FA300 Series
OWNER’S GUIDE
FlexBreeze™
Pro Mist Fan
IMPORTANT SAFETY INSTRUCTIONS
SUITABLE FOR OUTDOOR USE & HOUSEHOLD USE ONLY.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY: READ ALL THESE INSTRUCTIONS BEFORE USE.
The misting accessory is suitable for OUTDOOR USE ONLY.
DO NOT attempt to mist indoors as this could cause slippery conditions or water damage.
1. This appliance is operated by a rechargeable battery. ONLY recharge the battery
with the charger supplied with the unit, battery charger for use only with model
GQ36-120300-AUO power supply from Dongguan Gangqi Electronics Co., Ltd.
or with model AJJ3-1 from Anlian. A charger that may be suitable for one type of
battery may create a risk of fire when used with another battery.
2. Do not attempt to destroy, remove, or disassemble the battery pack from the
machine. Do not incinerate battery cells. Consult your local waste authority for
information regarding available recycling and/or disposal options.
3. To reduce the risk of an electric shock, connect only to an outlet provided with a
ground fault circuit interrupting (GFCI) device.
4. The fan should be used on a stable and level surface.
5. Never use this fan near pools, bathtubs, showers, basins, or other vessels
containing water.
6. Do not operate any unit with a damaged power supply wire or battery charger.
Discard the unit or return to an authorized service facility for examination and/or
repair.
7. Do not run cord under carpeting. Do not cover charge cord with throw rugs,
runners, or similar coverings. Do not route charger cord under furniture or
appliances. Keep charger cord away from high-trac areas. Place charger in an
area where the cord will not be tripped over.
8. If the charger cord is damaged, it should be replaced.
9. This appliance is not intended for use by anyone (including children) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
10. Children should be supervised to ensure that they do not play with the appliance.
11. Cleaning and user maintenance shall not be made by children without
supervision.
12. Prior to cleaning or other maintenance, the appliance must be unplugged from
the electrical outlet.
13. Only use Shark branded accessories.
14. Do not use if appliance is not working as it should, or has been dropped,
damaged, left outdoors for extended periods of time in poor weather without the
protective cover applied or dropped into water.
15. Turn o all controls before plugging in or unplugging the appliance.
16. Unplug from electrical outlet when not in use and before any maintenance or
cleaning.
17. Hand wash exterior/hard plastic/non-electronic parts with water only.
Do not immerse. Cleaning with chemicals could damage the unit.
18. Do not attempt to repair or adjust any electrical or mechanical functions of this
appliance, as this may cause danger and void the warranty.
19. Remove and immediately recycle or dispose of used batteries according to
local regulations and keep away from children. Do not dispose of batteries in
household waste or incinerate.
20. Even used batteries may cause severe injury or death.
21. Call a local poison control center for treatment information.
22. Non-rechargeable batteries are not to be recharged.
23. Do not force discharge, recharge, disassemble, heat above 140°F (60°C) or
incinerate. Doing so may result in injury due to venting, leakage, or explosion
resulting in chemical burns.
24. Ensure the batteries are installed correctly according to polarity (+ and -).
25. Do not mix old and new batteries, dierent brands or types of batteries, such as
alkaline, carbon-zinc, or rechargeable batteries.
26. Remove and immediately recycle or dispose of batteries from equipment not
used for an extended period of time according to local regulations.
27. Always completely secure the battery compartment. If the battery compartment
does not close securely, stop using the product, remove the batteries, and keep
them away from children.
28. Never attempt to mist substances other than filtered or clean tap water. Do not
use warm or hot water. Only use cold or room temperature water.
29. Do not handle live electrical products while in range of the misting stream.
30. Keep non-waterproof electronic equipment and appliances out of the misting
stream.
31. WARNING: CHOKING HAZARD. Always keep nozzles and any other small parts
out of the reach of children.
32. Do not apply any fragrance or scented products onto any part of the fan during
use or maintenance.
33. Always follow the warning information on the batteries and in the manuals of devices.
34. Only use the recommended battery types.
35. Keep batteries away from children.
36. Unpacked batteries shall not lie about in bulk.
37. In case of battery change always replace all batteries with new ones of identical
type and brand.
38. Do not swallow batteries.
39. Do not throw batteries into water.
40. Do not throw batteries into fire.
41. Avoid deep discharge.
42. Do not short-circuit batteries.
43. Use recommended charging time and current.
44. Do not open or disassemble batteries.
45. Do not expose the remote to long periods of rain or moisture.
46. Do not direct mist toward electrical wiring or devices.
COIN CELL BATTERY REMOTE MODELS
1. This appliance comes with a remote control which contains a coin cell battery.
Dispose of batteries properly. Always keep batteries away from children (choke
hazard). Even used batteries can cause injury.
2. Compatible battery type is CR2025.
3. The nominal battery voltage is 3V.
AAA BATTERY REMOTE MODELS
1. This appliance comes with a remote control which is suitable for 2 AAA batteries.
Dispose of batteries properly. Always keep batteries away from children (choke
hazard). Even used batteries can cause injury.
