5
Product Overview
1. Hand Vacuum Assembly
2. Power Trigger
3. Battery
4. Battery Release Button
5. Dirt Tank Release Button
6. Dirt Tank Lid Button
7. Wand Release Button
8. Extension Wand
9. Foot Release Button
10. Motorized Foot
11. Brush Roll Release
Important Safety Instructions ...................................... 2
Assembly .................................................................................... 3
Charging the Battery..........................................................4
Using Your Vacuum ............................................................. 5
Attaching Tools for Hand Vac Use............................ 5
Emptying the Dirt Tank.....................................................6
Cleaning & Replacing the Filter ................................... 6
Maintaining the Brush Roll ...............................................7
Troubleshooting ..................................................................... 8
Warranty ..................................................................................... 8
1
8
2
3
10
7
6
9
11
CLEANVIEW XR
®
(PET)
POWERLIFTER
™
TURBO (PET)
STICK VACUUM
SERIES 3789, 3797
4
Meet your new BISSELL® product!
Go to support.BISSELL.com for a walkthrough of your new purchase,
including videos, tips, support, and more. Want to get started right
away? This guide has all the information you need to set up your new
product. Let’s take a look...
2 BISSELL.com
IMPORTANT SAFETY INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
• Risk of injury from moving parts. Brush may start unexpectedly. Turn OFF
before cleaning or servicing.
• Do not charge the battery outdoors.
• Do not dismantle, open or shred battery pack. Do not subject battery pack to
mechanical shock. Dispose of used batteries promptly and properly.
• Do not turn your vacuum ON until you are familiar with all instructions and
operating procedures.
• If the vacuum is to be stored unused for a long period, the batteries should
be removed.
• Do not remove battery from its original packaging until required for use.
• The battery must be removed from the appliance before it is scrapped.
• Dispose of used batteries promptly.
• The battery is to be disposed of safely.
• Keep appliance on a level surface.
• Do not use appliance in an enclosed space filled with vapors given off by
oil-based paint, paint thinner, some moth-proofing substances, flammable
dust, or other explosive or toxic vapors.
• Do not use to pick up toxic material (chorine bleach, ammonia, drain cleaner,
etc.)
• Do not pick up hard or sharp objects such as glass, nails, screws, coins, etc.
• Plastic film can be dangerous. To avoid danger of suffocation, keep away
from children.
• Do not use the appliance outdoors or on wet surfaces.
• Do not charge the appliance outdoors.
• Do not allow appliances to be used as a toy. Paying close attention is
necessary when used by or near children.
• Use only as described in this manual. Use only manufacturer’s
recommended attachments.
• Do not handle the battery or the appliance with wet hands.
• Do not put any object into openings. Do not use with any opening blocked;
keep free of dust, lint, hair, and anything that may reduce air flow.
• Keep hair, loose clothing, fingers and all body parts away from openings
and moving parts.
• Use extra care when cleaning on stairs.
• Do not use to pick up flammable or combustible liquids, such as petroleum,
or use in areas where they may be present.
• Never allow children to operate the appliance. Adults should not operate the
appliance without proper instruction.
• Do not use appliance that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior resulting in fire, explosion or
risk of injury.
• Do not use to pick up flammable or combustible liquids, such as gasoline, or
use in areas where they may be present.
• Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
• Do not use without dirt tank, filter in place (if applicable).
• Do not use charger with damaged cord or plug. If appliance is not working
as it should, has been dropped, damaged, left outdoors, or dropped into
water, return it to a service center.
• Do not pull or carry charger by cable, use cable as a handle, close door on
cable, or pull cable around sharp edges or corners.
• Keep charger cable away from heated surfaces.
• Turn off all controls before removing the battery pack.
• Always turn off this appliance before connecting or disconnecting either
accessories.
• To reduce the risk of fire or electric shock, use appliance only with BISSELL®
identical parts and charger cords. If cord is damaged or lost, replace with
identical replacement part.
• Follow all charging instructions and do not charge the battery pack or
appliance outside of the temperature range specific in the instructions.
Charging improperly or at temperatures outside of the specific range may
damage the battery and increase the risk of fire.
