Shenzhen Reflying Electronic Co., Ltd
User manual
Model: RNE76 or 251313
10000mAh power bank for phone and watch
Please read these instructions carefully before charging and using this product,
and keep this booklet for future reference.
Product Overview
This 10,000mAh power bank provides portable charging for smartphones,
tablets, iWatch, and other USB-powered devices. Its compact design makes it
ideal for everyday use and travel.
Product specifications
Battery Capacity
10000mAh (3.7V/37Wh)
AC Input
100 - 240V~50/60Hz 0.3A(Max.)
USB - C port & cable input
5V/3A, 9V/2A, 12V/1.67A, 20W max
USB - C port output
5V/3A, 9V/2.22A, 12V/1.67A, 20W max
USB - A port output
5V/3A, 9V/2A, 10V/2.25A, 22.5W max
USB - C cable output
5V/3A, 9V/2.22A, 12V/1.67A, 20W max
Wireless output
15W max
Wireless charging for iwatch
2.5W
Total (power bank)
15W max
Shenzhen Reflying Electronic Co., Ltd
Features
Charge with cable, 20W max by USB C port or built-in USB C cable, or
22.5W max by USB A port.
With AC input
With LED display and built-in cable
High quality polymer battery
10000mAh large capacity
Connecting & charging with cable
Plug your cable into the USB-C or USB A port or pull out the USB C cable on
the power bank, and the other end goes into your device.
After you have charged your device, recharge the power bank before using it
again.
Charge the power bank
Use the built-in USB C cable connecting to your adapter, ensuring the USB
connector is securely plugged into the charger, or charge by AC plug, or use
your USB C cable to connect to the USB C port on power bank and your
adapter.
Once fully charged, disconnect the power bank for immediate use.
Safety precautions
Please thoroughly review all instructions and warnings before using the product. Improper
usage may result in damage to the product or your device, overheating, or impaired
functionality. Always observe basic precautions when using this product, including the
following:
1. Avoid exposing the device to moisture.
2. Adhere to the specified output rating of the device to prevent overloading beyond its
capacity, which may pose a risk of fire or injury.
3. Refrain from using the device if it shows any signs of damage or modification.
4. Damaged or modified batteries may demonstrate unpredictable behavior, potentially
resulting in fire, explosion, or injury.
5. Do not disassemble the device to avoid the risk of fire or injury.
6. Keep the power bank out of reach of children to prevent accidents.
7. Avoid exposing the device to fire or excessive temperatures, as it may lead to an
explosion.
8. When charging, do not place your charger on flammable material such as carpets, bed
linen, etc.
Shenzhen Reflying Electronic Co., Ltd
FCC Caution
：
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