2. Compatible battery type is AAA.
3. The nominal battery voltage is 1.5V.
WARNING: Not suitable for use with solid-state
speed controls.
LITHIUM BATTERY SAFETY WARNINGS
LITHIUM BATTERIES STORE A LARGE AMOUNT OF ENERGY
AND WILL VENT FIRE OR EXPLODE IF MISTREATED.
1. DO NOT DO ANY OF THE FOLLOWING TO THE BATTERY PACK:
a. Open d. Puncture
b. Drop e. Incinerate
c. Short-circuit f. Expose to temperatures
2. Keep battery pack dry.
3. Charge battery pack only according to its charger's instructions.
4. Inspect battery pack before every use: do not use or charge
if damaged.
BATTERY REMOVAL AND DISPOSAL
This product contains an integral lithium battery (not replaceable), and the remote
control uses a lithium coin battery (replaceable) or 2 AAA batteries (replaceable).
When the remote batteries no longer have charge, they should be removed from the
remote and recycled. DO NOT incinerate or compost the product with its integral
battery or the remote batteries. When your remote battery needs to be replaced,
dispose of it or recycle it in accordance with local ordinances or regulations. In some
areas, it is illegal to place spent lithium batteries in the rubbish or in a municipal
solid waste stream. Return spent batteries to an authorized recycling center or to
retailer for recycling. Contact your local recycling center for information on where to
drop o the spent battery.
POWER SUPPLY SAFETY
1. Read and follow all instructions that are on the product
or provided with the product.
2. Do not use an extension cord.
3. Do not use within 10 feet of pool and do not use in
a bathroom.
4. WARNING: Risk of Electric Shock. When used outdoors, install only to a
covered Class A GFCI protected receptacle that is weatherproof with the power
unit connected to the receptacle. If one is not provided, contact a qualified
electrician for proper installation. Ensure that the power unit and cord do not
interfere with closing the receptacle cover.
FCC WARNINGS
Note: This equipment has been tested and complies with the limits for a Class B
digital device - pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy,
and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
To see if this equipment interferes with radio or television reception, try turning the
equipment o and on.
To correct any interference:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to a dierent outlet than the receiver.
• Consult the dealer or an experienced technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to two
conditions:
1. This device may not cause harmful interference, and
2. this device must accept any interference received, including interference that
may cause undesired operation.
Caution: Any changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
IC statement:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause
undesired operation of the device.
READ AND SAVE THESE INSTRUCTIONS
WARNING
• INGESTION HAZARD: This
product contains a button cell
or coin battery.
• DEATH or serious injury can occur
if ingested.
• A swallowed button cell or coin
battery can cause Internal Chemical
Burns in as little as 2 hours.
• KEEP new and used batteries
OUT OF REACH of CHILDREN.
• Seek immediate medical attention
if a battery is suspected to be
swallowed or inserted inside
any part of the body.
NOTE: Before every use, empty and rinse the
misting hose and water tank to prevent
stagnant water from being misted.
CAR CHARGER
FAN COVER
INSTRUCTIONS FOR USE:
1. Firmly insert the car charger plug into a 12-volt outlet
in your vehicle.
2. Insert the charger connector into the charging
port on the underside of the fan head, between
the 4 support legs.
INSTRUCTIONS FOR USE:
1. Position the cover over fan head, then slide it on until the fan
is completely covered.
2. Cinch the drawstring on the bottom of the cover to secure it
in place.
1.
2.
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
1. SAVE THESE INSTRUCTIONS. This manual contains important safety
and operating instructions for battery charger model FA20XCAR
from Dongguan City Gangqi Electronics Co., Ltd.
2. Before using this battery charger, read all instructions and cautionary
markings on the battery charger, battery, and product using battery.
3. CAUTION: To reduce risk of injury, charge only the provided
rechargeable battery.
Other types of batteries may burst, causing injury to persons and damage.
4. Do not expose charger to rain, moisture, or snow.
5. Use of an attachment not recommended or sold by the battery
charger manufacturer may result in a risk of fire, electric shock, or
injury to persons.
6. To reduce risk of damage to cigarette lighter connector and cord,
pull by cigarette lighter connector rather than cord when
disconnecting charger.
7. To reduce risk of electric shock, unplug charger before attempting any
maintenance or cleaning. Turning off controls will not reduce this risk.
8. Do not operate charger with damaged cord or cigarette lighter
connector. Replace it immediately.
9. The car charger may be wiped clean with water once removed from
the power socket. Allow car charger to fully dry prior to use.
10. The car charger contains a 5-amp replaceable fuse. Only replace the
fuse with a 5-amp fuse, no higher. To do so, unscrew the chrome knob
at the top end of the car charging port to access the fuse.
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
1. SAVE THESE INSTRUCTIONS. This manual contains important safety
and operating instructions for battery charger model FA20XCAR
from Dongguan City Gangqi Electronics Co., Ltd.