• Do not modify or attempt to repair the appliance or the battery pack (as
applicable) except as indicated in the instructions for use and care.
• Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to battery pack, picking up or carrying the appliance. Carry the
appliance with your finger on the switch or energize appliance that have the
switch on invites accidents.
• Recharge only with the charger specified by the manufacturer. A charger
that is suitable for one type of battery pack may create a risk of fire when
used with another battery pack.
• Use only the charger supplied by the manufacturer to recharge: CAM811
• Use appliances only with specifically designated battery packs. Use of any
other battery packs may create a risk of injury and fire.
• Disconnect the battery pack from the appliance before making any
adjustments, changing accessories, or storing the appliance. Such preventive
safety measures reduce the risk of starting the appliance accidentally.
• When battery pack is not in use, keep it away from other metal objects
like paper clips, coins, keys, nails, screws or other small metal objects that
can make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts
eyes, immediately seek medical attention. Liquid ejected from the battery
may cause irritation or burns.
• Do not incinerate the appliance even if it is severely damaged. The batteries
can explode in a fire.
• Do not use a battery pack or appliance that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
• Do not expose a battery pack or appliance to fire or excessive temperature.
Exposure to fire or temperature above 265°F (130°C) may cause an
explosion.
• Unit should only be serviced by a qualified repair technician using only
BISSELL replacement parts. This will prolong the life of the unit and maintain
product safety.
• Don’t modify or attempt to repair the appliance or the battery pack (as
applicable) except as indicated in the instructions for use and care.
• Follow all charging instructions and do not charge the battery pack or
appliance outside of the temperature range specified in the instructions.
Charging improperly or at temperatures outside of the specified range may
damage the battery and increase the risk of fire.
• Do not unplug by pulling on cord. To unplug, grasp the charger, not the cord.
• Keep battery pack or appliance out of reach of children.
• Use only BISSELL battery pack 1638019 or 1635764.
• Use only TEN PAO charger CAM811.
• The recommended ambient temperature range:
Item Temperature
Vacuum storage temperature range 32°F (0°C) - 113°F (45°C)
Vacuum operation temperature range 32°F (0°C) - 113°F (45°C)
Battery charging temperature range 39°F (4°C) - 104°F (40°C)
Charger operation temperature range 39°F (4°C) - 104°F (40°C)
Battery storage temperature range 32°F (0°C) - 113°F (45°C)
Battery discharging temperature range 32°F (0°C) - 113°F (45°C)
READ ALL INSTRUCTIONS BEFORE USING YOUR APPLIANCE.
When using an electrical appliance, basic precautions should be observed, including the following:
BISSELL.com 3
SAVE THESE INSTRUCTIONS
THIS MODEL IS FOR HOUSEHOLD USE ONLY. COMMERCIAL USE OF THIS UNIT VOIDS THE MANUFACTURER’S WARRANTY.
WARNING
This product contains Lithium-Ion rechargeable batteries. DO NOT mix Lithium-Ion batteries with general household waste.
According to Federal and State regulations, removal and proper disposal of Lithium-Ion batteries is required.
For specific battery disposal instructions please contact Call2Recycle at 877-723-1297 or visit www.call2recycle.org.
For full instructions on battery removal for recycling visit support.BISSELL.com.
Assembly
1. Connect the
extension wand to the
motorized foot until it
clicks into place.
2. Connect the hand
vacuum assembly to
the extension wand
until it clicks into
place.
3. Attach tool clip to
extension wand and
add desired tools
4. Make sure to
charge your stick
vacuum before first
use.
SUPPLIER’S DECLARATION OF CONFORMITY 47 CRF SECTION 2.1077 COMPLIANCE INFORMATION Charger adapter for BISSELL product.
CONTACT: BISSELL Homecare Inc., 2345 Walker Ave. NW, Grand Rapids, MI 49544. This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation. Caution: Any changes or
modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more
of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and
receiver. (3) Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. (4) Consult the
dealer or an experienced radio/TV technician for help.
4 BISSELL.com
Charging with the Charging Station
1. Turn off vacuum and press/
hold battery release button
to remove battery from its
compartment.
