Portable Power Station
Universal Instruction Manual
ATTENTION:
1. Keep dry and do not expose to high heat.
2. Never disassemble, puncture, shock, crash, short or incinerate.
3. Recharge the power station every 3 months.
Thank you for applying our multi-function portable solar generator. In case of power failure or
you need to charge to travel, you can temporarily charge your electrical or digital devices with this
unit.This unit can provide USB, DC and AC output. You can keep laptops, appliances, lights and
more going for hours longer. Before using this unit, please read the user manual carefully and
properly keep it for reference.
This manual is to help you use the product correctly; it does not represent any description of
the hardware and software configuration of the product. About the product configuration,
please refer to the contract related to this product(if there is), or consult to the seller that sells
the product. Pictures in this manual are for reference only, if there are individual pictures do not
match the actual, please prevail in actual products.
ABOUT THE UNIT
ATTENTION!
【1】PRODUCT PARAMETERS
Capacity
(LWH)Dimensions
Weight
Built-in battery cell
26400mAh /97.68Wh
200x140x130mm
About 1.7kg
100% Original High Quality Lithium ion Batteries
The unit provides Modified Sine Wave output
The unit provides Modified Sine Wave output and can be compatible with AC electric appliance
that works with Corrected waveform(power
≦
150W). However, anything that uses an AC motor isn't
going to work to full capacity on a modified sine wave, such as an electrical fan. It will even make the
electric appliance arouse some noise. Appliances like refrigerators, microwaves, and compressors
that use AC motors and some delicate medical equipment will be better off with a pure sine wave
inverter. This product is only used for emergency, it cannot replace the normal alternating current, for
long-term use, please adapts the power station specification required by electrical appliances.
DC 15V: About 5 hours
Adapter: DC 15V/2A
Solar Panel Charging: DC 13V-25V/2A(Max)
Input Recharging
Fully Charged Time
Output
USB1+USB2: 5V/3.1A
USB C: 5V/3A 9V/2A
DC1+DC2: 9V~12.6V 10A (MAX)
9V~12.6V/10A(Max)
DC Output(MAX)
※
There may be some differences on different spare parts. Please adhere to the actual product instead.
The AC output range of this product between 110V/60Hz
( Attention: Actual AC voltage/frequency/Outlet(s) are customized
according to different countries and areas
）
.
AC output
Bulb Type
Power indicator
Working temperature
Lifecycle
Ultra bright LED Flashlight
LED Display
-10
℃
-40
℃
>1000 times
1 x Portable Power Bank 1 x Power Adapter
1 x Cigarette Lighter Adapter 1 x User Manual
Package include
【2】PRODUCT DESCRIPTION
Handle
ON/OFF
LCD Display
AC ON/OFF
USB 5V/3.1A output
USB-C 5V/3A;9V/2A output
AC Outlet
DC Input
DC Output
ATTENTION!:AC Outlets,AC output voltage and frequency will be different according to different
countries or areas. Please refer to the actual product before using.
【
Left
】
【
Front
】
【
Front
】
【
Back
】
【
Right
】
LED Flashlight Switch
Vent
LED Light
Cooling Fans
【3】PRODUCT INSTRUCTION
1). How to charge DC12V appliances(such as headlamp,fan)with this product?
The 5.5mm 12VDC output is plug and play. Connect the appliance to the DC port, short press the
power switch to turn on DC output so that the unit can supply power to the appliance.
Notices: Please confirm whether your DC12V appliance support charging with 5.5mm DC
head interface (The diameter of the DC Port of the Product is:5.5mm), otherwise it is unable to
connect with the DC output, you can consult the electrical manufacturer, buy the corresponding
adapter and connect with it.
Connect the power cable plug of the electrical appliance to the AC outlet of the product, shortly
press the power switch to turn on, then switch on the"AC" button and the unit will start offering power
to your appliances.
※
Note: The 12V DC output voltage is range between 9V~12.6V, the maximum output current is
10A. DC output voltage drops while battery capacity drops due to chemical characteristics of the
battery. If your DC 12V appliance is not built-in input voltage stabilizing function, it may shut down
when the input voltage is too low, please unplug your device from the unit in time. And please
charge the unit in time.
5.5mm DC12V for Fan or
LED lights
Or charge car kits via DC to
Cigarette Lighter Connector
【Display Screen】
Protection Mode:
Short-circuit/Overpower Protection:
If the DC output is short-circuited or overpowered,
the unit will shut down to protect itself. Please clear the problem and recharge the unit to re-press the
power switch.
2). How to charge AC appliances with this product?
※
When the AC port is not in use, turn it off to conserve power.
WARNING!The AC outlets, AC voltage, and frequency are different according to different countries;
please carefully check whether the product specifications are consistent with the appliance
specifications before use, otherwise, it can lead to dangerous situations.
3). How to charge USB digital appliances with this product?
Connect the standard USB cable of the digital appliance to the USB output of the unit to gain
power. Then press the " " button switch on and the unit will start offering power to the devices.
Quick Charge Output:
This product supports Qualcomm QuickCharge 3.0 output, support
5V/3.1A; 9V/2A max output for smart devices which also support Qualcomm QuickCharge 3.0. The
actual output voltage and current depend on the actual smart devices, it can be obtained by
consulting the smart device manufacturer.
Protection Mode:
Short-circuit/Overpower Protection:
If the AC output is short-circuited or overpowered
(Load(s) power>150W), the unit will shut down AC output to protect itself.
※
Some devices, such as refrigerator, ice maker or a laser printer may require a surge power to
start or work during a very time period, the surge power could exceed 250W or even higher,
this could cause overpower protection with this unit. Please remove the devices and consult
with the device manufacturers for more information.