2. Before using this battery charger, read all instructions and cautionary
markings on the battery charger, battery, and product using battery.
3. CAUTION: To reduce risk of injury, charge only the provided
rechargeable battery.
Other types of batteries may burst, causing injury to persons and damage.
4. Do not expose charger to rain, moisture, or snow.
5. Use of an attachment not recommended or sold by the battery
charger manufacturer may result in a risk of fire, electric shock, or
injury to persons.
6. To reduce risk of damage to cigarette lighter connector and cord,
pull by cigarette lighter connector rather than cord when
disconnecting charger.
7. To reduce risk of electric shock, unplug charger before attempting any
maintenance or cleaning. Turning off controls will not reduce this risk.
8. Do not operate charger with damaged cord or cigarette lighter
connector. Replace it immediately.
9. The car charger may be wiped clean with water once removed from
the power socket. Allow car charger to fully dry prior to use.
10. The car charger contains a 5-amp replaceable fuse. Only replace the
fuse with a 5-amp fuse, no higher. To do so, unscrew the chrome knob
at the top end of the car charging port to access the fuse.
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
1. WARNING: CHOKING HAZARD. The fan cover is not a
toy. Always keep small parts out of reach of children.
2. Children should be supervised to ensure that they
DO NOT play with the fan cover as it may become
unsanitary during outdoor use.
1.
2.
Fan Head
(already assembled)
WHAT’S INCLUDED
Remote Charger
(reference image only)
Misting Hose
Pole
Base Water Tank
ACCESSORIES AVAILABLE FOR PURCHASE
Bolt
Allen Wrench
Note: Images enlarged for clarity.
Dierent fan models come with dierent accessories. To purchase an accessory that was not included, go to sharkclean.com.
Garden Hose
Adapter Travel Tank
Bucket Filter Adapter
Car Charger Fan Cover Travel Bag Base Cover
ASSEMBLING YOUR FAN
COIN CELL BATTERY REMOTE MODELS
Remove the battery saver paper from
the remote.
AAA BATTERY REMOTE MODELS
1. Slide the battery cover o the rear side of the remote.
2. Place the 2 AAA batteries in the remote - ensure that
the batteries are placed in the remote with the correct
polarity ( + and - ).
3. Replace the battery cover by sliding it into the remote.
CHARGING THE FAN
PEDESTAL MODE: To charge the fan in
pedestal mode, insert the CHARGER into the
charging port near the bottom of the POLE.
TABLETOP MODE: To charge the fan in tabletop mode, insert the charger into
the charging port under the center shaft of the fan, between the 4 support
legs. DO NOT CHARGE OR USE IN THE RAIN.
4 5 6
Charging port
labeled with
.
1 A
B
Upper pole
The upper pole
has wider end.
Align yellow arrow on
bottom of pole with
yellow dot on base
2
3
Rotate clockwise to
tighten the bolt.
Note: Images enlarged
for clarity.
1. Align and insert
the Upper Pole
into the Lower
Pole until it clicks
into place.
2. Align the yellow
dot on the
assembled pole
with the yellow
arrow on the
Base, then slide
the pole down
onto the base.
Ensure that the
pole is fully against
the base before
proceeding.
3. Turn the base on its
side, then insert the
Bolt in the bottom
of the base. Use
the Allen Wrench
to turn the bolt
clockwise to
fasten it to the
assembled pole.
4. CAUTION: finger
pinch risk. Holding
the Fan Head
by the handle,
insert the legs
into the top of the
assembled pole
until they click
into place.
5. Holding the
Water Tank by
the handle, align
the rear of the tank
against the pole
and slide down to
latch into place.
6. Charge fan to
100% battery
power before use
without the cord.
First use: before
using remote
control, press
Power Button on
fan. Fan is operable
while charging.
8 9
7. Connect the
Misting Hose to
the back of the
water tank and
rotate clockwise
to lock it in place.
8. Connect the other
end of the misting
hose to the back
of the fan head
and rotate
counterclockwise
to lock it in place.
9. Tuck the rest of the
misting hose into
the channel and
clamp it onto the
back of the pole.
7
FEATURES
CORDLESS
BREEZEBOOST™ & NATURALBREEZE
OSCILLATION & TILT
OUTDOORS
OUTDOOR MISTING
REMOTE STORAGE
This is a 2-in-1 fan that can be
used with or without the cord.
Activate the extra-powerful
BreezeBoost for maximum-
strength airflow, or use one of
the NaturalBreeze modes to
simulate wind conditions.
Direct the airflow by choosing
between 3 electronic oscillation
angles and manually adjusting
the vertical tilt up to 55° degrees.
This fan can be enjoyed indoors
or outdoors.
DO NOT CHARGE OR USE IN
THE RAIN
Integrated misting enabled
through a portable water
tank, 2 misting nozzles, and 3
misting modes.
The misting feature is suitable
for OUTDOOR USE ONLY.
You can store the remote on the
convenient magnetic mount on
back of the fan head.
