Product Instructions
Product No. 2000274
2 0 LITRE
DEHUMIDIFIER
2 3
Need further help?
suppor[email protected]
See our full range at
www.vonhaus.com
Besoin d’aide supplémentaire ?
suppor[email protected]
Découvrez notre gamme complète sur
www.vonhaus.com
Benötigen Sie weitere Hilfe?
suppor[email protected]
Entdecken Sie unser gesamtes
Sortiment auf
www.vonhaus.com
Necesita más ayuda?
suppor[email protected]
Descubra toda nuestra gama en
www.vonhaus.com
Hai bisogno di ulteriore assistenza?
suppor[email protected]
Scopri tutta la nostra gamma su
www.vonhaus.com
Let’s get started!
Visit our product hub for
useful tips and tricks on
getting the most out of
your new product.
SCAN ME
Product Diagram
A B
D
C
E F
HG
A. Control Panel
B. Digital Display
C. Three Colour Digital
Display
D. Wheels
E. Handle
F. Air Outlet
G. Air Inlet with Air Filter
H. Water Tank
I. Continuous Drainage
Hole
J. Power Cord
I
J
4 5
Placement
30cm
30cm
Unit Placement
Place on a firm, level surface with at least
30cm of open space around the unit for
air circulation.
Install the unit in rooms larger than 4 m².
WARNING: Avoid these locations
• Near heat sources
• Where oil or water may splash
• Direct sunlight
• Vibration or shock
• Excessive dust
• Poor ventilation (e.g., inside cabinets)
M
Control Panel
1. Child Lock
Long press to activate or deactivate the child
lock function.
2. Fan Speed
Press once to switch between high and low
speeds. The relevant indicator light will show
the current setting.
3. Timer
Press this button to set the timer/check the
timer/cancel the timer.
• In the non-timing state, press this button to
activate the timer. The digital display screen
will flash to show the timer time. While the
screen is flashing, press the Adjust button to
amend the timer (1-24 hrs).
• To check how long is left on the timer, press
the Timer button and the screen will flash to
display the remaining time. Press the Timer
button again while the screen is flashing to
cancel the timer.
• After the timer setting ends, the product will
turn off.
4. Adjust
• Press to adjust the humidity (30-80%) or
timer (1-24 hrs).
• Each time you click the button, the humidity
level will increase by 5% from 30% to 80%,
then return to 30%.
• In the timer setting, each time you press this
button, it will add 1 hour. This ranges from
1 to 24 hours, then returns to 0.
5. Mode
Press the Mode button to switch between Auto
and Continuous Laundry mode.
Long press the Mode button to switch to Sleep
Mode.
The corresponding indicator will light up
Auto Mode
• When the environment exceeds the set
humidity level by more than 3%, the fan
and compressor will both be activated
• If the environments humidity drops 3%
lower than the set humidity, the fan and
compressor will stop working
• The fan speed and humidity setting can be
adjusted in this mode
654321
6 7
Continuous Laundry Mode
• The appliance will continue to run regardless
of the humidity level
• The fan speed can be adjusted
Sleep Mode
• After 10 seconds, the display screen will
turn off, but the display can be restored by
pressing any button.
• Fault codes will not be displayed. When
the water tank is full, the appliance will not
alarm, but it will turn off and the full water
tank indicator light will be on to remind you
to empty the tank.
• The humidity setting can be adjusted. The
fan speed cannot be adjusted in this mode.
• Press any button to restore the normal
display screen.
6. Power
Press POWER to start. Default settings are high
fan speed and 50% humidity. The compressor
stops immediately when turned off, with the
fan following after 30 seconds.
M
A B C D E
G
F
I
H
A. Timer
B. Auto Mode
C. Laundry Mode
D. Sleep Mode
E. Power
F. Child Lock
G. Full Water Tank
H. Low Fan
I. High Fan
Digital Display Icons
Colour Light Indicator
The light on the front of the unit will display
different colours depending on the ambient
humidity level of the environment:
• Blue: Humidity level is below 45%
• Green: Humidity level is between 45%
and 65%
• Red: Humidity level is above 65%
The light will also be red if there are any error
codes on the LED display screen.
Please see the “Error Codes” (Page 15)
section for more information.
Colour
Light
Indicator
Control Panel
8 9
Instructions
1. When the tank is full, the unit will beep,
and the Full Water Tank indicator will
show on the display screen
2. Turn the unit off and slide the tank out
of the main body of the dehumidifier.
The unit will beep if you remove the
tank while it is still turned on
3. Empty the water and replace the tank
back into the dehumidifier
IMPORTANT: If the Full Water Tank
indicator remains on, ensure the tank has
securely been placed back into the unit
and the float in the tank is correctly in
place.
Draining the Tank
1
2
Continuous Drainage
Instructions
The humidifier offers a continuous drain option,
which is ideal for humid environments.
To set up continuous draining, simply connect
a drain hose to the unit.
1. Insert one end of the hose into the humidifier
and place the other end in your drain area.
2. Make sure to keep the hose straight and
positioned below the outlet level.
3. Double-check that the connection is secure
and that nothing blocks the drain path.
