User Manual

This is the main product document for model YC-BASE-20.

The file format is pdf, 64 pages, you can download this manual here .

background
Fire Pit Heat Deflectors
MODEL: YC-BASE-20 / YC-BASE-25 / YC-BASE-27
Technical Support and E-Warranty Certificate
www.vevor.com/support
background
background
- 1 -
MODEL: YC-BASE-20 / YC-BASE-25 / YC-BASE-27
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Warning-To reduce the risk of injury, user must read
instructions manual carefully.
Fire Pit Heat Deflectors
background
- 2 -
PART LIST
When unpacking this product, ensure the parts listed below are included
and carefully inspect for any damage that may have occurred during transit.
Do not attempt to assemble or use the product if any part is missing or
damaged.
NO.
PART NAME
QTY
YC-BASE-27
A
(with hole)
Part A
3
B
Part B
3
C
Connecting
piece
1
D
Leg
3
E
Handel
2
F
Screws
36
background
- 3 -
INSTALLATION METHODS
Step1: Assemble part A and Part B together with screws.
YC-BASE-20 / YC-BASE-25
YC-BASE-27
Step2: Attach Part A to the part assembled in step 1 with screws.
YC-BASE-20 / YC-BASE-25
YC-BASE-27
Step3: Assemble in turn until the parts are all assembled together.
YC-BASE-20 / YC-BASE-25
YC-BASE-27
background
- 4 -
Step4: Attach the connecting piece to the front of the heat deflector with
screws.
YC-BASE-20 / YC-BASE-25
YC-BASE-27
Step5: Attach the legs to the heat deflector with screws.
YC-BASE-20 / YC-BASE-25
YC-BASE-27
Step6: Then, you can put the heat deflector on your smokeless fire pit.
YC-BASE-20 / YC-BASE-25
YC-BASE-27
background
- 5 -
Step7: Remove the heat deflector with handles when not in use.
YC-BASE-20 / YC-BASE-25
YC-BASE-27
Manufacturer: Shanghaimuxinmuyeyouxiangongsi
Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu,
shanghai 200000 CN.
Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD
NSW 2122 Australia
Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim
Place, Rancho Cucamonga, CA 91730
REP
UK
YH CONSULTING LIMITED. C/O YH Consulting
Limited Office 147, Centurion House, London
Road, Staines-upon-Thames, Surrey, TW18 4AX
REP
EC
E-CrossStu GmbH
Mainzer Landstr.69,
60329 Frankfurt am Main.