BATTERY LIFE – FAN ONLY
BATTERY LIFE – FAN + MIST
Settings Approx. Runtime
Fan Speed 1 24 hours
Fan Speed 1 + Oscillation 10 hours
Fan Speed 2 14 hours
Fan Speed 2 + Oscillation 8.5 hours
Fan Speed 3 6 hours
Fan Speed 3 + Oscillation 4.5 hours
Fan Speed 4 3 hours
Fan Speed 4 + Oscillation 2.5 hours
Settings Approx. Runtime
Fan Speed 1 12 hours
Fan Speed 1 + Oscillation 8.5 hours
Fan Speed 2 8.5 hours
Fan Speed 2 + Oscillation 6 hours
Fan Speed 3 4.5 hours
Fan Speed 3 + Oscillation 4 hours
Fan Speed 4 2.5 hours
Fan Speed 4 + Oscillation 2.5 hours
HOW TO USE YOUR FAN
Fan
Speeds
Press
on the fan head or < > arrows on the remote to switch between fan speeds. LED lights
will indicate selected fan speed.
BreezeBoost™
Mode
For maximum-strength airflow, press
on the remote or on the fan head again.
During cordless use, fan speed will automatically decrease after 20 minutes to save
battery power.
NaturalBreeze
Modes
To activate STRONG breeze mode, press
once on the REMOTE, or press on
the fan head an additional time.
To activate GENTLE breeze mode, press
a second time on the REMOTE, or press
on the fan an additional time.
Oscillation
Settings
Press
on the fan head or < > arrows on the remote to toggle between oscillation settings.
LED lights will indicate which setting is selected.
Horizontal
Angle Adjust
Press the <
> arrows on the remote to change the horizontal angle of the fan in 18° increments.
Misting
Settings
1-3
Press
once to turn on high-pressure consistent mist. Press a second time to
switch to low-pressure consistent mist. Press
a third time to switch to
low-pressure interval mist.
Runtime
Fan ONLY
MAXIMUM CORDLESS RUNTIME: 24 hours on fan speed 1.
AVERAGE CORDLESS RUNTIME: 6.0 hours on fan speed 3.
MAXIMUM CORDLESS PERFORMANCE: 2.0 hours on fan speed 5.
PLUGGED IN: Indefinite runtime; fan will charge while operating.
Fan + Misting
MAXIMUM MISTING RUNTIME: 16-hour high-pressure consistent misting on fan speed 1
(refilling the water tank every hour).
AVERAGE MISTING RUNTIME: 4-hour high-pressure consistent misting on fan speed 3
(refilling the water tank every hour).
MAXIMUM MISTING PERFORMANCE: 1-hour high-pressure consistent misting on fan
speed 5.
Charge
Time
FROM 0% TO FULLY CHARGED BATTERY: 5 to 6 hours
Battery
Indicator
70%-100 %: green light.
30%-69%: amber light.
6%-29%: red light steady.
5% and below: red light blinking.
To preserve battery life,
the fan will enter IDLE
mode if left unplugged
and powered o for
24 hours. In IDLE mode,
the remote cannot be used
to turn on the fan. To turn
o IDLE mode, press the
power button on top of
the fan head.
Settings Approx. Runtime
Fan Speed 5 2 hours
Fan Speed 5 + Oscillation 1.5 hours
BreezeBoost™ Mode 1.5 hours
BreezeBoost Mode + Oscillation 1.25 hours
Strong Breeze 3 hours
Strong Breeze + Oscillation 2.5 hours
Gentle Breeze 12 hours
Gentle Breeze + Oscillation 8 hours
Settings Approx. Runtime
Fan Speed 5 1.5 hours
Fan Speed 5 + Oscillation 1.5 hours
BreezeBoost™ Mode 1.25 hours
BreezeBoost Mode + Oscillation 1.25 hours
Strong Breeze 2.5 hours
Strong Breeze + Oscillation 2.5 hours
Gentle Breeze 8 hours
Gentle Breeze + Oscillation 6.5 hours
VERTICAL ADJUSTMENT
To adjust the vertical height of the fan head, use the handle to manually tilt the head up or down.
The fan has a vertical range of 55° degrees.
HOW TO CARRY YOUR FAN
• For short distances, carry the entire fan by placing one hand on the handle and the other on the pole.
Note: If the water tank is full, remove it before carrying the fan to avoid potential injury or accidental damage.
• For longer distances, disassemble the fan. Carry the fan head in tabletop mode separately from the base, pole, and
empty water tank. Note: Ensure you remove the misting hose from the back of the fan head before converting the fan
to tabletop mode to prevent accidental damage.
Fan head tilted UP Fan head tilted DOWN
TABLETOP MODE
To detach the fan head from
the pole, press the Lift-Away
button, then slide the fan
head off the pole.
Note: To avoid accidental damage to your fan, ensure the misting hose is disconnected from the back of the fan head before
converting to tabletop mode.
Spread out the four support
legs until they are fully
extended, then place the
fan head on a flat, level
surface to use.
