• Be thoroughly familiar with the controls and their proper operation. Know how to
stop the machine and disengage the controls quickly.
• If the unit is to be used by someone other than original purchaser, or is to be
loaned, rented, or sold, always provide this manual and any needed safety
training before operation. The user can prevent and is responsible for accidents or
injuries that may occur to themselves, to other people, or to property.
• Do not force the machine beyond its limits. Use the correct machine for your
application.
• Know how to stop the machine quickly in case of emergency. Understand the
use of all controls.
• ALL MAINTENANCE other than that listed in this manual, should be carried out by
professionally trained and certified personnel.
• When using this machine for the first time and before actual work, you MUST
learn how to handle the machine from an experienced or skilled person.
Personal Safety
• WARNING! Never allow children or people unfamiliar with these instructions to
use the product. Local regulations can restrict the minimum age of the operator.
• Keep children, pets, and other people not using the unit away from the work
area (at least 15m). Be alert and shut off the unit if anyone enters work area. Keep
children under the watchful care of a responsible adult.
• Stay alert, watch what you are doing and use common sense when operating
the machine. Never operate the machine when unwell or tired, or if you have
taken alcohol, medicine, drugs or any substances which may slow your reflexes
and compromise judgment. A moment of inattention while operating the machine
may result in serious personal injury.
• Appropriate Personal Protective Equipment (PPE), MUST be worn at all times
when operating or repairing the machine. Always wear anti-slip and resistant work
footwear and long trousers while using the machine. Do not use the machine
when barefoot, wearing sandals or similar lightweight footwear. Do not wear
chains, bracelets or clothing that is loose fitting or hanging ties or cords. Tie long
hair back. Always wear protective earplugs. Loose clothes, jewellery, or long hair
can be caught in moving parts. Protect eyes, face, and head from objects that
may be thrown from the unit. Always wear safety goggles or safety glasses with
side shields when operating.
•Always keep hands and feet away from all moving parts during operation.
Moving parts can cut or crush body parts. Always keep hands and feet away from
all pinch points.
!
!
www.hyundaipowerproducts.co.uk
5
Safety Information
Personal Safety (Continued)
• Do not touch parts that might be hot from operation. Allow parts to cool before
attempting to maintain, adjust, or service.
• Do not overreach. Keep proper footing and balance at all times. This enables
better control of the machine in unexpected situations. Extending your body too
far can result in a loss of balance and you may fall which will result in injury.
• Never place any part of your body where it would be in danger if movement
should occur during assembly, installation, and operation, maintenance, repairing
or moving.
• Keep in mind that the operator or user is responsible for accidents, hazards or
unexpected events involving the machine that occur to other people or their
property. It is the responsibility of the user to assess the potential risk of the area
where work is being carried out. The operator or user must take all necessary
precautions to ensure their own safety and that of others, especially on slopes or
rough, slippery and unstable ground.
Inspect Your Machine
• Check your machine before starting it. Keep guards in place and in working
order. Make sure all nuts, bolts, etc., are securely tightened.
• You must check the general condition of the machine before use.
• Never operate the machine when it is in need of repair or is in poor mechanical
condition. Replace damaged, missing, or failed parts before using it. Check for fuel
leaks. Keep the machine in safe working condition.
• Do not use the machine if the machine’s switch does not turn off the machine
when running. Any machine that can’t be controlled with the switch is dangerous
and must be replaced.
• Regularly check to see that keys and adjusting wrenches are removed from the
machine area before starting it. A wrench or a key that is left attached to a
rotating part of the machine may result in personal injury.
• If the machine should start to vibrate abnormally, stop the machine and check
immediately for the cause. Vibration is generally a warning sign of trouble.
• Avoid accidental starting. Be sure the switch is off before transporting the
machine or performing any maintenance or service on the unit. Transporting or
performing maintenance or service on a machine with its switch on invites
accidents.
• Do not tamper with or disable safety systems.
• Only use manufacturer-recommended attachments.
• Before using, always visually inspect to see that the tools are not worn out or
damaged. Replace worn out or damaged elements and bolts in set to preserve
balance.