Using the included AC Wall Charger cable, plug the unit into any wall outlet to charge the unit.
You will know the unit is charging when the blue LED battery indicators are blinking. The unit is fully
charged when all battery indicators stop blinking . After the unit is fully charged, please remove the
AC wall charger in time.
5). How to charge the unit?
Warning! Do not look at the flashlight directly in case of any damage due to the strong light.
a. Charge through AC Wall Charger
b. Charge from Solar panel
①
Place your solar panel where it will get as much direct sunlight as possible.
②
Plug the output of the solar panel into the input of the unit to start charging. You will know the unit
is charging when the blue LED Battery Indicator lights up and blinks. The unit is fully charged when
all battery indicators stop blinking.
4). How to use the flashlight?
This unit is built with dual white LED flashlight. Press the flashlight button to switch on the
flashlight and single press the button to switch to blink/ SOS mode, Press the button to switch off.
▲
AC Adapter
AC Socket
▼
【4】SECURITY AND MAINTENANCE
▲
Charging Input
13V~25V/2.4A
c. Charge from your car with a 12V cigarette lighter.
Using the car charger, plug the unit into a 12V cigarette lighter(carport) of your car. You will know
the unit is charging when the blue LED Battery Indicator lights up and blinks. The unit is fully charged
when all battery indicators stop blinking and remain solid
Cold temperatures (below freezing) can affect the unit s battery capacity due to chemical
characteristics of the battery. If you ll be living off-grid in sub-zero conditions, we recommend you
keep your unit in an insulated cooler, and connected to a power source (solar panels). The natural
heat generated by the unit contained in an insulated cooler will keep battery capacity at its highest.
a) Do not short-circuit the unit. To avoid short-circuiting, keep the unit away from all metal objects
(e.g. coins, hair-pins, keys, etc.).
b) Do not heat the unit, or dispose of it in fire, water or other liquids. Keep away from high
temperatures. Do not expose the unit to direct sunlight.
c) Keep away from high humidity, dusty places.
d) Do not disassemble or reassemble this unit.
e) Do not drop, place heavy objects or hit the product strongly.
f) This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
g) Children should be supervised to ensure that they do not play with the appliance.
h) Do not cover the device with towels, clothing and other items.
i) The unit may be hot when charging. This is normal. Use caution when handling
；
j) Do not charge the unit over the required time.
k) Disconnect the unit when fully charged
l) Use the unit properly to avoid electronic shock.
m) Please deal with scrap products in accordance with the regulations, do not treat the built-in battery
as a household garbage, so as not to cause the explosion and pollution.
n) The product is only used for emergency situations, it cannot replace the standard DC or AC power
of household appliances or digital products.
a) high-capacity, and it is durable. However, we still recommend you to use in the range of 10
℃
~30
℃
, so as to obtain the optimal charging capacity.
b) When charging, in order to avoid interference, please stay away from TV, radio and other
equipment.
c) If the device has not been used for a long time, please disconnect the cable and store.
d) In order to extend the life of product (lithium battery), it is best to charge within 3 months, and
charge at least once within 6 months.
Your device has an internal, non-removable, rechargeable battery. Do not attempt to remove the
battery.
The battery can be charged and discharged over 1000 times, but it will eventually wear out.
Attention: To avoid car battery power loss. Charging this unit through your car cigarette lighter is
only available when your car engine is started.
【5】PRODUCT APPLICATION SKILLS
Cold Weather Usage
Battery Information
Statement
Always return your used electronic products, batteries, and packaging materials to dedicated
collection points. This way you help prevent uncontrolled waste disposal and promote the recycling of
materials.
I. FCC Statement:
The operation meets the following two conditions:
(1) The equipment will not cause harmful interference.
(2) The equipment must accept any interference received, including interference that may result in
accidental operation.
Note: The equipment has been tested and meets the restrictions of Category B digital equipment in
Part 15 of FCC Rules.
These restrictions are designed to provide reasonable protection against harmful interference in
housing installation.
This equipment will generate, use and radiate radio frequency energy. If it is not installed and used
according to the instructions, it may cause harmful interference to radio communication.
However, there is no guarantee that interference will not occur in a particular installation.
If the device does cause harmful interference to radio or television reception (which can be
determined by switching off and switching on devices), users are advised to attempt to correct the
interference by one or more of the following measures:
Re-adjusting or placing the receiving antenna.
Increase the distance between the device and the receiver.
Connect the device to a different circuit outlet from the circuit connected to the receiver.
Consult distributors or experienced radio/television technicians for help.
All rights reserved. Without the written permission of the Company, no unit or individual may copy or
reproduce part or all of the contents of the book without authorization, and may not disseminate them
in any form. Other trademarks appearing in this manual shall be owned by their respective owners.
Due to product version upgrade or other reasons, the contents of this manual will be updated from
time to time. Unless otherwise agreed, this manual is only for use guidance. All statements,
information and suggestions in this manual do not constitute any express or implied guarantee.
Recycle
Support 5.5mm DC 12V car kits with
DC-Cigarette Lighter Adapter,such as
Vacuum Cleaner,Inflation,Pump,Electric
wrench,fridge.etc.
Limited Appliance Wattage<150W, such as lamp,Electric Fan,
TV, Game Machine, etc. AC will shut down when it's
short-circuted or power overloaded. Remove the device and the
unit will return to normal from short-circuit or overpower
protection in a few seconds. Repress the AC output button to
switch on AC out again.
【
Front
】
【
Front
】
【
Front
】
【
Front
】
尺寸：400x280mm
四折页(100x140mm)
材质：128g铜版纸，双面印刷
英文
AC output indicator
DC/USB output indicator
Remaining power indicator
Input indicator
’
’
