Sencor SCOOTER S25 Scooter User Manual

SCOOTER S21/S25

EN User Manual Electric scooter

Uživatelská příručka Elektrická koloběžka

Používateľská príručka Elektrická kolobežka

Felhasználói kézikönyv Elektromos roller

Podręcznik użytkownika Hulajnoga elektryczna

EN 3

Revision 12/2024

Table of Contents

1. Package Contents and Scooter Description ............................................................4

1.1. Package Contents .................................................................................................4

1.2. Description of the SCOOTER S21/S25 ...................................................................4

2.1. Control Panel and Application ..............................................................................5

2.2. Multifunction Button ..............................................................................................6

2.3. Riding Modes .......................................................................................................... 6

2.4. Starting the Operating Mode .................................................................................6

3. Assembling the Electric Scooter ..............................................................................8

4. Charging ...................................................................................................................9

5. Battery Over-Discharge Protection .........................................................................9

6. Folding and Transport ............................................................................................ 10

7. Operating the Electric Scooter ...............................................................................11

8. Safety Instructions .................................................................................................12

9. Maintenance and Adjustment ................................................................................13

10. Technical Speciﬁcations ....................................................................................... 17

4 EN

Package contents and scooter description

Revision 12/2024

1. Package Contents and Scooter Description

1.1. Package Contents

1x Electric scooter SCOOTER S21/S25

1x Charging adapter

1x Allen key

6x Handlebar mounting screws

1x User Manual

1x Tyre inﬂation adapter

4x front fork side reﬂectors

4x rear fork reﬂective stickers

2x long spare screws for the footboard

2x short spare screws for the footboard

1.2. Description of the SCOOTER S21/S25

5 6

3 4

13 14 15

16 17



➊ Rear mechanical brake lever

➋ Bell

➌ Hook for securing in transport state

➍ Speed controller

➎ Left turn indicator

➏ Buttons (left and right turn indicators)

➐ On/Off/Multifunction button

➑ Display

➒ Right turn indicator

➓ Front light

Release lever for folding mechanism

Front wheel with inner tube, tyre for

inﬂation, and electric motor

Charging connector

Stand (lowest point of the scooter

body)

Footboard, battery compartment

Notch for securing the handlebar in

folded state

Rear LED light / brake light

Rear mechanical disc brake

Rear wheel with inner tube and tyre

for inﬂation

Operation

EN 5

Revision 12/2024

2. Operation

2.1. Control Panel and Application

➊ Current speed

➋ Indicator for connected device via Bluetooth

➌ Riding modes (ECO – Economy; D – Drive;

S– Sport)

➍ Active front light

➎ Walk – mode (reduced speed mode)

➏ Overheating indicator – triggered when the

scooter’stemperature exceeds 90°C

➐ Device error indicator – contact aservice centre

➑ Battery level indicator

➒ Multifunction button

Settings via the Mobile App



ϭ Nastavenípomocí mobilní aplikace



Tuto elektrickou koloběžku je možné ŶĂƐƚĂǀŝƚprostřednictvím aplikace SENCOR HOME.



• Stáhněte si aplikaci do svého chytrého mobilního telefonu, zaregistrujte se a ŶĂƐƚĂǀƚĞ

elektrickou koloběžku. Pokud již aplikaci SENCOR HOME máte nainstalovanou, přidejte si do

ní elektrickou koloběžku.



• Návodjak zacházet saplikacínaleznete ke stažení na webu ŚƚƚƉƐǁǁǁƐĞŶĐŽƌĐŽŵ

ǀsekci KOLOBĚŽKY

• Reset spárování saplikací SENCOR HOME se provádí vzapnutém stavu elektrické koloběžky a

stiskem zapínacího tlačítka 8x za sebou. Úspěšné vyresetování bude oznámeno akustickým

tónem. 



This electric scooter can be set up via the SENCOR HOME app.

• Download the app to your smartphone, register and set up your electric scooter.

If you already have the SENCOR HOME app installed, add your electric scooter to

it.



ϭ Nastavenípomocí mobilní aplikace



Tuto elektrickou koloběžku je možné ŶĂƐƚĂǀŝƚprostřednictvím aplikace SENCOR HOME.