• Keep the machine in good operating condition. Operating the machine in poor
or questionable condition could result in serious injury.
• Be sure all safety devices are in working order and warning labels are in place.
These items are installed for your safety.
!
!
www.hyundaipowerproducts.co.uk
6
Safety Information
Work Area
• You must only work in daylight or with good artificial light in good visibility
conditions. Do not work at night, at times of heavy fog, or at any other times when
your field of vision might be limited and it would be difficult to gain a clear view of
the area.
• Keep people, children and animals away from the working area.
• Operate on flat, level ground.
• Do not work in the rain, when there is a thunderstorm or lightning risk, at times of
strong or gale force winds, or at any other times when the weather conditions
might make it unsafe to use this product. If there is bad weather conditions, do not
use the machine.
• Any liquid spilled on the floor may result in you slipping.
• DO NOT operate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases or dust. Power tools may create sparks, which may
ignite the dust or fumes.
!
www.hyundaipowerproducts.co.uk
7
Safety Information
During Use
• Do not operate the machine in confined areas where there may be a risk of
crushing the operator between the machine and another object.
• Never attempt to make any adjustments, while the machine is running.
• You must switch off the machine:
- Before checking or working on the machine.
- When transporting the machine.
- Whenever you leave the machine unattended.
- If the machine starts to vibrate abnormally.
• WARNING! If something breaks or an accident happens whilst working, you must
turn off the machine immediately and move the machine away to prevent further
damage. If an accident happens with injuries or third parties are injured, carry out
the first aid measures most suitable for the situation immediately and contact the
medical authorities for any necessary health care. Carefully remove any debris
that might cause damage or harm persons or animals should it not be seen.
• Never operate the machine without the defective guards or shields, or without
safety devices, or if the cord is damaged or worn.
• Always make sure that the power cord is not in the way of your work.
!
www.hyundaipowerproducts.co.uk
8
Safety Information
Batteries
Batteries present a risk if they become damaged by the possible leaking of
electrolyte. Electrolyte is an acid and can cause serious burn injuries. Care should
be taken when working on or near them. NOTE: the electrolyte may be in a liquid
or gel form.
Should you come in to contact with electrolyte you should;
• Remove all clothing contaminated with electrolyte. If you cannot remove then
saturate them in water.
• Get medical assistance as soon as possible.
You must advise the medical staff of the type of acid. This machine contains
LiFePO4 batteries with lipf6 electrolyte.
• Use fresh running water to wash off excess electrolyte, continue this until medical
assistance arrives. Make sure don’t transfer electrolyte to other body parts.
• If electrolyte comes in to contact with Eyes the electrolyte needs to be
immediately washed away with large amounts of water. Make sure that you do
not wash the electrolyte to another part of your face or body.
• Gasses from charging batteries are highly flammable and great care should be
taken to charge in well ventilated areas.
• There is an explosion risk if the battery terminals are short circuited,
when connecting/disconnecting ALWAYS exercise great care so that
the terminals or battery leads are NOT allowed to touch and cause a
spark. ALWAYS use suitable insulated tools.
DANGER : ELECTRICITY CAN KILL – NEVER WORK ON LIVE / ENERGISED EQUIPMENT.
!
Electricity (Where Applicable)
!
• Prior to carrying out any maintenance work you MUST identify electrical
. isolation methods and isolate all electrical supplies.
• Prior to use and with all electrical supplies isolated, you MUST check all
electrical cables, plugs and connectors for the following;
- Are intact and have no signs of damage, to include but not limited to bare wires,
chaffing, cuts and loose wiring.
- If there are any signs of damage, the damaged item MUST be taken out of
service until the damage has been repaired by a qualified technician.
- All trailing cables should be routed so as not to cause any kind of trip hazard.
- NEVER work on or near electricity with wet hands, wet clothing and wet gloves.
Battery Charger
!
• Do not place any objects on the battery charger and do not place the battery
charger on soft surfaces. There is a risk of explosion.
