Visit our website at: http://www.harborfreight.com
email our technical support at: [email protected]
Battery and charger sold separately
BRUSHLESS
10" CORDLESS CULTIVATOR
80V
LITHIUM
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 23k
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright
©
2023 by Harbor Freight Tools
®
. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
70312
Page 2 For technical questions, please call 1-888-866-5797. Item 70312
SaFety OperatiOn MaintenanceSetup
table of contents
Safety ........................................................................2
Specifications ............................................................6
Setup .........................................................................7
Operation ..................................................................11
Maintenance .............................................................13
Parts Lists and Diagrams .........................................14
Warranty ...................................................................16
WarninG SyMBOLS anD DeFinitiOnS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
iMpOrtant SaFety inStructiOnS
When using electric gardening appliances, basic safety precautions should always be followed
to reduce the risk of fire, electric shock, and personal injury, including the following:
reaD aLL inStructiOnS
Gardening appliance Safety
1. avoid Dangerous environment -
Do not use appliances in damp or wet locations.
2. Do not use in rain.
3. Keep children away - All visitors should
be kept at a distance from work area.
4. Dress properly - Do not wear loose clothing or
jewelry. They can be caught in moving parts.
Use of rubber gloves and substantial footwear
is recommended when working outdoors.
Wear protective hair covering to contain long hair.
5. use Safety Glasses - Always use face
or dust mask if operation is dusty.
6. use right appliance - Do not use appliance
for any job except that for which it is intended.
7. Wear anSi-approved safety goggles,
hard hat and heavy-duty rubber work
gloves. Use face or dust mask if
operation is dusty.
8. Keep hands away from blades.
9. Wear thick jeans and steel-toed
work boots to help prevent injury
caused by flying debris.
Page 3For technical questions, please call 1-888-866-5797.Item 70312
SaFetyOperatiOnMaintenance Setup
10. avoid unintentional Starting -
Do not carry appliance with finger on switch.
11. Don’t grasp the exposed cutting blades or cutting
edges when picking up or holding the appliance.
12. Do not Force appliance - It will do the
job better and with less likelihood of injury
at the rate for which it was designed.
13. Do not Overreach -
Keep proper footing and balance at all times.
14. Stay alert - Watch what you are doing. Use
common sense. Do not operate appliance when
you are tired.
15. Store idle appliances indoors - When not in use,
appliances should be stored indoors in dry, and
high or locked-up place – out of reach of children.
16. Maintain appliance With care - Keep cutting
edge sharp and clean for best performance and
to reduce the risk of injury. Follow instructions
for lubricating and changing accessories. Keep
handles dry, clean, and free from oil and grease.
17. check Damaged parts - Before further use of the
appliance, a guard or other part that is damaged
should be carefully checked to determine that it will
operate properly and perform its intended function.
Check for alignment of moving parts, binding of
moving parts, breakage of parts, mounting, and any
other condition that may affect its operation. A guard
or other part that is damaged should be properly
repaired or replaced by a qualified technician
unless indicated elsewhere in this manual.
18. Keep guards in place and in working order.
19. Keep hands and feet away from tines.
20. Wear full eye protection and protective clothing.
21. Stop working when you feel tired or exhausted.
Make regular breaks to rest.
22. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
23. When servicing use only identical
replacement parts.
24. carefully follow cutting procedures
explained in this manual. They are specifically
planned to reduce risk to the operator.
25. Only use accessories and attachments
designed for use with this appliance. Follow
all accessory and attachment instructions.
use of any other accessory or attachments
may increase the risk of injury.
Battery tool use and care
1. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to battery pack, picking up or carrying the
power tool. Carrying the power tool with your
finger on the switch or energizing power tool
that have the switch on invites accidents.
2. Disconnect the battery pack from the power
tool before making any adjustments, changing
accessories, or storing power tool. Such
preventive safety measures reduce the risk
of starting the power tool accidentally.
3. Recharge only with the charger specified by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of
fire when used with another battery pack.
4. Use power tools only with specifically designated
battery packs. Use of any other battery
packs may create a risk of injury and fire.
5. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
6. Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
7. Do not use a battery pack or power tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
8. Do not expose a battery pack or power tool to fire
or excessive temperature. Exposure to fire or
temperature above 140°F may cause explosion.
Page 4 For technical questions, please call 1-888-866-5797. Item 70312
SaFety OperatiOn MaintenanceSetup
9. Follow all charging instructions and do not charge
the battery pack or power tool outside of the
temperature range specified in the instructions.
Charging improperly or at temperatures
outside of the specified range may damage
the battery and increase the risk of fire.
10. Have servicing performed by a qualified
repair person using only identical
replacement parts. This will ensure that
the safety of the product is maintained.
11. Do not modify or attempt to repair the power
tool or the battery pack except as indicated
in the instructions for use and care.
12. The battery Charger gets hot during use.
The Charger’s heat can build up to
unsafe levels and create a fire hazard if it
does not receive adequate ventilation,
due to an electrical fault, or if it is used in a
hot environment. Do not place the Charger on a
flammable surface. Do not obstruct any vents on
the Charger. especially avoid placing the
charger on carpets and rugs; they are not only
flammable, but they also obstruct vents under
the charger. Place the Charger on a stable, solid,
nonflammable surface (such as a stable metal
workbench or concrete floor) at least 1 foot away
from all flammable objects, such as drapes or walls.
Keep a fire extinguisher and a smoke detector in the
area. Frequently monitor the Charger and
Battery Pack while charging.
13. To Reduce Risk of Injury to Persons:
a. Do Not Recharge Batteries in a
Confined or Unvented Area; and,
b. Do Not Smoke, Strike a Match, or Cause a Spark
in the Vicinity of the Battery During Charging.
14. Do not charge appliance in rain, or in wet locations.
15. Do not use battery-operated appliance in rain.
16. Remove or disconnect battery before
servicing, cleaning or removing material
from the gardening appliance.
17. Do not dispose of the battery(ies) in a fire.
The cell may explode. Check with local codes
for possible special disposal instructions.
18. Do not open or mutilate the battery(ies). Released
electrolyte is corrosive and may cause damage to
the eyes or skin. It may be toxic if swallowed.
19. Exercise care in handling batteries in order not
to short the battery with conducting materials
such as rings, bracelets, and keys. The battery
or conductor may overheat and cause burns.
Lithium Battery Safety Warnings
LitHiuM BatterieS StOre a
LarGe aMOunt OF enerGy
anD WiLL Vent Fire Or
eXpLODe iF MiStreateD:
1. Keep Battery pack dry.
2. DO nOt DO any OF tHe FOLLOWinG
tO tHe Battery pacK:
a. Open,
b. Drop,
c. Short-circuit,
d. puncture,
e. incinerate, or
f. expose to temperatures greater than 140°F.
3. Charge Battery Pack only according
to its Charger’s instructions.
4. Inspect Battery Pack before every use;
do not use or charge if damaged.
Page 5For technical questions, please call 1-888-866-5797.Item 70312
SaFetyOperatiOnMaintenance Setup
Vibration Hazard
This appliance vibrates during use.
Repeated or long-term exposure to vibration may
cause temporary or permanent physical injury,
particularly to the hands, arms and shoulders.
To reduce the risk of vibration-related injury:
1. Anyone using vibrating appliances regularly or
for an extended period should first be examined
by a doctor and then have regular medical
check-ups to ensure medical problems are not
being caused or worsened from use. Pregnant
women or people who have impaired blood
circulation to the hand, past hand injuries,
nervous system disorders, diabetes, or Raynaud’s
Disease should not use this appliance. If you
feel any symptoms related to vibration (such as
tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible.
2. Do not smoke during use. Nicotine reduces
the blood supply to the hands and fingers,
increasing the risk of vibration-related injury.
3. Wear suitable gloves to reduce the
vibration effects on the user.
4. Use appliances with the lowest vibration when
there is a choice between different processes.