• Stáhněte si aplikaci do svého chytrého mobilního telefonu, zaregistrujte se a ŶĂƐƚĂǀƚĞ

elektrickou koloběžku. Pokud již aplikaci SENCOR HOME máte nainstalovanou, přidejte si do

ní elektrickou koloběžku.



• Návodjak zacházet saplikacínaleznete ke stažení na webu ŚƚƚƉƐǁǁǁƐĞŶĐŽƌĐŽŵ

ǀsekci KOLOBĚŽKY

• Reset spárování saplikací SENCOR HOME se provádí vzapnutém stavu elektrické koloběžky a

stiskem zapínacího tlačítka 8x za sebou. Úspěšné vyresetování bude oznámeno akustickým

tónem. 



6 EN

Operation

Revision 12/2024

• Instructions for using the app can be downloaded from the website https://www.

sencor.com/ under the "SCOOTERS" section.

• Reset pairing with the SENCOR HOME app is done with the electric scooter

switched on and the power button pressed 8 times in succession. Successful

reset will be announced by an audible tone.

2.2. Multifunction Button

CAUTION:

Always conﬁgure riding settings before beginning your ride.

1) When the scooter is powered off, press and hold the multifunction button to turn

it on.

2) When the scooter is powered on, press and hold the multifunction button for 2

seconds to turn it off.

3) When the scooter is powered on, ashort press of the multifunction button turns

the LED front light on/off.

4) When the scooter is powered on, aquick double-press of the multifunction button

switches between riding modes.

5) When the scooter is powered on, aquick triple-press of the multifunction button

toggles the speed units on the display (km/h or mph).

2.3. Riding Modes

Switching between riding modes is done by double-clicking the multi-function but-

ton.

Walk up to 6 km/h

Eco up to 10 km/h

Drive up to 20 km/h

Sport up to 25 km/h

2.4. Starting the Operating Mode

1) Switch on the electric scooter.

2) Fully press and hold the speed controller until the display shows

the value 16.

3) Keep holding down the speed controller and press the brake lever simultaneously.

4) Release the brake lever.

5) The scooter will switch to the last set riding mode.

Operation

EN 7

Revision 12/2024

CAUTION:

Always activate the operating mode when the electric scooter is

stationary. Follow the activation instructions step by step and proceed

slowly.

Turn Indicators Control

• The turn indicator control is located on the left side of the handlebars, see

➏ on

the main diagram. The activated indicator will turn off automatically after awhile

or can be turned off manually using the same button it was activated with.

• Pressing the right button activates the turn indicator on the right end of the

handlebars.

• Pressing the left button activates the turn indicator on the left end of the

handlebars.

Replacing the Indicators

Exercise caution when storing, parking, or in the event of the scooter falling onto

objects that may damage the turn indicators located at the ends of the handlebars.

If the turn indicator is mechanically damaged, replacement indicators can be

purchased as spare parts. To replace the turn indicator, loosen the 1.5 mm Allen

screw located underneath the handlebars. Remove the turn indicator and disconnect

it at the connector. Attach the new turn indicator and secure the connector with

anew protective sleeve. Insert the turn indicator into the handlebar tube and gently

tighten the 1.5 mm Allen screw.

8 EN

Assembling the electric scooter

Revision 12/2024

3. Assembling the Electric Scooter

1. Straighten the handlebar pole and securely fasten it using the locking lever.



2. Check the connection of the control unit connectors to the control panel. The

connectors with wires must be properly connected to prevent loosening later on.



3. Carefully connect the handlebar with the handlebar tube. Avoid damaging the

connecting wire when placing it into the steering tube. Ensure he LED front light

faces the riding direction.

Charging

EN 9

Revision 12/2024

4. Screw the handlebars and the handlebar tube together. Insert two Allen screws

Afrom the left side andtwo Allen screws B from the opposite side, as shown

in the diagram. Tighten the screws ﬁrmly. Regularly check that the screws have

not loosened during use.

5. Switch on the electric scooter.

4. Charging

Before starting your ride, ensure the battery is fully charged. Turn on the control panel

and check the battery level.

