30 IN. STAND FAN
SKU: 92026
WARNING
CAUTION
1. Read and save these instructions. Do not operate fan unless you have
read these instructions.
2. Unplug the fan before moving it or performing maintenance. Do not touch
the fan when your hands are wet.
3. Those who are not qualified electricians should not disassemble, repair or
rebuild the fan.
4. Unplug the fan when it is not in use.
5. DO NOT unplug the fan by pulling the cable cord. Unplug by holding the
plug and pulling.
6. DO NOT use the fan when there is damage to the cable cord or plug. If
the supply cord is damaged, it has to be replaced by the manufacturer, its
service agent or similarly qualified persons.
7. DO NOT use the fan with an extension cord.
8. DO NOT use the fan close to fires or flammable material.
9. DO NOT insert your hand or other objects into the grille or the movable
parts.
10. To reduce the risk of fire or electric shock, do not use this fan with any
solid-state speed control device.
11. DO NOT use this fan outdoors, this fan is designed for indoor use only.
1. Unplug the fan from the socket and clean it with a soft cloth.
2. DO NOT immerse the fan in liquid.
3. Fit the guard onto the fan before starting up the fan.
4. This fan is not intended for use by people (including children) with
reduced physical, sensory or mental capabilities or lack of experience
and knowledge unless they have been given supervision or instruction
concerning use of the fan by a person responsible for their safety.
Supervise children to ensure they do not play with the fan.
SAFETY INFORMATION
1
ASSEMBLY
1. Remove the screws from the base.
Save them for Step 2.
2. Attach support post to base by
tightening with the five screws from
Step 1.
3. Insert the spring into the support
post as shown in the picture.
4. Remove three screws on black
ring around extension pipe. Save
them from Step 5.
2
ASSEMBLY
6. Mount fan head onto extension
pipe by tightening back the hexa-
gonal bolt, bolt sheath and washer.
7. Remove four sets of hexagonal
nuts, spring washers and big
washers from fan head. Save them
for Step 8.
8. Set rear guard in proper position
and fix it to fan head by securing
back the hexagonal nuts, spring and
washers and big washers from Step
7.
2
5. Insert extension pipe into support
post. Fix black ring onto support by
tightening back three screws from
Step 4. Adjust extensoin pipe to your
desired height and secure it by tight-
tening back the height adjustment
knob.
CAUTION:
To avoid injury and
prevent from cutting, never put your
head over the extension pipe during
or before the extension pipe was
secured onto the support post tightly.
ASSEMBLY
9. Remove two screws from fan blade.
Save them for Step 10.
10. Assemble fan blade onto motor
shaft by tightening two screws.
Make sure each screw is tightly
secured.
11. Assemble front guard to rear
guard by fixing both guards together
with clips on the rim of front guard.
12. Secure the assembly of front
guard and rear guard by tightening a
screw and nut on the bottom and
position of them.
3
OPERATION
Unplug the appliance before cleaning. Do not use water for cleaning metal
surfaces. Slightly moisten a cloth and wipe off the surfaces of the fan. In
order to remove dust from the grill, use a vacuum cleaner or remove the
front grill by removing the securing screws on the edge of the grill. After
cleaning, remount the grill. After doing this, fasten the screws on the edge
of the grill.
CARE AND CLEANING
4
1. Place the fan on a safe, flat surface where it can not fall or be pulled by
the cord.
2. Adjust the desired speed by pulling the chain switch
（Stop - Low- Medium - High）．
PRODUCT MADE IN CHINA
IO
5