Connect the misting hose to the water tank
and fan head while in tabletop mode for
misting on the go.
To convert the
fan to portable,
tabletop mode:
DISASSEMBLY
STORAGE
If grill screw, bolt, or Allen wrench have been lost, see Hardware Specs section for information on how to replace any hardware.
STORAGE TYPE INSTRUCTIONS
Short-term storage (less than 24 hours)
Remove, empty, and dry the misting hose and water tank. With the misting
hose and tank disconnected from the fan, run the misting system for 20
seconds to clear out any stagnant water remaining in the internal hose.
Carefully place the fan in the desired storage location. Ensure it is out of reach
of children and pets. Bring the fan indoors if inclement weather is predicted.
Long-term storage (more than 24 hours)
Remove, empty, and dry the misting hose and water tank. With the misting
hose and tank disconnected from the fan, run the misting system for 20
seconds to clear out any stagnant water remaining in the internal hose.
Carefully place the fan in the desired storage location. Store the fan indoors
when not in use for long periods. Always make sure to keep the fan out of
reach of children and pets.
9
9. Press the small button on
the Lower Pole to detach
the poles. Carefully fold as
needed for storage.
DO NOT strain the cord.
5
5. With the misting
hose fully removed,
press the Lift-Away
button on the side
of the pole, then lift
the Fan Head o
the pole.
6
6. Using the handle
located on the lid,
carefully lift the
Water Tank to
remove it from the
base.
1
Charging port
labeled with
.
1.
Ensure your fan is
unplugged before
disassembly. To
avoid accidental
damage, DO NOT
remove the charger
at an angle.
7. Turn the pedestal
Base on its side to
access the Bolt on
the bottom. Use
the included Allen
Wrench to rotate the
bolt counterclockwise,
then remove the bolt.
8
8. Carefully lift the
pole to remove it
from the base.
3
3. To detach the
misting hose
from the Fan
Head, rotate
the connector
clockwise.
2
2. Gently remove
the Misting Hose
from the channel
located on the
back of the Pole.
4
4. To detach the
other end of the
misting hose
from the Water
Tank, rotate
the connector
counterclockwise.
3
Rotate
counterclockwise
to loosen the bolt.
Note: Images enlarged
for clarity.
SETTINGS
REMOTE PAIRING INSTRUCTIONS
POWER ON/OFF
• Before first use, pull out the plastic tab from the battery compartment of the remote control.
• To preserve battery life, the fan will enter IDLE mode if left unplugged and powered o for 24 hours. In IDLE mode, the
remote cannot be used to turn on the fan. To turn o IDLE mode and turn on the power, press the power button on top
of the fan head.
• The LED lights on the fan head display will only remain illuminated for 20 seconds after a setting adjustment is made
before turning o to save battery.
• For information on how to activate or deactivate LOCK MODE for fan maintenance, please see the Maintenance section.
• Remote may be less eective when used outdoors.
Turn the unit on by pressing the power button on top of the fan head and check if the remote functions properly.
If the remote is not functioning, try the following:
1. Check to ensure the battery saver paper is removed from the remote (coin cell battery remote models). Check to ensure
the 2 AAA batteries are placed in the remote in the correct orientation (AAA battery remote models).
2. Try connecting the remote to the fan by pressing and holding the power button on the fan head for 5 seconds. While the
LEDs are flashing, press the fan speed up button on the remote.
3. If the remote still doesn’t work, then try replacing the batteries in the remote and repeat the connection process above.
POWER DISPLAY
ON
LED animations will play once
(LEDs will turn on from left to right, then turn o from right to left)
OFF
LED animation will play once
(LEDs will turn o from right to left)
To turn the fan on or o, press the POWER button on the remote or the POWER button on the fan head.
FAN SPEEDS
Changing the FAN SPEED will increase or decrease the airflow of the fan. The number of fan speeds varies by model, see
chart below for more details.
To change the speed, press
on the fan head to cycle through the dierent speeds. With the REMOTE, press the left
and right arrows to change speeds. The LEFT ARROW will DECREASE the speed of the fan and the RIGHT ARROW will
INCREASE the speed of the fan.
SPEED DISPLAY BEST FOR
1
Quiet operation
2
Moderate cooling
3
Balance of noise level
and fan power
4
Air circulation
5
High power cooling
BREEZEBOOST™ MODE
Turn on BreezeBoost for maximum-power airflow. When operating cordlessly, BreezeBoost will automatically turn o
after 20 minutes to save battery. BreezeBoost will run indefinitely when the fan is plugged in.
To activate BreezeBoost, press the
icon on the REMOTE or press the icon on the fan head 5 times. To deactivate
BreezeBoost press either of the buttons again.
DISPLAY SETTING BEST FOR
LED animation will repeat 5 times
(LEDs will turn on from left to right)
BreezeBoost
Maximizing
fan power
NATURALBREEZE MODES
Turn on either of the NaturalBreeze modes to simulate natural wind conditions.
