User Manual
Epower-B05
CATALOG
ENGLISH 001-021
DEUTSCH 000-000
FRANÇAIS 000-000
ESPAÑOL
POLSKI 000-000
000-000
000-000
000-000
ITALIANO
ČEŠTINA
ENGLISH
PRODUCT DESCRIPTION
PRODUCT FEATURES
001
Engine Start Power Bank LED Light Air Inflation Car Tires Motorcycle Tires Bicycle Tire Ball Supplies
Please read this manual carefully and keep it properly before using this product for the first time. It will guide
you to use it correctly and remind you of relevant precautions.
This product is a portable car jump starter + air compressor product. It can start a car whose battery (12V) is
losing electricity, and has the function of inflating cars, motorcycles, bicycle tires and balls; it can also be used
as a mobile power source for mobile phones, tablets, PSP, MP3/MP4, cameras, etc. Digital electronic
products are charged/powered, and the products also have LED light functions (lighting mode, SOS mode,
warning mode).
Note that this product is not a toy and children are forbidden to use it.
1.
2.
3.
6
1 32 4 5
8
9
10
11
12
7
ENGLISH
PRODUCT DIAGRAM
Inflatable Tube Interface
LED Light
Type-C Charging Port
USB 5V/2.1A Output
USB 5V/9V/12V Output
Jumper Cable Connection Port
Digital Tube Display
Air Pressure Set " + " Button
" M " Button(Mode/Unit Switching)
Power Button
LED Light Button
Air Pressure Set " - " Button
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
002
ENGLISH
CHARGE DIGITAL PRODUCTS
003
Plug the USB port of the
charging cable into the
product USB interface.
Output 1(2)
1
Insert the other end of the
charging cable into the
corresponding charging port
of the mobile phone or digital
device.
2
Press and hold the "Power"
button for 2 seconds to turn
on the power, and the USB
power supply can be started.
3
Remove the silicone plug and insert the EC5 connector of the jumper cable into the
hole position.
CAR JUMP START
Connect the red clamp to the positive pole (+) and the black clamp to the negative
pole (-) of the car battery.
Ignition within 30 seconds:
Press the car start button or turn the ignition switch to the START position.
After successful startup, pull the plug of the wire clip from the product and remove
the clip from the positive and negative terminals of the car battery.
Note: When starting the car,please make sure that the power of the product is above 50%.
ENGLISH
004
Please fully charge the product before using it for the first time.
Charging: The units digit of the battery percentage value flashes
(flashing once per second).the screen displays:
Fully charged: Stop flashing and stop charging, turn off the screen after
10 seconds and enter sleep state.
Note: The charging process will not be able to use this product.
ENGLISH
DETAILED INSTRUCTIONS FOR INFLATION FUNCTION
005
1. Charge The Product
ENGLISH
006
Press and hold the "Power" button for 2 seconds to turn on the device. At this time, the battery percentage and
the " " icon will be displayed on the screen, and the USB output function will be turned on at the same time.
After booting, single press the "Power" button to switch between on/pause of inflation.
Press and hold the "Power" button again for 2 seconds to shut down.
(If the product is turned on without any operation within 30 seconds, it will also automatically shut down.)
2. Power On/Off
When inflating the air bed and swimming ring, please select a suitable air nozzle, and
connect the air nozzle to the inflation tube before inflating.
1 32
Bicycles, electric bicycles, motorcycles, and cars are usually directly connected by this air pipe.
ENGLISH
007
3. Connect the Inflation Tube
4. Gas Nozzle / Gas Needle Mounting Method
When inflating basketball, football and other balls, you need to use an air
needle. Connect the air needle to the inflation tube before inflating.
1 2 3
ENGLISH
When inflating the air bed and swimming ring, please select a suitable air nozzle, and
connect the air nozzle to the inflation tube before inflating.
1 32
4. Gas Nozzle / Gas Needle Mounting Method
008
5. Inflation Air Pressure
To ensure safety, before using this device for inflation, please know the air pressure value required by the
inflated item (check the surface information of the inflated item or query the instruction manual of the inflated
item) to avoid personal injury caused by over-inflation.
