4
Fan speed
with oscillation
Fan speed
without oscillation
Control Panel
Warranty
Care and Maintenance
Cleaning
NOT IMMERSE THE FAN OR ANY WIRES IN WATER.
Replace front grille before fan use.
Allow fan to dry completely before use.
Periodic grille cleaning with a vacuum will prevent dust build up.
The motor is sealed and does not require any interior maintenance, cleaning or lubrication.
Maintenance
The Internal motor bearings are permanently lubricated at the factory and do not require any additional
lubrication.
Repair
Storage
This unit is guaranteed to the original retail purchaser against defects in quality or workmanship for a period of one year from the
date of original purchase. If this unit fails because of a manufacturing defect within 30 days of purchase, return the unit, with your
receipt, to the retailer. After 30 days, but within the warranty period, if the unit was purchased within the continental United States,
return it, to Mr. Brands LLC for repair or replacement. If the unit was purchased outside the continental United States, return the unit
to the place of purchase. This warranty does not cover damage caused by misuse, abuse, overheating or alteration. Repairs made by
anyone other than Mr. Brands LLC are not covered in this warranty. Mr. Brands LLC will not be held liable for any losses due to
neglectful operation. All implied warranties, including the warranties of merchantability and of fitness of purpose, if applicable, are
hereby limited in duration to the period of one year from the date of original retail purchase. Some states do not allow limitations
on how long an implied warranty lasts, so the above limitations may not apply to you. Incidental or consequential damages arising
from a breach of either express or implied warranties are hereby disclaimed and excluded. Some states do not allow the exclusion of
limitation of incidental or consequential damages, so this limitation or exclusion may not apply to you. Upon the expiration of this
warranty all such liability will terminate. No other warranties are expressed or implied. This warranty gives you specific legal rights,
and you may also have other rights which vary from state to state. No informal dispute settlement mechanisms are available. This
limited warranty is given in lieu of all other warranties.
Manufactured for:
Mr. Brands LLC
113 Fillmore St, Bristol, PA 19007
1-877-420-7555
www.mrbrands.com
www.comfortzoneproducts.com
Rev. 07/20/23
CZ12386 Series
32” Tower Fan with Oscillation
• Wide Area Oscillation
• Rotating Dial with 3 Speed Settings
•
Built-in Carrying Handle
•
Slim Design with Stable Base
• 120V A.C. / 60Hz
2
3
Important Safety Instructions
As with all electrical appliances, basic safety
precautions should always be followed to reduce
the risk of electric shock, fire, or injury to
persons, including the following precautions:
Any other use not recommended by the
manufacturer may cause electrical shock, fire
or injury to persons.
power cord or after the fan malfunctions or
has been dropped in any manner.
fan is used by or near children, disabled
persons or pets and whenever the fan is left
operating unattended.
uneven or any surface which might allow fan
to tip or fall.
a smooth, non-combustible, level surface.
moving from place to place, when assembling
or disassembling parts, and before cleaning.
sold by the manufacturer, may cause hazards.
electrical hazard (for non-window models).
any safety device removed.
cord must be minimum 14 AWG and rated not
less then 1875 watts.
not cover cord with throw rugs, runners or
the like. Arrange cord away from trac area
where it will not be tripped over.
This product is intended for indoor residential and oce use only, not for industrial or other commercial
ordinances. If you have any questions whether your wiring is adequate, consult a qualified electrician.
instructions, we have used the word "WARNING" to indicate the level of hazard: WARNING indicates a hazard
which, if not avoided, could result in injury or death.
WARNING: SHOCK HAZARD
fan is not intended for use in a bathroom,
laundry area, or similar locations, or near
sinks, washing machines, swimming pools
or other sources of water. Never locate fan
where it may fall into a bathtub or other
environments such as flooded basements.
WARNING: HOT SURFACES
motor is hot when in use, to avoid burns,
do not let bare skin touch hot surfaces.
WARNING: FIRE HAZARD
Fans have arcing or sparking parts inside.
not use in areas where gasoline, paint or
flammable materials are used or stored. To
prevent a possible fire, do not block air
insert or allow foreign objects to enter any
cause an electric shock, fire, or damage
the fan.
persons (including children) with reduced
physical, sensory or mental capabilities or
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
do not play with the appliance.
electric shock and/or fire hazard. Avoid
contact with moving parts.
WARNING: ELECTRICAL SHOCK HAZARD
Do not use with damaged cord or plug. Use
with adequate electrical system that is up
to code.
CAUTION: TO PREVENT ELECTRIC SHOCK,
this product has a polarized two prong plug
(one blade is wider than the other) that
must be fully inserted in to a matching
properly grounded outlet. This plug is
designed to fit a polarized outlet only one
way. If the plug does not fit fully into the
outlet, reverse the pl
ug. If the plug still does
not fit, contact a qualified electrician. Do not
attempt to defeat this safety feature.
SAVE THESE INSTRUCTIONS
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, do not use this
product with any solid-state speed control
device.
DO NOT operate any fan with a damaged cord
or plug or after fan malfunctions, has been
dropped or damaged in any manner.
Do not operate fan with a broken blade, safety
cage or any visual imperfections. Disconnect
power before servicing.
DO NOT run power cord under carpeting. DO
NOT cover cord with throw rugs,
runners or the
will not be tripped over. Avoid the use of
extension cords due to risk of fire. If an extension
cord must be used, the cord must be minimum
14 AWG and rated not less then 1875 watts. Do
not use an extension cord unless the plug can be
completely inserted into its receptacle. Unplug
the fan when not in use. Do not operate fan with
its ventilation obstructed.
Operating Instructions
Fan Operation
Always operate the fan in the upright position following all instructions and recommendations listed
in this manual.
Fan Location
Place the fan in the area of the room that will provide proper fan cooling.
Fan Connection
Plug fan directly into 120 Volt A.C., 60 Hz wall outlet. Be sure plug fits tightly in outlet. A loose
connection may cause overheating and damage to the plug or fan.
Note: To prevent overloading a circuit, do not plug the fan into a circuit that is servicing other
electrical needs.
Turning Fan On/
Place fan on stable level surface. Plug fan into proper polarized outlet. To start the fan, rotate top
control dial to desired fan speed (1, 2 or 3). Rotate the dial clockwise for standard use and
counter-clockwise for oscillation use. See Control Panel below. Rotate top control dial again to OFF
position to discontinue use. Unplug fan when not in use.
Fan Speed And Oscillation
Rotate top control dial to desired fan speed (1, 2 or 3). Rotate the dial clockwise for standard use and
counter-clockwise for oscillation use. See Control Panel below.
Fan Base Assembly
Simple assembly is required to use this fan.
1. Rotate the base holder (F) o , which is at
the bottom of the fan housing.
2. Place the Rear base panel (B) between the
fan housing (D) and base holder( F), in the
right direction.
3. Align the Rear base panel (B) and Front
base panel (A) together
4. Put the base holder (F) back and tighten it
to hold the base panels on the fan housing
(D).
1
2
3
4