The charging is performed with the supplied charging adapter. First, uncover the

rubber cap of the charging connector on the scooter and connect the charging

adapter. Then connect the adapter to your power outlet. When the charging process

is ﬁnished and the charging adapter is disconnected, cover the charging connector

opening again with the rubber cap. Regularly check if the protective cap covers the

charging connector when charging is not in progress.

The charging adapter includes acharging indicator displaying two states.

1. Red LED light: Indicates the battery charging process

2. Green LED light: Indicates the battery is fully charged

CAUTION:

Only use the original accessories provided in the package for charg-

ing. If the battery life becomes very short, it is asign that the bat-

tery'slifespan has been consumed. It is recommended to have the

battery replaced at an authorised service centre.

Recommendation:

If the unit is not to be used for an extended period of time, we recommend to fully

charge the battery once every two to three months. We do not recommend storing the

unit with aﬂat battery to prevent irreparable damage to the battery (loss of capacity).

5. Battery Over-Discharge Protection

The electric scooter is equipped with the protection of each component against dam-

age due to operational overload and lower battery charging level.

1. If the scooter is subject to ahigher load for example due to frequent riding uphill

or riding up asteep hill, the control unit/battery overheating protection will be

enabled, limiting the power for anecessary period of time. The speed will be

reduced to amaximum of 15 km/h.

10 EN

Folding and transport

Revision 12/2024

2. If the battery level drops below 30%, the maximum scooter speed will be limited

to 15 km/h. If the battery level drops below 25%, the maximum speed will be

limited to 10 km/h.

CAUTION:

Do not modify or interfere with the protective mechanisms of the

electric scooter (SCOOTER S21/S25). This will help prevent damage to

individual components of the scooter.

6. Folding and Transport

1. Ensure the electric scooter is turned off. Hold the scooter steady, unlock the

release lever of the folding mechanism located at the bottom of the handlebar

tube, and ﬂip the lever forward in the direction of travel.

CZ 9

Skládání a transport

2. Sklopte uvolněnou řídítkovou trubku směrem k zadnímu blatníku, kde ji zajistíte

pomocí háku na řídítkách a zářezu na zadním blatníku. Správné složení do

transportního stavu

3. Pro přenášení uchopte Scooter One 2020 za řídítkovou trubku. Pro pohodlnější

transport doporučujeme držet řídítkovou trubku v třetině její délky, na straně blíže

k přednímu kolu.

Sencor Scooter One EN CZ SK PL HU.indb 9Sencor Scooter One EN CZ SK PL HU.indb 9 16.08.2020 21:05:2416.08.2020 21:05:24

2. Fold the loosened handlebar tube towards the rear mudguard, securing it using

the hook

➌ on the handlebars and the notch on the rear mudguard.

3. To carry the scooter, hold it by the handlebar tube. For more convenient trans-

port, we recommend to hold the handlebar tube in one third of its length on the

side near front wheel.

CZ 9

Skládání a transport

2. Sklopte uvolněnou řídítkovou trubku směrem k zadnímu blatníku, kde ji zajistíte

pomocí háku na řídítkách a zářezu na zadním blatníku. Správné složení do

transportního stavu

3. Pro přenášení uchopte Scooter One 2020 za řídítkovou trubku. Pro pohodlnější

transport doporučujeme držet řídítkovou trubku v třetině její délky, na straně blíže

k přednímu kolu.

Sencor Scooter One EN CZ SK PL HU.indb 9Sencor Scooter One EN CZ SK PL HU.indb 9 16.08.2020 21:05:2416.08.2020 21:05:24

Operating the electric scooter

EN 11

Revision 12/2024

7. Operating the Electric Scooter

CAUTION:

• Before each ride, use helmet and protectors to prevent injury in case

of falling.

• Before each ride, please check if the mechanical brake is fully functional.

1. Place one foot on the footboard of the scooter and use the other foot to gently

push off from the ground.

CAUTION:

Always push off with the foot on the side where the stand

is not

located.

10 CZ

Řízení Scooter One 2020

7. Řízení Scooter One 2020

UPOZORNĚNÍ:

• Před každou jízdou použijte helmu a chrániče, abyste předešli zranění v

případě pádu.