• If other batteries are used, e.g. imitations, reconditioned batteries or third-party
products, there’s risk of injury as well as damage caused by explosion
• A charger that is suitable for one type of battery pack may create a risk of fire
when used with another battery pack. This may cause an internal short-circuit and
the battery to burn, smoke, explode or overheat.
www.hyundaipowerproducts.co.uk
9
Safety Information
Electricity (Continued)
• Power tools plug must match the outlet. Never modify the plug in any way. DO
NOT use any adapter plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric shock.
• DO NOT expose this power tool to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
• IMPORTANT: When charging, make sure that the electric circuit is fused, and that
the power, voltage and frequency of the charger is supported by your mains
supply. Also, make sure that your power supply is earthed. However, if it should
become necessary to do so, contact a qualified electrician. Make sure that you
will never touch live contacts, specifically when you plug or unplug your charger.
This charger and its power cord must never get into contact with water.
• Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
• Do not allow any part of the machine to make contact with water while it is in
operation. If the appliance becomes wet while turned off, wipe dry before starting.
Do not touch the appliance or its plug with wet hands or while standing in water.
Wearing rubber boots offers some protection.
!
Double-Insulated Appliances
In a double-insulated appliance, two systems of insulation are provided instead of
grounding. No grounding means that it is already provided on a double-insulated
appliance. Servicing a double-insulated appliance requires extreme care and
knowledge of the system, and should be performed only by qualified service
personnel. Replacement parts for a double-insulated appliance must be identical
to the parts they replace.
!
www.hyundaipowerproducts.co.uk
10
Safety Information
Vibrations (Where Applicable)
• Prolonged use of hand held (operated) machines will cause the user to feel the effects
of/from vibrations. These vibrations can lead to white finger (Raynaud’s phenomenon) or
carpal tunnel syndrome. This condition reduces the ability of the hand to feel and regulate
temperature, causing numbness and heat sensations and may cause nerve damage and
circulatory tissue death.
• Not all factors that lead to white finger disease are known, but cold weather, smoking
and other diseases that affect blood vessels and blood circulation as well as large and
long-lasting impact of shocks are considered factors in the formation of white finger. Note
the following to reduce the risk of white finger and carpal tunnel syndrome;
• Wear gloves and keep your hands warm.
• Take regular breaks.
• All of the above precautions may help reduce the risk of white finger disease but not rule
out the carpal tunnel syndrome. Long-term and regular users are therefore recommended
to observe the condition of your hands and fingers. Seek medical attention immediately if
any of the above symptoms should occur.
Noise (Where Applicable)
• The operating noise of the machine can damage your hearing. When wearing
protection such as earplugs or ear defenders to protect your hearing. Long-term and
regular users are advised to have hearing checked regularly. Be especially vigilant and
cautious when wearing ear protection because your ability to hear alarm warnings will be
reduced.
• Noise emissions for this equipment is unavoidable. Carry out noisy work at approved
times and for certain periods. Limit the working time to a minimum. For your personal
protection and protection of people working nearby it is also advisable for them to wear
hearing protection.
• See Certificate of Conformity section for Outdoor Noise declaration of .
. conformity.
!
!
Residual Risks
Even when tool is used as prescribed it is not possible to eliminate all residual risk
factors. The following hazards may arise in connection with the tool’s construction
and design:
1. Damage to lungs if an effective dust mask is not worn.
2. Damage to hearing if effective hearing protection is not worn.
Health defects resulting from vibration emission if the power tool is being used over
longer period of time or not adequately managed and properly maintained.
WARNING! This machine produces an electromagnetic field during operation.
This field may under some circumstances interfere with active or passive medical
implants. To reduce the risk of serious or fatal injury, we recommend persons with
medical implants to consult their physician and the medical implant manufacturer
before operating this machine.
!
!
www.hyundaipowerproducts.co.uk
11
Safety Information
Intended Use
The HY2187 is a 20V Cordless Grass trimmer. It is powered by a 775W HYUNDAI
motor.
This machine is specifically a pedestrian tool, manufactured according to the
latest safety requirements. Every precaution is only effective when it’s followed
exactly.
Intended Use
This machine is designed and manufactured for trimming grass and small
shrubbery.
This machine is intended for use in environments with a maximum ambient
temperature of 32
o
C.