Important Notes
Ensure hose is:
• Securely connected
• Not kinked
• Unobstructed
• Angled downward (>20°)
Don’t submerge the end of the hose
(prevents air lock)
WARNING: Incorrect setup may cause
water spillage
10 11
1
2
Cleaning the Air Filter
Instructions
IMPORTANT: Always turn off and
unplug the unit before cleaning.
1. Remove the water tank, then gently
pull the filter downwards from the
back of the air inlet
2. Gently vacuum any dust from the filter
surface
3. For heavily soiled filters, wash with
mild soap and water, then leave to air
dry completely
4. Reinstall the filter
Why This Matters
• Dust buildup restricts airflow
• Poor airflow reduces efficiency
• Blocked filters can damage the unit
• Never run the unit without a filter, as
this can contaminate the evaporator
Additional Tips
• Clean the filter regularly (every two
weeks)
• The filter is designed to be removable
for easy cleaning
• Ensure filter is completely dry before
reinstalling
2
3
1
Storing the Dehumidifier
Instructions
1. Unplug the dehumidifier.
2. Clean and air dry the filter completely.
3. Reinstall the filter.
4. Drain all water from the tank and let it
air dry completely.
5. Once the tank is completely dry, lift the
lid on the tank and place the power
cord into the tank for cord storage.
6. Put the lid back onto the tank and
place the tank back into the unit.
Storage Requirements
• The unit should always be kept upright
during storage
• Store indoors
• Store in a dry, ventilated area
12 13
R-290 Refrigerant
This product contains R-290 (propane)
refrigerant and requires specific safety
precautions:
• Only qualified technicians can service the
sealed refrigerant system
• Never release refrigerant into air
• Keep away from flames, cigarettes, and
ignition sources
• Use only identical parts for repairs
WARNING: R-290 is flammable, heavier
than air, and odorless. Failure to follow safety
guidelines could result in explosion and serious
injury.
Electrical Safety
• Use only grounded power outlets
• Never pull power cord to unplug
• Avoid extension cords and adapters
Operation Safety
• Keep away from fire and flammable objects
• Don’t insert objects into air outlets
• Don’t touch inlet or aluminum fins
• Stop using if unit shows damage
• Avoid chemical cleaning
• Keep ventilation areas unobstructed
Installation Requirements
• Follow national wiring regulations
• Maintain minimum 4m² space for
installation
• Ensure proper ventilation
• Protect connecting pipes from damage
• Install away from heat sources
WARNING: Improper use may risk fire,
electric shock, or injury.
Safety Information
Disposal Information
WARNING: Releasing refrigerant into
atmosphere is strictly forbidden!
Do not dispose of electrical appliances as
unsorted municipal waste, use separate
collection facilities.
Contact your local government for
information regarding the collection
systems available.
If electrical appliances are disposed of in
landfills or dumps, hazardous substances
can leak into the groundwater and get into
the food chain, damaging your health and
well-being.
Common Problems & Solutions
Why won’t my unit turn on?
If your unit won’t turn on, first ensure it’s properly
connected to a working power outlet. Check
if the water tank is full - it will need emptying
before the unit can operate again.
Also verify that the room temperature is
between 5°C and 35°C, as the unit won’t
function outside this range.
Why isn’t it working effectively?
If the dehumidifier isn’t working effectively, the
air filter may need cleaning, or the air vents
might be blocked. Check both the intake and
exhaust vents for any obstructions that could
be restricting airflow.
Why is it making unusual noise?
Unusual noise usually indicates the unit isn’t
placed on a level surface. Ensure it’s sitting
flat and stable. A dirty air filter can also cause
noise issues, so check if it needs cleaning.
Error Codes
FL: Water tank full
E1/E2: Sensor malfunction - contact
suppor[email protected]
Information
14 15
Customer Service
If you are having difficulty using this product
and require support, please contact
suppor[email protected]
Warranty
To register your product and find out if you
qualify for a free extended warranty please
go to www.vonhaus.com/warranty
Please retain a proof of purchase receipt or
statement as proof of the purchase date.
The warranty only applies if the product is used
solely in the manner indicated in the warnings
page of this manual, and all other instructions
have been followed accurately.
Any abuse of the product or the manner in
which it is used will invalidate the warranty.
Returns
Returned goods will not be accepted unless
re-packaged in its original packaging and
accompanied by a relevant and completed
returns form. This does not affect your statutory
rights.
No rights are given under this warranty to a
person acquiring the appliance second-hand
or for commercial or communal use.
Copyright
All material in this instruction manual are
copyrighted by DOMU Brands.
Any unauthorised use may violate worldwide
copyright, trademark, and other laws.
Thank You
Thank you for purchasing your product/
appliance.
Should you require assistance with your
purchase, please contact us at
suppor[email protected]
VonHaus is a registered trademark of DOMU
Brands Ltd.
Made in China for DOMU Brands Ltd.
Unit 30, Stakehill Industrial Estate
Middleton, Manchester, M24 2RW
EU Authorised Representative
Authorised Representative Service
77 Camden Street Lower
Dublin, D02 XE80
Ireland
Information
Product No. 2000274
Let’s get started!
Visit our product hub for
useful tips and tricks on
getting the most out of
your new product.
SCAN ME