• Před každou jízdou zkontrolujte plnou funkčnost mechanické brzdy.

1. Položte jednu nohu na nášlapnou plochu koloběžky a druhou nohou se lehce

odražte od země.

2. Jakmile koloběžku uvedete v pohyb, zmáčkněte ovládací páčku rychlosti, aby se

spustil motor. Jakmile se koloběžka rozjede pomocí vlastní síly, položte i druhou

nohu na plochu koloběžky.

Poznámka:

Spuštění motoru a rychlost koloběžky lze ovládat po dosažení rychlosti min. 5

km/h.

Sencor Scooter One EN CZ SK PL HU.indb 10Sencor Scooter One EN CZ SK PL HU.indb 10 16.08.2020 21:05:2416.08.2020 21:05:24

2. Once the scooter is in motion, press the speed control lever ➍ to activate the

motor. When the scooter starts moving under its own power, place the other foot

on the footboard

Note:

The motor will start, and the scooter'sspeed can be controlled once aminimum

speed of 5 km/h is reached.

10 CZ

Řízení Scooter One 2020

7. Řízení Scooter One 2020

UPOZORNĚNÍ:

• Před každou jízdou použijte helmu a chrániče, abyste předešli zranění v

případě pádu.

• Před každou jízdou zkontrolujte plnou funkčnost mechanické brzdy.

1. Položte jednu nohu na nášlapnou plochu koloběžky a druhou nohou se lehce

odražte od země.

2. Jakmile koloběžku uvedete v pohyb, zmáčkněte ovládací páčku rychlosti, aby se

spustil motor. Jakmile se koloběžka rozjede pomocí vlastní síly, položte i druhou

nohu na plochu koloběžky.

Poznámka:

Spuštění motoru a rychlost koloběžky lze ovládat po dosažení rychlosti min. 5

km/h.

Sencor Scooter One EN CZ SK PL HU.indb 10Sencor Scooter One EN CZ SK PL HU.indb 10 16.08.2020 21:05:2416.08.2020 21:05:24

12 EN

Safety instructions

Revision 12/2024

3. Stopping is essential for safe driving. First, release the speed controller ➍ and

then press the mechanical brake

➊ located on the left side of the handlebars.

4. Try the ﬁrst turns on aﬂat surface and at slow speed. Turning is done by slightly

shifting your body weight. Use gentle tilting in the desired direction of travel and

aslow rotation of the handlebars.

8. Safety Instructions

This electric scooter is designed for fun and recreational use. This is not ameans of

transport. Observe the safety of everyone in both private and public areas, follow the

instructions below as well as local trafﬁc regulations.

When meeting pedestrians, pay close attention to your ride and make sure pedestri-

ans are aware of

your presence. If you are outside their angle of view, ring the bell, slow down

and overtake (overtake from the left in case of right-hand trafﬁc).

Higher driving speed means automatically alonger braking path. Keep safe speed in

case of unexpected need to stop and keep asafe distance from others. Even on aﬂat

surface, you may encounter situations or terrain that cause you to lose balance, skid

or other unexpected situations that can cause you to fall. Always pay close attention

to driving.

Check the mechanical brake, battery charge status, wear of components and wheels

before each ride. In case of loose parts or unusual noises, carry out athorough

check and contact an authorised service centre if necessary.

Neither the manufacturer nor the distributor are liable for any ﬁnancial damages,

injuries, accidents, legal disputes or conﬂicts resulting from non-observance of

the safety instructions.

• Do not drive in the rain and avoid slippery surfaces.

• If you encounter an obstacle on your way, stop and carry the scooter over the

obstacle.

• Exercise caution when passing through low ceilinged areas.

• Do not accelerate downhill and always brake well in advance.If you encounter

asteep descent (e.g. asteep hill), stop and guide your scooter.

• Do not add speed while pushing the scooter.

• Always avoid obstacles.

• Avoid carrying heavy luggage on the handlebar.

• Always keep both feet on the scooter footboard while riding.

• Use the scooter only in areas designated for such activities. Observe the local

regulations of the regions, parks, cities and states where you want to operate

the scooter.

