48-22-2113
11 in 1 SCREWDRIVER / NUT DRIVER
Aug. 2014
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 48-22-2113 11 in 1 Screwdriver / Nut Driver (1)
3 45-76-0050 5/16" - 3/8" Nut Driver (1)
5 50-32-0200 PH2 - 1/4" Flat Blade Double Ended Bit (1)
6 50-32-0205 PH1 - 3/16" Flat Blade Double Ended Bit (1)
7 50-32-0215 #1 - #2 ECX Double Ended Bit (1)
8 50-66-4605 1/4" Nut Driver and Shank (1)
50-32-0220 #1, #2 Square Drive Bit - Optional (Not Shown) (1)
54-49-3105
REVISED BULLETIN
SERVICE PARTS LIST
BULLETIN NO.
WIRING INSTRUCTION
DATE
CATALOG NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
SERIAL
NUMBER
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 3
EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
0
00
8
7
3
5
6
3 5 6
7 8
1
10
11
1
2
3
4
5
6
7
8
9
10
11
1
2
3
4
5
6
7
8
9
PH1
3/16” Flat
PH2
1/4” Flat
#1 ECX
#2 ECX
1/4” Nut Driver
5/16” Nut Driver
3/8” Nut Driver
Loop Maker (Bend up to 12 gauge wire)
Wire Stripper (Strip up to 12 gauge wire)
11 IN 1 SCREWDRIVER / NUT DRIVER
Bit storage
in the
Nut Driver
