Product Instructions
Product No. 2000344
10L SLIMLINE
DEHUMIDIFIER
2 3
Need further help?
suppor[email protected]
See our full range at
www.vonhaus.com
Let’s get started!
Visit our product hub for
useful tips and tricks on
getting the most out of
your new product.
SCAN ME
Product Diagram
A. Control Panel
B. Handle
C. Air Exhaust
D. Front Shell
E. Water Tank
F. Continuous Drainage Nozzle
G. Filter
A
C
D
B
G
E
F
4 5
M
Placement
30cm
30cm
Unit Placement
Place on a firm, level surface with at least
30cm of open space around the unit for
air circulation.
Install the unit in rooms larger than 4 m².
WARNING: Avoid these locations
• Near heat sources
• Where oil or water may splash
• Direct sunlight
• Vibration or shock
• Excessive dust
• Poor ventilation (e.g., inside cabinets)
Control Panel
1. Child Lock
Long press to activate or deactivate the child
lock function.
2. Fan Speed
Press once to switch between high and low
speeds. The relevant indicator light will show
the current setting.
3. Timer
Press this button to set the timer/ check the
timer/cancel the timer
• Setting the timer: Press once. The digital
display screen will flash to show the timer
time. While flashing, press the Adjust button
to set the timer (0-24 hours).
• Checking the timer: Press the button once
and the display screen will flash to show
the time remaining.
• Cancelling the timer: Press the button so the
display screen shows the time remaining.
While the screen is flashing, press the timer
button again to cancel the timer.
4. Adjust
• Press to adjust the humidity (30-80%) or
timer (1-24 hrs).
• Each time you click the button, the humidity
level will increase by 5% from 30% to 80%,
then return to 30%.
• In the timer setting, each time you press this
button, it will add 1 hour. This ranges from
1 to 24 hours, then returns to 0.
5. Mode
Press the Mode button to switch between Auto
and Continuous Laundry mode. Long press
the Mode button to switch to Sleep Mode. The
corresponding indicator will light up.
Auto Mode
• When the environment exceeds the set
humidity level by more than 3%, the fan
and compressor will both be activated.
• If the environments humidity drops 3%
lower than the set humidity, the fan and
compressor will stop working.
• The fan speed and humidity setting can be
adjusted in this mode.
Continuous Laundry Mode
• The appliance will continue to run regardless
of the humidity level.
• The fan speed can be adjusted.
Sleep Mode
• After 10 seconds, the display screen will
turn off, but the display can be restored by
pressing any button.
• Fault codes will not be displayed. When
the water tank is full, the appliance will not
alarm, but it will turn off and the full water
tank indicator light will be on to remind you
to empty the tank.
• The humidity setting can be adjusted. The
fan speed can’t be adjusted in this mode.
• Press any button to restore the normal
display screen.
6. Power
Press POWER to start. Default settings are high
fan speed and 50% humidity. The compressor
stops immediately when turned off, with the
fan following after 30 seconds.
65321 4
6 7
Digital Display Icons
M
A B C D E
G
F
I
H
A. Timer
B. Auto Mode
C. Laundry Mode
D. Sleep Mode
E. Power
F. Child Lock
G. Full Water Tank
H. Low Fan
I. High Fan
Instructions
1. When the water tank is full, the unit
will beep and the indicator light will
illuminate on the display screen. The
unit will pause operation to prevent
the water tank from overflowing
2. Turn the unit off and gently slide the
water tank out from the main body of
the dehumidifier. The unit will beep if
you remove the water tank while it is
still turned on
3. Empty the water tank and gently slide
the water tank back in to the main
body of the dehumidifier
IMPORTANT: If the Full Water Tank
indicator remains on, ensure the tank has
securely been placed back into the unit
and the float in the tank is correctly in
place
Draining the Tank
1
2
8 9
Continuous Drainage
Instructions
The dehumidifier offers a continuous drain
option, which is ideal for humid environments.
To set up continuous draining, simply connect
a drain hose to the unit.
1. Insert one end of the hose into the humidifier
and place the other end in your drain area.
2. Make sure to keep the hose straight and
positioned below the outlet level.
3. Double-check that the connection is secure
and that nothing blocks the drain path.
Important Notes
Ensure hose is:
• Securely connected
• Not kinked
• Unobstructed
• Angled downward (>20°)
Don’t submerge the end of the hose
(prevents air lock)
WARNING: The drainage hose must
not be very long (recommended 1m).
1
2
Cleaning the Air Filter
Instructions
IMPORTANT: Always turn off and
unplug the unit before cleaning.
