User Instructions
EN
Maytronics Dolphin robotic pool cleaner
M600 / ZENIT 60 / ACTIVE 6 / ACTIVE X6 / ACTIVE ULTIMATE
1
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
M600 / ZENIT 60 / ACTIVE 6 / ACTIVE X6 /
ACTIVE ULTIMATE Robotic Pool Cleaner
User Instructions
EN
Contents
1. INTRODUCTION ......................................................................................................................................................2
2. SPECIFICATIONS .....................................................................................................................................................2
3. WARNINGS AND CAUTIONS ..............................................................................................................................2
3.1 Water conditions ...........................................................................................................................................3
4. ROBOTIC POOL CLEANER PARTS ................................................................................................................... 4
5. USING THE ROBOTIC POOL CLEANER ............................................................................................................5
5.1 Setup ..................................................................................................................................................................5
5.2 Placing the Robotic Pool Cleaner into the pool ............................................................................. 6
5.3 Plug in the power supply ........................................................................................................................ 6
5.4 Operating the Robotic Pool Cleaner without using your smart device ...............................7
5.5 Using the power supply ............................................................................................................................7
5.6 Robotic Pool Cleaner indicator lights ..................................................................................................7
5.7
Removing the Robotic Pool Cleaner from the pool
...................................................................... 8
6. CARE AND MAINTENANCE................................................................................................................................ 9
6.1
Cleaning after use - Removing and cleaning the dual filter baske
t ............................................9
6.2
Periodic filter cleaning
.............................................................................................................................10
6.3
Cleaning the impeller
.................................................................................................................................11
6.4
Periodic general maintenance - Recommended at least once a week
.................................. 12
7. OFF-SEASON STORAGE ...................................................................................................................................... 12
8. USE THE
MyDolphin™ Plus
IOT MOBILE APP ............................................................................................13
8.1
Getting Started with the MyDolphin™ Plus App
.............................................................................. 13
8.2
Prepare the Pool Cleaner for Connection
.........................................................................................13
8.3
Activate the Pool Cleaner Using your Mobile Smart Device
...................................................... 13
8.4
Led Lights
.......................................................................................................................................................14
9. TROUBLESHOOTING ........................................................................................................................................... 15
10.
MyDolphin™ Plus
- TROUBLESHOOTING .................................................................................................... 17
2
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
1. INTRODUCTION
Thank you for purchasing a Maytronics Robotic Pool Cleaner.
We are sure that your Maytronics Robotic Pool Cleaner will provide you with reliable, convenient, and
cost-effective pool cleaning, to enhance your pool’s hygiene.
Robotic Pool Cleaners by Maytronics deliver advanced cleaning technologies, exceptional ease of use,
long-lasting performance, and simple maintenance. You and your family will be free to enjoy your
swim with full confidence that your pool is completely clean.
2. SPECIFICATIONS
This product is in accordance with EU Regulation & Directive 2014/531EU.
For full information, please contact us at www.maytronics.com/contact-us-en and ask for the EC
declaration of conformity.
3. WARNINGS AND CAUTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
Please adhere strictly to the following WARNINGS:
Take the Robot Pool Cleaner out of the pool before allowing people to enter the pool.
When examining the Robot Pool Cleaner, disconnect the main power supply.
Ensure that children do not attempt to access Robot Pool Cleaner while it is operating.
Keep the Robot Pool Cleaner out of the reach of children or persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction.
Only an original power cable must be used, at all times. Replaced by a Robot Pool Cleaner
certified technician, in case of need to avoid hazard.
Digital switch-mode power supply
IP 54
Input: 100-250 AC Volts, 50-60Hertz, 180 Watt
Output: <30VDC
Bluetooth®/Wifi® Max tras power 10mW EIRR, 2.4 GHz frequency
WARNING
WARNING
WARNING
WARNING
WARNING
Robot
Motor protection: IP 68
Minimum depth: 0.4m / 1.33ft
Maximum depth: 5m / 16.4ft
3
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
The unit must be connected only to a supply circuit that is protected by a ground-fault circuit
interrupter (GFCI). This GFCI should be tested on a routine basis. To test the GFCI, push the test
button. The GFCI should interrupt power. Push the reset button. Power should be restored. If
the GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the
power unit without the test button being pushed, a ground current may be flowing, indicating
the possibility of an electric shock. Do not use the power unit. Disconnect the power unit and
contact the manufacturer for assistance.