5. Include vibration-free periods each day of work.
6. Grip appliance as lightly as possible
(while still keeping safe control of it).
Let the appliance do the work.
7. To reduce vibration, maintain the appliance
as explained in this manual. If any abnormal
vibration occurs, stop use immediately.
General Safety
this cutting machine is capable of amputating hands and feet and throwing objects. Failure
to observe the following safety instructions could result in serious injury or death.
1. Read, understand, and follow all instructions on
the machine and in the manual before starting.
2. Only allow responsible adults who are familiar
with the instructions to operate this machine.
3. thoroughly inspect the area where the
cultivator is to be used. Beware of possible
buried obstacles such as cable, conduit, irrigation
lines, and landscape fabric. Remove all large
sticks, stones, wires, or other foreign objects.
4. neVer operate above or near any
electrical cables, gas pipes, or any other
utility lines. Contact your local utility
company before using the Cultivator.
5. Do not put hands or feet near or under rotating parts.
6. Be sure the area is clear of bystanders before
operating. Stop machine if anyone enters the area.
7. Do not operate machine barefooted or while wearing
sandals. Always wear substantial footwear.
8. Do not pull machine backward unless absolutely
necessary. Always look down and behind
before and while moving backward.
9. Never leave a running machine unattended.
10. Never operate the Cultivator without good visibility
or light. Operate machine only in daylight.
11. Do not use the Cultivator on steep inclines.
Use only on level ground surfaces.
12. Keep a safe distance from the edges and
banks of ditches. Avoid any actions that
may cause the Cultivator to tip over.
13. Be careful when operating in hard ground. The
tines may catch in the ground and propel the
Cultivator forward. If this occurs, let go of the
handlebars and do not restrain the machine.
14. Do not operate machine while under
the influence of alcohol or drugs.
15. If the machine should start to vibrate
abnormally, stop the machine and check
for the cause immediately. Vibration is
generally a warning sign of trouble.
16. Always wear eye protection when
operating machine.
17. The warnings and precautions discussed in this
manual cannot cover all possible conditions and
situations that may occur. It must be understood
by the operator that common sense and caution
are factors which cannot be built into this
product, but must be supplied by the operator.
18. Maintain labels and nameplates on the appliance.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
SaVe tHeSe inStructiOnS.
Page 6 For technical questions, please call 1-888-866-5797. Item 70312
SaFety OperatiOn MaintenanceSetup
Grounding
tO preVent eLectric SHOcK anD DeatH FrOM incOrrect GrOunDinG:
check with a qualified electrician if you are in doubt as to whether the outlet is properly
grounded. Do not modify the power cord plug provided with the charger. Do not use the charger
if the power cord or plug is damaged. if damaged, have it repaired by a service facility before
use. if the plug will not fit the outlet, have a proper outlet installed by a qualified electrician.
extension cords
note: Extension cords must not be used with this item’s Charger.
Symbology
V
Volts
Direct Current
a
Amperes
n
0
xxxx/min.
No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
WARNING marking concerning
Risk of Hearing Loss.
Wear hearing protection.
Read the manual before
set-up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof surface only.
WARNING marking concerning
Risk of Electric Shock.
Properly connect Charger’s power
cord to appropriate outlet.
WARNING marking concerning
Risk of Explosion.
Do not puncture, short, or open
battery packs and do not charge
damaged battery packs.
Do not expose to rain or
damp conditions.
Thrown objects can ricochet and result
in personal injury or property damage.
Keep hands and feet away
from rotating tines.
