RICE
COOKER
CRD20L1B1BPH
User Manual
IMPORTANT NOTE: For your safety and continued enjoyment of this
product, always read the user manual carefully before using.
CONTENT
IMPORTANT SAFEGUARDS
PRODUCT OVERVIEW
1
4
SPECIFICATIONS
5
19
8
6
21
23
QUICK START GUIDE
OPERATION INSTRUCTIONS
CLEANING AND MAINTENANCE
TROUBLESHOOTING
SERVICE AND SUPPORT
1
• When using electrical appliances, basic safety
prcautions should always be followed including the
following:
• Read all instructions.
• Do not touch hot surfaces. Use handles or knobs.
• To protect against electrical shock, do not immerse
cord, plugs, or appliance in water or other liquid.
• Close supervision is necessary when any appliance is
used by or near children.
• Unplug from outlet when not in use and before
cleaning. Allow to cool before putting on or taking off
parts.
• Do not operate any appliance with a damaged cord or
plug or after the appliance malfunctions or has been
damaged in any manner. Return appliance to the
nearest authorized service facility for examination,
repair, or adjustment.
• The use of accessory attachments not recommended by
the appliance manufacturer may cause injuries.
• Do not use outdoors. HOUSEHOLD USE ONLY.
• Do not let cord hang over edge of table or counter, or
touch hot surfaces.
• Do not place on or near a hot gas or electric burner, or
in a heated oven.
• Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
IMPORTANT SAFEGUARDS
CAUTION
2
IMPORTANT SAFEGUARDS
• Always attach plug to appliance first, then plug cord
into the wall outlet. To disconnect, turn any control to
“off”, then remove plug from wall outlet.
• Do not use appliance for purposes other than its
intended use.
• CAUTION: Risk of Electric Shock. Cook only in removable
container.
• Intended for countertop use only.
• Do not solely use the handle to carry the rice cooker,
appliance must be supported from the bottom when
moved.
• A short power-supplycord is used to reduce the risk
resulting from it being grabbed by children.becoming
entangled in, or tripping over a longer cord.
3
WARNING
IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
• WARNING: Spilled food can cause serious burns. Keep
appliance and cord away from children. Never drape
cord over edge of counter, never use outlet below
counter, and never use with an extension cord. Cord:
• DO NOT IMMERSE IN WATER.
4
PRODUCT OVERVIEW
COMPONENT NAME
PARTS LIST
Inner pot
Upper lid
Steam valve
Cooker body
Socket
Steamer
Soup spoon × 1Rice spoon × 1
Power cord × 1 Manual × 1
Measurement cup × 1
Cover plate assembly
5
SPECIFICATIONS
TECHNICAL DATA OF THE PRODUCT
Product Model Voltage
CRD20L1B1BPH 120V~
Frequency
60Hz
Power
350W
Capacity
2L
NOTE
All the pictures in this manual are for explanation purpose only. Any discrepancy between
the real object and the illustration in the drawing shall be subject to the real subject.
Remove the accessories from the packaging bag before installation.
6
QUICK START GUIDE
Reservation
For example: Make an appointment to finish cooking in 8 hours.
Gentle Reminder:
Display status refers to actual product.
1. Prepare rice and water
Place the rinsed rice into the inner pot
and choose the appropriate water level
according to the rice amount.
2. After closing the lid, select Quick Rice or
other functions by using the Quick Rice
or MENU button.
3. Set the timer for cooking completion
Press the “DELAY ” button, the Time
Display flashes, and then press the
button “DELAY ” again to adjust the
displayed reservation time.
5. Cancel cooking
Pressing the “KEEP WARM/CANCEL”
button can cancel the selected cooking
function.
4. Start cooking
Press the “START” button, the cooking
will be finished at the appointed time.
OR
7
QUICK START GUIDE
Gentle Reminder:
1. The time displayed under pre-set timer mode is the length of time from the start to the
completion of cooking;
2. To avoid an unpleasant odor in the rice, it is advisable not to set the pre-set timer for
more than 12 hours."
3. The pre-set time of the selected cooking function’s should not be less than the cooking
time. For example, if the reservation time for “SOUP” is less than 2 hours then cooking
will start immediately because the cooking time is pre-set as 2 hours.