To reduce the risk of electric shock replace damaged cord immedietely.
Do not use extension cord to connect unit to electric supply; provide a properly located outlet.
Please ensure that the following PRECAUTIONS are implemented:
Operator should keep hands away from driving belt mechanism.
Position the Caddy and power supply at least 3.5m/12ft from pool’s edge – during operation.
For continued protection against possible electric shock, the power supply unit should be placed
at least 11cm/4in above ground.
When lifting the Robot Pool Cleaner, take care to prevent back injury.
Do not bury cord – locate cord to minimize abuse from lawn mowers, hedge trimmers and other
equipment.
Do not use the pool cleaner if you have added liquid flocculant or any other clarifier to the pool
water. These substances obstruct and damage the robot's filters.
3.1 Water Conditions
Use the Robotic Pool Cleaner in the following water conditions:
Chlorine Max 4 PPM
pH 7.0-7.8 PPM
Temperature 6-35°C / 43-95°F (below 15°C / 59°F climbing performance may be affected)
NaCl Maximum = 5000 PPM
WARNING
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
WARNING
4
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
4. ROBOTIC POOL CLEANER PARTS
Robotic Pool Cleaner
Filtration
Power supply
Caddy kit
Start the season with the net filters for large debris then use ultra-fine filters for daily use.
* The net filters are assembled in the filter basket.
5
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
5. USING THE ROBOTIC POOL CLEANER
5.1 Setup
Before using the Robotic Pool Cleaner for the first time, perform the following steps:
Position the power supply
at approximately the middle of the
long side of the pool, at least at a
distance of 3.5m /12ft.
Unwind the cable and stretch it out completely so that it
has no kinks.
Attach the floating cable to the power supply:
Insert the cable with the notch on the connector (1),
lined up with the groove in the socket on the power
supply, and turn clockwise (2).
11cm/4 in
minimum
11cm/4 in
minimum
5.1.25.1.1
5.1.3
1
2
6
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
5.2 Placing the Robotic Pool Cleaner into the pool
Place the Robotic Pool Cleaner in the pool.
Release it and let it sink to the floor of the pool.
Make sure that the floating cable is free of any obstacles.
5.2.1
Connect the power supply to the AC.
11cm/4 in
minimum
11cm/4 in
minimum
5.3 Plug in the power supply
5.3.1
7
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
5.4 Operating the Robotic Pool Cleaner without using your smart device
Press the power button to turn the robot ON.
The Robotic Pool Cleaner will now operate until it has reached the end of the cleaning cycle.
5.5 Using the power supply
Your power supply is designed to provide you with the most advanced
features to improve your experience.
• A single on/off button for an easy operation.
• LED indicators for the advanced features.
LED indications table:
5.6 Robotic Pool Cleaner indicator lights
Light Indication
Blue blinking
Normal operation of the Robotic Pool Cleaner
Green blinking
Remote-Control or Smartphone communicate
with the Robotic Pool Cleaner
Red constant
Robot error. Check the Troubleshooting section
for solutions.
If none of the solutions solve the issue,
contact your dealer to check the Robotic Pool
Cleaner.
5.6.1
Indicator lights
Indicator lights.
Lights display Meaning
Blue circle Blinks 4 times Occur after connecting the power-supply to the
power outlet.
Blue connectivity light is consistent Bluetooth® connected
Green and Blue connectivity lights
blink alternately
Pairing process is ongoing
Green connectivity light is on Wi-Fi® connected to home network
8
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
Place the Robotic Pool Cleaner on the side of the pool
and let the water drain out.
Option A
The easiest and most fun way to get the robot out of the water:
1. Log into the
MyDolphin™ Plus
app and click "Pick-up mode".
2. The robot will reach the wall closest to it and will rise above the water surface.
3. Grab the robot by the handle and pull it out the water.
Option B
Use the floating cable to pull the Robotic Pool Cleaner to the side of the pool.