User Types
This machine is intended for use by consumers, i.e. non professional operators. The
machine is intended for “DIY” and domestic use only.
Improper Use
Any other usage not in keeping with the above mentioned ones may be
hazardous and harm persons and/or damage things. Examples of improper use
may include, but are not limited to:
• Use within a household
• Use for cutting solid materials i.e rocks, plaster etc
• Use in wet environments, ponds, lake edges etc
!
www.hyundaipowerproducts.co.uk
12
Safety Information
Personal Protective Equipment
Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when
operating or repairing the machine. No protective equipment can ensure 100%
protection.
When selecting PPE, make sure it’s CE marked and it suits the user in terms of size,
fit, etc. If more than one item of PPE is worn at the same time, make sure they can
be used together, e.g. wearing safety glasses may disturb the seal of a respirator,
causing air leaks.
!
Hand Protection Must Be Worn
Protective electrically non-conductive gloves are highly
recommended when working.
Foot Protection Must Be Worn
Non-skid heavy duty footwear are highly recommended when
working.
Hearing Protection Must Be Worn
Suitable safety hearing protection is recommended.
Eye Protection Must Be Worn
Always wear safety glasses/goggles and/or face shields. Everyday
eyeglasses have only impact resistant lenses; they are not safety
glasses/goggles.
Protective Clothing Must Be Worn
Do not wear loose clothing, gloves, scarfs, neckties or jewellery (rings,
wrist watches), which can be caught in moving parts.
Head Protection Must Be Worn
Wear a safety helmet with a safety visor.
Face Shield Must Be Worn
Wear a face shield to protect your face.
www.hyundaipowerproducts.co.uk
13
Safety Information
Symbols On The Machine
We have provided safety messages in this manual and on the machine. This
information alerts you to potential hazards that could hurt you or others. Please
read these messages carefully. However, we may not have listed all of the possible
hazards, you must also use your own judgement.
!
Symbol
Description
Symbol
Description
Safety alert – Indicates a
precaution, a warning or
a danger.
Dust mask must be worn
Read operator’s manual. Class II tools symbol.
Hand protection must be
worn
Hearing protection must
be worn
Sharp blades can cut
limbs.
Eye protection must be
worn
The UKCA (UK Conformity
Assessed) marking is a UK
product marking that is
required for goods being
placed on the market in
Great Britain (England,
Wales and Scotland).
This product complies
with the European
directives and an
evaluation method of
conformity for these
directives was done.
This product should not
be disposed of in
domestic waste. Please
contact your local
recycling centre for
disposal service.
Sound power level LWA
data in dB.
www.hyundaipowerproducts.co.uk
14
Unboxing
WARNING : Unboxing and assembling the machine should be done on a flat,
surface with enough room. Disposal of the packaging should be done in
accordance with the local regulations in force.
!
WARNING : Some of the packaging material may be harmful to children. Keep
out of reach of children.
1. Carefully remove the product from the packaging and examine it for any sign of
damage caused during shipping.
2. Lay the contents out and check them. If any part is damaged or missing, you
must not use the machine. Contact HYUNDAI POWER PRODUCTS immediately.
3. You must keep the packaging material in case the machine needs to be
returned or repaired.
4. Ensure that you have all the accessories and tools you need for assembly and
operation including the suitable personal protective equipment.
We recommend that you fill out the information in the ‘Product Record’ section. If
you need to contact an authorised dealer or customer service, you may need to
provide this information.
!
www.hyundaipowerproducts.co.uk
15
Unboxing
*Not To Scale
M
L
K
A
H
J
B
C
E
I
D
F
G
Feature Descriptions on next
page
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Front Guide
Adjustment Collar
Auxiliary Handle
Handle Adjustment Knob
N
Power Safety Button
On/Off Trigger
Battery Carriage
Trimmer Head Angle Button
Trimmer Guard
Spool Head
Battery Charge Indicator
Battery Release Button
20V 2.0Ah Lithium Ion Battery
Battery Charger
O
Edging Wheel
O
P
Trimmer Head Rotation Collar
P
www.hyundaipowerproducts.co.uk
16
Features
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Front Guide – This is used when cutting near Flower beds
and fences. It prevents damage from the spool
Adjustment Collar – Used to Extended the tube
Auxiliary Handle – An additional grip
Handle Adjustment Knob – Use to adjust Auxiliary handle
Power Safety Button – Prevents accidental starting
On/Off Trigger – Starts the machine
Battery Carriage – Houses the battery
Trimmer Head Angle Button – Adjust cutting angle
Trimmer Guard – Guards the user from the cutting wire.