8
OPERATION INSTRUCTIONS
OPERATION PART
INSTRUCTIONS FOR USE
Display
Screen
START Button
DELAY START
Button
MENU Button
Rice-water Ratio
1. Use the measuring cup provided with the product to measure the rice.
1 cup of rice can cook about 2 bowls
of rice (the diameter of the bowl rim is
about 11.5cm)
Correct
The rice should
be level with the
rim of the cup
If it is higher or lower
than the rim, the
water level will not be
accurately controlled
NOTE
1. A 2-liter conventional rice cooker can cook up to 4 cups of rice, otherwise it may cause
overflow or undercooked rice;
2. 11.5cm is the size of a regular household bowl.
9
1. Measure and wash rice
Use the measuring cup provided with the product to measure the rice and rinse the rice
thoroughly.
2. Add water
Add water according to the rice water level in the picture on the right (taking long grain
rice as an example)
3. Cook
Close the rice cooker lid and press the “QUICK RICE“ button.
Select the “QUICK RICE” function and press the “START” button to enter the cooking
state. After about 30 minutes, the cooking is completed and it automatically enters the
keep-warm mode.
OPERATION INSTRUCTIONS
QUICK RICE COOKING STEPS
Corresponds to the right side of
the water level line in the inner pot
2 cups of rice Inner pot water
level line 2
Note: The cooking time is different
depending on the rice amount.
10
INSTRUCTIONS FOR USE
Rice-water Ratio
1. Rice measuring method
1 measuring cup of rice can be cooked
into 2 bowls of steamed rice, and the
diameter of the bowl is about 11.5 cm.
2. Put in the rice and water
Take cooking 2 cups of rice as an
example, put the washed rice into the
inner pot and add water to the
corresponding scale line 2 (the water
level line shall be subject to the actual
object.
FUNCTION DESCRIPTION
(For specific functions, please refer to the actual panel for selective reference)
QUICK RICE
1. Put the washed rice into the inner
pot,refer to the rice-water ratio and
inject the water according to the White
Rice water level line, or increase or
decrease the water quantity according
to personal preference.
2. Close the cover and select the
“QUICK RICE” cooking function (The
default time is 30 minutes, and the
cooking time varies depending on the
amount of rice and water added).
NOTE
1. The water shall not exceed the
highest scale line.
2. For example, the rice-water ratio for
bean or cereal quick rice can be
adjusted
according to the actual situation.
OPERATION INSTRUCTIONS
3. Press the “MENU” button to select the
“QUICK RICE” function, and press the
“START” button to enter the cooking
state.
QUICK RICE
11
OPERATION INSTRUCTIONS
BROWN
1. Measure and wash rice
Measure the rice in the measuring cup
supplied with the product and wash the
rice well.
3. Cooking
Close the rice cooker lid and press the
“MENU” button. Select the “BROWN”
function and press the “START” button
to enter the cooking state. after about
1 hour and 20 minutes, you will hear a
di-beep, which indicates that cooking is
finished, and the cooker will
automatically enter the keep warm
mode.
2. Add water
Add water with reference to the water
level of the RICE on the right.
NOTE
The cooking time will vary depending on
the amount of rice.
Tips
• “BROWN” is cooked for approximately 1 hour and 20 minutes.
• Soak for two hours before using the function “BROWN”.
BROWN
1. Measure and wash rice
Measure the rice in the measuring cup
supplied with the product and wash the
rice well.
3. Cooking
Close the rice cooker lid and press the
“MENU” button.
Select the “PORRIDGE” function and
press the “START” button to enter the
cooking state. (Default time is 1 hour
and 30 minutes) After cooking, it
automatically enters the keep-warm
mode.
2. Add water
Add water with reference to the water
level of the Porridge on the right.
NOTE
• The water shall not exceed the highest scale line.
12
OPERATION INSTRUCTIONS
PORRIDGE
PORRIDGE
13
OPERATION INSTRUCTIONS
GRAINS
1. Measure and wash rice
Measure the rice in the measuring cup
supplied with the product and wash the
rice well.
3. Cooking
Close the rice cooker lid and press the
“MENU” button. Select the “GRAINS”
function and press the “START” button
to enter the cooking state. after about
1 hour and 10 minutes, you will hear a
di-beep, which indicates that cooking is
finished, and the cooker will
automatically enter the KEEP WARM
mode.