Use the handle to remove the robot from the pool.
WARNING
Please use the cable to pull the robot to the surface, then use the handle.
5.7.3
5.7.2
Turn OFF the power supply.
5.7.1
5.7 Removing the Robotic Pool Cleaner from the pool
WARNING
9
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
Upon opening the filter cover,
the handle will lift independently.
Open the filter cover.
Clean the filter basket with a
hose.
Open the latch to
release the bottom lid.
Lift the basket.
Make sure the power supply is switched o.
We highly recommend cleaning the filter basket after each cleaning cycle.
Note: Do not let the filter panels dry out before cleaning.
6.1 Cleaning after use - Removing and cleaning the dual filter basket
click!
6.1.1
6.1.2
1
2
6.1.3 6.1.4 6.1.5
6. CARE AND MAINTENANCE
WARNING
10
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
6.2 Periodic filter cleaning - Recommended at least once a month
Dismantle the 4 ultra-fine filter panels of the outer basket, according to the following steps:
Hold down the
handle to remove the
inner net basket.
Dismantle the
panels; start by pressing on
panel 1, using your thumbs.
Continue to dismantle the
panels in order: 2
—
> 3
—
> 4.
Clean the filter panels with a hose.
Assemble the filter panels according to
the following order:
Panel 4
—
> 3
—
> 2
—
> 1.
6.2.1
6.2.2
6.2.4
6.2.3
6.2.5
Insert the clean filter basket and close the filter cover.
6.2.6
11
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
6.3 Cleaning the impeller
Make sure the power supply is switched off and unplugged.
Clean the debris trapped in the impeller opening, according to the following steps:
If you notice debris trapped in the impeller:
2
1
3
6.3.1
6.3.2
6.3.3 6.3.4
WARNING
12
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
Assemble the impeller compartment according to the next steps:
6.3.5
6.3.6
6.4 Periodic general maintenance - Recommended at least once a week
• When the cable is wet, spread it flat and straight in the yard, and allow it to dry for at least five
hours to avoid twisting of the cable.
• Wash the Robotic Pool Cleaner with fresh water, to reduce damage caused by the chemicals in the
pool water.
7. OFF-SEASON STORAGE
If the Robotic Pool Cleaner will not be in use for an extended period of time, perform the following
storage steps:
• Make sure that no water is left in the Robotic Pool Cleaner.
• Thoroughly clean the filter basket and panels and insert them back in place.
• Roll up the cable so that it has no kinks.
• Store the Robotic Pool Cleaner in a protected area out of direct sun/rain/frost, at a temperature
of between 5°- 45°C / 41°-113°F.
5°C
41°F
45°C
113°F
13
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
8. USE THE MyDolphin™ Plus IOT MOBILE APP
Please download the Maytronics MyDolphin™ Plus app to your mobile smart device from either Google Play
for Android or the Appstore for iOS.
The Maytronics MyDolphin™ Plus app is cloud-connected, enabling control from anywhere at anytime,
with real-time connectivity.
8.1 Getting Started with the MyDolphin™ Plus App
The app is compatible with the following smart devices:
·
Apple (iOS) – version 10 and up – iPhone, iPad, iPod
·
Android – version 5 and up operating system
1. Make sure your mobile smart device (phone/tablet) is connected to your home/pool Wi-Fi® network.
2. Make sure you have your Wi-Fi® network name and password in reach.
3. Ensure Bluetooth® is enabled on your smart device.
4. Android users - please make sure your GPS and Location Services are ON.
5. For iOS 13 only - while the app is working, enable Bluetooth® & location.
6. Please make sure your router is on 2.4Ghz Wi-Fi® frequency only.
8.2 Prepare the Pool Cleaner for Connection
1. Connect the Pool Cleaner to the power supply.
2. The connectivity LED light indicator on your power supply will start flashing blue.
3. Place the Pool Cleaner in the water.
4. Press the ON button on your IoT power supply, to start the Pool Cleaner.
8.3 Activate the Pool Cleaner Using your Mobile Smart Device
1. Activate the MyDolphin™ Plus app.
2. Click Agree and allow all the required permissions.
3. Sign up by creating an account or use your Gmail/Facebook accounts.
4. Scan the QR code located on the side of the power supply.
5. Alternatively, press "Search for your robot manually" to pair with your Pool Cleaner.
The app will start pairing with your power supply.