ENGLISH
Common Items Recommended Inflatable Air Pressure Gauge
Category Types
Recommended air
pressure range
Car
Car tires 2.2-2.8 Bar (32-40psi)
Motorcycle
Bike
Ball
Motorcycle, electric
Motorcycle tires
Folding bicycle tires
12”14”16”bicycle tires
20”22”24”bicycle tires
26”27.5”29”bicycle tires
Basketball
Football
Volleyball
Rugby
7-9psi
8-16psi
4-5psi
12-14psi
45-50psi
30-50psi
40-50psi
45-65psi
1.8-3.0 Bar (26-44psi)
009
Mode Selection
Car mode: Default 36psi (approximately equal to 2.5bar)
Motorcycle mode: Default 35psi (approximately equal to 2.4bar)
Bicycle mode: Default 45psi (approximately equal to 3bar)
Ball mode: Default 8psi (approximately equal to 0.6bar)
ENGLISH
Short press the "M" button to select the inflation mode: each time you press this
button, you can switch between the four inflation modes of "car", "motorcycle",
"bicycle" and "ball".(Long press this key to switch between PSI, BAR, KPA, Kg/cm2
four air pressure units.)
After select the matching inflation mode, the screen displays the default setting value and flashes three times at
a frequency of once per second, and then enters the air pressure detection state to detect the current air pressure
value of the inflated object. (When the inflated object is not connected, the air pressure value will display "0".)
6. Preset Inflation Air Pressure
010
ENGLISH
Adjust Presets
After selecting the inflation mode, short press the "+" key or "-" key to adjust
the preset air pressure value; long press to quickly adjust the air pressure
value.
After the setting is completed, the air pressure value flashes three times at
a frequency of once per second, and then the setting is automatically
confirmed.
Caution:
When adjusting the preset air pressure value, the number flashes to indicate the target air pressure
adjustment status, and the number is always on to indicate the real-time air pressure.
The default value will be restored after the mode is switched or restarted.
When inflating the swimming ring and air bed, just adjust to "ball mode".
1.
2.
3.
011
ENGLISH
Turn on inflation: After the air pressure setting is completed, short press the "Power"
button to start inflation, and the screen displays real-time air pressure changes during
inflation.
Stop inflation: When the air pressure reaches the preset value, the air pump will
automatically stop inflation. During the inflation process, you can also pause the inflation
by short pressing the "Power" button.
Shut down: In the power-on state, press and hold the "Power" button for 2 seconds to shut down.
In order to avoid accidental touch, it will automatically shut down if there is no operation within 30 seconds when it
is turned on.
7. Inflation Instructions
012
75-80dB noise will be generated during inflation.
The inflation air pressure of balloons, toy balls, swimming rings and other products is less than the range of the
air pump, and the inflation cannot be automatically stopped at the preset air pressure. Please be careful when
using it.
When the equipment continues to work for a long time, the temperature of the body and the gas tube will
increase significantly. Please avoid touching the air tube with your hands for a long time. If the temperature is too
high, please cool down before continuing to use it. Be careful of burns when disassembling the gas nozzle after
use, there will be slight air leakage, please disassemble it quickly.
Increased pressure load and lower ambient temperature may cause the endurance of this device to deteriorate.
As the air pump generates a large amount of heat, please rest for at least 10 minutes after inflating for 10 minutes
before using it.
①
②
③
④
⑤
ENGLISH
SPECIAL REMINDER
After the power is turned on, press the "LED light" button to turn on the lighting
mode. Short press again in turn to switch to SOS distress light mode, warning
light mode, and off.
8. Multifunctional Lighting
013
ENGLISH
BASIC PARAMETERS
Brand
Model
Size
Inflation Pressure Range
Operating Temperature
Storage Temperature
Inflatable Tube Length
Battery Capacity
Working Noise
Charging Input
Charging Time
USB Output 1
USB Output 2
Air Pressure Sensor Accuracy
Start Car Voltage
Peak Current
Andeman
Epower-B05
193 × 110 × 53mm
0.2~10bar / 3~150psi
Charge：0℃~45℃，Discharge：-10℃~45℃
-10℃~50℃
435mm(Including gas nozzle)
24000mAh(88.8Wh)
Less than 80dB away from 1 meter
Type-C 5V⎓3A
About 3.5 hours
5V⎓3A, 9V⎓2A, 12V⎓1.5A
5V/2.1A
±1psi
12V
4000A
014
PRECAUTIONS
ENGLISH
This product is not a toy, and it is forbidden for children to use it; it is recommended for users over 16 years of
age.
When the product is used for the first time, charge the product for more than 3 hours.
This product has a built-in non-removable lithium battery. It is forbidden to throw this product into a fire or throw
it away at will. The lithium battery may catch fire, spontaneously ignite and explode due to overheating, impact
or water. Please avoid exposure to the sun in the car, or exposed to high temperature environment.