• Do not turn sharply at high speeds.

• Do not ride through puddles, water or in rain.

• Never ride with other persons, even with children.

• Do not step on the mudguards.

Maintenance and adjustment

EN 13

Revision 12/2024

• Do not touch the brake components.

• Always hold onto the handlebars.

• Do not try to ride up the stairs, down the stairs or jump with your scooter.

• Remember that the stand is the scooter'slowest point. Exercise caution to pre-

vent it from catching on elevated surfaces during rides.

9. Maintenance and Adjustment

Regular maintenance and correct adjustment of all parts of the electric scooter pro-

longs its lifespan. Clean individual components of the electric scooter with adamp

cloth and apply apreservation oil (excluding brake discs and pads).

Before each ride, check the tightness and attachment of all removable parts. If any

screws, Allen screws, or nuts are loose, tighten them with the appropriate tool.

The brake mechanism must be adjusted before the ﬁrst ride. Contact aspecialised

provider (e.g. abike service) for proper adjustment. Brake adjustments are not in-

cluded under the manufacturer or distributor'swarranty or post-warranty service.

CAUTION:

Never use high-pressure water cleaning methods on the electric scooter.

Brake Adjustment – If the brakes are too tight or too loose, use a4 mm Allen key to

loosen the brake mechanism screw (counterclockwise) and adjust the brake cable

length as needed. Then tighten the screw ﬁrmly. Further ﬁne-tune the brake cable

tension using the nut on the mechanical brake mounted on the handlebars. Regu-

larly inspect brake pads for wear and replace them as necessary. Brake pads are

consumable parts that degrade with use. Keep the entire braking system clean and

avoid greasy deposits on the brake disc and pads.

12 CZ

Údržba a seřízení

• Neprojíždějte kalužemi, vodou a nejezděte v dešti.

• Nejezděte ve dvou ani v případě dětí.

• Nestoupejte na blatníky.

• Nedotýkejte se brzdových komponentů.

• Vždy se držte řídítek.

• Nesnažte se jezdit do schodů, ze schodů ani skákat s koloběžkou.

9. Údržba a seřízení

Před první jízdou je nutné provést seřízení brzdového mechanismu. Pro správné

seřízení se obraťte na specializovaného poskytovatele (např. cykloservis). Seřízení

nelze provádět v rámci záručního ani pozáručního servisu u výrobce ani distributora.

V případě příliš utažených nebo příliš povolených brzd použijte 4mm imbusový klíč a

uvolněte šroub brzdového mechanismu proti směru hodinových ručiček a upravte délku

brzdového lanka. Poté šroub pevně utáhněte. Pro doladění upravte napětí brzdového

lanka matkou u mechanické brzdy upevněné na řídítkách.

V transportním stavu je v kloubu řídítkové trubky přístupný šroub (4mm imbus) pro

utažení jejího upevnění.

Sencor Scooter One EN CZ SK PL HU.indb 12Sencor Scooter One EN CZ SK PL HU.indb 12 16.08.2020 21:05:2516.08.2020 21:05:25

Handlebar Joint Adjustment – When in the folded position, a4 mm Allen screw C

is accessible on the handlebar joint for tightening its attachment. Before tightening

the Allen screw in the handlebar tube joint, ﬁrst loosen the screws on the clamp

(indicated by arrows in diagram B). Tighten the joint ﬁtting gently to ensure that the

steering rotation is not rigid and that the slack in the joint ﬁtting is as small as possi-

ble. After adjustment, align the handlebars and securely tighten screws B. Whenev-

er steering looseness increases due to riding, tighten the components according to

the procedure.

14 EN

Maintenance and adjustment

Revision 12/2024

A B C

Folding Mechanism Lever Adjustment – If the folding mechanism becomes loose,

an adjustment is required. The adjustment screw ﬁts into the folding mechanism

lever and is located at the bottom of the handlebar tube. Fold the handlebars into the

transport position and eliminate the play by loosening the Allen screw (turn counter-

clockwise). Loosen the screw gradually and repeatedly test folding the scooter into

the operational state until the lever'slocking mechanism is appropriately ﬁrm. Never

loosen the screw to the extent that the folding mechanism lever can only be locked

with excessive force.