6. Wait for the steady blue connectivity LED light and a success message in the app.
7. Connect to your home/pool Wi-Fi® network.
8. Enter the password of your home Wi-Fi® network, and press CONTINUE
After a short while, your power supply will flash green and blue.
9. Wait for the steady green connectivity LED light and a success message in the app.
NOTE: Please make sure to fill in the Warranty details and name your Dolphin Pool Cleaner.
14
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
8.4 LED Lights
Connectivity LEDs
The connectivity LED light on the power supply has several modes:
1. Flashing blue light - waiting for Bluetooth® connection.
2. Steady blue light - connected via Bluetooth®.
3. Flashing green light - power supply is connected to your home/pool Wi-Fi® network and
trying to connect to the cloud.
4. Steady green light - power supply is now connected to the Wi-Fi® network and to the cloud.
5. Alternating blue and green light - power supply is connected via Bluetooth® and to the cloud.
Appear also while using the remote-control.
On/Off LEDs
1. Steady blue light - Power supply is ON, and the pool cleaner is working.
2. Flashing green light - waiting for the next operation (delay mode or weekly timer).
3. Alternate blue/green/red lights – program updating remotely.
Please wait until process is completed.
4. Steady red light – error. Refer to troubleshooting.
5. Orange light - Filter is clogged up. Please clean the filter.
Tips
• If the app is stuck on the same screen for over 2 minutes, close the app and re-open it.
• To test your Wi-Fi® signal strength and quality, play a video via your smart device browser.
Power supply On/Off button features:
1. Operating - Press the On/Off button for up to 5 sec.
2. Quick start - This feature activates a specific feature via the power supply.
*In selected models, these features can be changed via the app.
To activate the quick start feature, press and hold the On/Off button for 5 sec.
The blue led light will blink 3 times.
3. Automation mode - This feature allow you to connect to your smart-home.
To activate the automation mode, press and hold the On/Off button for 15 sec.
The blue led light will blink 3 times.
15
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
WARNING
Unplug the power supply before performing any action.
9. TROUBLESHOOTING
Symptom Possible reason Corrective action
The power supply
or its switch LED
are not working.
• No voltage in the power socket in the wall.
• The power supply is not switched ON.
• The power cable is not properly connected
to the power supply inlet.
• The Ground Fault Interrupter is switched
OFF (closed).
• Check that there is voltage in the power socket in the wall.
• Check that the power supply is plugged in and turned ON.
• Check that the power cable is securely connected all the way
into the power supply.
• Turn the power supply OFF. Wait 30 seconds, then turn it back
on.
The Robotic Pool
Cleaner does NOT
move.
• The floating cable is not properly
connected to the power supply outlet.
• An obstacle is blocking the impeller, tracks,
or wheels.
• Check that the floating cable is securely connected to the
power supply.
• Unplug the power supply. Open the impeller cover and check
that nothing is trapped in the impeller.
• Verify that nothing blocks the tracks or wheels.
The Robotic Pool
Cleaner is moving
in circles.
• Clogged filter basket.
• Debris stuck in the impeller house or
impeller cover.
• Power supply incorrectly positioned.
• Algae buildup or pool water does not meet
specifications.
• Clean the filter basket.
• Remove debris stuck in the impeller house or impeller cover
(see illustrations 6.3.1 to 6.3.4).
• Place power supply in a position that enables the Robotic Pool
Cleaner to freely reach the entire pool area.
• Correct pool and water conditions.
The Robotic Pool
Cleaner does not
turn or moves in
one direction only.
• Debris stuck in the impeller house or
impeller cover.
• Remove debris stuck in the impeller house or impeller cover
(see illustrations 6.3.1 to 6.3.4).
The Robotic Pool
Cleaner moves but
does not clean the
pool.
