Installation
04
Name of each part
Toubleshooting
09
Power Connection
05
How to Use
06
How to use
07
Cleaning and maintenance
08
需折叠
Please check the accessories before use, in case of any missing
parts, please contact the seller.
Actural product might be different from picture, please refer to the actural product.
Note: Before breast pumping, please confirm the relevant accessories have been properly installed
and tightened.
Dust cover
Silicone massage pad
Flange
Backflow protector
Backflow protector cap
Connecting pipe
Duckbill valve
Base
Baby bottle(150ml)
Breast pump body (Shell)
Baby bottle dust-proof cap
Pacifier
Baby Bottlescrew cap
Storage cover
USB cable
PP
Liquid Silicone
PP
Liquid Silicone
PP
PP+PVC
Liquid Silicone
PP
PP
ABS
PP
Liquid Silicone
PP
PP
-
-20~120℃
-20~200℃
-20~120℃
-20~200℃
-20~120℃
-20~70℃
-20~120℃
-20~120℃
-20~120℃
-20~80℃
-20~120℃
-20~200℃
-20~120℃
-20~120℃
-
2
2
2
2
2
1
4 (including 2 free)
2
2
1
2
2
2
2
1
Name Material
Working temp
range
QTYNO
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Installation
A B
Put massage silicone ② into the suction
cap ③, and tightly contact the edge of
suction cup to the groove of massage
silicone (as shown in Figure A).
Note: Keep notched part of massage
silicone upward.
1.
Put in the anti-backflow silicone ④, then
hold the upper cover ⑤ and align it with
the groove to turn it tightened. (Keep the
center line of upper cover hole horizontal
with the suction cup cover). (As shown in
Figure B)
2.
C D
9
7
Fix the vacuum valve ⑦ on the column at
the lower end of suction cup ③, make
sure the vacuum valve has been fully
pushed into correct position; (as shown in
Figure C)
3.
Screw the wide-mouth baby bottle ⑨ into
the bottom of suction cup ③, and turn to
make it tightly installed (as shown in D)
4.
E F
Connect one end of conduit to the joint of
upper cover and the other end to the
suction port of the breast pump;(as shown
in Figure E)
5.
Put the baby bottle to the base to
complete the installation and get ready for
use; (as shown in Figure F)
6.
Power Connection
AC Adapter Installation
Insert the plug of AC adapter into the
socket on the side of breast pump, and
plug the AC adapter into power socket
(shown in Figure G)
Note: Power adapter is not included in
packing list. Specification: 5V/current≥1A.
G
Suction Gear Instruction
Automatically Battery Recognition
1. When the battery is low, the time digits will
flash on the screen to remind battery charging.
2. During charging, the flashing circle will be
displayed on the screen to indicate the battery
charging. When the battery is fully charged, the
breast pump will enter the standby mode. (As
shown in Figure H)
Note: Please turn off the machine before
connecting to the power adapter for charging.
A1: Shutdown
A2: Working Status
A3: Min (minimum suction)
A4 : Max (maximum suction)
Bl : Working Time
B2 : Minutes
B3 : Massage Mode
B4: Expression Mode
B5: Battery Status
Icons and Descriptions
Note: Knob operation is adopted. Rotate the
knob clockwise till the sound of "click" is heard,
which indicates the power is connected for
operation.
H
Specification
10
Basic parameters
Product Name: Electric Breast Pump
Model: AOV6826
Charging time: 2-3 hours
Rated voltage: 5V=
Rated current: 1A
Rated power: 5W
Battery: 3.7V 2500mAh polymer lithium battery
Certification: CE FDA
Manufacturer: Jiangxi AOV Maternity & Baby Products Co.,Ltd
Manufacture Address: No.8,Nanhuan Road,Industrial Park,Guixi City,Jiangxi
Province,China,335400
Made in China
I Have a Fault
If you have any issues at all, please contact us directly
(service@grownsyofficial.com) and we will help you
out.
We are really passionate about providing the best possible
customer experience and have even been know to jump on
a Skype call with our customers to give advice and resolve
issues.
Register Your Free Warranty
At GROWNSY we only use the highest quality products
standard - but please don’t forget to register for your FREE
one year warranty just in case...
www.grownsyofficial.com/warranty
The breast pump adopts the stepless speed suction design.
Massage Mode:
Massage Mode: Higher suction and release frequency with lower suction force, effectively
massage the breasts to stimulate mammary glands for lactation secretion;
Expression Mode:
Expression Mode: Automatic simulation of infant rhythm of“sucking, stopping and releasing"
with lower suction and release frequency and higher suction force for quick breast milk
collection.
Operation Instructions
Please wash your hands before use, confirm all the
parts have been thoroughly cleaned and properly
installed as required. (As shown in Figure ①)
Maintain normal sitting posture and feel relaxed.
During breast pumping, put a stool under feet to
help maintain the sitting posture and avoid
pressure on the waist. (Before breast pumping,
apply warm towel and massage the breasts for
better pumping effect)
Align the center of suction cup with the nipple and
tightly press on the breast. Hold the breast with the
other hand to ensure no air leakage. (As shown in
Figure ②)
In normal working mode, turn the knob to the
“MAX" to increase the suction force while turn the
knob to the “MIN” position to reduce the suction
force. (As shown in Figure ④)
Turn on the power and enter the standby mode;
turn the knob clockwise till the sound of "click" is
heard, which indicates the normal operation mode
and the timing starts; (Turn the knob till the " " is
on which indicates the massage mode, turn the
knob till the " " indicator is on which indicates the
expression mode). (As shown in Figure ③)
Note: The breast pump shall work at room temperature. If it’s not used for a long time, please
turn the knob to the "OFF" position and remove the accessories (default breast pumping time
in normal working mode is 30 minutes and the machine will automatically shut down after
breast pumping. When you use it next time, turn the knob to “OFF” first and then switch on).