Specifications
Electrical Rating 80 VDC
Battery Type Atlas Li-ion 57014 or 58958 (sold separately)
Charger Type Atlas Li-ion 56993 or 56997 (sold separately)
Maximum Cultivating Depth 5 Inches
Maximum Cultivating Width 10 Inches
Page 7For technical questions, please call 1-888-866-5797.Item 70312
SaFetyOperatiOnMaintenance Setup
Setup - Before use:
components and controls
power
Switch
tines
Bail
control
Bar
Battery
compartment
Wheel
assembly
Lower
Handle
upper
Handle
Middle
Handle
Page 8 For technical questions, please call 1-888-866-5797. Item 70312
SaFety OperatiOn MaintenanceSetup
assembly instructions
read the entire iMpOrtant SaFety inStructiOnS section at the beginning of this manual
including all text under subheadings therein before set up or use of this product.
tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn:
release trigger of the appliance and remove Battery pack before performing any procedure in this section.
note: For additional information regarding the parts listed in the following pages,
refer to the Assembly Diagram near the end of this manual.
attach Wheel assembly
1. Place Cultivator in a stable
position on a level surface.
2. Insert the shaft on the Wheel Assembly
into the support bracket.
3. Align holes in Wheel Assembly shaft with
hole in bracket to desired position:
a. Use lower hole to increase cultivating depth.
b. Use higher hole to decrease cultivating depth.
4. Slide Clevis Pin (13) through
holes in shaft and bracket.
5. Secure Clevis Pin in place with R-Clip (12).
r-clip
Wheel
assembly
Support Support
BracketBracket
Highest hole:
least
cultivating
depth
Lowest hole:
most
cultivating
depth
clevis
pin
Page 9For technical questions, please call 1-888-866-5797.Item 70312
SaFetyOperatiOnMaintenance Setup
install tines
nOtice: Tines must be installed in the exact orientation described for the Cultivator to
function properly. Perform these procedures facing the front of the Cultivator.
1. Lean the Cultivator back on its wheels with
the lower handle resting on the ground.
2. Place Tine B (20) on Tine Shaft on
right side of Gearbox with sleeve on
Tine facing away from Gearbox.
3. Place Tine C (22) on Tine Shaft on
left side of Gearbox with sleeve on
Tine facing away from Gearbox.
4. Slide a Felt Washer (19) onto
each side of Tine Shaft up against
sleeves on Tines B and C.
5. Place Tine D (23) on left side of
Tine Shaft with sleeve facing Felt
Washer on Tine C.
6. Place Tine A (18) on right side
of Tine Shaft with sleeve facing
Felt Washer on Tine B.
7. Insert Linch Pins (17) into holes on
each side of Tine Shaft to secure
Tines in place.
note: When Tines are properly
installed, directional arrows on Tines
will point to the front and sleeves
on Tines will face each other.
two tine installation
For cultivating narrow areas, Cultivator
may be used with two tines.
1. Place Tine B (20) on Tine Shaft on
right side of Gearbox with sleeve on
Tine facing away from Gearbox.
2. Place Tine C (22) on Tine Shaft on
left side of Gearbox with sleeve on
Tine facing away from Gearbox.
3. Insert Linch Pins (17) into inner
holes on each side of Tine Shaft
to secure Tines in place.
Linch pin
through
inner hole
Sleeve
C
Sleeve
Gearbox
tine
Shaft
Felt
Washer
A
Sleeve
Felt
Washer
Linch
pin
Linch pin
attached
Linch pin
attached
Page 10 For technical questions, please call 1-888-866-5797. Item 70312
SaFety OperatiOn MaintenanceSetup
Handle assembly
1. Connect Middle Handle (2) to
Lower Handles (7, 49) using two
Handle Knobs (5) and Handle Knob
Bolts (4). Tighten securely.
2. Connect Upper Handle (1) to Middle
Handle using two Handle Knobs and
Handle Knob Bolts. Tighten securely.
Middle
Handle
upper
Handle
Lower
Handle
Handle
Knob
Handle
Knob
Bolt
Handle
Knob
Page 11For technical questions, please call 1-888-866-5797.Item 70312
SaFetyOperatiOnMaintenance Setup
Operating instructions
read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this manual
including all text under subheadings therein before set up or use of this product.
tO preVent SeriOuS inJury:
Before operating the gardening appliance, put on anSi-approved safety goggles, steel toe
work boots, long pants, and other safety gear. Safety goggles and other safety gear are sold
separately. Keep hands, fingers, feet, and loose clothing away from rotating tines.
tO preVent SeriOuS inJury anD prOperty DaMaGe:
inspect the area before using the cultivator. remove all hard objects from work area.
use both hands when operating the cultivator.