Wheel and Tyre Inspection – The wheels of the electric scooter are inﬂatable and

equipped with inner tubes. Regularly check the condition of the tyres. If the tyres

show damage or excessive wear from use, replace them immediately.

CAUTION:

The correct tyre size and pattern prescribed by the manufacturer must

always be observed. Do not attempt to change the tyre without profes-

sional assistance.

Before each ride, check the air pressure in the tyres. The air pressure must be main-

tained between 2.2 bar and 2.4 bar. If the tyre pressure is lower, use apump with

aSchrader valve ﬁtting to inﬂate it to the required value. If the pressure is higher,

deﬂate it to the recommended level.

Removing the Front Wheel

List of tools:

4 mm Allen key

small Phillips screwdriver

blunt tool

hair dryer

18 mm wrench

double-sided adhesive tape

EN 15

Revision 12/2024

Maintenance and adjustment

Unscrew two Phillips screws Aon the right side of the scooter. Carefully heat

the side reﬂectors B with ahair dryer and gently peel them off with ablunt tool.

Unscrew the Allen screw C (2 on each side of the electric scooter). Remove the side

covers of the front fork and unscrew the nuts D of the front wheel. Pull slide the

wheel downward E.

For reassembly, follow the reverse order, ensuring the wheel is reassembled as it

was before disassembly. To attach the reﬂector B, clean the contact surfaces (with

acleaning agent*) and use new double-sided adhesive tape.

CAUTION:

Perform all tasks carefully to avoid damaging individual parts. When

assembling, pay attention to precision and ensure that all connecting

nuts and screws are securely tightened. Exercise extra caution when

handling the front wheel near the motor wire connection area. The

motor wire cannot be disconnected. If you are unsure about assembly

or disassembly, contact aspecialised service centre. The replacement

of tyres and inner tubes is not covered under warranty repair.

* Use only cleaning agents that do not corrode the materials used.





н



 

Removing the Rear Wheel

List of tools:

4 mm Allen key

5 mm Allen key

hair dryer

Use ahair dryer to heat and peel off reﬂector A. Unscrew the Allen screws and

remove the plastic covers of the rear wheel on both sides. Unscrew the Allen screw

C from both sides of the rear wheel and pull the wheel backward D.

16 EN

Revision 12/2024

Maintenance and adjustment

CAUTION:

Perform all tasks carefully to avoid damaging individual parts. When

assembling, pay attention to precision and ensure that all connecting

screws are securely tightened. If you are unsure about assembly or

disassembly, contact aspecialised service centre. The replacement of

tyres and inner tubes is not covered under warranty repair.





н



 

EN 17

Revision 12/2024

10. Technical Speciﬁcations

SCOOTER S21

Key Features

Motor power 250 W

Maximum speed up to 25 km/h

Range up to 20 km

SENCOR SCOOTER app available at Google Play and APP Store

Front and rear LED light

LED display (mode, speed, battery, lighting, Bluetooth)

Turn signal indicators

Drive

Motor power 250 W

Speed:

- SPORT mode up to 25 km/h

- DRIVE mode up to 20 km/h

- ECO mode up to 10 km/h

- WALK mode up to 6 km/h

Range up to 20 km at aweight of 70 kg

Cruise control

Maximum incline up to 12°

Wheels

8.5-inch front and rear inﬂatable tyres

Dual braking system - electrical and mechanical

Disc brakes

SENCOR HOME App

Available at Apple App Store and Google Play

Scooter locking via the app

Bluetooth 5.0

Technical Speciﬁcations

Maximum load: 120 kg

Dimensions: 107 x 49 x 115 cm (unfolded)

Dimensions: 107 x 49 x 47cm (folded)

Weight: 12.5 kg

Working temperature: 0 to 40 °C

Storage temperature: 0 to 45 °C

Noise level < 70 dB(A)

