1. SAFETY
9 Read operating instructions before use.
9 Check capacity and maximum inflation pressure of inflatable before commencing inflation.
9 Monitor the pressure gauge while in operation. The gauge should be used as an indication of pressure only. We recommend the use of
a dial pressure gauge for definitive reading.
WARNING! DO NOT inflate any item beyond its maximum capacity.
8 DO NOT carry by the hose, or yank the hose from an inflation valve.
8 DO NOT use the pump for a task it was not designed to perform.
8 DO NOT operate the pump when you are tired, under the influence of alcohol, drugs or intoxicating medication.
8 DO NOT operate the pump if any parts are missing as this may cause failure or possible personal injury.
9 Keep children and non essential persons away from the inflation area.
9 Keep the pump clean and in good condition.
9 Replace or repair damaged parts.
2. INTRODUCTION
Durable construction with chrome plated steel upright tube. Digital gauge calibrated in psi, kPa and bar with ranges from 0-120psi and
0-8bar. Fitted with twin head for both Presta and Schrader valves and a 360° rotatable hose. Features a wide base for added stability.
Auto-shut-off after 30 seconds. Supplied with accessories for inating items such as small inatable boats, air beds and balls stored in
a compartment located in the handle.
3. SPECIFICATION
4. OPERATION
4.1. Remove all packaging.
4.2. Select Presta or Schrader valve connection.
4.3. Unscrew the valve cap.
4.4. Place the pump head onto the tube valve, lift the lever up to the
locked position (Fig.2).
4.5. Use On/Off button (Fig.3) to turn on digital gauge. Use On/Off
button to select the display unit (psi, bar, kPa).
4.6. Place feet on to base, grasp handles. Raise and lower handles to
pump air into item to be inated.
4.7. Inate tyre to desired pressure.
4.8. Lower lever to unlocked position to release pump head (Figure 2).
4.9. Fasten the tube valve cap.
4.10. CHANGING THE BATTERY
4.10.1. Slide the battery tray out to change the battery. Make sure you
insert the battery the correct way up see g.4 for reference.
TRACK PUMP WITH DIGITAL GAUGE, BICYCLE PUMP,
8BAR, 180PSI, AUTO-SHUT-OFF
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Original Language Version
© Jack Sealey Limited
Refer to
instructions
MODEL NO: BC115D
Model No: BC115D
Accuracy: ±0.8%
Battery Run Time: Continuous working time: 20 hours
Battery: CR2032 (Supplied)
Maximum Pressure Output: 120psi
Nett Weight: 0.89kg
Pressure Units: Psi, bar, kPa
Range: 0-8 bar (0-120psi)
BC115D Issue 3 03/03/25
Battery in
product
Locked
Position
Unlocked
Position
g.2
Digital gauge
g.1
5. MAINTENANCE
5.1. Keep tyre pump clean and check for damage before
every use. If damage is observed, remove from use until
unit is repaired.
5.2. Keep the tyre pump clean by wiping with a damp cloth.
8 DO NOT allow water ingress into the tyre pump.
8 DO NOT use solvents to clean tyre pump.
5.3. Store tyre pump in a dry childproof area.
5.4. LIFE TIME OF THE MACHINE/DISPOSAL
5.4.1. Through years of normal wear, the tyre pump will
eventually become unserviceable. When this happens
ensure that it is disposed of in accordance with local
authority regulations.
Original Language Version
© Jack Sealey Limited
BC115D Issue 3 03/03/25
REGISTER YOUR
PURCHASE HERE
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
g.3
Digital Display
On/Off button
Battery
compartment
g.4