BeWare of possible buried obstacles such as cable, conduit, irrigation lines, and landscape fabric.
DO nOt operate above or near any electrical cables, gas pipes, or any other utility
lines. contact your local utility company before using the cultivator.
Battery charging
Charge Battery Pack before using this tool. Follow instructions included
with Battery Charger. Battery and Charger sold separately.
installing and removing Battery pack
1. To install: Open Battery Door, insert Battery Pack
into battery compartment and push down until it
clicks into place. Close Battery Door.
2. To remove: Press Battery Pack Release
Button and pull Battery Pack out of battery
compartment. Close Battery Door.
Battery
Door
Battery
pack
Page 12 For technical questions, please call 1-888-866-5797. Item 70312
SaFety OperatiOn MaintenanceSetup
General Operation
tO preVent SeriOuS inJury: Do not put hands or feet near or under rotating tines.
Wear anSi-approved safety goggles, steel toe work boots, heavy-duty work gloves,
long pants, and other safety gear during use.
clear the area of large sticks, rocks, wire, or other foreign objects
which could be thrown by the tines.
Stay behind the handle when the cultivator is running.
Be sure the area is clear of bystanders before operating.
Stop machine if anyone enters the area.
1. Set the desired cultivating depth by
adjusting the Wheel Assembly. Refer to
Attach Wheel Assembly on page 8.
note: Optimum cultivating depth will vary with
soil conditions. If Cultivator shakes or is difficult
to control, the cultivating depth is not correctly set
for the conditions. Adjustment through trial and
error is required to achieve the correct setting.
WarninG! tO preVent SeriOuS inJury:
Before first use, practice operating the Cultivator
controls with Tines raised off of the ground. Know
how to keep control at all times and how to stop the
Tines from turning. For actual field use, operate at
a slow pace until familiar with Cultivator handling.
2. Open Battery Door, insert fully-charged Battery
Pack into battery compartment and push down
until it clicks into place. Close Battery Door.
3. Press and hold down Power Switch, then pull
and hold Bail Control Bar against Handle.
4. When Cultivator has started, release Power Switch.
5. Grip the Handle firmly with both hands.
power
Switch
Bail
control
Bar
6. To stop Cultivator, release Bail Control Bar.
7. The following soil conditions can
affect cultivating results:
a. On soil that is too hard and/or dried out for
the Tines to penetrate, the Cultivator will
shake excessively and jump across the soil
surface. Moisten dry, hardened soil prior to
cultivating and use a shallow depth setting.
b. Exceedingly wet soil will form clumps during
cultivating and clog the Tines. Allow wet
soil to partially dry before cultivating and
operate at a slow pace to improve results.
nOtice: Should the Tines jam or the Cultivator strike
a foreign object during use, immediately release
the Bail Control Bar to shut off the Cultivator. Wait
until the machine completely stops, then remove
the Battery Pack. Remove foreign objects and
inspect the Cultivator. If any damage is found
have the problem corrected before further use.
8. After use, to prevent accidents, remove
Battery Pack, then clean and store tool
according to Cleaning, Maintenance,
and Lubrication on page 13.
Page 13For technical questions, please call 1-888-866-5797.Item 70312
SaFetyOperatiOnMaintenance Setup
Maintenance and Servicing
procedures not specifically explained in this manual
must be performed only by a qualified technician.
tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn:
remove Battery pack before performing any procedure in this section.
tO preVent SeriOuS inJury FrOM tOOL FaiLure:
Do not use damaged equipment. if abnormal noise or vibration occurs,
have the problem corrected before further use.
cleaning, Maintenance, and Lubrication
1. BeFOre eacH uSe, inspect the general
condition of the tool. Check for:
• loose or damaged Tines
• leaking, swollen, or cracked battery pack
• loose hardware
• misalignment or binding of moving parts
• cracked or broken parts
• any other condition that may
affect its safe operation.
