ML200
Bluetooth-Enabled Digital Keypad Smart Lock
Features
Brief Introduction
ML200 is a new entry-level digital keypad smart lock with Bluetooth communication for semi-outdoor scenarios.
With the water-resistant design in all aspects, it reliably secures the front door in some rainy situations. It's super
easy to install on the existing lever or knob of a single-hole door directly, and finish the lock's setup with just a
few processes in minutes.
The additional Bluetooth Gateway allows you to unlock the door lock remotely, check the log history and share
the temporary or dynamic passcode via ZSmart App. More importantly, you can unlock the lock with voice
commands when paired with a compatible Amazon Echo or Google Nest device.
ML200 will be a better choice for the front door, garage entry and dramatically creates a more straightforward,
smarter, and more convenient life.
Voice Control
Work with Amazon Alexa and Google Assistant
Temporary Access
Share digital keys valid for specific time to friends
or guests
Random Passcode
Secure your passcode from prying eyes
Reversible Design
Fit for all door opening directions
No Drilling Required
Directly replace the existing lever or knob
of a single-hole door
Smart Alerts
Receive real-time notifications of low battery,
illegal attempts and hijack
Water Resistance
Keep the front door work well in rainy season
Remote Control
Unlock and manage the lock from anywhere
with the optional gateway
Applicable Scenarios
Mobile Application
Accessories
Front Door Garage Entry Short-term Rental
• Unlock and manage the lock from anywhere
• Works with Amazon Alexa and Google Assistant
• Receive real-time notifications of low battery,
illegal attempts and hijack
• Support up to 128 sub-devices
• Easy and fast network configuration
• Full 128-bit encryption
Bluetooth Gateway
App Control Manage Users Check Records
Share Temporary
Password
ZSmart App
Specifications
Configuration
Dimensions
Case Material
Zinc Alloy (Level & Front Panel) + ABS (Back Shell)
Mortise
American Standard Single Latch
German Standard Mortise (optional)
Identification Mode
Smart Phone and Passcode
Communication
Bluetooth 5.0
User Capacity
100
Passcode Capacity
100
Remote Access
Bluetooth Gateway Required
Voice Control
Amazon Alexa, Google Assistant
Battery Life
Up to 1.5 years (about 12,000 access)
Power Supply
4×AA Alkaline Battery (not included)
Backup Power Interface
Micro-USB Port Supported
Door Thickness
30-60mm (standard)
Backset
Adjustable 60 or 70 mm (only for single latch)
Dimensions (W*L*D)
Front – 75*138*23 (mm)
Back – 75*150*27 (mm)
Color Options
Silver / Gray
Operating Temperature
-20°C to 55°C
Operating Humidity
10%~90% RH (non-condensing)
ZKTECO CO.,LTD.
V1.0 2020.10.29
Copyright © 2020 ZKTECO CO., LTD. All rights reserved.
www.zkteco.com E-mail: sales@zkteco.com
Certifications
CE-RED, FCC ID
Bluetooth
(optional)
Wi-Fi
Mobile Phone
Cloud Server
Smart Lock Bluetooth Gateway
Wi-Fi Router
Bluetooth
138mm
75mm
115mm
79mm
90mm
27mm
23mm
74mm
150mm