Spool Head – Houses the cutting wire
Battery Charge Indicator – Shows the charge level of the
battery
Battery Release Button – Latches and de-latches the battery
20V 2.0Ah Lithium Ion Battery
Battery Charger
O
Edging Wheel – Used to easily cut along edges
www.hyundaipowerproducts.co.uk
17
Assembly
Attach Edging Wheel
1. Insert the Edging Wheel (O) onto the Trimmer Head.
2. Secure it into place with 2 screws
!
Warning : Ensure the Battery is not attached during Assembly
www.hyundaipowerproducts.co.uk
18
Assembly
Attach Trimmer Guard
1. Insert the Trimmer Guard (I), lining up the screw holes.
2. Insert a screw into the hole, and secure until tight.
*Note* - Double check the trimmer head is secured, shake it gently to
ensure it stay in place.
www.hyundaipowerproducts.co.uk
19
Assembly
Attach Front Guard and Auxiliary Handle
1. Insert the Front Guard (A) into it’s guided slot. Either side of the
Trimmer Head is a guide where the Front Guard sits.
2. Put the Auxiliary handle (C) onto it’s seat. Insert the large bolt from
the left hand side, and secure with the hand nut on the opposite
side.
www.hyundaipowerproducts.co.uk
20
Assembly
Insert Battery
!
Ensure battery is fully charged before assembly, see page 21.
Insert the Battery (M) with the Battery Release Button (L) facing away
from the Battery Carriage (G). An audible *click!* will be heard when
it’s secured into place. To Remove, press the Battery Release Button (L)
and out the battery away from the machine.
www.hyundaipowerproducts.co.uk
21
Operation
Battery Charger Operation
!
Ensure the power source switch is OFF when plugging in Battery Charger
1. Slide the Battery (M) into the Battery Charger (N), by lining up the
terminals on both. It will be secured with an affirmative *click!*.
NOTE – To remove the battery, press the Battery Release Button(L) whilst
pulling away from the Battery Charger (N).
2. Plug in the Battery Charger (N), then turn on the power source.
3. The Charge State Lights will indicate the following:
Solid Green – Ready to charge
Flashing Red – Charging
Solid Green & Solid Red – Fully Charged
Flashing Green – Temperature Issue
Flashing Red – Defective Battery
!
You MUST understand the whole Instruction Manual before any operation
Charge State
Lights
Operation
Machine Adjustment
!
Before Operation, you MUST read and understand the whole User Manual
www.hyundaipowerproducts.co.uk
22
The HY2187 has adjustable for all heights of user. Use the Adjustment
Collar (B), to extended the telescopic shaft of the machine. Loosen the
collar, extended to preferred length and then secure by tightening the
collar.
The Trimmer head angle can also be changed, press the Trimmer Head
Angle Button (H) to adjust the position of the trimmer head. It will snap
into it’s varying positions when the button is released.
B
H
Operation
Edging Wheel Use
www.hyundaipowerproducts.co.uk
23
The Trimmer Head Rotation Collar (P) is used to rotate the Trimmer head
for the Edging wheel use. Pull the whole trimmer head downward, this
will open up the Trimmer Head Rotation Collar (P), allowing the trimmer
head to rotate. It will rotate either way dependant on preference.
P
The wheel will now roll
along with the machine
Operation
Stopping and Starting
www.hyundaipowerproducts.co.uk
24
1. When using the HY2187, the machine required use of both hands.
Ensure the Auxiliary handle is in a comfortable position. Loosen the
hand nut on the Auxiliary handle, and adjust to preferred position.
Secure by tightening the hand nut.
2. To start the machine, you my firstly press the Power Safety Button
(E). Whilst pressing this, press the On/Off Trigger. With these 2
simultaneously pressed, the machine will start. Allow the machine a
second or two to get to full speed.