2. aFter uSe, clean external surfaces with
clean cloth. Wipe Tines with oil to prevent
rust. Apply oil to Bail Control Bar cable.
3. Li-Ion BATTERY MUST BE RECYCLED OR
DISPOSED OF PROPERLY.
Do not short, incinerate or open battery.
4. Remove Battery Pack and store Battery
Pack, Charger, and Cultivator in dry,
indoor area out of reach of children. Keep
Battery Pack away from metal objects
(i.e., paperclips, coins) to prevent shorting.
troubleshooting
problem possible causes probable Solutions
Cultivator
won’t start.
1. Battery Pack not properly connected.
2. Battery Pack not properly charged.
3. Debris jamming Tines.
4. Internal damage or wear.
1. Make sure Battery Pack is inserted
correctly and locked in place.
2. Make sure Charger is connected and
operating properly. Give enough time
for Battery Pack to charge properly.
3. Turn off Cultivator, remove battery pack
and remove debris from Tines.
4. Have machine serviced by qualified technician.
Excessive
shaking /
Cultivator
difficult to
control.
1. Ground too hard and / or dried out.
2. Cultivating depth not correctly
set for soil conditions.
1. Moisten the ground prior to cultivating.
2. Adjust Wheel Assembly as needed
to achieve correct depth setting.
Motor runs
but Tines do
not rotate.
Gear train failure. Have machine serviced by qualified technician.
Cultivator
stops during
use.
Thermal overload protection has tripped.
Remove Battery Pack and allow
Cultivator to cool at least 15 minutes.
Follow all safety precautions whenever diagnosing or servicing the equipment.
Page 14 For technical questions, please call 1-888-866-5797. Item 70312
SaFety OperatiOn MaintenanceSetup
parts Lists and Diagrams
pLeaSe reaD tHe FOLLOWinG careFuLLy
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
parts List
part Description Qty
1 Upper Handle 1
2 Middle Handle 1
3 Wire Hook 1
4 Handle Knob Bolt 4
5 Handle Knob 4
6 Insulation Sleeve 2
7 Left Lower Handle 1
8 M6 External Hex Bolt 6
9 Type 1 Non-Metallic Hex Locknut 6
10 Upper Support Plate 1
11 Lower Support Plate 1
12 R-Clip 1
13 Clevis Pin 1
14 Hex Flange Bolt 2
15 Wheel 2
16 Wheel Frame 1
17 Linch Pin 2
18 Tine A 1
19 Felt Washer 2
20 Tine B 1
21 Gearbox 1
22 Tine C 1
23 Tine D 1
24 Hex Flange Bolt 4
25 Spring Washer 4
26 Flexible Shaft 1
part Description Qty
27 Nylon Bracket 1
28 Shock Absorbing Cushion 1
29 Blade Guard 1
30 Lift Handle 1
31 Rubber Gasket 1
32 Motor 1
33 Hoop 1
34 Rubber Gasket 1
35 Rubber Gasket 1
36 PCBA 1
37 Right Housing 1
38 Cover 1
39 Hex Pan Head Self-Tapping Screw 13
40 Male Plug 1
41 Pin 1
42 Battery Door 1
43 Self-Tapping Screw 1
44 Magnet 1
45 Compression Spring 2
46 Spring Seat 1
47 Left Housing 1
48 Cover 1
49 Right Lower Handle 1
50 Type 1 Non-Metallic Hex Locknut 4
51 Lower Handle Bolt 4
record product’s Serial number Here:
note: If product has no serial number, record month and year of purchase instead.
note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175495723 when ordering parts.
Page 15For technical questions, please call 1-888-866-5797.Item 70312
SaFetyOperatiOnMaintenance Setup
assembly Diagram
1
2
5
4
7
6
8
9
10
11
12
13
14
15
16
17
18
19
20
21
23
22
24
25
26
27
28
29
51
30
31
32
33
34
35
36
37
38
39
40
41
42
44
45
46
43
48
47
3
49
50
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
26677 agoura road • calabasas, ca 91302 • 1-888-866-5797