To activate STRONG NaturalBreeze, press the
icon on the REMOTE or press the icon on the fan head until the
corresponding LEDs are displayed on the unit (see table below for LED patterns).
To transition from STRONG NaturalBreeze to GENTLE NaturalBreeze press the
icon on the REMOTE again,
or press the
icon on the fan head again.
To deactivate NaturalBreeze, press the
icon on the REMOTE to return to your previously selected fan speed or press
the
icon on the fan head until you reach your desired fan speed setting.
DISPLAY SETTING BEST FOR
STRONG
NaturalBreeze
Simulating
strong wind
conditions
GENTLE
NaturalBreeze
Simulating
gentle wind
conditions
NATURALBREEZE WIND PATTERNS
STRONG NaturalBreeze Mode GENTLE NaturalBreeze Mode
• 6 seconds in Speed 3
• 5 seconds in Speed 4
• 4 seconds in Speed 5
• 5 seconds in Speed 4
• The sequence will repeat
• 6 seconds in Speed 1
• 5 seconds in Speed 2
• 4 seconds in Speed 3
• 5 seconds in Speed 2
• The sequence will repeat
OSCILLATION
HORIZONTAL ANGLE ADJUST
Choose one of the 3 oscillation angles.
To change the oscillation settings, press the Oscillation
icon on the REMOTE or the fan head.
To turn o oscillation, press the same Oscillation
icon on the REMOTE or the fan head until no LEDs are illuminated.
You can use the remote control to change the horizontal angle of the fan from a distance.
Press the left or right arrows on the remote to adjust the horizontal angle.
DISPLAY ANGLE BEST FOR
45°
Circulating air in small area,
1-2 people
90°
Circulating air in moderate
area, 3-4 people
180°
Circulating air in large area,
5+ people
NOTE: The LEDs on the fan head will not illuminate when you use this feature.
OUTDOOR MISTING
The misting feature is suitable for OUTDOOR USE ONLY.
Choose between 3 misting settings to best suit your needs. To change the misting settings, press the Misting
icon on
the remote or the fan head to cycle through the settings.
To turn o misting, press the Misting
icon on the remote or the fan head until no LEDs are illuminated.
DISPLAY SETTING BEST FOR
High-Pressure
Consistent
Maximum
cooling power
Low-Pressure
Consistent
Balance of
cooling power
and misting
duration
Low-Pressure
Interval
Longest
misting duration
TROUBLESHOOTING AND FREQUENTLY ASKED QUESTIONS
GENERAL USE
Why is the mist too wet?
The misting feature is suitable for OUTDOOR USE ONLY. Do not
attempt to mist indoors as this could cause slippery conditions or
water damage.
The fan is equipped with 3 mist settings designed to provide varying
amounts of mist density. Press the misting
icon on either the
remote or fan head until you reach your desired setting.
Adjusting the speed of the fan can aect the intensity of the mist.
Try lowering the speed if the mist feels too wet.
Sometimes, standing too close to the fan can make the mist feel
wetter than it should. Try moving a few feet back and check if it
improves the mist experience.
Why is the remote not working?
When using the remote control, make sure it is pointed
directly at the LEDs on the front of the fan.
The fan may have entered IDLE mode. To preserve battery life, the fan will
enter IDLE mode if left unplugged and powered o for 24 hours. In IDLE
mode, the remote cannot be used to turn on the fan. To turn o IDLE mode
and turn on the power, press the power button on top of the fan head.
If your remote has lost its connection to the fan, you can easily
reconnect it. Press and hold the power button on the fan head for
5 seconds, then press the right fan speed button on the remote while
the LEDs on the fan head are flashing.
If the remote still doesn’t work, then try replacing the batteries
in the remote.
Why are the remote and UI
buttons not working?
Make sure the fan has battery power by pressing the Power button.
If the Battery LED indicator blinks red, then the fan needs to be
charged. When the fan is charging, the battery LED will blink green.
See the Battery Life and How To Use Your Fan sections for more
detailed information on runtimes and battery indicators.
If all the LEDs are flashing, the fan may be in Lock mode, which
deactivates the fan to allow you to safely maintain it. To turn o
Lock mode, press the Oscillation
icon on the fan and hold it
down for 8 seconds. When Lock mode is successfully deactivated,
the LEDs will display the Power On pattern. See the Maintenance
section for more information.
Why is the battery light flashing
red when I am trying to turn on
BreezeBoost™ mode?
If the battery level is low, BreezeBoost mode cannot be activated.
Charge the fan battery to use BreezeBoost.
Can I leave the fan outdoors?
This fan is water-resistant and will not be damaged by light rain.
However, it is not suitable to withstand heavy rain or water submersion.
Do not charge or use your fan in the rain.
Why is the fan rattling?
Ensure that the fan blade cap is fully installed before
operating the fan. Please see the Maintenance section
for more details.
The second LED indicator and
the Battery LED (in amber)
are flashing. What is wrong?
This error state indicates an issue with the voltage of the charger.
Please be sure to only use the provided Shark™ charging cable and
power supply.