E
F
C
Automatic Line Feed
Every time the machine is switched on, the trimmer line will automatically be given
out. You do not need to extend it yourself. There is a built-in line cutter so it will cut
the line to make sure it is not too long. You must make sure the cutting head has
stopped completely before switching the machine on again.
When the trimmer line has run out, you can replace it following the instructions in
this manual. You can either replace the trimmer line or replace the whole spool.
www.hyundaipowerproducts.co.uk
25
Operation
Tips For Use
After reading the safety instructions carefully, follow the instructions below
attentively in order to get the most out of your grass trimmer.
1. Start off slowly, when you have gained experience, you will be able to use the
grass trimmer to its full potential.
2. Start the grass trimmer before getting close to the grass being cut.
3. Cut the grass by moving the grass trimmer from right to left and proceed slowly.
4. High grass should be cut in layers, always beginning from the top. The cuts
should be short.
5. You must always work with the cable away from the trimmer.
www.hyundaipowerproducts.co.uk
26
Maintenance & Care
General Maintenance
WARNING : Turn OFF the machine, allow all moving parts to come to a
complete stop, and disconnect the power cord before maintaining the machine.
You need to wear proper clothing and protective gloves whenever your hands are
at risk.
• Keep all nuts, bolts and screws tight to be sure the machine is in a safe working
condition.
• Replace worn or damaged parts for safety. Only use manufacturer-
recommended parts and accessories.
!
Storage
Keep the machine stored in a dry, level area away from damp, moisture and
rain fall. Allow the machine to cool down before storing.
• Make sure the machine is clean and dry before storing.
• Ensure the machine is stored in a position, where any persons cannot step on, to
attempt to reach items up high, due to risk of movement.
• DO NOT store the machine near an ignition source, such as a wood stove, gas
or electric heater, or an appliance or heater with a pilot light.
• Store the machine out of reach of children or anyone who is not familiar with
operation.
• DO NOT stack other items on top of the machine when in storage.
• Make sure the machine is stored away from direct sunlight. Store indoors or in a
safe, frost-free area during severe weather and winter months.
!
www.hyundaipowerproducts.co.uk
27
Maintenance & Care
Replacing Trimmer Line
1. Turn the trimmer so that the cutting head is facing upwards. Squeeze the two
tabs on the spool cover. See image 1.
2. Pull spool cover away from spool. See image 2.
3. Cut two lengths of nylon trimmer line 5m in length and insert the end of each line
into the two holes in the trimmer spool reel. See image 3.
4. Wind the trimmer line around the reel in the direction of the arrow. See image 4.
Image 1
Image 2
Image 3
Image 4
!
WARNING : Make sure the battery is disconnected.
We recommend using 1.3mm, 1.4mm or 1.5mm nylon grass trimmer line.
www.hyundaipowerproducts.co.uk
28
Maintenance & Care
Replacing Trimmer Line (Continued)
5. Clip the trimmer lines onto the reel as shown. See image 5.
6. Thread the trimmer line through the holes in the spool body. Slide the reel onto
the drive shaft. See image 6.
7. Pull the trimmer line outwards to release it from the reel clips. See image 7.
8. Slide the spool cover over the spool assembly and push firmly into place. When
you use the trimmer, any excess trimmer line will be cut off with the trimmer blade
mounted on the guard. See image 8.
Image 5
Image 6
Image 7
Image 8
www.hyundaipowerproducts.co.uk
29
Maintenance & Care
Replacing Spool
1. Turn the trimmer so that the cutting head is facing upwards. Squeeze the two
tabs on the spool cover. See image 1.
2. Pull spool cover away from spool. See image 2.
Image 1
Image 2
3. Remove the empty line spool. See image 3.
Image 3
!
WARNING : Make sure the battery is disconnected.
Continued on next page
Spare Spool Part Number : 1317019
www.hyundaipowerproducts.co.uk
30
Maintenance & Care
Replacing Spool (Continued)
4. On the new spool, free both ends of the line. Thread both ends of the line
through the holes on the spool body with the smooth side with the arrow facing
upwards. Make sure the ends of the line do not slip out of the holes. See image 4.
