OUTDOOR GRILL CART
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Model: TB0100001
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
OUTDOOR
GRILL CART
Note: the quantity of parts shown in the manual is the actual usage and the
unused parts are spare parts.
1
Warning-To reduce the risk of injury, user must read instructions
manual carefully.
IMPORTANT SAFEGUARDS
Thank you for using this product. In order to make sure that you can
operate the machine correctly, read this instruction carefully before
operation and keep it properly for future reference. Please be sure to read
the precautions and safety rules on this page to ensure your safe use.
This manual will outline safety warnings and precautions, operating,
maintenance and cleaning. The warnings and instructions reviewed in this
manual cannot cover all possible conditions and situations that may occur.
Caution and common sense are not built into this product, since we believe
that the uses will comply with these codes.
Please read ALL the instructions before using your machine.
1. Do NOT let children and minors get close to or touch the product.
2. Do NOT immerse the appliance in water or any other liquid.
3. Using accessories or attachments not provided or recommended by the
manufacturer may cause injury.
4. Do not attempt to modify the machine in any way.
5. If the machine is not to be used for a long period of time, clean and fold it
and store it in a dry and safe place.
6. KEEP IT OUT OF CHILDREN'S REACH.
7. Children shall not play with the machine alone. Cleaning and user
maintenance shall not be made by children without supervision.
8. The machine must never be left unattended during operation or cleaning.
9. Make sure that the machine is always placed on a firm, level and fire
retardant surface, and also placed far away from combustibles. Improper
placement can cause the product to tip over, slide, or cause items on
the table to fall off !
10. While every effort has been made in the manufacture of your machine
to remove any sharp edge, you should handle all components with care in
order to avoid accidental injury.
2
11. DO NOT CLEAN IT WITH ANY ABRASIVE MATERIAL.
12. The machine should only be repaired or serviced by an authorized
Service Engineer and only genuine approved spare parts should be used.
13. This product cannot be used for other purposes.
14. Not suitable for commercial use.
15. Wear safety goggles and heavy-duty work gloves during assembly and
using.
16. Do not assemble when tired or when under the influence of alcohol,
drugs or medication.
WARNING! Remove all packaging materials and keep them for future
use.Packaging materials are not a toy.
WARNING! Keep children and pets from playing with the packaging
materials. If they swallow the packaging materials, they will suffocate!
WARNING! Keep children and pets away.Children must not operate or
play near this machine.
WARNING! Failure to follow instructions could result in death, serious
bodily injury and property loss.
WARNING! This product is not a toy. Do not allow children to play with or
approach this item.
WARNING! Use as intended only. Do not sit or stand on the table.
ATTENTION! Inspect before every use.Do not use if parts are loose or
damaged.
ATTENTION! Use only on flat, level, hard surfaces.
ATTENTION! The weight on the countertop must be evenly distributed,
careful of tipping and weight falling
！
PRODUCT PARAMETERS
Model No.
Product Size
Material Quality
TB0100001
32.27x25.2x29.72 inch
(972x640x755 mm)
Q235
3
LOADING CAPACITY
Model No.
Loading Capacity
TB0100001
Fixed desktop ---Max 220Lbs (100kg)
Folding Desktop---Max 11Lbs (5kg)
The hook---Max 11Lbs (5kg) / PCS
ATTENTION!
1. Do not exceed the listed weight capacity. Be aware of dynamic loading!
The sudden load movement may briefly create an excess load, causing
product failure.
WARNING! Placing items separately on a foldable desktop can
tip over, and the weight of items placed on the main desktop must be
greater than those set on the foldable desktop.
Max 11 LBS (5Kg)
Max 220 LBS (100Kg)
ATTENTION!
The weight on the
countertop must be
evenly distributed,
careful of tipping and
weight falling ！
4
PRODUCT COMPONENTS
1. Please dispose of all plastic bags carefully and keep them away from
children.
2. Check all components provided according to the list in this
manual.Make sure you have all of the parts listed.
3. Although paying particular attention when manufacturing this product,
you must be careful during the assembly process to avoid being scratched
by sharp edges.
4. Wear safety goggles and heavy-duty work gloves during assembly and
using.
5. Before using the appliance for the first time, peel off any promotional
materials and packaging materials, and check that the machine is clean
and dust-free. If necessary, wipe them over with a damp cloth. Spread over
with an absorbent kitchen towel and wipe off any excess oil.
No.
Diagram
Qty
No.
Diagram
Qty
1
1 PCS
9
2PC
S
2
1(LF)
PCS
10
2PC
S
3
1(RF)
PCS
11
1PC
S
4
1(LB)
PCS
12
1PC
S
5
1(RB)
PCS
13
1PC
S
6
1PCS
14
1PC
S
7
2PCS
15
1PC
S
5
8
1PCS
16
1PC
S
17
4PCS
D
1PC
S
A
M5x12:
34PCS
E
M5x10:
2PCS
B
M6x50:
2PCS
F
2PC
S
C
2PCS
NOTE: Assembly
requires the use of
a wrench and a
Phillips
screwdriver, but
requires self
purchase.
Explosion Diagram
6
SETP 1
A: 6pcs
E: 2pcs
SETP 2
A: 4pcs
7
SETP 3
A: 8pcs
SETP 4
A: 8pcs
8
SETP 5
D: 1pcs
C: 2pcs
SETP 6
B: 2pcs
9
SETP 7
A: 4pcs
SETP 8
A: 4pcs
10
SETP 9
F: 4pcs
SETP 10
A: 4pcs
11
CLEANING MAINTENANCE AND STORAGE
1. For cleaning, wipe the surface with a damp (not wet) cloth or wipe dry
with a clean lint free cotton cloth.
2. Keep the product dry after cleaning
3. Put the cleaned products and accessories into the carton.
Note: Only clean when the product is not working.
SETP 11
PVC Table Mat
NOTE:
1. Although PVC tablecloth
have good high temperature
resistance, it 's still
necessary.
2.Due to packaging reasons,
some tablecloth will have a
little smell when they are
received, which is a normal
phenomenon, and the smell
can be removed by blowing
on the balcony or washing
with detergent and drying in
the sun.
12