2. Add water
Add water with reference to the water
level of the RICE on the right.
NOTE
The cooking time will vary depending on
the amount of rice.
Tips
• “GRAINS” is cooked for approximately 1 hour and 10 minutes.
• Soak for two hours before using the function “GRAINS”.
GRAINS
14
OPERATION INSTRUCTIONS
MIXED
1. Measure and wash rice
Measure the rice in the measuring cup
supplied with the product and wash the
rice well.
3. Cooking
Close the lid and press the “MENU”
button Select the “MIXED” function and
press the “START” button to enter the
cooking state.After cooking for about
20 minutes, when the sound starts,
spread the marinated ingredients on
the rice, close the lid of the pot, and
wait patiently until the cooking is over
After about 40 minute, you will hear a
di-beep, which indicates that cooking is
finished, and the cooker will
automatically enter the keep warm
mode.
2. Add water
Add water with reference to the water
level of the RICE on the right.
NOTE
1.The cooking time will vary depending on
the amount of rice.
2.When adding rice, the maximum
amount should not exceed 2 cups.
3.Mixed rice needs to add cooking oil,
otherwise the cooking effect may not be
good.
MIXED
Mix the ingredients (such as spare ribs)
and the appropriate amount of ingredi-
ents (such as scallions, ginger, garlic,
soy sauce), and marinate the stirred
ingredients for a little time according
to personal taste.
15
OPERATION INSTRUCTIONS
STEAM
1. Add water
Add water with reference to the STEAM
water level.
2. Cook
Put the food in the steamer, then put
the steamer into the inner pot, close
the lid, press the MENU button and
select STEAM (30 minutes by default),
and finally press the “START” button
and the cooker will enter the cooking
state. When the cooking is finished, you
will hear five beeps, and the cooker
automatically enters into the KEEP
WARM mode.
STEAM
3. Press the “MENU” button to select the
“SOUP” function, and press the “START”
button to enter the cooking state.
(Cooking time is approximately 2 hours)
SOUP
SOUP
1. Prepare the ingredients
Wash the ingredients, cut them into
pieces and put in the inner pot.
2. Add water
Add water according to personal
preference, not exceeding the highest
scale line.
NOTE
1. The water shall not exceed the highest
scale line.
16
OPERATION INSTRUCTIONS
3. Press the “MENU” button to select the
“STEW” function, and press the “START”
button to enter the cooking state.
(Cooking time is approximately 2 hours)
1. Prepare the ingredients
Wash the ingredients (ribs, corn,
carrots), cut into small pieces and place
in the inner pot.
2. Add water
Add water according to personal
preference, not exceeding the highest
scale line.
STEW
STEW
17
OPERATION INSTRUCTIONS
KEEP WARM/CANCEL
1. During the cooking process, press the KEEP WARM/CANCEL button to cancel the
cooking process and enter standby mode.
Gentle Reminder:
1. After cooking, it will automatically trigger the heat preservation function;
2. During the process of warm keeping, the product will be heated to maintain the
temperature above 149 degrees Fahrenheit;
3. The product can keep warm for as long as 24-hour;
4. In order to maintain the food taste and appearance, the heat preservation time is
suggested within 5 hours.
18
Rice: When adding water, for QUICK RICE, BROWN, the water level line depends on the
water level line scale of the rice.
Porridge: Refer to the Porridge water line when adding water.
OPERATION INSTRUCTIONS
THE USE OF WATER LEVEL LINES
Maximum rice amount Minimum rice amount
4 cups 0.5 cup
Maximum rice amount Minimum rice amount
0.5 cup 0.25 cup
19
CLEANING AND MAINTENANCE
REMOVE THE COVER
REMOVE/INSTALL STEAM VALVE
Please disconnect the power supply before cleaning and maintenance
Press the white button in the
direction of the arrow to
remove the cover. (the cover
will tilt forward)
After cleaning and drying,
reinstall it in place.
Grasp the cover and lift it out.
Step 2
第一步
Step 1
Rotate " " to " " as
shown in the figure to
install it in place.
Assemble in order
Install clockwise
Install
Rotate " " to " " as shown
in the figure to disassemble.