1. Remove the water tank, then gently
pull the filter downwards and back
from the back of the air inlet
2. Gently vacuum any dust from the filter
surface
3. For heavily soiled filters, wash with
mild soap and water, then leave to air
dry completely
4. Reinstall the filter
Why This Matters
• Dust buildup restricts airflow
• Poor airflow reduces efficiency
• Blocked filters can damage the unit
• Never run the unit without a filter, as
this can contaminate the evaporator
Additional Tips
• Clean the filter regularly (every two
weeks)
• The filter is designed to be removable
for easy cleaning
• Ensure filter is completely dry before
reinstalling
10 11
Safety Information
Common Problems & Solutions
Why won’t my unit turn on?
If your unit won’t turn on, first ensure it’s properly
connected to a working power outlet. Check
if the water tank is full - it will need emptying
before the unit can operate again.
Also verify that the room temperature is
between 5 C and 35 C, as the unit won’t
function outside this range.
Why isn’t it working effectively?
If the dehumidifier isn’t working effectively, the
air filter may need cleaning, or the air vents
might be blocked. Check both the intake and
exhaust vents for any obstructions that could
be restricting airflow.
Why is it making unusual noise?
Unusual noise usually indicates the unit isn’t
placed on a level surface. Ensure it’s sitting
flat and stable. A dirty air filter can also cause
noise issues, so check if it needs cleaning.
Error Codes
• E1: Wash the filter. If that doesn’t fix it, the
sensor may need replacing.
• FL: Water tank is full, empty it.
• EF: DC motor problem. Switch off all
functions and power down.
• CL: Room is too cold (below 5°C). The unit
has shut itself down for protection and can’t
run in these conditions.
• CH: Room is too hot (above 39°C). Same
self-protection applies.
Humidity Warnings
20%RH: Humidity is too low, the machine will
stop.
90%RH: Humidity is fine at this level, it’ll run
normally.
Information
Electrical Safety
• Use only grounded power outlets
• Never pull power cord to unplug
• Avoid extension cords and adapters
Operation Safety
• Keep away from fire and flammable objects
• Don’t insert objects into air outlets
• Don’t touch inlet or aluminum fins
• Stop using if unit shows damage
• Avoid chemical cleaning
• Keep ventilation areas unobstructed
Installation Requirements
• Follow national wiring regulations
• Maintain minimum 4m² space for
installation
• Ensure proper ventilation
• Protect connecting pipes from damage
• Install away from heat sources
R-290 Refrigerant
This product contains R-290 (propane)
refrigerant and requires specific safety
precautions:
• Only qualified technicians can service the
sealed refrigerant system
• Never release refrigerant into air
• Keep away from flames, cigarettes, and
ignition sources
• Use only identical parts for repairs
WARNING: R-290 is flammable, heavier
than air, and odorless. Failure to follow safety
guidelines could result in explosion and serious
injury.
Electrical Safety
• Use only grounded power outlets
• Never pull power cord to unplug
• Avoid extension cords and adapters
Operation Safety
• Keep away from fire and flammable objects
• Don’t insert objects into air outlets
• Don’t touch inlet or aluminum fins
• Stop using if unit shows damage
• Avoid chemical cleaning
• Keep ventilation areas unobstructed
Installation Requirements
• Follow national wiring regulations
• Maintain minimum 4m² space for
installation
• Ensure proper ventilation
• Protect connecting pipes from damage
• Install away from heat sources
WARNING: Improper use may risk fire,
electric shock, or injury.
Disposal Information
WARNING: Releasing refrigerant into
atmosphere is strictly forbidden!
Do not dispose of electrical appliances as
unsorted municipal waste, use separate
collection facilities.
Contact your local government for information
regarding the collection systems available.
If electrical appliances are disposed of in
landfills or dumps, hazardous substances can
leak into the groundwater and get into the food
chain, damaging your health and well-being.
12 13
Customer Service
If you are having difficulty using this product
and require support, please contact
suppor[email protected]
Warranty
To register your product and find out if you
qualify for a free extended warranty please
go to www.vonhaus.com/warranty
Please retain a proof of purchase receipt or
statement as proof of the purchase date.
The warranty only applies if the product is used
solely in the manner indicated in the warnings
page of this manual, and all other instructions
have been followed accurately.
Any abuse of the product or the manner in
which it is used will invalidate the warranty.
Returns
Returned goods will not be accepted unless
re-packaged in its original packaging and
accompanied by a relevant and completed
returns form. This does not affect your statutory
rights.
No rights are given under this warranty to a
person acquiring the appliance second-hand
or for commercial or communal use.
Copyright
All material in this instruction manual are
copyrighted by DOMU Brands.
Any unauthorised use may violate worldwide
copyright, trademark, and other laws.
Thank You
Thank you for purchasing your product/
appliance.
Should you require assistance with your
purchase, please contact us at
suppor[email protected]
VonHaus is a registered trademark of DOMU
Brands Ltd.
Made in China for DOMU Brands Ltd.
Unit 30, Stakehill Industrial Estate
Middleton, Manchester, M24 2RW
EU Authorised Representative
Authorised Representative Service
77 Camden Street Lower
Dublin, D02 XE80
Ireland