Charging Adapter

Input voltage: 100–240 VAC 50/60 Hz

Input current: 1.5 A

Output voltage: 42 V

Connector: Φ 5.5 x 10 mm

Battery

Capacity: 187 Wh – 5.2 Ah/36 VLi-ion

Charging time: max. 4 hours

Protection against: short circuit, overvoltage, overcharging, overheating

Battery discharge protection

Technical speciﬁcations

18 EN

Revision 12/2024

SCOOTER S25

Key Features

Motor power 350 W

Maximum speed up to 25 km/h

Range up to 25 km

SENCOR SCOOTER app available at Google Play and APP Store

Front and rear LED light

LED display (mode, speed, battery, lighting, Bluetooth)

Turn signal indicators

Drive

Motor power 350 W

Speed:

- SPORT mode up to 25 km/h

- DRIVE mode up to 20 km/h

- ECO mode up to 10 km/h

- WALK mode up to 6 km/h

Range up to 25 km at aweight of 70 kg

Cruise control

Maximum incline up to 15°

Wheels

10-inch front and rear inﬂatable tyres

Dual braking system - electrical and mechanical

Disc brake

SENCOR HOME App

Available at Apple App Store and Google Play

Scooter locking via the app

Bluetooth 5.0

Technical Speciﬁcations

Maximum load: 120 kg

Dimensions: 107 x 49 x 118 cm (unfolded)

Dimensions: 107 x 49 x 49 cm (folded)

Weight: 13 kg

Working temperature: 0 to 40 °C

Storage temperature: 0 to 45 °C

Noise level < 70 dB(A)

Charging Adapter

Input voltage: 100–240 VAC 50/60 Hz

Input current: 1.5 A

Output voltage: 42 V

Connector: Φ 5.5 x 10 mm

Battery

Capacity: 270 Wh – 7.5 Ah/36 VLi-ion

Charging time: max. 6 hours

Protection against: short circuit, overvoltage, overcharging, overheating

Battery discharge protection

Technical speciﬁcations

EN 19

Revision 12/2024

Charging Adapter Value and Accuracy Unit

Manufacturer’sname or

trademark, company ID and

address

"Dongguan Green Power One Co., Ltd

No.26, Hongyun Street, Chonghe

Village, Qingxi Town,

Dongguan City, Guangdong, P. R.

China"

Model identiﬁcation code GA20-4201500T -

Input voltage 100–240 V

Input frequency 50/60 Hz

Output voltage 42.0 V

Output current 1.5 A

Output power 63.0 W

Average efﬁciency in active

mode

89.61 %

Low load efﬁciency (10%) / %

No load power consumption 0.19 W

Bluetooth

Version 5.0

Maximum transmitter power 100 mW at 2.4 GHz – 2.4835 GHz

Noise Emissions

The weighted sound pressure level of amoving vehicle is less than 70 dB (A).

Technical speciﬁcations

20 EN

Revision 12/2024

Warranty conditions

Warranty card is not apart of the device packaging.

This product is warranted for the period of 24 months from the date of purchase to the end-user. Warranty

is limited to the following conditions. Warranty is referred only to the customer goods using for common

domestic use. The claim for service can be applied either at dealer’sshop where the product was bought, or

at below mentioned authorized service shops. The end-user is obligated to set up aclaim immediately when

the defects appeared but only till the end of warranty period. The end user is obligated to cooperate to certify

the claiming defects. Only completed and clean (according to hygienic standards) product will be accepted.

In case of eligible warranty claim the warranty period will be prolonged by the period from the date of claim

application till the date of taking over the product by end-user, or the date the end-user is obligated to take it

over. To obtain the service under this warranty, end-user is obligated to certify his claim with duly completed

following documents: receipt, certiﬁcate of warranty, certiﬁcate of installation.

This warranty is void especially if apply as follows:

 Defects which were put on sale.

 Wear-out or damage caused by common use.

 The product was damaged by unprofessional or wrong installation, used in contrary to the applicable

instruction manual, used in contrary to legal enactment and common process of use or used for another

purpose which has been designed for.

 The product was damaged by uncared-for or insufﬁcient maintenance.

 The product was damaged by dirt, accident of force majeure (natural disaster, ﬁre, and ﬂood).

 Defects on functionality caused by low duality of signal, electromagnetic ﬁeld interference etc.

