OIL DISPENSING UNIT 14LTR
MODEL NO: TP16.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure health & safety, local authority, and general workshop practice regulations are strictly adhered to when using this equipment.
9 Familiarise yourself with product application and limitations, as well as the specic potential hazards peculiar to this product.
9 Maintain the pump in good condition (use an authorised service agent).
9 Replace or repair damaged parts. Use genuine parts only. Non authorised parts will invalidate the warranty.
9 Use only to pump oils up to SAE 40 viscosity.
9 Ensure safety eye protection and protective clothing are worn when using this product.
9 Keep the work area clean, uncluttered and ensure there is adequate lighting.
9 Maintain correct balance and footing. Ensure the oor is not slippery and wear non slip shoes.
9 Keep children and unauthorised persons away from the working area.
9 Dispose of waste liquids in accordance with local authority regulations.
9 Maintain foot pressure on the foot plate at all times while using the pump.
8 DO NOT use to extract corrosive uids.
8 DO NOT dismantle, tamper with or adapt the pump for any purpose other than for which it is designed.
8 DO NOT use the unit if it has been dropped or mishandled, check the unit to ensure there is no damage.
9 Keep the pump clean and store in a safe, dry, childproof location.
WARNING! DO NOT allow uncontrolled discharge of uids thus polluting the environment.
2. INTRODUCTION
Self-priming lever pump manufactured from galvanized steel, supplied with 14ltr reservoir. Features carry handle for ease of manoeuvrability
and foot plate for stability while in use. 1.8m delivery hose with angled spout. Drip opening/spout storage within bucket cover for tidy storage
when not in use. Suitable for oils up to SAE 40 viscosity.
3. SPECIFICATION
Model No: ............................TP16.V3
Capacity:................................. 14ltr
Nett Weight: ............................ 5.51kg
4. ASSEMBLY
4.1. Attach the pump handle to the unit, with the bolts
provided.
4.2. Attach the carry handle to the pump handle and
the unit with the bolts provided.
4.3. Attach the hose with the hose clamp provided.
5. OPERATION
3.1 FILLING
3.1.1 Slacken off the three thumbscrews and twist the
top of the dispenser clockwise and lift off.
3.1.2 Fill the reservoir with oil. NOTE: Only use oils up
to SAE 40 viscosity.
3.1.3 Replace the top of the dispenser and twist
anti-clockwise to locate the bayonet xings,
tighten the three thumbscrews to secure the top.
3.2 DISPENSING
3.2.1 Insert the angled spout into the item to be lled.
3.2.2 Place foot on the foot plate and pump handle to
dispense oil.
3.2.3 When the desired amount has been dispensed,
locate the hose/spout into the top of the dispenser.
Refer to
instructions
Wear eye
protection
Wear protective
clothing
TP16.V3 | Issue 2 (H,F) 25/01/2019
Original Language Version
© Jack Sealey Limited
TP16.V3 | Issue 2 (H,F) 25/01/2019
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. Please log on to www.sealey.co.uk, email sales@sealey.co.uk or telephone 01284 757500