• Clogged filter basket.
• Debris stuck in the impeller house or
impeller cover.
• Clean the filter basket.
• Remove debris stuck in the impeller house or impeller cover
(see illustrations 6.3.1 to 6.3.4).
The Robotic Pool
Cleaner cleans
only part of the
pool.
• Power supply incorrectly positioned.
• Not enough floating cable is released for
the correct operation of the Robotic Pool
Cleaner.
• Place the power supply in a position that enables the Robotic
Pool Cleaner to freely reach the entire pool area, while verifying
a minimal distance from the pool of 3.5m / 12ft and minimal
height above the ground of 11cm / 4in.
• Check that there is enough slack in the floating cable for the
Robotic Pool Cleaner to reach the entire pool.
• Clean the filter basket.
The floating cable
has kinks.
• Clogged filter basket.
• Debris stuck in the impeller house or
impeller cover.
• Clean the filter basket.
• Remove debris stuck in the impeller house or impeller cover.
(see illustrations 6.3.1 to 6.3.4).
• To remove the kinks, stretch the floating cable out completely
and let it sit for at least a day in the sun.
The Robotic Pool
Cleaner doesn’t
climb the walls.
• Clogged filter basket.
• Algae on walls.
• Unsuitable pH level.
• Debris stuck in the impeller house or
impeller cover.
• Clean the filter basket.
• Check the level of chemicals in the water. Improper levels may
allow the growth of algae, making the walls slippery.
If so, adjust the levels and scrub the walls.
• Remove debris stuck in the impeller house or impeller cover
(see illustrations 6.3.1 to 6.3.4).
16
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
Symptom Possible reason Corrective action
Can not connect
to your Wi-Fi®, and
the communication
Led is blinking
Green.
• The power supply is too far from the router
(weak signal) or your router is not working
properly.
• Reset the power supply (disconnect the power cord),
and wait 1 min.
• Check that your smartphone has a strong Wi-Fi® connectivity
near the power supply (try to play any online video streaming
application).
• Check the home router if it’s working properly.
• Locate the power supply to be as closer as possible to the
home router.
• Consider installing a Wi-Fi® extender (2.4Ghz) to ensure that
you have a sufficient signal strength.
• Note: In case the communication LED is still blinking Green,
you have the option to connect via Bluetooth®.
Can not connect
to your Robotic
Pool Cleaner via
Bluetooth®, and
the communication
Led is blinking
Blue.
• The power supply is too far from the smart
device, or your Bluetooth® is disabled, or
not working properly.
• Try to turn Off and then On the Bluetooth® in your smartphone
For IOS – Go to settings → Bluetooth®.
For Android – Go to slider and turn Off/On the Bluetooth® icon.
• Get closer to the power supply.
• Ensure that you don’t have any obstructions or obstacles
between you and the power supply.
• Turn the power supply Off and then ON.
• If none of the above troubleshooting helps, then contact the
dealer for further support.
Steady Orange
light on the power-
supply unit.
* In selected
models only
• Filter is clogged up. • Please clean the filter.
• We highly recommend cleaning the filter basket after each
cleaning cycle.
17
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
10. MyDolphin™ Plus - TROUBLESHOOTING
Action What To Do
Pool cleaner does not connect to Wi-Fi®, and
the power supply is Flashing green light
power supply is trying to connect to your home/pool Wi-Fi® network and cloud.
1. Weak internet signal.
2. Get the power supply closer to the Wi-Fi® source.
3. Consider use Wi-Fi® extender for a stronger signal.
Second connection after losing router/
Wi-Fi®:
How to change to Bluetooth® after first
Wi-Fi® /3G connection.
Losing router/ Wi-Fi®:
1. Open the app. The "our cloud services seems to be down" message will appear (can
take a few seconds) and the globe on the top bar will turn red.
2. Scroll down and click "choose another solution" which will direct you to the
Bluetooth® option. (*this solution will be a one-time solution. Note that in order to
continue with Bluetooth® connection, the end user must be near the robot).
3. The app will connect to Wi-Fi® automatically when the connectivity returns. If it
doesn’t reconnect, restart the app.