If the product is swollen, leaking or smells, please stop using it immediately.
If the product has abnormal noise or high temperature during use, please stop using it and shut it down
immediately.
Please store or use in a dry and clean environment. Avoid dampness, heavy falls, water immersion and sand
intrusion. The intrusion of sand and dust may cause damage to the product; this product is also not waterproof,
and it is forbidden to wash in water.
Please keep away from corrosive materials when storing this product, and the storage temperature should not
be lower than -10℃ or higher than 50℃. Too cold or too hot will shorten the life of the product and damage the
built-in battery.
Please keep this product charged at least once every 3 months.
Do not disassemble the machine by yourself, otherwise it may cause a safety accident.
Usage Notice
015
Inflation Notice
ENGLISH
The product has a built-in DC motor, which may generate electric sparks during operation. Please do not use it
in an flammable and explosive environment.
Before inflating, please confirm the required air pressure value of the inflated item to avoid personal injury
caused by explosion caused by over-inflation.
When setting the inflation air pressure value, please make sure that the measurement unit is selected correctly,
otherwise it may cause accidents such as a tyre burst. Common unit conversion: 1bar=14.5psi, 1bar=100kPa.
When inflating objects, please keep this product a safe distance from children.
Do not bend or step on the inflation tube when inflating, and be sure to keep the airflow unobstructed.
Operators are not allowed to leave the scene during inflation. Please observe the inflation process to prevent the
inflation air pressure from being too high due to the unpreset air pressure.
Jump Start Notice
This product can be used to start a 12V battery engine, but cannot be used to start a 24V battery engine.
Be sure to use the cord clamp provided with the product to start the vehicle.
It is forbidden to start the car when the power of the product is lower than 50%, otherwise it will cause damage
to the product.
Do not clamp the battery clamps at both ends, otherwise it may cause a safety accident.
If a startup fails, please try again after at least 1 minute to avoid damage to the product.
After starting the car, please wait at least 30 minutes before charging the product.
016
ENGLISH
PACKING LIST
Note: The illustrations of products, accessories, and display interface in this manual are all schematic diagrams and
are for reference only. Since the product is iteratively upgraded from time to time, the actual product and the schematic
diagram may be different, please refer to the actual product!
Inflatable tube ×1
Guide ×1 Storage bag ×1
Gas nozzle ×2 Charging cable ×1
Gas needle ×1
Product ×1
Jumper cable ×1
017
Elimination MethodProblem
Slow inflation
Has been turned on,
but cannot be inflated
The inflation is normal, but the
display pressure value is zero
After installing the gas nozzle
tightly, the power has been
automatically turned off
There is air leakage when
connecting the trachea
1. Check whether the battery power is sufficient.
2. Check for air leaks in the trachea.
3. Check whether the connecting parts at both ends
4. Check whether the tires are flat.
1. Check whether the battery power is sufficient.
2. Check whether the air pressure of the inflated item
Low-pressure inflated objects such as balloons are
not within the measurable range of this device.
It will automatically shut down if there is no operation
within 30 seconds, just restart it.
Install the trachea tightly.
of the trachea are tightly installed.
is higher than the preset value.
ENGLISH
TROUBLE SHOOTING
018
The company does not assume any responsibility for problems caused by misoperation beyond the instructions.
If the product is damaged by disassembling and installing by oneself, our company will not bear any responsibility.
If the use of a mismatched charger causes problems, our company does not assume any responsibility.
The company does not assume any responsibility for products beyond the warranty period.
DISCLAIMER
ENGLISH
1.
2.
3.
4.
019
ENGLISH
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC statement：
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
020
Thank you for your support of our original Audew products, Andeman has upgraded
the original products, launched a more efficient jump starter, and enriched the product
line by adding car repair and maintenance products. We hope that this brand can
bring you a one-stop shopping experience for auto supplies and meet the needs of all
users for auto supplies.
Contact Us: ande[email protected]
ENGLISH
021
EU importer：VISHTEC ltd
Address：3 rd floor office 5, Plovdiv
2 Liuben Karavelov bul, 4002
Bulgaria
Email: [email protected]
UK Importer:VISHTEC UK Co.,Ltd
Address：275 ISLINGTON SUITE
1405 NEW NORTH ROAD
LONDON ENGLAND N1 7AA
Email: Vincent.feng@vish-tec.com
