Shenzhen Reflying Electronic Co., Ltd
User manual
Model: RST97B
MagSafe Car Vent Mount Charger
Please read these instructions carefully before charging and using this product,
and keep this booklet for future reference.
Product Overview
This MagSafe Car Vent Mount Charger is compatible with most smartphones
that support the wireless charging function.
Attachment to AC vents
1.Open the holder lock and fit the holder onto the vent slats.
2.Tighten the clip by twisting to secure it to the car vent..
3. Insert the end of your USB-C cable into the USB-C charging input on this
charger. Insert the other end of USB-C cable’s connector in the cigarette
lighter(not included)in your car.
Charging
This MagSafe Car Vent Mount Charger is compatible with most smartphones
that support the wireless charging function.
1.Place your phone in the centre of the charging base. The magnet holds the
phone in place. Charging starts automatically.
2. The phone can be simply picked up off the charging base at any time.
Shenzhen Reflying Electronic Co., Ltd
Note: The charging chip automatically detects the holder of the phone and,
depending on its location, can determine the best charging point on the phone
to ensure maximum efficiency.
Product specifications
Input voltage
DC5V/2A; 9V/2.22 A
Output power
5W, 7.5W (for iPhone), 10W, 15W max
Wireless charging reach
4 mm
Supported fast charging
standards
PD 2.0/PD 3.0(input)/Qi 2(output)
Dimensions
93*59.3*4 mm
Features
15W Wireless charging.
Strong Magnetic Attachment
Vent Clip Installation, easy to install on car air vent, stable and does not
block air flow.
Wide Compatibility, compatible with most magnetic-supported
smartphones and cases.
Compact & Lightweight, mini size, does not obstruct driving vision, perfect
for daily commuting and travel.
Premium aluminum
Safety Information
Check your phone's compatibility with the specifications indicated on this
product before use.
This product is not a toy. It may contain small components. Keep out of
reach of children.
Do not use the product to charge devices that require a charging current
greater than that specified in the technical specification. Once your device
is fully charged, disconnect it from the product.
Unplug the product from power sources when not in use.
Only use the product for its intended purpose.
Do not place the product on surfaces covered with cloth,tablecloth,etc. Do
not place the product on heat-sensitive surfaces, as it may heat up during
use.
Do not cover the product during use. Provide adequate clearance around
the product.
Improper use carries risk of fire, explosion and other hazards.
Shenzhen Reflying Electronic Co., Ltd
Do not use or leave the product in dusty or otherwise contaminated
environments.
Do not expose the product to extreme temperatures, direct sunlight, heat
sources,etc.
Avoid contact with open flame. Do not place open flame sources, such as
lit candles, on the product. Keep the product in a dry environment.
Do not expose the product to dripping or splashing water. Do not place
water containers, such as vases, on the product.
Do not place heavy objects on the product. Do not subject it to shocks, falls
or other mechanical damage.
Route the power cable so that it does not hang over the edge of a table,
does not touch sharp objects or come into contact with heat sources,
cannot be tripped over, etc.
Do not disassemble the product. Attempting to modify the product may
damage it and result in serious injury.
Do not use the product if it appears damaged or emits an unusual odour.
Use only a soft,clean,dry cloth to clean the surface. Do not use harsh or
chemical cleaners, petrol, thinners,etc.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Shenzhen Reflying Electronic Co., Ltd
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an u
ncontrolled environment. This equipment should be installed and operated wit
h a minimum distance of 20 cm between the radiator and your body.