2. Slide battery into charging
dock until it clicks into place.
3. Plug charger into wall.
4. Slide out to remove battery
from charger
5. Align grooves on battery
with grooves of battery
compartment.
6. Guide battery into
compartment until it clicks
into place.
Charging with the Wall Mount & Charging Station
1. Turn vacuum OFF and
press/hold battery release
button.
2. Insert battery into wall
mount charger until it clicks.
3. Lift up battery to remove
from wall mount charger
Charging the Battery
BISSELL.com 5
Using Your Vacuum
This vacuum can be used as a stick vacuum, hand vacuum, or extended reach with a hand vacuum
and wand.
1. Press trigger to start
machine. The machine starts
in Medium mode.
Press trigger again to stop
machine.
2. Press + or – on the screen to adjust the power mode.
This machine has three modes.
• Standard For quiet operation and long runtime on hard floors
••Medium For balanced power and runtime when cleaning
carpet and area rugs (this is the default mode when turning on
vacuum)
•••TURBO For maximum suction power
Note: The run time and power of batteries vary for each model. Choose the appropriate cleaning
mode for your task and surface type, as this affects run time and power. Use TURBO mode sparingly
to preserve battery life.
Attaching Tools for Hand Vac Use
Clean stairs or furniture easily with the tools provided. Pair your desired tool with the hand vacuum
or extension wand. Tools vary by model.
1. Turn OFF. Press release
button on extension wand or
accessories to remove.
2. Attach your chosen tool. 3. Use tool to clean furniture,
stairs or other surfaces in your
home.
6 BISSELL.com
Emptying the Dirt Tank
1. Power OFF. Press release
button on hand vacuum to
unlock the dirt tank.
2. Twist dirt tank
counterclockwise to unlock
and remove.
3. Press button on front of dirt
tank. Dump debris into a waste
basket.
Cleaning & Replacing the Filter
1. Power OFF. Follow steps
above to remove dirt tank.
2. Use metal handle to remove
filter assembly.
3. Twist filter cup
counterclockwise to remove.
4. Tap filter against side of
trash bin to remove debris.
5. Rinse under warm water. 6. Let dry for 24 hours before
reinstalling.
BISSELL.com 7
Maintaining the Brush Roll
1. Power OFF. Release foot
from extension wand and lay
with brush roll face-up. Push
foot release button on bottom
of foot and lift side plate.
2. Remove brush roll and clear
any debris.
3. Optional: Rinse brush
roll with warm water and
let dry for 24 hours before
reinstalling.
4. Wipe out brush roll
chamber with a cloth.
5. To reinstall brush roll, press
button at end of brush roll in
and guide into motorized foot.
Note: Any other maintenance or servicing not included in this manual should be performed by an
authorized service representative.
8
Problem Possible Cause Remedies
Machine won’t
turn ON
Battery power is low. Fully charge battery.
Dust
discharges
from the
exhaust
Filter is damaged. Replace filter.
Filter is incorrectly installed. Remove and reinstall filter.
Filter is dirty. Clean or replace filter.
Loss of suction
Filter is clogged. Clean or replace filter.
Dirt tank is full. Empty tank.
Blinking Error
Lights
Various reasons
Turn machine OFF and allow to cool before
turning back on. If this does not work, contact
BISSELL Support.
Troubleshooting
Warranty
Limited 2-year warranty, may vary by state. Visit support.BISSELL.com or call 1-800-237-7691 for
complete warranty information.
Terms and Conditions
Your purchase is subject to the BISSELL Terms and Conditions, which includes dispute resolution
through arbitration and class waiver. For complete terms or to opt out from arbitration or class waiver,
visit BISSELL.com/terms-of-use or call 1-800-237-7691.
©2024 BISSELL Inc. All rights reserved.
Part Number 1643042 04/24 v4
Every Purchase Saves Pets
™
BISSELL proudly supports BISSELL Pet Foundation®
and its mission to help save homeless pets. When you
buy a BISSELL® product, you help save pets, too. We’re
proud to design products that help make pet messes,
odors and pet homelessness disappear.
Visit BISSELLsavespets.com to learn more.