MAINTENANCE
Why do I have to activate Lock mode
before maintenance?
The fan must be in Lock mode when any maintenance is performed.
Lock mode prevents the fan from accidentally powering on.
How often should I clean the fan?
We recommend cleaning the fan every 6 months or as needed.
How do I maintain
the misting hose?
Every 12 months, use a damp cloth to clean the rubber seals on both
ends of the misting hose to prevent buildup.
How often should I clean
the misting nozzles?
Clean the misting nozzles every 12 months or as needed. Using harder
water will require more frequent cleaning. See Maintenance section for
more information on cleaning misting nozzles.
Why isn’t my fan
misting eectively?
Ensure the misting hose is securely connected to the water tank and
fan head. See the Assembling Your Fan section for more information.
The misting hose and nozzles may clog if not maintained properly.
See the Maintenance section for details on cleaning instructions.
If the issue persists, the water tank filter may be clogged.
Visit sharkclean.com to order a replacement water tank filter.
MAINTENANCE
• LOCK MODE must be activated prior to performing maintenance. This will temporarily block all fan functions until
deactivated. Lock mode prevents the fan from accidentally powering on.
1 2 3 4
1. Turn on Lock mode before
performing maintenance
for safety. To activate, hold
down the OSCILLATION icon
on the Fan Head for
8 seconds until the LEDs
flash three times.
2. Place the fan upright on a
flat, level surface in tabletop
mode. Use the Phillips-head
end of the Allen wrench
to remove the screw at the
bottom of the Fan Grill. Set
screw aside.
3. Rotate the fan grill
counterclockwise to remove
it from the fan head. Set grill
aside.
4. Remove the Fan Blade Cap.
Hold the Fan Blades in place
while rotating the fan blade
cap clockwise to remove it
from the shaft.
Hold for 8 seconds
Lights will blink
three times when
Lock mode has
been activated
• We recommend cleaning the water tank and misting hose with unscented soap and water every 3 months or as needed.
Ensure you empty and dry the water tank and misting hose after every use.
• We recommend cleaning the misting nozzles every 12 months or as needed. Using harder water will require more
frequent cleaning. To clean the misting nozzles:
1. Carefully remove each brass nozzle. CAUTION: Residual pressure may remain in the misting system.
2. To remove a nozzle, twist it counterclockwise. DO NOT use a wrench or any other tool. WARNING: CHOKING
HAZARD. Keep nozzles out of the reach of children.
3. Soak the nozzles in a solution of undiluted distilled white vinegar (5% acetic acid by volume) to loosen debris
that may be clogging or restricting water flow. DO NOT soak the nozzles for more than 2 hours.
4. After soaking the nozzles in the solution, rinse them thoroughly with water.
5. Carefully reinstall each nozzle by twisting clockwise until you feel resistance.
• We recommend cleaning the fan every 6 months or as needed. If the grill screw, bolt, or Allen wrench have been lost,
see the Hardware Specs section for more information on how to replace any hardware.
5 86
9
7
5. Remove the fan blades by
gently pulling them out.
With a slightly damp cloth,
wipe down the interior parts
of the fan.
8. Rotate the fan grill
clockwise to secure it
to the fan head.
6. Carefully replace
the fan blades onto
the center shaft.
9. Place the fan upright on a
flat, level surface. Use the
Phillips-head end of your
Allen wrench to replace and
tighten the screw at the
bottom of the fan grill.
7. Reinstall the fan blade cap.
Hold the fan blades in place
while rotating the fan blade
cap counterclockwise to
reinstall it to the shaft.
10. Turn o Lock mode
by holding down the
OSCILLATION
icon
on the fan head for
8 seconds until the LEDs
display the Power On pattern.
10
Hold for 8 seconds
Lights will display
the Power On
pattern when
Lock mode has
been deactivated.
HARDWARE SPECS
Grill Screw
For securing the grill to the fan
Drive Type Phillips
Thread Size / Pitch M3 x 0.5mm
Length 16mm
Bolt
For securing base to pole
Drive Type Hex
Thread Size / Pitch M6 x 1mm
Length 85mm
Screwdriver
For driving the screw
Drive Type Phillips
Size No. 1
Allen Wrench
For driving the bolt
Drive Type Hex
Size 5mm
6mm
6mm
5mm
No.1
146 x 1mm
16mm
85mm
24mm
6mm
TWO (2) YEAR LIMITED WARRANTY
The Two (2) Year Limited Warranty applies to purchases made from
authorized retailers of SharkNinja Operating LLC. Warranty coverage
applies to the original owner and to the original product only and is
not transferable.
SharkNinja warrants that the unit shall be free from defects in material and
workmanship for a period of two (2) years from the date of purchase when
it is used under normal household conditions and maintained according to
the requirements outlined in the Owner’s Guide, subject to the following
conditions and exclusions:
What is covered by this warranty?
1. The original unit and/or non-wearable parts deemed defective, in
SharkNinja’s sole discretion, will be repaired or replaced up to two (2)
years from the original purchase date.