Dissemble
20
CLEANING AND MAINTENANCE
CLEAN COOKER BODY
Wipe with a clean soft cloth
CLEAN INNER POT/STEAMER
Soak in clean water for 10 minutes to allow the remaining rice to fully absorb water and
then rinse
DRY
After cleaning, dry the inner pot and steamer
Note: After cleaning the inside of the cooker, be sure to dry it. Avoid turning on the
power when there is water.
Note: Do not use steel wool to clean the inner pot to avoid scratching the coating.
Possible reasons Solutions
Abnormal
situation
Too soft, too
hard, too thick,
too thin, not
cooked, burnt
rice, rice soup
overflowing and
insufficient
boiling
Peculiar smell,
discolouration
and dry during
heat preservation
Abnormal noise
in the working
process
• Not adding water according to
the water level line
• Wrong selection of the
function
• There is foreign matter on
heating plate
• No proper installation of the
steam valve
• Deformation of inner pot
• The sealing ring and the edge
of the inner pot are mixed
with foreign matters
• Product air leakage
• Too long warm preservation
time
• Water on the inner pot has
not been dried
• The sound of the lid snapping
shut when turning on or off
the rice cooker
• Remove the foreign objects
• Contact customer service
center to replace the sealing
ring
• It is recommended that the
heat preservation shall be
within 5 hours
• Dry the water on the inner
pot before using
• Normal phenomenon
• Add water according to the
water level line
• Select the corresponding
function
• Remove foreign matters on
the heating plate and cook
again
• Steam valve is installed in
place
• Contact customer replace the
inner pot
TROUBLESHOOTING
Operation of your appliance can lead to errors and malfunctions. The following tables
contain possible causes and notes for resolving an error message or malfunction. It is
recommended to read the tables carefully below in order to save your time and money
that may cost for calling to the service center.
21
22
TROUBLESHOOTING
Indicat
or state
Abnormal
display
Possible
Reason
Solutions
Pull out and re-connect the
power cord, the display still
shows same message, please
send the cooker to your local
after-sales service centre for
maintenance.
Communication errorFlash
Light on
Main thermistor (bottom
sensor) open circuit
E1
Light on
Main thermistor (bottom
sensor) short circuit
E2
Light on
Top lid sensor (handle
thermistor) open circuit
E5
Light on
Top lid sensor (handle
thermistor) short circuit
E6
Communication errorLight on EU
EU
1 YEAR LIMITED WARRANTY
This is the only express warranty for this product and is in lieu of
any other warranty or condition. This product is warranted to be
free from defects in material and workmanship for a period of one
(1) year from the date of original purchase. During this period, your
exclusive remedy is repair or replacement of this product or any
component found to be defective, at our option; however, you are
responsible for all costs associated with returning the product to
us and our returning the product or component under this war-
ranty to you. If the product or component is no longer available,
we will replace with a similar one of equal or greater value.
This warranty does not cover wear from normal use, and
operation doesn't conformity with the instruction manuals, or
damages to the product resulting from accident, alteration,
abuse, or misuse. This warranty extends only to the original
consumer purchaser or gift recipient. Keep the original sales
receipt, as proof of purchase is required to make a warranty claim.
This warranty is void if products is used for other than single-
family household use or subjected to any voltage and waveform
other than as specified on the label.
We exclude all claims for special, incidental, and consequential
damages by breach of express or implied warranty. All liability is
limited to amount of the purchase price. Every implied warranty,
including any statutory warranty or condition of merchant-ability
or fitness for particular purpose, is disclaimed except to the extent
prohibited by law, in which case such warranty or condition is
limited to the duration of this written warranty.
This warranty gives you specific legal rights. You may have other
legal rights that vary depending on where you live. Some states or
provinces do not allow limitations on implied warranties or special,
incidental consequential damages, so the foregoing limitations
may not apply to you. Please note that failure to complete and
submit this form does not diminish your warranty
SERVICE AND SUPPORT
23
In the Event of a warranty period claim,
question, comments or if service is required
for this product, please contact us at the
following:
Customer Service Management Office:
Parsippany, NJ 07054
Toll Free: 1-866-646-4332
Amazon Store:
https://www.amazon.com/comfee
Tel: 866-646-4332
E-mail: offi[email protected]
Made in China
SERVICE AND SUPPORT
24