 The product was mechanically damaged (e.g. broken button, fall).

 Damage caused by use of unsuitable media, ﬁllings, expendable supplies (batteries) or by unsuitable

working conditions (e.g. high temperatures, high humidity, quakes).

 Repair, modiﬁcation or other failure action to the product by unauthorized person.

 End-user did not prove enough his right to claim (time and place of purchase).

 Data on presented documents differs from data on products.

 Cases when the claiming product cannot be indentiﬁed according to the presented documents (e.g. the

serial number or the warranty seal has been damaged).

Manufacturer:

FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic

info@sencor.com

Authorized service centers:

Visit www.sencor.com for detailed information about authorized service centers.

The original version of the instructions is in the Czech language, other language versions are made by the

appropriate translation.

INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED PACKAGING MATERIAL

Take the packaging material to adesignated municipal waste facility.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT

This symbol on products or original documents means that used electric

or electronic products must not be added to standard municipal waste. For

proper disposal and recycling, take these products to designated collection

points. Alternatively, in some European Union states or other European

countries the products can be returned to the local retailer when buying an

equivalent new product. Correct disposal of this product helps save valua-

ble natural resources and prevents damage to the environment caused by

improper waste disposal. Ask your local authorities or collection facility for

more details. Fines may be imposed for improper disposal of this type of

waste in accordance with national regulations.

For Business Entities in European Union States

If you want to dispose of electric or electronic devices, ask your retailer or

supplier for the necessary information.

Disposal in Other Countries Outside the European Union

This symbol is valid in the European Union. If you wish to dispose of this

product, request the necessary information about the correct disposal

method from the local council or from your retailer.

FAST ČR, a.s. hereby declares that the type of radio device SCOOTER

S21/S25 complies with Directive 2014/53/EU.

Changes in the text, design and technical speciﬁcations may be made without prior

notice and we reserve the right to make such changes.

CZ 15

Technické parametry

POKYNY AINFORMACE ONAKLÁDÁNÍ SPOUŽITÝM OBALEM

Použitý obalový materiál odložte na místo určené obcí kukládání odpadu.

LIKVIDACE POUŽITÝCH ELEKTRICKÝCH AELEKTRONICKÝCH

ZAŘÍZENÍ

Tento symbol na produktech anebo vprůvodních dokumentech znamená,

že použité elektrické aelektronické výrobky nesmí být přidány do běžného

komunálního odpadu. Ke správné likvidaci, obnově arecyklaci předejte tyto

výrobky na určená sběrná místa. Alternativně vněkterých zemích Evropské

unie nebo jiných evropských zemích můžete vrátit své výrobky místnímu

prodejci při koupi ekvivalentního nového produktu. Správnou likvidací tohoto

produktu pomůžete zachovat cenné přírodní zdroje anapomáháte prevenci

potenciálních negativních dopadů na životní prostředí alidské zdraví, což

by mohly být důsledky nesprávné likvidace odpadů. Další podrobnosti si

vyžádejte od místního úřadu nebo nejbližšího sběrného místa. Při nesprávné

likvidaci tohoto druhu odpadu mohou být vsouladu snárodními předpisy

uděleny pokuty.

Pro podnikové subjekty vzemích Evropské unie

Chcete-li likvidovat elektrická aelektronická zařízení, vyžádejte si potřebné

informace od svého prodejce nebo dodavatele.

Likvidace vostatních zemích mimo Evropskou unii

Tento symbol je platný vEvropské unii. Chcete-li tento výrobek zlikvidovat,

vyžádejte si potřebné informace osprávném způsobu likvidace od místních

úřadů nebo od svého prodejce.

Tímto FAST CR a.s. prohlašuje, že typ rádiového zařízení Scooter One 2020

je vsouladu se směrnicí 2014/53/EU.

Změny vtextu, designu atechnických speciﬁkací se mohou měnit bez předchozího

upozornění avyhrazujeme si právo na jejich změnu.

Sencor Scooter One EN CZ SK PL HU.indb 15Sencor Scooter One EN CZ SK PL HU.indb 15 16.08.2020 21:05:2516.08.2020 21:05:25