2. In the event a replacement unit is issued, the warranty coverage ends
six (6) months following the receipt date of the replacement unit or
the remainder of the existing warranty, whichever is later. SharkNinja
reserves the right to replace the unit with one of equal or greater value.
What is not covered by this warranty?
1. Normal wear and tear of wearable parts (such as batteries, etc.) which
require regular maintenance and/or replacement to ensure the proper
functioning of your unit, are not covered by this warranty. Replacement
parts are available for purchase at sharkaccessories.com.
2. Any unit that has been tampered with or used for commercial purposes.
3. Damage caused by misuse, abuse, negligent handling, failure to perform
required maintenance (e.g., not replacing the filters), or damage due to
mishandling in transit.
4. Consequential and incidental damages.
5. Defects caused by repair persons not authorized by SharkNinja. These
defects include damages caused in the process of shipping, altering, or
repairing the SharkNinja product (or any of its parts) when the repair is
performed by a repair person not authorized by SharkNinja.
6. Products purchased, used, or operated outside North America.
How to get service
If your appliance fails to operate properly while in use under normal
household conditions within the warranty period, visit sharkclean.com/
support for product care and maintenance self-help. Our Customer
Service Specialists are also available at 1-855-523-4061 to assist with product
support and warranty service options, including the possibility of upgrading
to our VIP warranty service options for select product categories. So we may
better assist you, please register your product online at registeryourshark.
com and have the product on hand when you call.
SharkNinja will cover the cost for the customer to send in the unit to us for
repair or replacement. A fee of $25.95 (subject to change) will be charged
when SharkNinja ships the repaired or replacement unit.
How to initiate a warranty claim
You must call 1-855-523-4061 to initiate a warranty claim. You will need the
receipt as proof of purchase. We also ask that you register your product
online at registeryourshark.com and have the product on hand when you
call, so we may better assist you. A Customer Service Specialist will provide
you with return and packing instruction information.
How state law applies
This warranty gives you specific legal rights, and you also may have other
rights that vary from state to state. Some states do not permit the exclusion
or limitation of incidental or consequential damages, so the above may not
apply to you.
IMPORTANT INFORMATION
REGISTER YOUR PURCHASE
registeryourshark.com
Scan QR code using
mobile device
RECORD THIS INFORMATION
Model Number:
�������������������������������������������������������������������������������������������������������������������������������������������������������������������������������
Serial Number:
���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������
Date of Purchase:
�����������������������������������������������������������������������������������������������������������������������������������������������������������������������
(Keep receipt)
Store of Purchase:
���������������������������������������������������������������������������������������������������������������������������������������������������������������������
TECHNICAL SPECIFICATIONS
Voltage: 120V 60Hz / 3A
Watts: 36W
4000 mAh
Benefits of registering your product and creating an account:
• Get easier, faster product support and access to
warranty information
• Access troubleshooting and product care instructions
• Be among the first to know about exclusive product promotions
TIP: You can find the model and serial numbers on the QR code label
on the underside of the fan head.
BATTERY REMOVAL AND DISPOSAL
This product contains an integral lithium battery (not replaceable), and the
remote control uses a lithium coin battery (replaceable) or 2 AAA batteries
(replaceable). When the remote batteries no longer have charge, they should
be removed from the remote and recycled. DO NOT incinerate or compost the
product with its integral battery or the remote batteries. When your remote
battery needs to be replaced, dispose of it or recycle it in accordance with
local ordinances or regulations. In some areas, it is illegal to place spent lithium
batteries in the rubbish or in a municipal solid waste stream. Return spent
batteries to an authorized recycling center or to retailer for recycling. Contact
your local recycling center for information on where to drop o the spent battery.
FCC WARNINGS
Note: This unit has been tested and found to comply with FCC limits for Class
B digital devices. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This unit generates,
uses, and can radiate radio frequency energy, and if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
To see if this unit interferes with radio or television reception, try turning it
o and on.
To correct any interference:
■ Reorient or relocate the receiving antenna.
■ Increase the distance between the unit and the receiver.
■ Connect the unit to a dierent outlet than the receiver.
■ Consult the dealer or an experienced technician for help.
Caution: Any changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user’s authority to
operate it.
IC statement:
This device contains licence-exempt transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic Development Canada’s licence-exempt
RSS(s). Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may
cause undesired operation of the device.
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
This Owner’s Guide is designed to help you get a complete
understanding of your new Shark™ fan.
SharkNinja Operating LLC
US: Needham, MA 02494
CAN: Ville St-Laurent, QC H4S 1A7
1-800-798-7398
sharkclean.com
Illustrations may dier from actual product. We are constantly striving
to improve our products; therefore the specifications contained herein
are subject to change without notice.
This product may be covered by one or more U.S. patents. See
sharkninja.com/patents for more information.
© 2025 SharkNinja Operating LLC. BREEZEBOOST, FLEXBREEZE, and SHARK are trademarks of SharkNinja Operating LLC.
FA300Series�IB�A4�Online�MP�Mv12