5. Insert the new spool onto the cutting head. See image 5.
Image 4
Image 5
Image 6
6. Slide the spool cover over the spool assembly and push firmly into place. When
you use the trimmer, any excess trimmer line will be cut off with the trimmer blade
mounted on the guard. See image 6.
www.hyundaipowerproducts.co.uk
31
Maintenance & Care
Troubleshooting
Problem Possible Cause Possible Solution
Machine will not start. Faulty Battery Check on charger for
fault.
Internal wiring fault. Contact your service
dealer.
Machine functions
intermittently.
Internal wiring fault. Contact your service
dealer.
Trimmer line not feeding. Trimmer line not installed
correctly.
Check user manual for
fitting instructions.
Trimmer not cutting
cleanly.
Incorrect trimmer line
installed.
Check trimmer line
thickness – replace if
incorrect.
Trimmer head clogged
with grass trimmings.
Cut power to motor and
clear any built up grass
trimmings around the
trimmer head.
Trimmer head not
spinning at correct
speed.
Contact your service
dealer.
NOTE : All corrective actions should be carried out by suitably qualified person/s.
!
If the trimmer line breaks or
snaps and is not long enough,
you can manually extend the
trimmer line.
1. There is a small button (see
diagram). You can press this
button and then pull the line
out 1cm.
2. If you need to extend the
line more than 1cm, you must
press the button again and
pull the line out another 1cm.
3. Any excess trimmer line will
be cut off with the trimmer
blade mounted on the guard.
Snapped Trimmer Line
www.hyundaipowerproducts.co.uk
32
Technical Data
Machine Specification
Model HY2187
Motor Rated Power 775W
No Load Speed 8000 RPM
Cutting Width 25cm
Voltage 20V
www.hyundaipowerproducts.co.uk
33
Recycling & Disposal
Recycling & Disposal
We do not offer a takeback scheme for the recovery of Waste Electrical Electronic
Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and/or
Batteries is passed onto you by us.
So when it becomes necessary to dispose of your machine you must take it to your
local Civic Amenity Site. For further information please contact your local Authority
for disposal advice.
You MUST make sure that all unused oil and fuel is disposed of correctly either
beforehand or at your local Civic Amenity Site.
• Under NO circumstances must any fuel or oil be put down any drains.
• Certain products contain WEEE waste which should not be disposed of in your
domestic waste.
• You MUST recycle WEEE in accordance with your local authority or recycling
centre.
• Certain products contain batteries which should not be disposed of in your
domestic waste.
• You MUST recycle batteries in accordance with your local authority or recycling
centre.
• Unwanted packaging and materials should be stored and taken to a recycling
centre so it can be disposed of in a manner which is compatible with the
environment.
We are a Member of the VALPAK National Compliance Scheme and our
registration number is RM08660. For further information about disposal please
contact your Local Authority.
You can also get more advice and guidance about recycling at the following
website http://www.recycle-more.co.uk
Should you pass this product on to another user either sold or loaned, you MUST
pass on this user manual. This will make sure that all other users can use and
maintain this machine safely.
1. Environmental protection should be a priority of considerable importance when
using the machine, for the benefit of both social coexistence and the environment
in which we live. Try not to cause any disturbance to the surrounding area.
2. You must comply with local regulations and provisions for the disposal of
packaging, oils, fuel, filters, damaged parts or any elements which have a strong
impact on the environment. This waste must not be disposed of as normal waste. It
needs to be separated and taken to specified waste disposal centres where the
material will be recycled.
3. You must comply with local regulations for the disposal of waste materials after
mowing.
4. When disposing, do not pollute the environment with the machine, but hand it
over to a disposal centre, in accordance with the local laws in force.