Precautions for Operation
Please read the user manual carefully before use;
Do not keep the machine unattended during use;;
Do not clean the breast pump in water and it is strictly prohibited to put it in steam sterilizer
for disinfection;
Do not put the conduit in water for cleaning in case the water is sucked into the machine to
cause damages.;
Keep the product or removable parts beyond the reach of infants and children;
Please follow the instructions of your doctor and nursing staff if you want to use it during the
period of less milk secretion;
In case of any malfunctions, do not disassemble the machine without authorization. The
machie shall be repaired or placed by the manufacturer or professional personnel;
All accessories in the packaging list must be placed out of the reach of chidren.
Cleaning precautions
Please remove all accessories in contact with breasts or breast milk (Do not include the
breast pump);
Please clean the parts in contact with breast milk immediately after use to avoid milk
residue and bacterial growth;
Place the accessories on dry towel after cleaning and place in a cool place with good
ventilation;
During disassembling or assembling, please strictly follow the procedures to assemble
each part;
During cleaning, take care of the small parts to avoid failure of assembling or malfunction
due to missing spare parts;
Baby bottle, nipple, suction cup, massage silicone, anti-backflow silicone and other
accessories can be put in sterilizer for disinfection. (Do not include the breast pump,
adapter, USB cable and conduit).
Troubleshooting
Please make sure the power adapter has been correctly plugged into the DC socket of the
machine.
Mulfunction: Machine cannot work
Solution:
Store/heat breast milk
After breast milk collected, tighten the storage cover/seal the storage bag and put it in the
refrigerator immediately. It can be refrigerated or frozen.
This table only applies to healthy babies older than one month.
Breast milk just
collected
Room Temperature Refrigerating Chamber Freezing Chamber
No storage 10 hours Do not freeze
Do not store at room
temperature
Store at 4℃ for
3~5 days
Store at -16℃ for
6 months
Unfreezed breast milk
The suction force can be adjusted to the most
comfortable level for the mothers. (Research
shows the most suitable pumping force brings the
more comfortable breast pumping, which means
more milk collection within a relatively short time).
1.
2.
3.
4.
5.
6.
1.
Please confirm the battery level. If the battery is low, please fully charge before use.
2.
Check whether the suction cup and the breast have been tightly contacted.
Mulfunction: Suction force is not enough
Solution:
1.
Check whether all the accessories have been properly installed.
2.
If the room temperature is below 15°C, please run the pump for 30 seconds before breast
milk collection.
3.
When freezing, do not make the breast milk exceed 3/4 of total volume to leave room
for the liquid expansion.
To avoid no nutrients loss, please place breast milk in the refrigerating chamber to
defreeze naturally, or place it in running warm water (below 37°C) to defreeze.
Please shake the milk storage container gently before use so that the milk fat can be
evenly mixed.
Do not place frozen breast milk in microwave oven or boiling water to heat up in case
of nutrients loss and scald injury.
Gift
Heartfelt Thank you
Thank you so much for purchasing from us and placing
your trust in our brand.
GROWNSY develops innovative, modern, and credible
products for babies and children that make parents live
easier and more enjoyable by thinking of "the little
things". We are passionate, creative, and devote in
making the best products that are trusted and effective.
For any questions or issues, please email us:
service@grownsyofficial.com
We will go above and beyond to resove any customer
issue within 24 hours.
Thank you again for your custom, and we truly hope you
love your new electric breast pump as much as we do.
Best Regards,
Randell
Founder of GROWNSY
P.s. we mean it when we say we are grateful for every
single customer...and that’s why would love to send
you a free bottle warmer!
Visit grownsyofficial.com/gift
Stepless Speed
Electric Breast Pump
Manual
Please read the user manual carefully before use, and keep it
in a safe place for future reference.
AOV6826
Stepless Speed Lithium Electric Breast Pump
Specially designed for maternal breastfeeding, GROWNSY Stepless Speed
Lithium electric breast pump adopts the latest Stepless Speed system to
adjust suction force most comfortable for the mothers by simple, convenient
and fast knob rotation; the unique design of soft massage silicone pad can
provide mothers with the most effective and comfortable experience of
breast milk collection.
Stepless Speed Control System
Unique Stepless Speed system to adjust suction force most
comfortable for the mothers by knob rotation;
Double Breast Pump Design
Double breast pump design. It helps stimulate the milk production
of the other breast during milk pumping on one side.Simultaneous
bilateral breast pumping is available to increase milk pumping,
avoid milk waste and shorten the collection time;
Lactation Stimulation & Milk Collection with Stepless Speed
Design
Stepless Speed design for adjustment of suction force, automatic
simulation of infant rhythm of“sucking, stopping and releasing" and
easy collection of breast milk;
New Anti-Backflow Design
New anti-backflow design can prevent the milk from flowing back to
the pump and avoid the damages due to improper use or
overturned milk bottles;
Easy Milk Storage Design
Milk bottle accessories are provided for free, the milk can be fed to
babies immediately after pumping or sealed for refrigerated
storage;
Built-in Large-Capacity Lithium Battery
The built-in large-capacity lithium battery can easily support the
all-day breast pumping so as to enjoy the joy of milk feeding
without worrying about low battery.
General Introduction
01
02 03
1 2
3
4
6
7 8
9
10
11
5
AOV6826美规