4. If network interruptions continue, try to improve the quality of the home router
signal (move closer to the router).
Initial connection.
How to connect with Bluetooth® only.
Before you start: CONNECT VIA Wi-Fi®, 3G/4G MUST BE OPEN
1. Plug in the power supply.
2. Connect the robot to the power supply.
3. Download the new MyDolphin™ Plus app.
4. Login to the app and allow the required permissions.
5. Scan the QR code and follow the app instructions.
6. Click "go online" (at this stage, iOS users need to minimize the app and re-open it.
Android users can click "choose network" and "Later").
How to change to Wi-Fi® after initial
Bluetooth® connection.
1. Make sure your Bluetooth® and Wi-Fi® are enabled.
2. Open the MyDolphin™ Plus app and connect to the robot via Bluetooth®.
3. Go to Settings and click “Wi-Fi® Settings”.
4. Follow the app instructions to go online.
Changing your Wi-Fi® network. Router was replaced
1. Log into the app → you will see a connection error.
2. Go to "settings" at the top bar on the screen.
3. Go to "Wi-Fi® settings" → Click "change Wi-Fi® network" → “change to the new Wi-Fi®
network” (enter the Wi-Fi® name and passcode) → Click "continue" and wait to receive
notification that the robot has been configured to the new Wi-Fi®.
4. Simultaneously, the LED color on the power supply will turn solid green (this is the
confirmation that the Wi-Fi® is connected).
For Android users.
Power supply replacement for new Wi-Fi®
connection.
New power supply for a robot connected through Wi-Fi®
1. Turn on the power supply while it is connected to the robot and let it work for
several seconds (it will sync with the robot).
2. Login to the app. A connection error message will appear.
3. Go to “check other solutions”.
4. Click on the Bluetooth® icon in the top bar.
5. Click “change connectivity”, “set Wi-Fi® connectivity” and then “go online”.
6. Enter your Wi-Fi® name and password. You see the home screen.
The power supply LED will flash green.
Before using the app, make sure you have:
• Cellular connection 3G/4G/5G or Wi-Fi®, with strong signal strength
• Power supply support 2.4Ghz ONLY
• Bluetooth® enabled
18
M600 / ZENIT 60 / ACTIVE X6 / ACTIVE ULTIMATE Robotic Pool Cleaner | User Instructions
Action What To Do
For iOS users.
Power supply replacement for new Wi-Fi®
connection
New power supply for a robot connected through Wi-Fi®
1. Turn on the power supply while it is connected to the robot and let it work for
several seconds (it will sync with the robot).
2. Login to the app. A connection error message will appear.
3. Go to “settings”, on the top bar → click on “robot details” → “disconnect from the
robot” →“proceed” → “search for nearby robots” → your robot” → click on “change
connectivity” → ”set Wi-Fi® connectivity” → ”go online”.
4. Enter your Wi-Fi® name and password.
Motor unit replacement for unit that was
not reported to the support system by the
technician.
1. Disconnect the power supply from the wall socket before use.
2. After replacing the motor unit (MU), reconnect the power supply to the wall socket
and turn on the power supply. Let the robot work for several seconds.
3. Open the MyDolphin™ Plus app. You will see a connection error.
4. Go to “settings” in the top bar → “robot details” → “disconnect from the robot”
→“Proceed” → “search for nearby robots” find and select the “new Dolphin MU s/n” →
a “is this your robot?” message will appear. After checking the s/n number, press “Yes
this is my robot” → The MU will link to robot and the app → home screen.
If you do not recognize the serial number, press to add the robot s/n manually or scan
the QR Code.
If none of these solutions do not solve your problem, contact Maytronics Customer Care:
North America
1-888-365-7446 ext. 1002
customersupport@maytronicsus.com
France
+33 (0)4 42 98 14 90
support@maytronics.fr
Australia, NZ, South Africa
1 300 693 657
infoau@maytronics.com
Rest of the world / Maytronics HQ
00 800 69694141 (toll free number)
00 972 77 96 14 204 (international call)
wecare@maytronics.com
For full information and additional troubleshooting please visit us at: www.maytronics.com