Environmental Protection
www.hyundaipowerproducts.co.uk
34
Declaration Of Conformity
Importer and Authorised Representative
Genpower Ltd
Isaac Way, Pembroke Dock, SA72 4RW
Country of Origin: China
Description: 20V Cordless Grass Trimmer and Charger
SKU Code: HY2187
Date of Issue: 17/12/2021
Regulations and Directives of Compliance
2006/42/EC - The Machine Directive
IEC/EN 60335-2-29 - Safety of household and similar electrical appliances
Part 2: Particular requirements for battery chargers
EN 55014-1:2017+A11:2020; EN 55014-2:2015;
EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019 - Electromagnetic
Compatibility Regulations 2016
REFERENCES TO THE RELEVANT HARMONISED SAFETY STANDARDS USED
OR REFERENCES TO THE OTHER TECHNICAL SPECIFICATIONS IN RELATION
TO WHICH CONFORMITY IS DECLARED:
EN 60335-1:2012/A2:2019 - Household and similar electrical appliances - Safety -
Part 1: General requirements
EN 50636-2-91:2014 - Household and similar electrical appliances - Safety - Part 2-
91: Particular requirements for walk-behind and hand-held lawn trimmers and
lawn edge trimmers
BS EN 60335-2-29:2004 + A2:2010 + A11:2018 to be used in
conjunction with BS EN 60335-1:2012 + A11:2014 + A13:2017 +
A1:2019 + A2:2019 + A14:2019 and BS EN 62233:2008 -
Electrical Equipment (Safety)
Regulations 2016
Statement of Declaration
We the importer and authorised representative of the product described confirm
conformity within the provisions of applicable regulations and directives listed
within this document.
Signed on Behalf of Genpower Ltd
Place of Issue: Genpower Ltd
Signatory Name: Roland Llewellin
Position: Managing Director
……………………………………
www.hyundaipowerproducts.co.uk
35
Useful Information
Check Out Our YouTube Channel
Our videos on YouTube include:
• Unboxing
• Assembly of your machine
• How to service your machine
• Products in use
• ‘How To’ videos
• Product features
Go to YouTube and search ‘Hyundai Power Products’.
Manual Updates
Our manuals are constantly being reviewed and updated. Should you find an
error, omission or something unclear, please contact us for assistance. We reserve
the right to make any modifications without prior notice whenever necessary.
Our latest manuals are also placed online. All our manuals can be downloaded at:
www.hyundaipowerproducts.co.uk
Returning Your Product
If you are returning your product, please contact the dealer for their returns policy.
Leaving A Review
We work very hard to give all of our customers the best possible service. If you have
any problems, before leaving negative feedback, please contact us to give us a
chance to resolve the issue. We would be delighted if you left us positive
feedback! To leave a review, please go to:
uk.trustpilot.com/review/hyundaipowerequipment.co.uk
Ordering Spare Parts
You can find the spare part you are looking for at power-spares.co.uk
Warranty
Proof of purchase will be required before you make a warranty claim. Full warranty
terms and conditions can be found on the HYUNDAI POWER PRODUCTS website:
www.hyundaipowerproducts.co.uk
www.hyundaipowerproducts.co.uk
36
Product Record
Information
As soon as you have purchased the machine, we recommend that you fill out the
following. If you need to contact an authorised dealer or customer service for
information on servicing, you may need to provide the following information.
Date Of Purchase:……………………………………………………………………………….....
Dealer Name:………………………………………………………………………………………..
Dealer Phone:…………………………………………………………………………………….....
Model Number:…………………………………………………………………………………......
Serial/Batch Number:………………………………………………………..………………........
www.hyundaipowerproducts.co.uk
37
Notes
www.hyundaipowerproducts.co.uk
38
Notes
www.hyundaipowerproducts.co.uk
39
Contact Us
Need Help? Talk To Our Experts
Our friendly aftersales team will be more than happy to help you.
Phone
Call our team on 01646 687 880
Email
Online Live Chat
Go to www.hyundaipowerproducts.co.uk
Post
Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW.
Hyundai Support Website
Go to hyundaisupport.co.uk
For Inquiries, Please Contact:
GENPOWER LTD
Isaac Way, London Road,
Pembroke Dock, UK, SA72 4RW.
T: +44 (0) 1646 687 880
E: [email protected].uk
www.hyundaipowerproducts.co.uk
Imported / Distributed by Genpower Ltd for
the United Kingdom & Ireland
Licensed by Hyundai Corporation Holdings, Korea
